FabiaTech Fanless Series User manual

FabiaTech Corporation
IPC Solution
Website: http://www.FabiaTech.com
Email: [e-mail]
Small Cube System
Fanless Series
FX5404 User’s Manual
APR 2008
Version: 1.1
Part Number: FX5404

Copyright
Copyright © 2008 FabiaTech Corporation, The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, and magnetic… or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system or setting up the relevant
devices, and software that are not explained in this manual, please contact our
service engineer for service, or send email to sup[email protected].
Returning Your Board For Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
Description of you peripheral attachments
Description of your software (operating system, version, application
software, etc.) and BIOS configuration
Description of the symptoms (Extract wording any message)
For updated BIOS, drivers, manuals, or product information, please visit us at
www.FabiaTech.com
ii

Table of Contents
Small Cube System..................................................................................................................i
Fanless Series...........................................................................................................................i
FX5404 User’s Manual ...........................................................................................................i
Chapter 1 Introducing the FX5404 System ............................................................................... 1
Overview..................................................................................................................................1
Series Comparison Table.......................................................................................................2
Layout.......................................................................................................................................3
Specifications..........................................................................................................................4
Packing List..............................................................................................................................5
Chapter 2 Hardware Installation ............................................................................................... 7
Before Installation...................................................................................................................7
Removing Covers –Installing Hardware...........................................................8
LED Indicators (On the Front Panel)...............................................................12
Connecting the Monitor, Keyboard and Mouse.........................................12
Connecting the COM ports............................................................................13
Connecting the L1/L2 LAN ports and USB Ports ...........................................13
Connecting the Audio Microphone In/ Speak Out ....................................14
Connecting the DC Power and Power Button ............................................14
Jumper Setting ..................................................................................................16
Chapter 3 BIOS Setup............................................................................................................... 17
Overview................................................................................................................................17
BIOS Functions...................................................................................................18
Keyboard Convention ..............................................................................................19
Main Setup ............................................................................................................................20
Advanced Setup..................................................................................................................21
CPU Configuration............................................................................................21
IDE Configuration..............................................................................................21
SuperIO Chipset - Configuration WIN627 Super IO Chipset.......................24
Hardware Health Configuration.....................................................................25
Advanced ACPI Settings.................................................................................26
USB Configuration.............................................................................................27
iii

PCIPnP Setup.........................................................................................................................29
Boot Setup.............................................................................................................................32
Boot Setting Configuration..............................................................................33
Boot Device.......................................................................................................35
Hard Disk Drives.................................................................................................36
Security setup........................................................................................................................37
Chipset Setup........................................................................................................................39
Northbridge Configuration..............................................................................39
Southbridge Configuration..............................................................................40
POWER MANAGEMENT........................................................................................................42
Power Management/APM..............................................................................42
Chapter 4 Software Installation ............................................................................................... 45
System Driver.........................................................................................................................45
WIN 98/2000/XP Driver...............................................................................................45
VGA Driver for WIN98SE/ME/2000/XP/NT4.0.....................................................................46
Audio Drivers .........................................................................................................................46
WIN 98/2000/XP Driver...............................................................................................46
USB 2.0 Driver.........................................................................................................................47
WIN 98 Driver...............................................................................................................47
LAN Utility & Driver (82562ET & RTL8110SX)........................................................................47
BIOS Flash Utility.....................................................................................................................47
Watchdog Timer...................................................................................................................48
Watchdog Timer Setting...........................................................................................49
Watchdog Timer Enabled ........................................................................................50
Watchdog Timer Trigger ...........................................................................................50
Watchdog Timer Disabled........................................................................................51
Programming RS-485............................................................................................................52
Initialize COM port .....................................................................................................52
Send out one character (Transmit).........................................................................53
Send out one block data (Transmit – the data more than two characters)...53
Receive data..............................................................................................................53
Basic Language Example.........................................................................................53
Chapter 5 Technical Reference .............................................................................................. 55
Trouble Shooting for Post Beep and Error Messages.......................................................55
iv

Technical Reference............................................................................................................58
Physical and Environmental.....................................................................................58
Real-Time Clock and Non-Volatile RAM ................................................................58
CMOS RAM Map........................................................................................................60
I/O Port Address Map................................................................................................61
Interrupt Request Lines (IRQ)....................................................................................62
DMA Channel Map ...................................................................................................63
DMA Controller 2........................................................................................................63
Serial Ports ...................................................................................................................64
Appendix................................................................................................................................... 68
Dimension..............................................................................................................................68
v

vi

FabiaTech Corporation
Chapter1IntroducingtheFX5404System
Overview
The FX5404 is an embedded system with low-power CPU module inside. This user’s
manual provides information on the physical features, installation, and BIOS setup
of the FX5404.
Built to unleash the total potential of the Celeron-M Processor, Able to support
600MHz CPU, this system supports one 10/100/1000M Base –TX and one 10/100
Base –T LAN ports, 512MB DDR-RAM on board, mini PCI socket for wireless LAN, Four
USB2.0 ports, and a VGA controller.
Each FX5404 has two ports for I/O communications. Two RS-232C ports are
available.
The FX5404 is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,
gaming and infotainment, measurement technology, lotteries, and banking and
small Embedded Control. The unit is only 120.0mm (D) X165.0mm (W) X65mm (H).
1

FabiaTech Corporation
SeriesComparisonTable
Model FX5404
Processor Intel Celeron-M
600MHz
Chipset 852GME+ICH4
1 200 Pin-DIMM (Max.) 512MB/1GB
VGA Yes
Watchdog Timer Yes
Multi I/O Two Serial
Enhanced IDE One
CF (Compact Flash Socket) One
USB 2.0 Four
Audio Line -Out And MIC-In
RJ45 WAN port
(10/100/1000Mbps) One Giga LAN+ One 10/100Base -T
Mini-PCI Socket One
Dimensions (Unit: mm) 120(D) x165(W) X 65(H)
2

FabiaTech Corporation
3
Layout
2
1
2
DC 12 ~ 24V 1
1 2
Upper Side
Compact Flash

FabiaTech Corporation
Specifications
Processor Board –
Intel Low Power Celeron-M 600MHz CPU with 512MB DDR-RAM.
I/O Outlets –
One 10/100 and One 10/100/1000 base-TX Ethernet LAN ports.
Four USB ports (2.0) and two RS-232 serial ports.
One CRT and one PS/2 compatible keyboard and mouse interfaces.
One Audio Line-Out and Microphone-Input
One Mini PCI Socket for Wireless LAN module.
One DC-In plug connector and one terminal block with power switch.
One push button reset switch.
One power LED, One HDD/CF access LED, and two LAN LED’s.
Storage Bay-
Compact Flash socket for Compact Flash modules or MicroDrives.
One 2.5" hard disk space
Power requirement –
FX5404:+12~+24V DC with 15% tolerance, 25VA maximum with 2.5” HDD
and 19V input voltage.
Dimensions -
120.0mm(D) x 165.0mm(W) x 65.0mm(H)
4

FabiaTech Corporation
PackingList
Upon receiving the package, verify the following things. Should any of the
mentioned happens, contact us for immediate service.
•Unpack and inspect the FX5404 package for possible damage that may
occur during the delivery process.
•Verify the accessories in the package according to the packing list and see
if there is anything missing or incorrect package is included.
•If the cable(s) you use to install the FX5404 is not supplied from us, please
make sure the specification of the cable(s) is compatible with the FX5404
system.
Note: after you install the FX5404, it is recommended that you keep the diskette or
CD that contains drivers and document files, and keep the document
copies, or unused cables in the carton for future use.
The following lists the accessories that may be included in your FX5404 package.
Some accessories are optional items that are only shipped upon order.
•One FX5404 embedded system.
•One AC to DC power adapter and 1 AC power code.
•One Y cable (3-end) PS2 Keyboard plus mouse port adapter Cable.
•One 44-pin flat cable and 4 screws for fixing and connecting 2.5” hard disk
drive.
•One 2-pin apartable terminal block.
•One FX5504k1 or one FX5404K1 universal fixers and 6 screws.(Optional)
•One compact disc includes software utility and manual.
5

FabiaTech Corporation
6

FabiaTech Corporation
Chapter2HardwareInstallation
This chapter introduces the system connectors & jumper settings, and guides you to
apply them for field application.
BeforeInstallation
Before you install the system, make sure you follow the following descriptions.
1. Before removing the cover, shut down the operation System and disconnect
power switch to off and unplug AC-to DC Adapter cable.
2. Install any connector, Compact Flash, and hard disk be sure that the power is
disconnected or power switch to off from the system. If not, this may damage
the system.
3. The ESD (Electricity Static Discharge) may be created from human body that
touches the board. It may do damage to the board circuit.
7

FabiaTech Corporation
Removing Covers –Installing Hardware
If you are installing hardware option, you can remove the back cover.The
following figure will guide you how to install 2.5" HDD inside, Compact Flash
modules, mini PCI WLAN module and DDR-RAM module the FX5404 and how to
install the FX5404 fixers. (Please see the spots circled.)
¾a. Installing Compact Flash
¾b. Unscrew back cover and Installing Hard Disk
Note: The Compact Flash socket supports Compact Flash Modules and Micro Drives.
8

FabiaTech Corporation
b1. Installing Hard Disk
Note: Use caution when handling the hard disk to prevent damage to IDE
connector as you inserted hard disk. Be careful withthe pin orientation when
installing connectors. A wrong connection can easily destroy your hard disk.
¾c. Installing Mini PCI Card: Mini PCI Socket for WLAN Modules
You may extend additional mini PCI WLAN module to FX5404 by removing the
back cover and draw-out CPU modules. Connect the antenna cable from
backside antenna hole to Mini PCI WLAN (the auxiliary board). Release the
screws on the back of the unit. (Please see the spots circled.)
c1. Unscrew back covers and draw-out CPU modules
9

FabiaTech Corporation
c2. Unscrew transfer board and add Mini-PCI module
¾d. Installing Memory: DIMM Socket For DDR Modules
You may extend additional memory to FX5404, See as following figure and rear
pictures. The DIMM socket supports 128MB to 1GB of DDR RAM modules.
10

FabiaTech Corporation
¾e. Installing the universal fixers on FX5404
Please refer to the down side figure for installing the FX5404 with universal fixers.
e1. FX5404K1 universal fixers.
e2. FX5504K1 universal fixers.
11

FabiaTech Corporation
12
LED Indicators (On the Front Panel)
The Power and HDD LED’s has two distinctive statuses: Off for inactive operation
and blinking light for activity. And the 2 LED’s for LAN ports. The LAN1 and LAN2
LED’s (Green) indicate on-line/access status of LAN1 and LAN2 respectively.
2
1
Connecting the Monitor, Keyboard and Mouse
If you are connecting the monitor, keyboard, mouse to the FX5404 using the
connections provided on the side of the chassis. See following figure and a side
pictures.
2
DC 12 ~ 24V 1
1 2
Upper Side
Compact Flash
1. A CRT connector is provided for CRT signals
DB15 Signal
1 Red
2 Green
3 Blue
13 Hsync
14 Vsync
12 DDC Data
15 DDC Clock
5 & 10 Digital Ground
6,7,8 Analog Ground
Others Not Used

FabiaTech Corporation
2. The connectors use the included adapter cable you can attach standard PS/2
type keyboard and mouse. Standard PS/2 keyboard can be plugged into this
connector without any adapter cable. If PS/2 keyboard and mouse will be used
simultaneously, a Y-type (3-terminal) adapter cable is needed.
Connecting the COM ports
The DB9 (COM1/2) is standard serials port connector. The following tables show
the signal connections of these connectors.
DB-9 RS-232 Signal
1 -DCD
6 -DSR
2 RXD
7 -RTS
3 -TXD
8 -CTS
4 -DTR
9 -RI
5 Ground
Case Case Ground
Connecting the L1/L2 LAN ports and USB Ports
The RJ45 connector with 2 LED’s for WAN/LAN. The right side LED (orange) indicates
data is being accessed and the right side LED (green) indicates on-line status. (On
indicates on-line and off indicates off-line)
KB /Mouse Description
1 Keyboard Data
2 Mouse Data
3 Ground
4 VCC
5 Keyboard Clock
6 Mouse Clock
RJ45 connector
1
8
The following lists the pin assignment of RJ45.
RJ45 LAN1 LAN2 RJ45 LAN1 LAN2
1 TPTX+ TPTX+ 5 FBG1 TPTX1-
2 TPTX - TPTX - 6 TPRX - TPRX -
3 TPRX+ TPRX+ 7 FBG2 TPRX1+
4 FBG1 TPTX1+ 8 FBG2 TPRX1-
(Front View)
13

FabiaTech Corporation
The FX5404 supports a four port USB connector. Any USB device can be attached to
USB ports with plug-and-play supported. The left side port is USB # 1/2 and the right side
port is USB # 3/4
4 1
USB#1~4 Signal
Pin 1 USBV
Pin 2 USBD-
Pin 3 USBD+
Pin 4 USBG
(Front View)
Connecting the Audio Microphone In/ Speak Out
Connecting the DC Power and Power Button
Power is supplied through an external AC/DC power adapter or power DC In.
Check the technical specification section for information about AC/DC power
input voltage. See following figure and a side pictures.
1. DC-Power Jack: Use External AC/DC power adapter
Line-Out
Mic-In
DC +12~+24V, 15% tolerance
FX5404: 45VA minimum
14
