Extremis INUMBRA User manual

Inumbra

IMPORTANT! RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY.

Table of contents 1/2
Mounting kit 
Assembly with Gargantua 
Assembly with Pantagruel 
Assembly concrete base 
This is an interactive PDF
You can easily navigate through this manual, allowing you to
smoothly jump from one page to the other.

Table of contents 2/2
Assembly concrete wheel base 
Assembly floor fastening 
Open/Close 
Warnings - Text instructions -
Maintenance 

6
4 x M8x12
4 x foot4 x plug4 x screw M5x40
4 x M10x115
4 x M8
Mounting kit INU183 to fix the connection
piece to the Gargantua/Pantagruel
Mounting kit INU180 to fix the concrete base
Mounting kit

7
2.
1.
20’
N° 5
With Gargantua

8
INU183
4 x M8x124 x M8
3.
2.
First remove the central cube if already mounted

9
4.
GAR025
8 x M10x608 x M10

10
5.
Attention!
The parasol
should always be
fully opened or
completely closed!

11
OpenClose

12
1.
20’
N° 5
2.
INU183
4 x M8x124 x M8
With Pantagruel

13
3.
4.
Attention!
The parasol
should always be
fully opened or
completely closed!

14
OpenClose

15
1.
20’
N° 17
2.
INU180
4 x foot4 x plug4 x screw Mx40
Concrete base
Repeat this for all
concrete blocks
Place on level and solid ground

16
3.
INU180
4 x M10x115
4.

17
Attention!
The parasol
should always be
fully opened or
completely closed!

18
1.
20’
N° 5
INU182
4 x M10x115
2.
Concrete wheel base
Place on level and solid ground

19
3.
Attention!
The parasol
should always be
fully opened or
completely closed!

20
1.
20’
N° 5
Floor fastening
Place on level and solid ground
