Extraflame BABYFIAMMA User manual

PELLET STOVES
Instruction Manual
Babyfiamma
Preziosa
Karolina
Isabella
Ecologica
Inserto Comfort Maxi
Bella
Bella Lux
Contessa
uchessa
ivina
ivina Plus
Falò 1 XLP
Falò 1 CP
Falò 2 CP

2
Congratulations! You are now the owner of an EXTRAFLAME stove!
The EXTRAFLAME pellet stove is an ideal heating solution. It utilises the most advanced
technology and is manufactured to the highest standards with a contemporary design,
allowing you to enjoy the ambience and warmth of a natural flame in complete safety.
This manual tells you how to use your stove correctly. Please read the entire manual
carefully before using your stove.
IMPORTANT
Make sure that the dealer completes the following bo with the details of the authorised
specialist who will help you if you have any problems in using your new pellet stove.
AUTHORISE SPECIALIST
Company___________________________________________________________________
Full name __________________________________________________________________
Address ______________________________________________ No._________________
Postal Code _________________ City _________________________________________
TEL. _____________________________ FAX ____________________________________
All E traflame products are manufactured according to the following directives:
• 89/106 EEC (CP ) construction materials
• 73/23 EEC (LV ) electrical safety
• 98/37 EEC machinery
• 2004/108 EEC (EMC) electromagnetic compatibility
And the following standards:
• prEN14785
• EN60335.1 EN50165 EN50366
• EN292 EN294
• EN55014.1 EN55014.2 EN61000-3-2 EN61000-3-3

3
Contents
1 PRECAUTIONS AN SAFETY 4
2 TECHNICAL SPECIFICATIONS 5
3 WHAT ARE PELLETS? 13
3.1 Pellet storage 13
4 SAFETY EVICES 14
4.1 Warm air blower breakdown 14
4.2 Fume e hauster breakdown 14
4.3 Pellet feed motor breakdown 14
4.4 Lighting failure 14
4.5 Temporary power failure 14
4.6 Electrical safety 14
4.7 E haust system safety 14
4.8 Pellet overheating safety 14
5 ASSEMBLY and INSTALLATION INSTRUCTIONS 15
5.1 Glossary 15
5.2 Installation 16
5.2.1 Connection to the e haust venting system 17
5.2.2 Chimney or single flue 18
5.2.3 Connection to the flue and combustion product e haust venting 20
5.2.4 Chimney cap 20
5.2.5 Connection to e ternal air intakes 21
5.2.6 Insulation, trims, facings, and safety precautions 21
5.2.7 National, regional, provincial and municipal laws 21
5.3 Divina Plus distributed heating 22
6 MAXI COMFORT INSTALLATION 23
7 FALÒ 1XLP, FALÒ 1CP AN FALÒ 2CP 30
8 CONTROL PANEL 31
8.1 Table of display messages 32
9 CURRENT TIME AN AY SETTINGS 35
10 USING THE STOVE 35
11 LIGHTING 36
12 STOVE OPERATION 36
12.1 Normal operation 36
12.2 DIVINA PLUS operation 37
12.3 Shutdown 37
12.4 Remote control 37
13 ROOM THERMOSTAT 38
13.1 Digital thermostat 38
13.2 Mechanical thermostat (optional) 38
13.2.1 Installing a mechanical thermostat (optional) 38
13.2.2 Mechanical thermostat operation 38
13.2.3 Mechanical thermostat with energy saving, Standby function (Stby) 39
13.2.4 Mechanical thermostat operation for heat distribution motor (DIVINA PLUS only) 39
14 WIRING IAGRAMS 40
15 USER PARAMETERS 42
15.1 Weekly programmer 42
15.2 Day/Night temperature function 45
15.3 Pellet feed adjustment 46
15.4 Heat distribution parameters (DIVINA PLUS only) 47
16 STOVE CLEANING 48
16.1 Ecologica – Ma i Comfort Insert 48
16.2 Bella-Bella Lu – Contessa – Divina – Divina Plus –Duchessa 50
16.3 Babyfiamma – Preziosa – Karolina - Isabella 52
16.4 Falò 1XLP – Falò 1CP – Falò 2CP 54
16.5 Burn pot partition 56
16.6 Chimney connection 56
17 WARRANTY 57
18 QUALITY CONTROL 59

4
1. PRECAUTIONS AN SAFETY
The stoves manufactured in our factory are
built with the ma imum dedication to the
individual components so as to protect both
the user and the installer from accidents.
Authorized personnel are therefore advised
to pay special attention to the electrical
connections after any servicing operation on
the product, especially with regard to the
stripped part of the wires, which must not
protrude in any way from the terminal block
to prevent possible contact with the live
parts of the wire.
Installation must be carried out by
authorized personnel, who must issue
the purchaser a declaration of
compliance of the system. The
purchaser shall assume responsibility
for the definitive installation and
consequent proper operation of the
product installed. Extraflame S.p.A.
may not be held responsible in the
event of failure to observe these
precautions.
This instruction manual constitutes an
integral part of the product. It must always
accompany the appliance, also when it is
transferred to another owner or user or
moved to another location. If the manual
gets damaged or lost, ask your local service
centre for another copy.
This stove must only be used for the
applications for which it was e pressly
designed.
The manufacturer declines any responsibility,
contractually or e tra-contractually, for any
damage caused to persons, animals or
property by errors in installation, adjustment,
and maintenance, or by improper use.
After removing the packaging, check to make
sure that the contents are intact and
complete.
If this is not the case, contact the vendor
from whom the appliance was purchased.
The electrical components of the stove must
only be replaced by an authorized service
centre.
General stove maintenance must be carried
out at least once a year, scheduled sufficiently
in advance with the service centre.
The following safety precautions must
be observed:
Do not allow the stove to be used by
unattended children or disabled persons.
Do not touch the stove if you are bare-footed
or if parts of your body are wet or damp.
Modifying the safety or adjustment devices
without the manufacturer’s approval or
instructions is forbidden.
Never pull, detach, or twist the electrical
cables coming out of the stove, even if it is
disconnected from the electrical power.
Do not plug or reduce the size of the air vents
of the room in which the stove is installed.
The air vents are critical for correct
combustion.
Keep the packaging materials out of the reach
of children and unattended disabled persons.

5
2. TECHNICAL SPECIFICATIONS
Babyfiamma Preziosa
Height
mm 858 884
Width
mm 440 446
Depth
mm 470 477
Weight
kg 100 110
E haust pipe diameter
mm 80 80
Ma . heating volume
m³ 100 100
Total power (heating power)
kW/h 1.9 - 5.1 1.9 - 5.1
Water heating power
kW/h / /
Pellet consumption per hour
kg/h 0.5 - 1.2 0.5 - 1.2
Absorbed electrical power
W 25 - 100 25 - 100
Lighting power
W +280 +280
Power supply
V, Hz 230, 50 230, 50
Hopper capacity
kg ~11 ~11
Water in/out pipe diameter
" / /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
Babyfiamma
Preziosa

6
Karolina Isabella
Height
mm 976 864
Width
mm 488 453
Depth
mm 501 497
Weight
kg 115 110
E haust pipe diameter
mm 80 80
Ma . heating volume
m³ 140 100
Total power (heating power)
kW/h 1,9 - 7 1,9 - 5,1
Water heating power
kW/h / /
Pellet consumption per hour
kg/h 0,5 - 1,5 0,5 - 1,2
Absorbed electrical power
W 25 - 100 25 - 100
Lighting power
W +280 +280
Power supply
V, Hz 230, 50 230, 50
Hopper capacity
kg ~15 ~11
Water in/out pipe diameter
" / /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
Karolina
Isabella

7
Ecologica
Height
mm 953
Width
mm 670
Depth
mm 677
Weight
kg 170
E haust pipe diameter
mm 80
Ma . heating volume
m³ 220
Total power (heating power)
kW/h 3.0 - 11.0
Water heating power
kW/h /
Pellet consumption per hour
kg/h 0.8 - 2.4
Absorbed electrical power
W 25 - 100
Lighting power
W +280
Power supply
V, Hz 230, 50
Hopper capacity
kg ~35
Water in/out pipe diameter
" /
Pump head
m /
Pump position
/ /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.

8
I.C. Ma i
Height
mm 606
Width
mm 640
Depth
mm 717
Weight
kg 140
E haust pipe diameter
mm 80
Ma . heating volume
m³ 190
Total power (heating power)
kW/h 3.0 - 9.4
Water heating power
kW/h /
Pellet consumption per hour
kg/h 0.8 - 2.0
Absorbed electrical power
W 25 - 100
Lighting power
W +280
Power supply
V, Hz 230, 50
Hopper capacity
kg ~28
Water in/out pipe diameter
" /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
*** Minimum height
The particular “adjust pipe” is pierced with 3 holes Ø 9 of
a 90 – 100 distance; for different adjustments, pierce
according to your necessity.

9
Bella Bella-Lu
Height
mm 1043 1043
Width
mm 520 520
Depth
mm 513 513
Weight
kg 150 160
E haust pipe diameter
mm 80 80
Ma . heating volume
m³ 170 170
Total power (heating power)
kW/h 3.0 – 8.5 3.0 - 8.5
Water heating power
kW/h / /
Pellet consumption per hour
kg/h 0.8 - 1.6 0.8 - 1.6
Absorbed electrical power
W 25 - 100 25 - 100
Lighting power
W +280 +280
Power supply
V, Hz 230, 50 230, 50
Hopper capacity
kg ~25 ~25
Water in/out pipe diameter
" / /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
Bella Bella Lu

10
Contessa Duchessa
Height
mm 1168 1032
Width
mm 522 538
Depth
mm 500 504
Weight
kg 170 177
E haust pipe diameter
mm 80 80
Ma . heating volume
m³ 180 170
Total power (heating power)
kW/h 3,0 - 9,4 3,0 – 8,5
Water heating power
kW/h / /
Pellet consumption per hour
kg/h 0,8 – 2,0 0,8 - 1,8
Absorbed electrical power
W 25 - 100 25 - 100
Lighting power
W +280 +280
Power supply
V, Hz 230, 50 230, 50
Hopper capacity
kg ~21 ~25
Water in/out pipe diameter
" / /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
Contessa
Duchessa

11
Divina Divina Plus
Height
mm 1150 1150
Width
mm 610 610
Depth
mm 576 576
Weight
kg 200 200
E haust pipe diameter
mm 80 80
Ma . heating volume
m³ 220 220
Total power (heating power)
kW/h 3.0 - 11.0 3.0 - 11.0
Water heating power
kW/h / /
Pellet consumption per hour
kg/h 0.8 - 2.4 0.8 - 2.4
Absorbed electrical power
W 25 - 100 25 - 170
Lighting power
W +280 +280
Power supply
V, Hz 230, 50 230, 50
Hopper capacity
kg ~30 ~30
Water in/out pipe diameter
" / /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
Divina Divina Plus

12
Falò 1XLP Falò 1CP Falò 2CP
Height
mm 1522 1522 1522
Width
mm 950 1800 1800
Depth
mm 800 800 800
Weight
kg 373 373 373
E haust pipe diameter
mm 80 80 80
Ma . heating volume
m³ 180 180 180
Total power (heating power)
kW/h 3.0 - 9.4 3.0 - 9.4 3.0 - 9.4
Water heating power
kW/h / / /
Pellet consumption per hour
kg/h 0.8 - 2.0 0.8 - 2.0 0.8 - 2.0
Absorbed electrical power
W 25 - 100 25 - 100 25 - 100
Lighting power
W +280 +280 +280
Power supply
V, Hz 230, 50 230, 50 230, 50
Hopper capacity
kg ~32 ~32 ~32
Water in/out pipe diameter
" / / /
All data are indicative and not binding. The manufacturer reserves the right to make technical
modifications for improving the product.
Falò 1XLP
Falò 1CP e Falò 2CP

13
3. WHAT ARE PELLETS?
Pellets are made by applying very high
pressure to sawdust; i.e. the residue of
raw timber (without paint) produced by
sawmills, carpentry works and other
activities involved in processing wood.
This type of fuel is completely
environmentally friendly, as no binders of
any kind are used to keep it compact. In
fact, the compactness of the pellets over
time is guaranteed by lignite, a natural
substance found in the wood itself.
As we
ll as being an environmentally
friendly fuel, since wood residues are
e ploited to the ma imum, pellets also
have technical advantages.
While the heating power of wood is 4.4
kW/
kg (with 15% humidity, after about
18 months seasoning), the power of
pellets is 5.3 kW/kg.
The density of the pellet is 650kg/m
3
and
the water content is 8% of its weight.
For this reason, pellets do not need to be
seasoned to obtain a sufficient heating
yield.
Pellet diameters range from a minimum
of 5 mm to a ma imum of 8 mm, tho
ugh
E traflame recommends using 6 mm
pellets.
3.1 Pellet storage
To guarantee problem-
free combustion, the
pellets must be stored in a dry place.
WARNING
THE USE OF POOR QUALITY PELLETS OR
ANY OTHER MATERIAL MAY DAMAGE THE
YOUR STOVE AND MAY LEAD TO
THE
INVALIDATION OF THE WARRANTY
AND THE RELATED RESPONSIBILITIES
OF THE MANUFACTURER.

14
4. SAFETY EVICES
4.1 Warm air blower breakdown
If the blower stops for any reason, the stove automatically shuts down to prevent overheating.
4.2 Fume exhauster breakdown
If the e hauster stops, the electronic unit immediately prevents pellet feeding.
4.3 Pellet feed motor breakdown
If the motor stops, the stove continues to operate until the minimum cooling level is reached.
4.4 Lighting failure
If no flame develops during the lighting stage, the stove display shows “ NO ACC”. If you attempt to light
the stove again, the display shows “ATTE” which means “WAIT”. This function reminds you that before
lighting the stove, you must be sure that the burn pot is free of dirt and debris.
4.5 Temporary power failure
The appliance will re-light automatically after a brief power failure. When the power goes off, the stove may
emit a minute quantity of smoke inside the house for a period of 3 to 5 minutes.
THIS DOES NOT POSE ANY SAFETY RISK.
4.6 Electrical safety
The stove is protected against violent power swings by a master fuse on the rear of the stove (2A 250V
delayed).
4.7 Exhaust fume safety
If the e haust system fails, an electronic pressure switch stops the stove and an alarm is signalled.
4.8 Pellet overheating safety
In case of overheating inside the pellet hopper, this safety device blocks stove operation; resetting is manual
and must be performed by an authorized technician.

15
5. ASSEMBLY AN INSTALLATION INSTRUCTIONS
The installation must comply with:
UNI 10683 (2005) heat generators fed with wood and other solid fuels: installation.
The chimneys must comply with:
UNI 9731 (1990) chimneys: classification according to thermal resistance.
UNI 9615 (1995) calculation of the internal dimensions of the chimneys with single connection.
UNI 7129 point 4.3.3 provisions, local rules and prescriptions of the fire brigade.
UNI 1443 (2005) chimneys: general requirements.
UNI 1457 (2004) chimneys: internal ducts in terracotta and ceramics.
5.1 Glossary
CLOSE HEARTH EVICE
Heat generator that can only be opened to load fuel during use.
BIOMASS
Material of organic origin, e cluding the material incorporated in geological formations and
fossilised.
BIOFUEL
Fuel produced directly or indirectly from biomass.
FLUE or CHIMNEY
Vertical duct for collecting and e pelling combustion products from a single appliance at a suitable
height from the floor.
EXHAUST CHANNEL OR PIPE
Duct or connecting element between the heat generating device and the chimney for e tracting
the combustion products.
INSULATION
The series of measures taken and materials used to prevent heat transmission through a wall
dividing rooms at different temperatures.
CHIMNEY CAP
Device located at the top of the chimney that facilitates dispersion of the combustion products in
the atmosphere.
CON ENSATE
Liquid products that form when the temperature of the combustion gas is lower than or equal to
the dew point of the water.
HEAT GENERATOR
Device that permits the production of thermal energy (heat) by the rapid transformation of the
chemical energy of the fuel by means of combustion.
AIR LOCK
Mechanism for modifying the dynamic resistance of the combustion gasses.

16
EXHAUST VENTING SYSTEM
A system for fume e haust venting that is independent from the appliance, composed of a pipe or
channel, chimney or single flue, and chimney cap.
FORCE RAUGHT
Air circulation by means of a fan driven by an electric motor.
NATURAL RAUGHT
Draught resulting in a chimney/flue due to the difference in the volume mass e isting between the
(hot) fumes and the surrounding atmospheric air, without any mechanical suction aid installed
inside or on top of it.
RA IANCE AREA
Area immediately adjacent to the hearth in which the heat produced by combustion is diffused;
this area must not contain any objects made of combustible material.
REFLUX AREA
Area in which the combustion products come out from the appliance towards the room in which it
is installed.
5.2 Installation
Before carrying out installation, it is necessary to check the positioning of the chimneys, flues or
e haust terminal ducts of the appliance, keeping in mind the following:
•Installation prohibitions
•Legal clearances
•Limitations set forth by local administrative regulations or specific regulations of the
authorities.
•Common limitations deriving from building regulations, and easement or contract
regulations.
Admissible installations
In the room in which the heat generator is to be installed, any e isting or installed appliances must
be airtight to the room and must not cause depression in the room with respect to the e ternal
environment.
Appliances used for cooking foods and the related hoods without e tractor can only be installed in
rooms used as kitchens.
Prohibited installations
The room in which the heat generator is to be installed must not contain any of the following
devices, either pre-e isting or installed:
- Hoods with or without e tractor;
- Ventilation ducts of the collective type.
Should these devices be located in adjacent rooms communicating with the installation room, it is
forbidden to use the heat generator simultaneously where there is the risk that one of the two
rooms may be subject to depression with respect to the other.

17
5.2.1 Connection to the exhaust venting system
Exhaust channel or pipe
For the assembly of the e haust channels it is imperative to use non-flammable materials that are
resistant to combustion products and any condensates.
It is forbidden to use fle ible metal pipes and asbestos cement for connecting the stove to the
flue, also for pre-e isting e haust channels.
There must be continuity between the e haust channel and the flue so that the flue does not lean
on the stove.
The e haust channels must not pass through rooms in which the installation of combustion devices
is forbidden.
The assembly of the e haust channels must be carried out in such a way as to ensure that they
are airtight for the operating conditions of the appliance, as well as to limit the formation of
condensates and prevent them from being conveyed towards the appliance.
The assembly of horizontal sections must be avoided where possible.
Where roof or wall e haust outlets have to be reached that are not coa ial in relation to the
e haust outlet from the appliance, the direction changes must be made using open elbows no
greater than 45° (see figures below).
For heat generating devices equipped with an electric e haust fan, i.e. all products made by
E traflame, it is necessary to observe the following instructions:
•Horizontal sections must have a minimum slope of 3% upwards.
•The length of the horizontal section must be as short as possible, and in any case no
greater than 3 meters.
•No more than four direction changes may be used, including the one resulting from the use
of the “T”-element. (When four bends are used, use double wall piping with a 100 mm
diameter.)
In any case, e haust channels must be sealed in relation to combustion products and condensates,
as well as insulated, if they pass outside the installation room.
It is forbidden to use elements in counter-slope.
The e haust channel must allow soot recovery and cleaning using a swab.
The e haust channel must have a constant cross-section. Any changes in cross-section are allowed
only at the flue connection.
45°
45°
Insulation
Flue
Inspection

18
It is forbidden to run other air feed channels or piping for utilities inside the e haust channels,
even if they are oversized. It is also forbidden to fit manual draught adjustment devices on the
forced draught appliance.
5.2.2 Chimney or single flue
The chimney or flue must meet the following requirements:
- be airtight to combustion products, waterproof and properly insulated according to the usage
conditions;
- be made of materials suitable to resist normal mechanical stress, as well as heat and the action
of combustion products and any condensates;
- have a predominantly vertical layout with deviations from the a is no greater than 45°;
- be situated at a proper distance from combustible or flammable materials by means of an air gap
or suitable insulation material;
REFERENCES Flammable
objects
Non-
flammable
objects
A 200 100
B 1500 750
C 200 100
- preferably have a round internal section: square or rectangular sections must have rounded
edges with radius no less than 20 mm;
- have a constant, free and independent internal section;
- have rectangular sections with a ma imum ratio between sides of 1.5.
The e haust duct should be equipped with a chamber for the collection of solid materials and any
condensates located below the mouth of the e haust channel, so that it is easy to open and
inspect from the airtight hatch.
A
Minimum 80 cm²
Floor protection
B
20 cm
C

19
Maximum 3 m
3
–
5 %
Inspection
Windproof
chimney
cap
Flue
Inspection
External
insulated duct
Inspection
Maximum 3 m
45°
Inspection

20
5.2.3 Connection to the flue and combustion product exhaust venting
The connection between the appliance and the flue must only receive the discharge from a single
heat generator.
Direct discharge towards enclosed areas, even when roofless, is forbidden.
Direct discharge of combustion products must take place on the roof and the e haust duct must
have the features set forth in the section “Chimney or single flue” .
5.2.4 Chimney cap
The chimney cap must meet the following requirements:
- have an internal section equivalent to that of the chimney;
- have a useful outlet section no less than twice the internal section of the chimney;
- be constructed in such a way as to prevent the penetration of rain, snow and foreign bodies into
the chimney, as well as to assure the discharge of the combustion products also in the presence of
winds coming from any direction and at any angle.
- be positioned in such a way as to assure proper dispersion and dilution of the combustion
products and, in any case, outside the reflu area in which the formation of counter-pressure is
most likely to occur. This area has different sizes and shapes depending on the slope of the roof;
therefore, it is necessary to use the minimum heights indicated in the figures below.
The chimney cap must not have any mechanical suction devices.
50 cm
> 5 m
< 5 m
50 cm
< 5 m
FLAT ROOF
SLOPE
ROOF
istance
> A
istance
< A
50 cm beyond the ridge beam
H min
β
REFLUX AREA
Reflux area height
