FAAC T-MODE TM 45 E User manual

T-MODE
TM 45 E
TM 58 E

ENGLISH
2
WARNINGS FOR THE INSTALLER
1. ATTENTION! To ensure the safety of people, it is important that
you read all the following instructions. Incorrect installation or
incorrect use of the product could cause serious harm to people.
Keep these instructions for future reference.
2. Carefully read the instructions before beginning to install the
product.
3. This product was designed and manufactured exclusively for
the purpose indicated in this documentation. Any other use, not
expressly indicated here, could compromise the good condition/
operation of the product and/or be a source of danger.
4. FAAC declines any responsibility for improper use or use other than
that for which the automated system was intended.
5. Disconnect the power supply before any operation on the sys-
tem.
6. The installation must be carried out by qualified technical personnel
in conformity with the norms in force.
7. The power mains of the automated system must be fitted with a
multi-pole power switch with a switch-contact gap of at least 3
mm.
8. The min. installation height for the automated system is 2.5 m.
9. Make sure that a differential switch with trip threshold of 0.03 A
is fitted upstream of the system.
10. Several motors can be connected with the same inverter if the
latter supports the power needed by the motors.
11. Two inverters can be connected with the same motor paying at-
tention that a few motor parameters could be changed pressing
simultaneously the up/down button on different inverters.
12. Use only FAAC original parts for maintenance.
13. The equipment handling must always be at sight.
14. Do not allow children or adults to stay near the product while
it is operating.
15. Keep remote controls or other pulse generators out of reach of
children, to prevent the automated system from being activated
unintentionally.
16. The automated system cannot be repaired/adjusted by the
end-user; these operations can only be carried out by quali-
fied personnel.
17. Anything not expressly specified in these instructions is not
permitted.
18. The setting of the travel stops must be made with the motor installed
inside the tube (not at the bench).
19. The obstacle detection while lowering is active only if the suitable acces-
sory is installed on the motor.
20. The equipment is not intended to be used by people (children included)
without sufficient experience or knowledge, unless they are surveilled or
instructed on the equipment use by a person responsible for the safety.
21. Children must be supervised to make sure they do not play with the
equipment.
22. In case of outdoor installation install the designated cable H05RR-F with a
min. carbon percentage of 2% and a min. section of 4 x 0.75 mm².
23. In the version with radio control the installation of the step button for the
manual operation in case of radio control problems is mandatory.
DECLARATION OF CONFORMITY
Manufacturer: FAAC S.p.A.
Address: Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY
Declares that: Operator mod. TM 45 E, TM 58 E
 • conformstotheessentialrequirementsofthefollowingEECdirectives:
-2006/95/EEC
- 2004/108/EEC
 •itthusconformstothefollowingstandardizednorms:
  -EN60335-1-95,EN60335-2-97/10-2000.
  -EN61000-3-2,EN61000-3-3,
  -EN55014-1,EN55014-2
Bologna, 1st May 2011 The Managing Director
A. Marcellan

a
b
c
ed
f
41 mm
ENGLISH
3
T-MODE TUBULAR MOTORS WITH ELECTRONIC TRAVEL STOP
2 TECHNICAL SPECIFICATIONS
Fig. 1
aTubular motor
b Exampleofwheeladapter
(Accessory)
cExampleofcrownadapter
(Accessory)
dTravel stop ring nut
e Exampleofmotorsupport
(Accessory)
fMechanical sensor for obstacle
detection
(Accessory)
BEFORE INSTALLING, CHOOSE:
1) THE ADAPTER (Fig.1 re. b - c) MOST SUITABLE FOR THE ROLLER TYPE TO BE DRIVEN.
2) THE MOTOR SUPPORT MOST SUITABLE FOR THE APPLICATION.
3 INSTALLATION
T-MODE
45E
MODEL
TORQUE
(Nm)
FREQUENCY
OFUSE
MAX.
USETIME
(min.)
SPEED
(Rpm)
VOLTAGE
(V)
FREQUENCY
(Hz)
POWER
(W)
CURRENT
(A)
MOTOR
SHAFT
MAX.
ROTATIONS
MOTOR
DIAMETER
(mm)
“L”LENGTHWITH
ADAPTER
(mm)
PROTECTION
CLASS
8/17 8 20% 4 17 230 50 135 0.6 50 45 440 IP44
15/17 15 20% 4 17 230 50 200 0.8 50 45 465 IP44
20/17 20 20% 4 17 230 50 50 45 480 IP44
30/17 30 20% 4 17 230 50 285 1.3 50 45 500 IP44
35/12 35 20% 4 12 230 50 275 1.2 50 45 500 IP44
45/12 45 20% 4 12 230 50 310 1.4 50 45 500 IP44
50/12 50 20% 4 12 230 50 50 45 500 IP44
T-MODE
58RE
MODEL
TORQUE
(Nm)
FREQUENCY
OFUSE
MAX.
USETIME
(min.)
SPEED
(Rpm)
VOLTAGE
(V)
FREQUENCY
(Hz)
POWER
(W)
CURRENT
(A)
MOTOR
SHAFT
MAX.
ROTATIONS
MOTOR
DIAMETER
(mm)
“L”LENGTHWITH
ADAPTER
(mm)
PROTECTION
CLASS
70/12 70 20% 4 12 230 50 377 1.64 50 45 536 IP44
80/12 80 20% 4 12 230 50 405 1.76 50 45 536 IP44
100/12 100 20% 4 12 230 50 50 45 IP44
120/12 120 20% 4 12 230 50 50 45 IP44
1 DESCRIPTION AND VALUES
USING THE MECHANICAL SENSOR FOR OBSTACLE DETECTION, THE “L” LENGTH OF THE MOTOR WITH THE ADAPTER INCREASES BY
41 mm (L + 41 mm)
L

c
aA = ..x.. mm
A = ..x.. mm
b
4X10
a
Ø 3 mm
b
b
a
a
c
b A
b
ENGLISH
4
3) Measure the value A on the tubular motor as described
in figure 3 re. a.
4) Make a hole with a drill Ø 3 mm on the roller (Fig. 3 re. b)
at the distance A, previously measured on the tubular
motor (Fig. 3 re. a).
5) Fit the assembled tubular motor inside the roller from
the side opposite the cover, until the crown adapter is
completely inside the roller (Fig. 4 re. a).
3.2 INSTALLATION OF THE TUBULAR MOTOR
6) Fasten the wheel adapter to the roller with a tapping
screw 4x10 fit in the previously drilled hole, like in figure 4
re. b.
7) Install the previously chosen motor support from the side
of the electric presetting (Fig. 5 re. a).
8) Fit the motor-driven roller in the motor support (Fig.5 re.
b), and on the cover support (Fig. 5 re. c).
9) Check with a level that the motor-driven roller is per-
fectlyhorizontal;possiblymodifytheheightofthemotor
or cover supports.
3.1 ASSEMBLY OF THE TUBULAR MOTOR
1) Fit the crown adapter (Fig. 2 re. a) in the tubular mo-
tor, until it is completely inserted in the guide on the travel
stop ring nut.
2) Fit the wheel adapter (Fig. 2 re. b) in the motor shaft
and lock it with the supplied stop. (Fig. 2 re. c).
If, in the application for roller shutters, you choose the
obstacle detection while lowering, it is necessary to fit
the obstacle detection mechanical sensor (fig. 2 re. b A)
before the wheel adapter.
Fig. 2
Fig. 3
Fig. 4
ELECTRICPRESETTINGSIDE
Fig. 5

===
LN
230 V ~
OK
L
ENGLISH
5
3.3 ELECTRIC CONNECTIONS
1) Before attempting any job on the system, cut the power supply off.
2) The power mains of the automated system must be fitted with a multi-pole power switch with a switch-contact
gap of at least 3 mm.
3) For the set-up, use non-interlocked buttons or use the XTM PROG programmer.
4) Wire according to the scheme; if the motor rotates in the opposite direction do not reverse the black and
brown wires, as, at the end of the set-up, the up/down buttons are automatically matched to the correct rota-
tion direction.
5) Several remote control buttons can be connected with the same motor.
1) Connect the wires from the motor to two buttons (NOT INTERLOCKED BY SET-UP), the black wire to the up button and
the brown wire to the down button. (Figure 6)
2) Connect the buttons with the line according to figure 6.
3) Supply the motor and press the up/down buttons to check their operation. If the motor rotates in the opposite direc-
tion do not reverse the black and brown wires, as, at the end of the set-up, the up/down buttons are automatically
matched to the correct rotation direction.
Fig. 6
Fig. 7
4 SET-UP
The SET-UP procedure enables to set the up/down travel stop and the correct functions for the rolling shutter to
be motor-driven by pressing suitably connected buttons (ROLLER SHUTTER MODE, UNIVERSAL AWNING MODE AND
CASSETTE AWNING MODE).
TheSET-UPprocedurecanbeinAUTOMATICmode(withtwomodes)orinMANUALmode.
The AUTOMATIC SET-UP is possible for roller shutters only.
The MANUAL SET-UPispossibleforallapplications(ROLLERSHUTTER,STANDARDAWNINGORCASSETTEAWNING).
If the set-up has not been performed or completed, the motor does not move smoothly pressing a control button but makes
a small step.
If the XTM PROG programmer is used for the set-up, pressing simultaneously the two buttons corre-
sponds to pressing the red “SET-UP” button, while the up/down buttons correspond to the buttons “L1”
and “L2”.
L 2 L 1
BLACK BROWN
BLUE
BLACK
BROWN
UP DOWN
YELLOW
GREEN

ac
ENGLISH
6
4.2 SET-UP FOR ROLLER SHUTTERS
The automatic set-up can be carried out exclusively if the motor is installed on roller shutters with upper mechanical
stop (example up travel stop plugs Fig. 8 re. c), with the obstacle detection mechanical sensor (Fig. 9 re. b) and
with stiff connection types between tube and roller shutter (example: anti-intrusion devices or stiff fastening belts).
If the procedure is performed the motor sets all travel stops automatically.
4.1 FUNCTIONS SET WHEN THE APPLICATION TYPE IS DEFINED IN THE SET-UP MODE
ROLLER
SHUTTERS
UNIVERSAL
AWNINGS
CASSETTE
AWNINGS
DURING THE SET-UP, DO NOT REVERSE THE MOTOR PHASES IN CASE OF OPPOSITE ROTATION OF THE ROLLING SHUTTER. AT THE END
OF SET-UP, THE UP/DOWN PUSH-BUTTONS ARE AUTOMATICALLY MATCHED TO THE CORRECT ROTATION DIRECTION.
OBSTACLE
DETECTION
MECHANICAL
SENSOR
1) Press and hold down the button controlling the rise.
2) The rolling shutter rises till meeting the up mechanical stop, then it lowers, stops at the down mechanical stop and
makes 2 short movements (one in one direction and one in the other direction).
3) Release the button controlling the rise.
4) By controlling the rolling shutter rise and lowering, check the correct setting of the two travel stops.
5) If the travel stops have not been set correctly, make a reset (chapter 7) and repeat the automatic, semi-automatic
or manual set-up procedure.
UPPER
MECHANICAL
TRAVEL STOP
Fig. 8
WHEN THE AUTOMATIC SET-UP IS PERFORMED, THE MOTOR SETS IN THE ROLLER SHUTTER MODE.
4.2.1 AUTOMATIC SET-UP FOR ROLLER SHUTTERS (For roller shutters in the configuration described below only)
1) Obstacle detection while lowering. (OBSTACLE DETECTION)
(ONLY WITH MECHANICAL SENSOR FOR OBSTACLE DETECTION OR MOTOR TM35 ERO)
2) Ice detection on the rolling shutter guides or bolts while rising (ANTI_ICE)
(Modification of the detection end position, and torque can be modified during the travel - default 100%)
3) Torque reduction during the last centimetres before the travel limits, with possibility to modify it on 4 levels:
40% , 60% , 80% , 100 % (default) of rated torque. ( SOFT TOUCH )
4) After the automatic set-up, the up travel limit is lower than the mechanical stop
( This avoids useless tensioning of the rolling shutter )
5) Possibility of modifying the obstacle detection sensitivity on 10 levels and of the torque in the last centimetres before
the travel limits
6) During the set-up, the first confirmation movement occurs in the opposite direction to the last movement.
1) Detection of possible winding blocks when rising and following automatic shut-off of the motor.
2) During the set-up, the first confirmation movement occurs in the opposite direction to the last movement.
3) Torque reduction in the last centimetres before the travel limits, with possibility to modify it on 4 levels: 40% , 60% ,
80% , 100 % (default) of rated torque. ( SOFT TOUCH )
1) Search for the up travel limit at each total winding cycle. (BOX ALWAYS CLOSED)
( This function balances in a totally automatic way the awning cloth extension )
2) Torque reduction in the last centimetres before the up travel limit, with possibility to modify it on 4 levels: 40% , 60% ,
80% (default) , 100 % of rated torque. ( SOFT TOUCH )
( It enables a softer closure of the cassette, without stressing the mechanical parts and the awning cloth)
3) Cloth release after cassette closure ( RELEASE SYSTEM )
( It enables to eliminate the cloth tensioning, without having to re-open the box )
4) Detection of possible winding blocks when rising and following automatic shut-off of the motor.
5) During the set-up, the first confirmation movement occurs in the opposite direction to the last movement.
After setting the up travel limit, the motor performs N movements in both directions, to confirm the performed memory
storing of the up travel limit and of the operating mode being set :
- 1 confirmation movement in both directions = rolling shutter mode selected and up travel limit set
- 2 confirmation movements in both directions = standard awning mode selected and up travel limit set
- 3 confirmation movements in both directions = cassette awning mode selected and up travel limit set

X 1
X 1
ENGLISH
7
FIND THE PUSH-BUTTON CONTROLLING THE UP MOVEMENT AND HOLD IT PRESSED UNTIL
THE MOTOR ROTATES IN BOTH DIRECTIONS (END OF SET-UP).
Fig. 8
4.2.2 AUTOMATIC SET-UP FOR ROLLER SHUTTERS, WITH MANUAL SETTING OF THE DOWN TRAVEL STOP
(For roller shutters with opening mechanical stops only)
WHEN THE SEMI-AUTOMATIC SET-UP IS PERFORMED, THE MOTOR SETS IN THE ROLLER SHUTTER MODE.
If the mechanical obstacle detection sensor has not been installed, the semi-automatic set-up can be performed
and the down travel stop can be set manually. Up mechanical stops MUST BE AVAILABLE to set the up travel stop.
1) Press and hold down the button controlling the rolling shutter rise.
2)The rolling shutter rises till meeting the up mechanical stop, then it lowers. (Do not release the button)
3) Release the button where the down travel stop is to be set.
4) Press the up and down buttons at the same time till the motor makes 1 short movement in both directions.
5) By controlling the rolling shutter rise and lowering, check the correct setting of the two travel stops.
6) If the travel stops have not been set correctly, make a reset and repeat the set-up procedure.
FIND THE BUTTON CONTROLLING THE UP MOVEMENT AND HOLD IT PRESSED WITHOUT
RELEASING IT TILL REACHING THE WISHED POSITION OF DOWN TRAVEL STOP. PRESS THE
UP AND DOWN BUTTONS AT THE SAME TIME TO CONFIRM THE POSITION TILL THE MOTOR
MAKES THE INDICATED MOVEMENTS.
DOWN
TRAVEL STOP
IF THE MOTOR DOES NOT REACH ONE OF THE TWO STOPS RATHER STOPS EARLIER, CHECK POSSIBLE FRICTIONS ON THE ROLLING
SHUTTER AND REMOVE THEM; OTHERWISE, PERFORM THE MANUAL SET-UP.
Fig. 9

x 1
x 1
x 1
ENGLISH
8
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE UP TRAVEL STOP
DURING THE SET-UP, DO NOT REVERSE THE MOTOR PHASES IN CASE OF OPPOSITE ROTATION OF THE ROLLING SHUTTER (FOR EX-
AMPLE PRESSING THE DOWN BUTTON THE MOTOR RISES THE SHUTTER). AT THE END OF SET-UP, THE UP/DOWN PUSH-BUTTONS ARE
AUTOMATICALLY MATCHED TO THE CORRECT ROTATION DIRECTION.
1) Press the up or down button and take the roller shutter to the wished position for the up travel stop; then, release the
button.
2) Press both buttons for 1 second, release them, within 1 second, hold them pressed till the motor makes one short
movement in both directions, to check the correct mode setting.
3) Press the button controlling the lowering and go to the down travel stop.
4) Press the up and down buttons at the same time till the motor makes one short movement in both directions.
5) Check if the positions of the set travel stops are correct. If the travel stops have not been set correctly, make a reset
and repeat the set-up procedure.
PRESS THE UP AND DOWN BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 0.5 SECONDS AND
PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN BOTH DIRECTIONS,
TO CONFIRM THE STORING OF THE UP TRAVEL STOP.
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE DOWN TRAVEL STOP, RELEASE THE BUTTON
AND PRESS THE UP AND DOWN BUTTONS AT THE SAME TIME, TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN
BOTH DIRECTIONS. THE SET-UP IS ENDED.
UP TRAVEL
STOP
DOWN
TRAVEL STOP
OR
OR
4.2.3 MANUAL SET-UP FOR ROLLER SHUTTERS
Within 1 second
During the manual set-up it is possible to choose which travel stop must be set first.
4.2.3.1 MANUAL SET-UP FOR ROLLER SHUTTERS STARTING FROM THE UP TRAVEL STOP SETTING

x 1
x 1
x 1
ENGLISH
9
4.2.3.2 MANUAL SET-UP FOR ROLLER SHUTTERS STARTING FROM THE DOWN TRAVEL STOP SETTING (function available from the software version 4.90)
PRESS THE UP AND DOWN BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 0.5 SECONDS AND
PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN BOTH DIRECTIONS,
TO CONFIRM THE STORING OF THE UP TRAVEL STOP. THE SET-UP IS ENDED.
Within 1 second
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE UP TRAVEL STOP
UP TRAVEL
STOP
OR
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE DOWN TRAVEL STOP, RELEASE THE BUTTON
AND PRESS THE UP AND DOWN BUTTONS AT THE SAME TIME, TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN
BOTH DIRECTIONS.
DOWN
TRAVEL STOP
OR
1) Press the button controlling the lowering and go to the down travel stop and release the button.
2) Press the up and down buttons at the same time till the motor makes one short movement in both directions.
3) Press the up or down button and take the roller shutter to the wished position for the up travel stop; then, release the
button.
4) Press both buttons for 1 second, release them, and hold them pressed till the motor makes one short movement
in both directions, to check the correct mode setting.
5) Check if the positions of the set travel stops are correct. If the travel stops have not been set correctly, make a reset
and repeat the automatic or semi-automatic set-up procedure.

x 2
x 2
x 1
ENGLISH
10
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE UP TRAVEL STOP
DURING THE SET-UP, DO NOT REVERSE THE MOTOR PHASES IN CASE OF OPPOSITE ROTATION OF THE ROLLING SHUTTER (FOR EX-
AMPLE PRESSING THE DOWN BUTTON THE MOTOR RISES THE AWNING). AT THE END OF SET-UP, THE UP/DOWN PUSH-BUTTONS ARE
AUTOMATICALLY MATCHED TO THE CORRECT ROTATION DIRECTION.
1) Press the up or down button and take the roller shutter to the wished position for the up travel stop; then, release the
button.
2) Press both buttons for 1 second TWICE, release them, and hold them pressed till the motor makes two short move-
ments in both directions, to check the correct mode setting.
3) Press the button controlling the lowering and go to the down travel stop.
4) Press the up and down buttons at the same time till the motor makes one short movement in both directions.
5) Check if the positions of the set travel stops are correct. If the travel stops have not been set correctly, make a reset
and repeat the set-up procedure.
PRESS TWICE THE UP AND DOWN BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 0.5 SECONDS
AND PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES TWO SHORT MOVEMENTS IN BOTH
DIRECTIONS, TO CONFIRM THE STORING OF THE UP TRAVEL STOP.
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE DOWN TRAVEL STOP, RELEASE THE BUTTON
AND PRESS THE UP AND DOWN BUTTONS AT THE SAME TIME, TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN
BOTH DIRECTIONS. THE SET-UP IS ENDED.
UP TRAVEL STOP
DOWN TRAVEL
STOP
OR
OR
4.3 SET-UP FOR UNIVERSAL AWNINGS (SPRING OR FALL TYPE)
Within 1 second
4.3.1 SET-UP FOR STANDARD AWNINGS STARTING FROM THE UP TRAVEL LIMIT

x 1
x 2
ENGLISH
11
PRESS THE UP OR DOWN PUSH-BUTTON AND TAKE THE AWNING TO THE UP TRAVEL LIMIT
DURING THE SET-UP DO NOT REVERSE THE MOTOR PHASES IN CASE OF OPPOSITE ROTATION OF THE ROLLING SHUTTER (FOR
EXAMPLE YOU PRESS THE DOWN PUSH-BUTTON AND THE MOTOR RISES THE AWNING). AT THE END OF THE SET-UP, THE UP/DOWN
PUSH-BUTTONS ARE AUTOMATICALLY MATCHED TO THE CORRECT ROTATION DIRECTION.
1) Press the up or down push-button and take the awning to the selected position for the down travel limit, then release
the push-button.
2) Press the up and down push-buttons at the same time until the motor performs a brief movement in both
directions.
3) Press the up or down push-button and take the awning to the selected position for the up travel limit, then release
the push-button.
4) Press TWICE both push-buttons for 1 second, release them, and hold them down until the motor performs two
brief movements in both directions, to check the correct mode setting.
5) Check if the positions of the set travel limits are correct. If the travel limits have not been set correctly, perform a reset
and repeat the set-up procedure.
PRESS THE UP OR DOWN PUSH-BUTTON AND TAKE THE AWNING TO THE DOWN TRAVEL LIMIT, RELEASE THE
PUSH-BUTTON AND PRESS THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME, UNTIL THE MOTOR PERFORMS
ONE BRIEF MOVEMENT IN BOTH DIRECTIONS. THE SET-UP HAS BEEN COMPLETED
Within 1 second
4.3.2 SET-UP FOR STANDARD AWNINGS STARTING FROM THE DOWN TRAVEL LIMIT
DOWN
TRAVEL LIMIT
OR
OR
UP
TRAVEL LIMIT
PRESS TWICE THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 0.5
SECONDS AND HOLD DOWN BOTH PUSH-BUTTONS UNTIL THE MOTOR PERFORMS 2 BRIEF MOVEMENTS IN BOTH
DIRECTIONS TO CONFIRM THE MEMORY-STORAGE OF THE UP TRAVEL LIMIT.

x 3
x 3
x 1
ENGLISH
12
DURING THE SET-UP, DO NOT REVERSE THE MOTOR PHASES IN CASE OF OPPOSITE ROTATION OF THE ROLLING SHUTTER (FOR EX-
AMPLE PRESSING THE DOWN BUTTON THE MOTOR RISES THE AWNING). AT THE END OF SET-UP, THE UP/DOWN PUSH-BUTTONS ARE
AUTOMATICALLY MATCHED TO THE CORRECT ROTATION DIRECTION.
1) Press the up or down button and take the roller shutter to the wished position for the up travel stop; then, release the
button.
2) Press both buttons for 1 second THREE TIMES, release them, and hold them pressed till the motor makes three short
movements in both directions, to check the correct mode setting.
3) Press the button controlling the lowering and go to the down travel stop.
4) Press the up and down buttons at the same time till the motor makes one short movement in both directions.
5) Check if the positions of the set travel stops are correct. If the travel stops have not been set correctly, make a reset
and repeat the set-up procedure.
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE UP TRAVEL STOP
PRESS THE UP AND DOWN BUTTONS THREE TIMES SIMULTANEOUSLY FOR 1 SECOND, RELEASE THEM FOR 0.5
SECONDS AND PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES THREE SHORT MOVEMENTS
IN BOTH DIRECTIONS, TO CONFIRM THE STORING OF THE UP TRAVEL STOP.
PRESS THE UP OR DOWN BUTTON AND TAKE THE ROLLING SHUTTER TO THE DOWN TRAVEL STOP, RELEASE THE BUTTON
AND PRESS THE UP AND DOWN BUTTONS AT THE SAME TIME, TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN
BOTH DIRECTIONS. THE SET-UP IS ENDED.
DOWN TRAVEL
STOP
UP TRAVEL STOP
OR
OR
4.4 SET-UP FOR BOX OR CASSETTE AWNINGS
Within 1 second
4.4.1 SET-UP FOR CASSETTE OR IN-BOX AWNINGS STARTING FROM THE UP TRAVEL LIMIT

x 3
x 3
x 1
ENGLISH
13
DURING THE SET-UP DO NOT REVERSE THE MOTOR PHASES IN CASE OF OPPOSITE ROTATION OF THE ROLLING SHUTTER (FOR
EXAMPLE YOU PRESS THE DOWN PUSH-BUTTON AND THE MOTOR RISES THE AWNING). AT THE END OF THE SET-UP, THE UP OR DOWN
PUSH-BUTTONS ARE AUTOMATICALLY MATCHED TO THE CORRECT ROTATION DIRECTION.
1) Press the up or down push-button and take the awning to the selected position for the up travel limit, then release
the push-button.
2) Press THREE TIMES both push-buttons for 1 second, release them and hold them down until the motor performs
three brief movements in both directions to check the correct mode setting.
3) Press the down push-button and go to the down travel limit.
4) Press the up and down push-buttons at the same time until the motor performs one brief movement in both
directions.
5) Check if the positions of the set travel limits are correct. If the travel limits have not been set correctly, perform a reset
and repeat the set-up procedure.
PRESS THE UP OR DOWN PUSH-BUTTON AND TAKE THE AWNING TO THE UP TRAVEL LIMIT
PRESS THREE TIMES THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME FOR 1 SECOND , RELEASE THEM FOR
0.5 SECONDS AND HOLD DOWN BOTH PUSH-BUTTONS UNTIL THE MOTOR PERFORMS 3 BRIEF MOVEMENTS IN
BOTH DIRECTIONS TO CONFIRM THE PERFORMED MEMORY-STORAGE OF THE UP TRAVEL LIMIT.
PRESS THE UP OR DOWN PUSH-BUTTON AND TAKE THE AWNING TO THE DOWN TRAVEL LIMIT, RELEASE THE
PUSH-BUTTON AND PRESS THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME, UNTIL THE MOTOR PERFORMS
A BRIEF MOVEMENT IN BOTH ROTATION DIRECTIONS. THE SET-UP HAS BEEN COMPLETED
4.4.2 SET-UP FOR CASSETTE OR IN-BOX AWNINGS STARTING FROM THE DOWN TRAVEL LIMIT
UP
TRAVEL LIMIT
DOWN
TRAVEL LIMIT
OR

RESET
X 1
ENGLISH
14
4 seconds 1 second
1 second
HOLD THE BUTTONS PRESSED TILL THE MOTOR MAKES THE INDICATED MOVEMENTS
5 RESET
AT THE RESET, THE MOTOR IS RESTORED TO THE FACTORY SETTING. THIS OPERATION CAN BE PERFORMED AT ANY TIME, EVEN DUR-
ING THE SET-UP PROCEDURE.
1) Press the two buttons at the same time for 4 seconds
2) Release them for 1 second
3) Press them at the same time for 1 second
4) Release them for 1 second
5)Holdbothbuttonspressedtilloneshortmovementisperformedinbothdirections,confirmingtheperformedRESET
procedure:
1 second
6 ADVANCED MENU
6.1.1 MODIFYING THE SENSITIVITY OF THE OBSTACLE DETECTION WHEN LOWERING (ONLY FOR ROLLING SHUTTERS)
THE ADVANCED MENU CAN BE ACCESSED EXCLUSIVELY AFTER HAVING SET THE TRAVEL STOPS; IN THIS MENU IT IS POSSIBLE TO CHANGE
THE OBSTACLE DETECTION SENSITIVITY AND THE TORQUE IN THE LAST CENTIMETERS BEFORE THE UP TRAVEL STOP. TO EXIT
THE ADVANCED MENU, HOLD ONE OF THE TWO BUTTONS PRESSED TILL THE MOTOR MAKES 1 SHORT MOVEMENTS IN BOTH DIREC-
TIONS. TO BE SURE HAVING EXITED THE ADVANCED MENU, PRESS THE UP OR DOWN BUTTON AND CHECK THE LINEAR MOVEMENT
OF THE ROLLING SHUTTER.
1) Press the two buttons at the same time for 4 seconds.
2) Release them for 1 second.
3) Press them at the same time for 1 second.
4) Release them for 1 second.
5) Press them at the same time for 1 second.
6) Release them for 1 second.
7) Hold both buttons pressed till one short movement is performed in both directions, confirming the advanced menu
has been entered, and the motor makes three short movements in both directions.
8) Press twice the up and down buttons for 1 second at the same time and press them again at the same time till the
motor makes one short movement in both directions.
9)PresstheupanddownbuttonNtimesfor1secondsimultaneouslytoselectthewishedobstacledetectionsensitivity
level (1 pressing - disabled obstacle detection .....10 pressings - max. obstacle sensitivity)
10) Press the up and down button at the same time till making 1 short movements.
11) If the motors makes three short movements in both directions, the correct procedure has not been performed and
you are still inside the advanced menu. Perform point 9 again.
Within 1 second
6.1 FUNCTIONS CONNECTED TO THE OBSTACLE DETECTION
The obstacle detection in the last centimetres before the travel limit is “inhibited”. If you wish to activate this function also
for that area, observe the operations described in chapter 6.1.2

x 2
x 2
x 1
x N
X 3
ENGLISH
15
4 seconds
HOLD THE BUTTONS PRESSED TILL THE MOTOR MAKES THE INDICATED MOVEMENTS, CONFIRMING THE
ADVANCED MENU IS ACCESSED.
1 second 1 second 1 second 1 second 1 second
Within 1 second
PRESS TWICE THE UP AND DOWN BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 1 SECOND
AND PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES TWO SHORT MOVEMENTS IN BOTH
DIRECTIONS.
PRESS THE UP AND DOWN BUTTONS n TIMES FOR 1 SECOND SIMULTANEOUSLY, RELEASE THEM FOR 1 SECOND AND
PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES ONE SHORT MOVEMENT IN BOTH DIRECTIONS,
TO CONFIRM THE SENSITIVITY CHANGE AND THE EXIT FROM THE ADVANCED MENU.
1 up+down button pressing = Obstacle detection not active
....2, 3, 4, 5, 6, 7, 8, 9 up+down button pressings
10 up+down button pressings = Obstacle detection at max. sensitivity
within 1 second press and hold pressed
within 1 second press and hold pressed

X 1
x 1
X 3
x 2
x 2
ENGLISH
16
HOLD DOWN THE PUSH-BUTTONS UNTIL THE MOTOR PERFORMS THE INDICATED MOVEMENTS
TO CONFIRM YOU HAVE ENTERED THE ADVANCED MENU
Within 1 second
PRESS TWICE THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 1
SECOND, THEN PRESS AND HOLD DOWN BOTH PUSH-BUTTONS UNTIL THE MOTOR PERFORMS 2 BRIEF MOVEMENTS
IN BOTH DIRECTIONS
PRESS THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME FOR 1 SECOND UNTIL THE MOTOR PERFORMS
1 BRIEF MOVEMENT IN BOTH DIRECTIONS TO CONFIRM THE MODIFICATION OF THE OBSTACLE DETECTION END
POINT AND THE EXIT FROM THE ADVANCED MENU
Within 1 second press and hold down
TAKE THE ROLLING SHUTTER
UP TO THE POINT WHERE
YOU WISH TO HAVE A HIGH SENSITIVITY
DETECTION END AREA
4 seconds
1 second 1 second 1 second 1 second 1 second
DETECTION END AREA
OBSTACLE DETECTION
AREA
MODIFYING THE POSITION OF OBSTACLE DETECTION END

X 3
ENGLISH
17
6.2 CHANGE OF THE TORQUE DELIVERED BY THE MOTOR IN THE LAST CENTIMETERS BEFORE THE TRAVEL STOPS
1) Press the two buttons at the same time for 4 seconds.
2) Release them for 1 second.
3) Press them at the same time for 1 second.
4) Release them for 1 second.
5) Press them at the same time for 1 second.
6) Release them for 1 second.
7) Hold both buttons pressed till one short movement is performed in both directions, confirming the advanced menu
has been entered, and the motor makes three short movements in both directions.
8) Press once the up and down buttons for 1 second at the same time and press them again at the same time till the
motor makes one short movement in both directions.
9)PresstheupanddownbuttonNtimesfor1secondsimultaneouslytoselectthewishedtorquelevel(1pressing40%
of max. delivered torque... 4 pressings 100% of delivered torque) and press the up and down buttons at the same time
till one short movement is performed in both directions.
10) If the motors makes three short movements in both directions, the correct procedure has not been performed and
you are still inside the advanced menu. Perform point 9 again.
4 seconds 1 second 1 second 1 second 1 second 1 second
Within 0.5 seconds
HOLD THE BUTTONS PRESSED TILL THE MOTOR MAKES THE INDICATED MOVEMENTS, CONFIRMING YOU
ARE IN THE ADVANCED MENU.
NUMBER OF PRESSING OF THE UP PUSH-BUTTON SET TORQUE
1UPandDOWNPUSH-BUTTONPRESSING1SECOND+UPandDOWNHELDDOWN
TILLCONFIRMATION
40% of total torque
2UPandDOWNPUSH-BUTTONPRESSINGS1SECOND+UPandDOWNHELDDOWN
TILLCONFIRMATION
60% of total torque
3UPandDOWNPUSH-BUTTONPRESSINGS1SECOND+UPandDOWNHELDDOWN
TILLCONFIRMATION
80% of total torque
(default for cassette awnings)
4UPandDOWNPUSH-BUTTONPRESSINGS1SECOND+UPandDOWNHELDDOWN
TILLCONFIRMATION
100% of total torque
(default for rolling shutters and standard or
fall-type awnings)

x 1
x N
x 1
x 1
ENGLISH
18
within 1 second press and hold pressed
PRESS ONCE THE UP AND DOWN BUTTONS AT THE SAME TIME FOR 1 SECOND, RELEASE THEM FOR 1 SECOND
AND PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES ONE SHORT MOVEMENTS IN BOTH
DIRECTIONS,
1 up+down button pressing = 40% torque selected
2 up+down button pressings = 60% torque selected
3 up+down button pressings = 80% torque selected
4 up+down button pressings = 100% torque selected
Within 1 second
PRESS THE UP AND DOWN BUTTONS n TIMES FOR 1 SECOND SIMULTANEOUSLY, TO SET THE WISHED TORQUE,
RELEASE THEM FOR 1 SECOND AND PRESS AND HOLD BOTH BUTTONS PRESSED TILL THE MOTOR MAKES ONE SHORT
MOVEMENT IN BOTH DIRECTIONS, TO CONFIRM THE PERFORMED CHANGE AND THE EXIT FROM THE MENU.
6.3 DETECTING ICE ON THE GUIDES AND FITTED BOLTS DURING THE ROLLING SHUTTER RISE
The T-MODE motor with electronic travel limit is able to detect any
bolts fitted in the rolling shutter as well as the presence of ice on the
guides during the whole travel of the rolling shutter. These events would
prevent the normal rise of the rolling shutter, thus damaging it.
When the rolling shutter is at rest, if you send a rise signal and the rolling
shutter stays at rest for 1 second due to the presence of bolts or ice on
the guides, the motor changes to stop status.

ENGLISH
19
1) Take the rolling shutter up to the point where you require a higher sensitivity during detection of bolts or ice on the
guides(Youcanalsosetthewholerollingshuttertravel)
Press both push-buttons at the same time for 4 seconds.
2) Release them for 1 second.
3) Press them at the same time for 1 second.
4) Release them for 1 second.
5) Press them at the same time for 1 second.
6) Release them for 1 second.
7) Hold down both push-buttons until a brief movement is performed in both directions to confirm you have entered
the advanced menu and the motor performs three brief movements in both directions.
8) Press 3 times the up and down push-buttons at the same time for 1 second and then press them again at the same
time until the motor performs a brief movement in both directions.
9) Press the up and down push-buttons at the same time for 1 second, press them again and hold them down until 1
brief movement is performed in both directions.
10) If the motor performs three brief movements in both directions, this means that the procedure was not performed
correctly and that you are still in the advanced menu. Repeat point 9.
6.3.1 INCREASING ICE AND FITTED BOLTS DETECTION SENSITIVITY
You can increase the detection sensitivity of fitted bolts or ice in an area between the down travel limit and a
chosen point.
In this area, if the presence of ice or bolts is detected, the motor response time is of 0.2 seconds. When the motor
detects the presence of ice or bolts, it changes to stop status and, to open the rolling shutter, you must send a down
command.
Youcanalsojoinatorquereduction(seechapter9.1)tothesensitivityincreasefunction.
6.3.1.1 SETTING THE HIGH SENSITIVITY AREA
TAKE THE ROLLING SHUTTER TO THE POINT WHERE YOU REQUIRE A HIGH SENSITIVITY.
HIGH SENSITIVITY AREA
(Power to the motor is cut after the rolling shutter has been blocked for 0.2 seconds)
Down
travel limit
Up
travel limit
STANDARD SENSITIVITY AREA
(Power to the motor is cut after the rolling shutter has been blocked for 1 second)
THE HIGH SENSITIVITY AREA IS SET STARTING FROM THE DOWN TRAVEL LIMIT UP TO THE SELECTED POINT, AS DESCRIBED IN THE
PROCEDURE BELOW

X 3
x 3
x 3
x 1
x 1
ENGLISH
20
4 seconds
1 second 1 second 1 second 1 second 1 second
PRESS 3 TIMES THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME FOR 1 SECOND AND THEN PRESS THEM
AGAIN AT THE SAME TIME UNTIL THE MOTOR PERFORMS THREE BRIEF MOVEMENTS IN BOTH DIRECTIONS.
Within 1 second press and hold down
HOLD DOWN THE PUSH-BUTTONS UNTIL THE MOTOR PERFORMS THE INDICATED MOVEMENTS
TO CONFIRM YOU HAVE ENTERED THE ADVANCED MENU
Within 1 second
PRESS TWICE THE UP AND DOWN PUSH-BUTTONS AT THE SAME TIME FOR 1 SECOND AND THEN PRESS THEM AGAIN
AT THE SAME TIME UNTIL THE MOTOR PERFORMS A BRIEF MOVEMENT IN BOTH DIRECTIONS.
Within 1 second press and hold down
