Extraflame LCD User manual

1
Pellet stoves user manual
lcd
english

2

index
3
We thank you for having chosen our company; our product is a great heating solution developed from the
most advanced technology with top quality machining and modern design, aimed at making you enjoy
the fantastic sensation that the heat of a ame gives, in complete safety.
Extraame S. p. A.
enGLiSH....................................................................................................................................................................................................................................4
WarninGS.................................................................................................................................................................................. 4
Safety........................................................................................................................................................................................ 4
routine Maintenance.......................................................................................................................................................... 4
Safety deviceS........................................................................................................................................................................ 5
inStaLLation............................................................................................................................................................................ 5
InstallatIons allowed ...................................................................................................................................................................................................... 6
InstallatIons not allowed............................................................................................................................................................................................ 6
ConneCtIon to the smoke evaCuatIon system................................................................................................................................................... 6
smoke Channel or fIttIngs............................................................................................................................................................................................. 6
ChImney or IndIvIdual flue............................................................................................................................................................................................. 7
ChImney Cap ............................................................................................................................................................................................................................... 8
ConneCtIon to external aIr Inlets ........................................................................................................................................................................... 9
InsulatIon, fInIshIngs, CoverIng and safety reCommendatIons ........................................................................................................ 9
PeLLetS and feedinG ............................................................................................................................................................. 9
Souvenir SPacerS ................................................................................................................................................................10
Hot air ductinG....................................................................................................................................................................10
grazIosa plus .........................................................................................................................................................................................................................10
souvenIr .....................................................................................................................................................................................................................................11
elIsIr ..............................................................................................................................................................................................................................................11
emma plus and tosCa plus.............................................................................................................................................................................................12
addItIonal thermostat for duCt motor Control......................................................................................................................................12
controL Board.....................................................................................................................................................................13
dIsplay ICons...........................................................................................................................................................................................................................13
GeneraL Menu .......................................................................................................................................................................14
BasIC InstruCtIons .............................................................................................................................................................................................................14
tHe reMote controL...........................................................................................................................................................15
delayed swItCh-off aCtIvatIon..................................................................................................................................................................................15
type and replaCement of BatterIes........................................................................................................................................................................15
coMMiSSioninG SettinGS...................................................................................................................................................16
adjustIng tIme, day, month and year.....................................................................................................................................................................16
adjustIng language..........................................................................................................................................................................................................16
functioninG and LoGic .....................................................................................................................................................17
additionaL externaL tHerMoStat (oPtionaL)...........................................................................................................18
uSer Menu...............................................................................................................................................................................18
dIsplay .........................................................................................................................................................................................................................................18
pellet feed adjustment...................................................................................................................................................................................................18
v1-fan............................................................................................................................................................................................................................................19
stand By ......................................................................................................................................................................................................................................19
keys loCked...............................................................................................................................................................................................................................20
v2 -fan...........................................................................................................................................................................................................................................21
reset ..............................................................................................................................................................................................................................................21
cHrono....................................................................................................................................................................................21
programmIng example.....................................................................................................................................................................................................22
cLeaninG under uSer'S reSPonSiBiLity.........................................................................................................................23
routine Maintenance .......................................................................................................................................................24
diSPLayS ..................................................................................................................................................................................25
aLarMS ....................................................................................................................................................................................26
Warranty conditionS .......................................................................................................................................................27

4
WARNINGS
The instruction manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred
to other owners or user or is transferred to another place. If it is damaged or lost,request another copy from the area technician.
This product must be destined for the use for which it has been expressly realised.The manufacturer is exempt from any liability,
contractual and extracontractual, for injury/damage caused to persons/animals and objects, due to installation, adjustment
and maintenance errors and improper use. Installation must be performed by qualied sta, which assumes complete
responsibility for the denitive installation and consequent good functioning of the product installed. It is necessary to
bear in mind all laws and national, regional, provincial and town council Standards present in the country the appliance
has been installed.
Extraame S.p.A. cannot be held responsible for the failure to comply with such precautions.
After removing the packaging, ensure that the content is intact and complete. If not so, contact the dealer where the appliance
was purchased.
All electric components that make up the product must be replaced with original spare parts exclusively by an authorised after-
sales centre, thus guaranteeing correct functioning.
SAFETY
The stove must not be used by persons (including children) with reduced physical, sensorial and mental capacities or who
are unskilled persons, unless they are supervised and trained regarding use of the appliance by a person responsible for their
safety.
Children must be controlled to ensure that they do not play with the appliance.
Do not touch the stove when you are barefoot or when parts of the body are wet or humid.
The safety and adjustment devices must not be modied without the authorisation or indications of the manufacturer.
Do not pull, disconnect, twist electric cables leaving the stove, even if disconnected from the electric power supply mains.
It is advised to position the power supply cable in a way that it does not come into contact with hot parts of the appliance.
The power supply plug must be accessible after installation.
Do not close or reduce the dimensions of the airing vents in the place of installation. The airing vents are indispensable
for correct combustion.
Do not leave the packaging elements within reach of children or unassisted disabled persons.
The hearth door must always be closed during normal functioning of the product.
When the appliance is functioning and hot to the touch, especially all external surfaces, attention must be paid
Check for the presence of any obstructions before switching the appliance on following a prolonged standstill period.
The stove has been designed to function in any climatic condition (also critical). In particularly adverse conditions (strong
wind, freezing) safety systems may intervene that switch the stove o. If this occurs, contact the technical after-sales service
and always disable the safety system.
If the ue should catch re, be equipped with suitable systems for suocating the ames or request help from the re
service.
This appliance must not be used to burn waste
Do not use any inammable liquids for ignition
During the lling phase do not allow the bag of pellets to come into contact with the product
The majolicas are top quality artisan products and as such can have micro-dots, crackles and chromatic imperfections.
These features highlight their valuable nature. Due to their dierent dilation coecient, enamel and majolica produce
crackling,. which demonstrate their eective authenticity. To clean the majolicas, it is recommended to use a soft, dry cloth. If
a detergent or liquid is used, the latter could penetrate inside the crackles, highlighting the same.
ROUTINE MAINTENANCE
Based on the Decree 22 January 2008 n°37 art.2, routine maintenance means interventions aimed at reducing degradation from
normal use, as well as dealing with accidental events entailing the need of rst interventions, which however do not modify the
structure of the system upon which one is intervening or its intended use according to the prescriptions foreseen by technical
standards in force and by the manufacturer's use and maintenance booklet.
ENGLISH

5
SAFETY DEVICES
SAFETY DEVICES
KEY: * = PRESENT,  = NOT PRESENT
STOVES
Circuit board: intervenes directly by sending the product
into alarm conditions until complete cooling, in the case
of: breakage of ue gas motor, pellet feed motor breakage,
black out (if more than 10 seconds), no ignition
*
Insert blocking micro switch: if the end run micro switch
warns that the insert is not blocked, electric energy does
not pass to power it
-
Electronic pressure switch: in the event of inadequate
depression, it takes the machine to alarm conditions *
F 2.5 A 250 V fuse (stoves): protects the machine from
violent current drops *
85°C calibrated mechanical bulb with manual rearm:
intervenes by blocking fuel feed whenever the pellet tank
t° reaches the limit of 85°C. Rearm must be performed
by qualied sta and/or the manufacturer's technical
after-sales assistance.
*
Pellet feed-box temperature control probe: if the tank
over-heats, the machine automatically modulates to return
to normal temperature values (* in the models envisioned)
*
Mechanical air pressure switch: blocks the pellet in the
event of insucient depression (in the models envisioned) *
INSTALLATION
The installation must be in compliance with:
UNI 10683 (2005) heat generators fed with wood and other
solid fuels: installation.
The chimneys must be in compliance with:
UNI 9731 (1990) chimneys: classication based on thermal
resistance.
EN 13384-1 (2006) Thermal and uid dynamic calculation
methods.
UNI 7129 point 4.3.3 Fire Department dispositions, local rules and
prescriptions.
UNI 1443 (2005) chimneys: general requisites.
UNI 1457 (2004) chimneys: clay/ceramic ue liners.
NATIONAL, REGIONAL, PROVINCIAL AND TOWN
COUNCIL REGULATIONS
It is necessary to bear in mind all laws and national, regional,
provincial and town council Standards present in the country
the appliance has been installed.
GLOSSARY
CLOSED HEARTH APPLIANCE
Heat generator which opening is only allowed through the
loading of the fuel during use.
BIOMASS
Biological material, excluding the material incorporated in
geological formations and transformed into fossils.
BIOFUEL
Fuel produced directly or indirectly by biomass.
CHIMNEY
Vertical pipe with the aim of collecting and expelling the fuel
products coming from only one appliance, at a convenient
height from the ground.
SMOKE CHANNEL OR FITTING
Pipeor connecting element between heatgenerator appliance
and chimney to evacuate combustion products.
INSULATION
Group of set-ups and materials used to prevent the
transmission of heat through a wall that separates rooms with
dierent temperatures.
CHIMNEY CAP
Device positioned at chimney peak to ease the dispersion of
combustion products into the atmosphere.
CONDENSATE
Liquid products that form when the combustion gas
temperature is lower or equal to the water dew point.
HEAT GENERATORS
Appliance which allows to produce thermal energy (heat)
through the rapid transformation, via combustion, of the
chemical energy of the same fuel.
GATE VALVE
Mechanism for modifying the combustion gas dynamic
resistance.
COMBUSTION PRODUCT EVACUATION SYSTEMS
Flue gas exhaust system independent from the appliance
constituted by a tting or smoke channel, chimney or
individual ue and chimney cap.
FORCED DRAUGHT
Air circulation by means of the fan activated by electric motor.
NATURAL DRAUGHT
Draught which is determined in a chimney/ue for eect of
the volume mass dierence existing between smoke (hot) and
surrounding atmosphere air, without any mechanical intake
aid installed inside it or at its peak.
ENGLISH

6
RADIATION AREA
Area immediately near the hearth in which the heat caused by
combustion is diused, where no combustion materials must
be present.
REFLUX AREA
Area where leaking of the combustion products is veried,
from the appliance towards the installation room.
The installation must be preceded by checking the chimneys,
ues or unload terminals positioning of appliances similarly
to:
Installation prohibitions
Legal distances
Limitations disposed by local administrative regulations
or particular authority prescriptions.
Conventional limitations deriving from condominium
regulations, constraints or contracts.
INSTALLATIONS ALLOWED
Only appliances working in a sealed manner respect to the
room or which do not place the room in depression respect to
the external environment, can exist or be installed in the room
where the heat generator will be installed.
Appliances for cooking food and relative hoods without
extractor are only allowed in kitchens.
INSTALLATIONS NOT ALLOWED
In the room where the heat generator will be installed the
following must not pre-exist or be installed:
hoods with extractor.
collective type ventilation pipes.
Should these appliances be in rooms adjacent, communicating
with the installation room, the simultaneous use of the heat
generator is forbidden, where a risk exists of one of the two
rooms being placed in depression respect to the other.
CONNECTION TO THE SMOKE EVACUATION SYSTEM
UNI 10683 (2005) Standard
SMOKE CHANNEL OR FITTINGS
To mount the smoke channels, non-ammable elements will
have to be used, ideal for resisting combustion products and
their eventual condensing.
The use of exible metal and asbestos cement pipes to
connect the appliances to the ue is forbidden, even for pre-
existing smoke channels.
There must be continuity between the smoke channel and the
ue so that the ue does not lean on the generator. The smoke
channels must not cross rooms where the installation of the
combustion appliances is not allowed.
The mounting of the smoke channels must be carried out in
order to guarantee smoke seal for the appliance functioning
conditions, limit the forming of condensate and avoid it being
transported towards the appliance.
The mounting of horizontal routes must be avoided.
For appliances where ceiling or wall non-coaxial discharges
with respect to the appliance combustion product outlet have
to be reached, the direction changes will have to be realised
using open bends not greater than 45° (see gures below).
For the heat generator appliances equipped with electric fan
for expelling combustion products, the instructions below
must be followed:
45°
<
45°
<
The horizontal routes will have to have a minimum
upward slope of 3%
The length of the horizontal route must be minimal and,
however, not longer than 3 metres
The number of direction changes including the one for
eect of using the "T" element must not be more than 4.
In any case, the smoke channels must seal the combustion and
condensate products and be insulated if they pass outside the
installation room.
The use of counterslope elements is forbidden.
The smoke channel must allow the recovery of soot or be
brushable.
The smoke channel must have constant section. Any section
changes are only allowed at the ue coupling.
It is forbidden to have other air supply channels and pipes for
plant engineering, especially if over-sized, transit inside the
smoke channels.The mounting of manual draught adjustment
devices on forced draught appliances is forbidden.
Insulating
product
Flue
pipe
Inspection
ENGLISH

BC
A
S
< 3 m
3 - 5 %
7
CHIMNEY OR INDIVIDUAL FLUE
The chimney or individual ue must respond to the following requisites:
seal the combustion products, be waterproof and adequately insulated in line with the use conditions;
be realised with materials which resist the normal mechanical stress, heat, action of the combustion products and any
condensate;
have mainly vertical progress with deviations from the axis not higher than 45°;
be adequately distanced from fuel or ammable materials through air space or opportune insulation;
have preferably circular internal section: the square or rectangular sections must have round corners with a radius not
lower than 20 mm;
have constant internal section, free and independent;
have rectangular section with max. ratio between the sides of 1.5.
It is recommended that the smoke pipe be equipped with a collection chamber for solid materials and any condensate situated
under the smoke channel inlet, so that it can be easily opened and inspected from airtight door.
REFERENCES INFLAMMABLE OBJECTS NONINFLAMMABLE OBJECTS
A 200 mm 100 mm
B 1,500 mm 750 mm
C 200 mm 100 mm
Minimum 80 cm2
S= oor protection
Air inlets
Chimney cap
Flue
Inspection
Inspection
Flue
Inspection
ENGLISH

< 3 m
45°
45°
50 cm
< 5 m > 5 m < 5 m
50 cm
H min
β
>A
<A
>50 cm
Z
8
External pipe
that is isolated
Inspection
Inspection
Appliance connection to the ue and combustion products evacuation
The ue must receive the discharge from only one heat generator.
Direct discharge towards closed spaces is forbidden, even with clear sky.
The direct discharge of the combustion products must be at roof and the smoke pipe must have the features provided in the
"Chimney or individual ue" section.
CHIMNEY CAP
The chimney cap must comply with the following requisites:
have an internal section equivalent to that of the chimney;
have useful outlet section not lower than double the chimney internal section;
be built in order to avoid rain, snow, foreign bodies penetrating the chimney and so that, in the event of winds in any
direction and inclination, the discharge of the combustion products is assured.
be positioned in a way to guarantee an adequate dispersion and dilution of the combustion products and, however, outside
the reux area in which the formation of counterpressures occurs. Such area has dierent dimensions and conguration
depending on the covering inclination angle. It is therefore necessary to adopt the minimum heights indicated in the gure
layouts below.
The chimney cap must not have mechanical intake means.
FLAT ROOF SLOPING ROOF
Z=REFLUX AREA
ENGLISH

9
CONNECTION TO EXTERNAL AIR INLETS
The appliance must be able to use the necessary air to guarantee regular functioning through external air inlet. The air inlets
must comply with the following requisites:
have a total free section of at least 80 cm².
must be protected by grates, metal net or suitable protections as long as they do not reduce the minimum section stated
in the previous point and positioned in order to avoid them being obstructed.
If the combustion agent air is withdrawn directly from outside through a pipe, a downward bend must be mounted outside
or a protection against the wind and no grates or similar must be positioned, (it is recommended that the air vent always
communicates directly with the installation room even if the air is withdrawn from outside through a pipe).The air ow can also
be obtained from an adjacent room, as long as the ow takes place freely through permanent openings communicating with
the outside.
The adjacent room, with respect to the installation room, must not be put in depression with respect to the external environment
by means of reverse draught caused by the presence of another used appliance or intake device in such room. The permanent
openings in the adjacent room must comply with the above-described requisites.The adjacent room cannot be set up as garage,
storage for combustion material or activity with danger of re.
INSULATION, FINISHINGS, COVERING AND SAFETY RECOMMENDATIONS
The coverings, independently from the materials from which they are made, must constitute a self-supporting construction
with respect to the heating block and not be in contact with it.
The cross members and nishings in wood or combustion materials must be positioned outside the hearth radiation area or
adequately insulated.
If coverings in combustion material or sensitive to heat exist in the space above the generator, an insulating and non combustible
protection diaphragm must be inserted.
Elements in combustible or inammable material like wooden furniture, curtains, etc. directly exposed to the hearth radiation,
must be positioned at a safe distance. The appliance installation must guarantee easy access for cleaning the appliance itself,
discharge gas pipe and ue.
CHIMNEY CAPS, DISTANCES AND POSITIONING
Roof inclination Distance between the ridge and the chimney Minimum chimney height (measured from outlet)
β A (m) H (m)
15° < 1,85 0.50 m over the ridge
> 1,85 1,00 m from roof
30° < 1,50 0.50 m over the ridge
> 1,50 1,30 m from roof
45° < 1,30 0.50 m over the ridge
> 1,30 2,00 m from roof
60° < 1,20 0.50 m over the ridge
> 1,20 2.60 m from roof
Open the tank lid and load the pellets using a scoop.
PELLETS AND FEEDING
The pellets used must comply with the features described by
the Standard:
Ö-norm M 7135
DIN plus 51731
UNI CEN/TS 14961
Extraame recommends the use of pellets with
a 6 mm diameter for its products.
THE USE OF EXPIRED PELLETS OR ANY OTHER MATERIAL DAMAGES THE FUNCTIONS OF YOUR STOVE AND CAN
DETERMINE THE INVALIDITY OF THE WARRANTY AND THE ANNEXED RESPONSIBILITY OF THE MANUFACTURER.
ENGLISH

10
HOT AIR DUCTING
The pipe destined for ducting the hot air must have an internal diameter of 80 mm, be insulated and protected from heat loss.
INsTAllATION Of THe pIpes UseD fOR DUCTING THe HOT AIR mUsT be peRfORmeD by qUAlIfIeD sTAff
AND/OR THe mANUfACTUReR's TeCHNICAl AfTeR-sAles AssIsTANCe.
sOUveNIR spACeRs
The“Souvenir” model has for spacers at the back to mark the minimum distance to be kept from any surface on the rear.
The spacers must not be removed.
GRAzIOsA plUs
For the Graziosa Plus model, hot air ducting is mandatory.
On the rear there is a cover that must be removed and connected to the duct.
Features:
• duct outlet diameter: 80 mm
• maximum recommended duct length: 6 m
• the duct can be thermostated by means of an additional thermostat
• the fan speed percentage can be adjusted.
Remove the cover!
fOR THIs pRODUCT IT Is mANDATORy TO DUCT THe HOT AIR.
IT Is NOT pOssIble TO DeACTIvATe THe DUCTING mOTOR.
DO NOT COveR OR ClOse DUCTING!
eNGlIsH

11
sOUveNIR
The“Souvenir” model can be ducted on the rear, on the side or on the top; for further information on installation, refer to the
instruction leaet provided.
Option to decide when to use the duct, thanks to a hot air ow deviation by means of a key provided, which can be inserted in
its special housing on the upper part of the stove.
Turn it anticlockwise to "open the duct" and clockwise to "close" it.
You can use one duct according to requirements.
Features:
• duct outlet diameter: 80 mm
• maximum recommended duct length: 6 m
• the duct cannot be thermostated
• the fan speed percentage can be adjusted.
OPEN
CLOSED
elIsIR
The“Elisir” model can be ducted on the rear on the side or on top; for further information
on installation, refer to the instruction leaet provided.
You can use one duct according to requirements.
Features:
• duct outlet diameter: 80 mm
• maximum recommended duct length: 2 m
• the duct can be thermostated by means of an additional thermostat (optional)
• the fan speed percentage can be adjusted; the duct cannot be deactivated.
eNGlIsH

12
emmA plUs AND TOsCA plUs
The Emma and Tosca Plus models also oer the option to decide where to direct the hot air ow, thanks to two gate valves
controlled by 2 levers positioned inside the pellet tank, which must be activated via the re irons supplied.
(see gure below).
You can use both outlets on the rear of the machine
Features:
• duct outlet diameter: 2x80 mm
• maximum recommended duct length: 2 m
• the duct cannot be thermostated
• the fan speed percentage can be adjusted.
ADDITIONAl THeRmOsTAT fOR DUCT mOTOR CONTROl
For models with ducting motor there is also the possibility of thermostatting the motor itself. The connection of an external
thermostat will allow to control the ducting motor independently from stove functioning.
At this point just set the desired temperature on the thermostat. The thermostat will control the functioning of the second
motor:
with temperature to be reached (close contact) the second
motor will follow the trend of the stove.
when the temperature has been reached (open contact), it takes the
ducting motor to 1st speed and will be
indicated by the blinking motor LED
The ducting thermostat clamp is tted with jumper as per standard.
See following explanatory drawing.
eNGlIsH

OFF
13
CONTROL BOARD
BUTTON
ON/OFF
DISPLAY OF VARIOUS
TEXT MESSAGES
TO ACCESS
THE MENU
TEMPERATURE
SETTING
OPERATING POWER
ADJUSTMENT
ENGLISH
DISPLAY ICONS
Indicates the receipt of the radio signal
On = during radio communication
O = no radio communication
Fixed light = serial input deactivated
Indicates the status of the additional thermostat input (GND - I3)
It indicates functioning of the fumes motor.
O = ue gas motor deactivated
On = ue gas motor active
Flashing = breakdown
It indicates functioning of the ducted motor
O = Motor deactivated
On = Motor active
Flashing = the motor is running at minimum and in modulation
mode (additional input open)
1
It indicates functioning of the tangential fan (where present)
O = not working
On = working
Flashing = motor at minimum
Indicates the activation of the F1 function (future set-up)
O = function deactivated
On = function active
It indicates functioning of the pellet feed motor.
O = pellet feed motor deactivated
On = pellet feed motor active.
It indicates weekly programming functioning
Indicator on = Weekly programming active
Indicator o = Weekly programming not active
indicates the compensation function
O = the function is deactivated
On = the function is active
Indicates the stove modulation
On = the stove is working at the set power
Flashing = the power at which the stove is working is dierent to
the power set, the stove is modulating (for various reasons)
Indicates the contact of the external additional thermostat
Contact closed: the contact of the external
additional thermostat is closed and
the STBY function is deactivated
Open contact: the contact of the external
additional thermostat is open and
the STBY function is deactivated
Flashing with closed
contact:
the contact of the external
additional thermostat is closed and
the STBY function is activated
Flashing with open
contact:
the contact of the external
additional thermostat is open and
the STBY function is activated
Indicates the presence of an alarm.
On: indicates the presence of an alarm
O: indicates the absence of alarms
Flashing: indicates the deactivation of the depression sensor.
Indicates the environment temperature status
O = the T° read by the probe is over the set temperature set
On = the T° read by the probe is below the set temperature set
Feed box probe
O = probe ok
On = broken probe (short circuit or open)
Flashing = tank cause modulation

OFF
2
2
2
6
1 4
3
2
5
6
6
6
6
6
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
1
23
45
6
2
14
GENERAL MENU
SET CLOCK
SET CHRONO
LANGUAGE
USER
TECHNIC SET
RESERVED TO THE QUALIFIED
TECHNICIAN YEAR
MONTH
DATE
MINUTES
HOURS
ENABLE CHRONO
REPEAT THE SAME PASSAGES
FOR
THE OTHER 3 TIME PERIODS
SET PRG1
07°C
MONDAY PRG1...
ONOFF
STOP PRG1
START PRG1
IT,EN,FR,DE,ES CONFIRMATION
WITH KEY 6
...SUNDAY PRG1
ONOFF
DAY
GO BACK  EXIT
BROWSE PARAMETERS: NEXT 2; PREVIOUS 3
MODIFY SETTING DATA: INCREASE 4; DECREASE 5
CONFIRM  ACCESS MENU
BASIC INSTRUCTIONS
The following recommendations must be followed the rst
times the stove is ignited:
It is possible that slight odours are produced due to the
drying of the paints and silicones used. Avoid staying in the
room for a long time.
Do not touch the surfaces as they could still be
unstable.
Air the room well several times.
The hardening of the surfaces is terminated after
several heating processes.
This appliance must not be used to burn waste.
Before igniting the stove, the following points must be
veried:
The hydraulic system must be nished in compliance
with the standards and with the indications of this manual.
The feed-box must be full of pellets
The combustion chamber must be clean
The burn pot must be completely clear and clean
Check the hermetic closure of the re door and the ash
drawer
Ensure that the power supply cable is connected correctly
The bipolar switch in the rear right part must be positioned
on 1
IT IS PROHIBITED TO USE THE APPLIANCE WITHOUT DIVIDER
AND/OR HEARTH PLATE SEE FOLLOWING FIGURE.
ITS REMOVAL JEOPARDISES THE SAFETY OF THE PRODUCT AND
WILL IMMEDIATELY MAKE THE WARRANTY NULL AND VOID.
IN THE EVENT OF WEAR OR DETERIORATION, REQUEST THE
SPARE PART FROM THE AFTERSALES SERVICE
REPLACEMENTS ARE NOT COVERED BY THE WARRANTY SINCE
ITEMS ARE SUBJECT TO WEAR.
ENGLISH
POT DIVIDER
HEARTH PLATE
DISPLAY
PELLETS
IN %
V1FAN
TANGENTIAL
STANDBY
KEYS LOCKED
V2 FAN
DUCTING
RESET

15
If the remote control is o because it has no
batteries, stove can be controlled from the
control panel on top of it.
While replacing the battery, pay attention to the
polarity by observing the symbol on the inside
compartment of the remote control.
THE REMOTE CONTROL
The remote control allows adjusting all that can normally be done through the LCD display
The table below shows the various functions in detail:
INFO
1
2
3
4
5
6
7
8
9
10
11 12 13
14 15 16
1ON / OFF Pressing the key for three seconds, the stove will switch-on or o
2POWER INCREASE Pressing the key will increase the operating power
3POWER DECREASE Pressing the key will decrease the operating power
4T° INCREASE This button allows increasing the temperature setpoint
5T° DECREASE This button allows decreasing the temperature setpoint
6ENABLE/DISABLE
CHRONO Press this button once to enable or disable the chrono
7DELAYED SWITCHOFF
ACTIVATION
This button allows setting the delayed switch-o.
For example, if the stove is set to switch o in an hour, it shall switch o
automatically once the set time elapses, displaying the countdown every
minute.
8MENU this key provides access to the user and technical menu (the technical
menu is reserved for assistance)
9INCREASE This button allows increasing the temperature setpoint
10 ESC KEY This key allows the user to exit any program or display and return to the
main menu without storing the data
11 REVERSE This button goes back in the display of the various menus
12 CONFIRMATION KEY This key conrms the adjustments made during the user menu
programming phase
13 FORWARD This key moves forward in the various menus
14 ENABLE F1 FUNCTION Button designed for future applications
15 DECREASE This key decreases the value to be set
16 STOVE STATUS Press this key to view the general status of the stove
TYPE AND REPLACEMENT OF BATTERIES
The batteries are housed in the lower part of the remote
control.
To replace it, remove the battery holder (as indicated in the
gure at the back of the remote control), remove or
insert the battery, following the symbols on the
remote control and on the battery itself.
For operation, 1 CR2025, 3V lithium buer battery is
required.
The batteries used contain metals harmful
for the environment. They must therefore
be disposed of separately in appropriate
containers.
Note: the numbers shown on the remote control are purely explanatory and are not present on the remote control supplied with the product.
ENGLISH

16
COMMISSIONING SETTINGS
Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (I).
The switch at the back of the stove powers the stove board.
The stove remains o and a rst screen appears on the panel
with the word OFF.
ADJUSTING TIME, DAY, MONTH AND YEAR
Set clock allows to adjust the time and date
CONTROLS PROCEDURE
Press button 6 and SET CLOCK will appear.
Confirm using key 6.
Use keys 4 and 5 to assign the day.
Proceed pressing key 2
Follow the same procedure (4 or 5 to set and 2 to proceed)
to adjust the hours, minutes, date, month and year.
Press button 6 to conrm and button 1 to return to the
previous menus up to the initial status.
SET CLOCK
DAY MON, TUE, WED, ...SUN
HOURS 0...23
MINUTES 00...59
DATE 1...31
MONTH 1...12
YEAR 00...99
ADJUSTING LANGUAGE
It is possible to select the preferred language to display the various messages.
CONTROLS PROCEDURE
Press button 6 and SET CLOCK will appear.
Press button 2 until SET LANGUAGE is displayed.
Conrm using key 6.
Select the language using button 4 or 5.
Press button 6 to conrm and button 1 to return to the
previous menus up to the initial status.
SET LANGUAGE
LANGUAGE
ITALIAN
ENGLISH
GERMAN
FRENCH
SPANISH
J
NO IGNITION
FIRST IGNITION COULD EVEN FAIL AS THE AUGER IS EMPTY AND IS NOT ALWAYS ABLE TO LOAD THE BURN POT
WITH THE REQUIRED AMOUNT OF PELLETS ON TIME TO REGULARLY START THE FLAME.
IF THE PROBLEM OCCURS AFTER ONLY A FEW MONTHS WORKING, CHECK THAT ROUTINE CLEANING STATED IN THE
STOVE BOOKLET, HAS BEEN CARRIED OUT CORRECTLY.
J
NO FLOW ALARM  CLEAN CHECK UP ALARM
SHOULD THE "CLEAN CHECK UP" ALARM BE TRIGGERED, MAKE SURE
THAT THE BOTTOM OF THE BURN POT IS FREE FROM RESIDUES OR
SCALES. THE HOLES AT THE BOTTOM MUST BE COMPLETELY FREE TO
GUARANTEE CORRECT COMBUSTION.
"PELLET FEED ADJUSTMENT" TO ADJUST COMBUSTION ACCORDING
TO REQUIREMENTS. IF THE ALARM PERSISTS AND THE ABOVE LISTED
CONDITIONS HAVE BEEN CHECKED, CONTACT THE QUALIFIED AFTER
SALES ASSISTANCE CENTRE.
BURN POT BOTTOM
ENGLISH

OFF
17
FUNCTIONING AND LOGIC
IGNITION
Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. During the switch-on
phase there are 15 minutes available; after switch-on and upon reaching the control temperature, the
stove interrupts the ignition phase and passes to STARTING.
STARTING
During the starting phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and pass on to
WORK.
WORK
During the work phase, the stove reaches the set power and works to reach the set room temperature. See following item.
ADJUSTING THERMOSTAT SETTING
The room temperature setpoint can be set using buttons 4 and 5, from Low-07 to 40°C -Hot
LOW  HOT
If the temperature setting is“Low” (setpoint below the threshold of 7°C) the stove will always function at minimum.
If the setting is at “Hot” (set higher than the threshold of 40°C) the stove will not modulate, functioning always and only at the
power set.
ADJUSTING POWER SETTING
The power setting has 5 operating levels, by means of button 5 (on), 1 and 2 (adjustment).
Power 1 = minimum level - Power 5 = maximum level.
WORKING WITH ROOM PROBE STANDARD
The appliance controls the room temperature by means of the probe on board the machine.
Having reached the set temperature, it will automatically go to the minimum or switch o activating the Stand by function,
reducing pellet consumption to a minimum.
The STBY function is set to OFF by default ( indicator on).
For its activation and logic, follow the indications on the following page, chapter: Stand by
BURN POT CLEANING
While working, the stove has an internal counter which cleans the burn pot after a set amount of time.
This phase will be shown on the display, it will bring the stove to a lower power level and will increase the ue gas motor for a
programmed amount of time.
When the cleaning phase is nished, the stove will continue work going back to the selected power level.
SWITCHOFF
Press key 1 for three seconds.
When the operation has been performed, the appliance automatically enters the switch- o phase, blocking the supply of
pellets.
The ue exhaust motor and the hot air ventilation motor will remain on until the temperature of the stove has dropped
below the factory parameters.
REIGNITION
The stove can only be re-ignited if the ue gas temperature has lowered and the preset timer has been reset to zero.
DO NOT USE ANY INFLAMMABLE LIQUIDS FOR IGNITION!
DO NOT ALLOW THE BAG OF PELLETS TO COME INTO CONTACT WITH THE BOILING HOT STOVE DURING THE FILLING PHASE!
IN THE EVENT OF CONTINUOUS NO IGNITION, CONTACT AN AUTHORISED TECHNICIAN.
ENGLISH

18
PELLET FEED ADJUSTMENT
The following menu allows the adjustment of pellet feed as a percentage.
If the stove has functioning problems owing to the quantity of pellets, adjust pellet feeding directly from the control board.
The problems correlated to the amount of fuel can be divided into 2 categories:
USER MENU
DISPLAY
This menu allows to regulate the brightness of the display. The possible settings are from OFF - 10 to 31.
By activating OFF, the backlit display shall turn o after a set delay.
Adjust lighting between 10 and 31. (10: minimum brightness; 31: maximum brightness)
The backlight will turn on again upon pressing a button or when the machine enters in alarm mode.
CONTROLS PROCEDURE
Press the key 6, SET CLOCK will appear.
Press key 2 several times until "USER" is displayed
Press key 6.
"DISPLAY" will appear
Use buttons 4-5 to select display brightness.
Press key 6 to conrm and 1 to return to the menu
back to the initial status.
OFF
OFF
ADDITIONAL EXTERNAL THERMOSTAT OPTIONAL
The appliance can control the room temperature by means of an additional external thermostat (optional).
after ignition (pressing button 1 or via chrono mode), the stove will work to reach the thermostat setpoint, displaying
WORK(closed contact). The standard room probe is automatically ignored.
When the thermostat reaches the temperature (open contact), the stove will go to minimum, displaying MODULATION.
TO INSTALL AND ENABLE IT:
A mechanical or digital thermostat is required.
Remove the plug from the socket.
Referring to the gure to the side, connect the two thermostat wires
(potential free contact- no 220 V!) on the relative terminals at the back of the
machine, one red and the other black.
Power the stove.
Press button 5, and set the temperature setpoint to LOU.
The stove is now congured correctly.
It will work controlling the additional external thermostat.
INSTALLATION MUST BE PERFORMED BY QUALIFIED PERSONNEL AND/ORTHE MANUFACTURER'S TECHNICAL
ASSISTANCE.
ENGLISH
J
THERE ARE TWO STOVE OPERATING MODES ACCORDING TO THE
STANDBY FUNCTION. SEE “STANDBY” CHAPTER.

19
CONTROLS PROCEDURE
Press the key 6, SET CLOCK will appear.
Press key 2 several times until "USER" is displayed
Press key 6.
"DISPLAY" will appear
Press key 2 until "PELLET" is displayed.
Use key 4 to increase and 5 to decrease the load during the WORK
phase.
Press key 6 to conrm and 1 to return to the menu
back to the initial status.
ENGLISH
V1FAN
The menu allows adjusting the speed percentage of the front fan.
CONTROLS PROCEDURE
Press the key 6, SET CLOCK will appear.
Press key 2 several times until "USER" is displayed
Press key 6.
"DISPLAY" will appear
Press key 2 until "V1 FAN" is displayed.
Use keys 4 to increase and 5 to decrease
Press key 6 to conrm and 1 to return to the menu
back to the initial status.
1
NO FUEL:
the stove can never develop a suitable ame, tending to remain very low even at high powers.
at minimum power the stove tends to almost switch-o taking the stove into “NO PELLETS”alarm condition.
when the stove displays the “NO PELLETS”alarm, there may be non-burned pellets inside the burn pot.
EXCESS FUEL:
the stove develops a very high ame even at low power.
the panoramic glass is very dirty, obscuring it almost totally.
the burn pot tends to become encrusted, blocking the holes for air intake due to the excessive pellet feed, as it is only
burned partially.
The regulation to be performed is a percentage. Therefore a modication of this parameter will lead to a proportional
variation of all stove feeding speeds. Feeding is from -30% to +20%.
Follow the procedure on the display to perform this adjustment:
STAND BY
STANDBY WITH DIGITAL THERMOSTAT STANDARD
STBY FUNCTION SET AT ON
If the Stby function is active (ON), when the stove reaches the room temperature set exceeding it by 2°C, it will switch o after a
factory set delay time, displaying stand-by.
When the room temperature is lower by 2°C than the setting and once the stove has cooled, it will start to work again at the set
power and the display will show work.

20
ENGLISH
STBY FUNCTION SET TO OFF FACTORY SETTING
If the Stby function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and
displaying modulate. When the room temperature is lower than the setpoint, the stove will start working again at the power set
on the display, showing work.
STANDBY WITH ADDITIONAL EXTERNAL THERMOSTAT
The STBY function is used if immediate stove switch-o is required when the set temperature has been reached.
The STBY function is set to OFF by default ( indicator on).
STBY FUNCTION SET AT OFF FACTORY SETTING
If the STBY function is not active (OFF), if the stove reaches the room temperature set, it will go to minimum, modulating and
displaying MODULATION. When the room temperature is lower by 2°C than the setting, the stove will start to work again at the
power set on the display, showing WORK.
STBY FUNCTION SET AT ON
When the STBY function is activated (ON), the stove, upon reaching the set room temperature and exceeding it by 2°C,
will switch o after a delay set in the factory, displaying STAND - BY.
When the room temperature is 2°C less than the setting, the stove will start to work again at the set power
displaying WORK.
CONTROLS PROCEDURE
Press button 6, the message SET CLOCK will appear.
Press key 2 several times to reach SET USER.
Conrm using key 6.
Press key 2 several times to reach STAND BY.
Press button 4 or 5 to select ON.
Press key 6 to conrm and 1 to return to the menu
back to the initial status.
STANDBY function is active
KEYS LOCKED
The menu allows to lock the display keys (like mobile phone).
With the function activated,“KEYS LOCKED” will appear every time a key is pressed.
CONTROLS PROCEDURE
Press the key 6, SET CLOCK will appear.
Press key 2 several times until "USER" is displayed
Press key 6.
"DISPLAY" will appear
Press key 2 until "KEYS LOCKED" is displayed.
Use keys 4-5 to enable/disable.
Press key 6 to conrm and 1 to return to the menu
back to the initial status.
J
UPON ACTIVATING THE FUNCTION, USE BUTTONS 1 AND 5 SIMULTANEOUSLY TO LOCK OR UNLOCK THE
KEYBOARD
