Fagor Platino Plus User manual

PLATINO PLUS
SLOW JUICER/SORBET MAKER
EXTRACTOR LENTO DE JUGO/SORBETERA
PRESSE-FRUITS LENT/SORBETIÈRE
User’s Manual
Manual de Instrucciones
Manuel D’utilisation

1
ENGLISH
Contents
The Platino Plus Difference..................................................................2
General Safety Regulations..................................................................3
Technical Data .......................................................................................4
Platino Plus Components.....................................................................5
Operation ...............................................................................................6
Assembly when Slow Juicing ...........................................................6
Slow Juicing with the Platino Plus ...................................................8
Slow Juicing Tips..............................................................................9
Assembly when Making Sorbet......................................................10
Making Sorbet with the Platino Plus ..............................................11
Sorbet Making Tips ........................................................................12
Cleaning ...............................................................................................13
For Tough Stains.............................................................................14
Other Cleaning Tips........................................................................14
Troubleshooting...................................................................................15
Limited Warranty .................................................................................17
Español ................................................................................................19
François ...............................................................................................37

2
ENGLISH
The Platino Plus Difference
The Platino Plus upgrade has given this unit the capability of being a slow juicer
and sorbet maker all-in-one! The versatility and ease of use makes this unit
suitable for any kitchen novice and will have you creating delicious juice, sorbet,
pureés and other creations in no time.
Slow Juicing in the Platino Plus allows you to consume more fruits and vegetables
in one glass than you could eat in one sitting. There is no oxidation or separation
in slow juicing, so it preserves more of the organic nutrients from the food and
keeps it closer to its natural state. Fresh juice from a slow juicer is absorbed
directly into the body, allowing the intake of important vitamins and nutrients from
your food. In addition, you can create a wide variety of juice recipes from fruits
and vegetables you may not normally enjoy eating whole.
The Platino Plus uses a 2-step process in which the juice is extracted from the fruit
or vegetable twice before it enters your glass. The Auger, the main component of
the unit, precisely squeezes the food without shredding or chopping it, helping
you to get more juice in your glass.
Creating freshly made sorbet with the Platino Plus gives you an all-natural dessert
that you can create right at home. Sorbet made in the Platino Plus has no added
sugars or artificial sweeteners, simply use fruit that has been frozen to make a
quick and delicious treat the entire family can enjoy.
The Platino Plus helps in creating a healthier lifestyle by using all-natural fruits
and vegetables to develop an array of delicious creations. This unit also helps
you become environmentally conscience by using less energy, in turn saving
you money and helping to lower your carbon footprint. We hope you enjoy your
Platino Plus experience and thank you for choosing Fagor.

3
ENGLISH
General Safety Regulations
When using the Platino Plus, basic safety precautions should always be
implemented, including the following:
• Please carefully read the INSTRUCTIONS and COMPONENTS before
operating.
• Make sure the voltage mark (110-120V) on the appliance corresponds to the
voltage in your home before plugging in the power cord in order to avoid
damage to the appliance.
• To protect against electrical shock, do not place cord, plug, or base of the unit
in water or other liquids. Do not let the cord hang over the edge of the table or
counter, or touch hot surfaces.
• This appliance is intended for household use only.
• Always check all removable parts before operating the appliance. If you detect
any cracks or damage, do not use the appliance and contact Fagor Customer
Service: 1-800-207-0806.
• Unplug from outlet when not in use.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.
• Always securely fasten all parts in place before the motor is turned on. Do not
unfasten any parts while appliance is in operation.
• Avoid contacting moving parts. Make sure the motor stops completely before
disassembling.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• To disconnect, remove plug from the electric outlet. Do not use the appliance
for use other than intended or specified purposes.
• Do not walk away from the appliance when it is in operation.
• Do not disassemble the Base.
• Do not put any foreign materials into the machine.
• Please do not use for more than 20 minutes at a time; allow motor to cool.
SAVE THESE INSTRUCTIONS

4
ENGLISH
Technical Data
Rated Voltage 110V-120V
Rated Power 150W
Rated Frequency 60Hz
Speed 90RPM

5
ENGLISH
Platino Plus Components
PUSHER
FOOD CHUTE BASE
DRIP
STOPPER
CLEANING
BRUSH SORBET/PULP COLLECTOR
Make sure all parts are securely in
place before operation. Do not
operate without food.
NOTE: All parts in contact with food are BPA Free.
AUGER
STRAINER
ROTATING
BASKET
DESSERT
DRUM
BOWL
JUICE EJECTORSORBET/PULP EJECTOR
JUICE
COLLECTOR
WARNING
Be sure when attaching the Food Chute that
the arrow on the Food Chute is aligned with
the arrow on the Base. The unit will not
operate if the arrows are not aligned properly.

6
ENGLISH
Operation
The Platino Plus is virtually assembled straight out of the box. We suggest taking
it apart and washing the removable parts in warm water with non-abrasive liquid
detergent before the first use. Rinse thoroughly with warm water and allow to
air dry. This will eliminate any traces of dust or residue from manufacturing or
shipping. Never submerge the Platino Plus Base in water or any other liquid.
Assembly when Slow Juicing
1. Assemble the Bowl to the Base. (Figure 1)
a. Make sure the Bowl fits all the way into the shell of the Base.
b. Align the arrow on the Bowl with the arrow on the Base. (Note: If the Bowl
is not completely lowered onto the Base, the machine will not start.)
1
c. Under the Bowl there is a silicone pad (Figure 2) that prevents juice from
exiting through the Sorbet/Pulp Ejector. When juicing, make sure the
silicone pad is firmly in place. When cleaning the Bowl, make sure to slide
the pad out and run water through the Sorbet/Pulp Ejector to remove
excess food debris.
2

7
ENGLISH
2. Assemble the Strainer and Rotating Basket to the Bowl. (Figure 3)
a. Make sure the red dot on the Strainer lines up with the red dot on the
Bowl.
3
3. Place the Auger in the center of the Bowl. (Figure 4)
a. Twist the Auger clockwise until it drops into place.
4
4. Place the Food Chute onto the Bowl.
a. Make sure the white dot on the top of the Food Chute is aligned with the
red dot on the Bowl. (Figure 5)
5
b. Turn the Food Chute clockwise until the lid clicks into the locked position.
The arrow on the Food Chute will line up with the arrow on the Base.
(Figure 6)
6

8
ENGLISH
Slow Juicing with the Platino Plus
1. Once all parts are securely in place, connect the power cord to an approved power
source.
2. Place a collector under the Sorbet/Pulp Ejector, and either a glass or the additional
collector under the Juice Ejector.
3. The Platino Plus has 3 settings (Figure 7)
a. ON- this starts the motor.
b. OFF- this stops operation.
c. REV- this moves the Auger in the opposite direction.
7
4. Before placing food in the Platino Plus, make sure all foods have been thoroughly washed;
if food has to be peeled, there is no need to wash. Also make sure to cut all foods to an
appropriate size, so it easily fits into the Food Chute. We recommend cutting food into
slim, 3-inch pieces. Please make sure to remove any hard seeds or pits, such as cherry or
plum pits, as they will not process in the Platino Plus and can damage the Auger.
5. Make sure the unit has been switched to ON before placing any food into the Platino
Plus. Once the food has been dropped into the Food Chute, the Auger will begin
squeezing the food to form the juice. DO NOT push, force, or overstuff the unit. The
Pusher provided with the Platino Plus is only to use when food obstructs the inside of
the Food Chute. Do not insert any other utensil into the unit other than the Pusher when
operating this unit.
6. It is best to insert all food at a slow pace, allowing all pulp to be extracted from the fruit
or vegetable completely.
7. Turn the Platino Plus off when juicing is complete. Do not run the Platino Plus without
any food inside the unit as this could overheat the motor.
8. Remember to close the drip stopper on the Juice Ejector when you have finished juicing
to avoid dripping or spilling juice onto your counter.
9. The Platino Plus has a unique cleaning process when switching between different types
of juices. To clean, simply place one of the collectors under the Juice Ejector, make sure
the drip stopper is open and pour water though the Food Chute with the unit running.
This will rinse out most of the remaining residue from your last juice. When the water
begins to run clear, that is an indication the unit is clean and ready to make a new juice
recipe. When you have finished rinsing, close the drip stopper on the Juice Ejector to
prevent dripping.
NOTE: This process is not an alternative to a complete cleaning of each
disassembled part.
a
b
c

9
ENGLISH
Slow Juicing Tips
Please read the instruction manual carefully and follow the below juicing
suggestion for best results, as a slow juicer has different operating instructions
than that of a traditional juicer.
• Carefully drop food into the Food Chute. The Pusher provided is only for use if
any food obstructs the inside of the Food Chute. Do not overstuff, shove or
force the food down.
• For best results when juicing, cut food into slim, 3-inch pieces and insert foods
slowly to allow pulp to be extracted.
• Do not put any frozen fruits, vegetables or ice into the unit as this will damage
the Strainer.
• Combine leafy greens with a variety of fruit for the best results.
• When juicing foods like carrots or beets, it will be necessary to combine them
with other fruits and vegetables with a higher water content to increase the
amount of juice yielded.
• When juicing foods with a lot of seeds like tomatoes and cucumbers, the
Strainer might clog. Remove your glass or collector from beneath the Juice
Ejector and place an empty glass or collector in its place. Pour water through
the Food Chute to unclog it before continuing to juice.
• Please read the enclosed recipes included with the Platino Plus for other
creative ideas.
• For a more detailed fruits and vegetables slicing chart, visit our website at
www.fagoramerica.com.
NOTE: If the Platino Plus jams/clogs or stops operating, turn it off, and switch
to reverse (REV) for 3-5 seconds. Switch back to ON to continue juicing. Repeat
this process if necessary. While operating in reverse, the Food Chute may come
loose; this is perfectly normal.

10
ENGLISH
Assembly when Making Sorbet
1. When assembling the Platino Plus to make sorbet, repeat step 1 in the
“Assembly when Slow Juicing” section (page 6).
2. Assemble the Dessert Drum to the Bowl. (Figure 1)
a. Make sure the red dot on the Dessert Drum lines up with the red dot on
the Bowl.
1
3. Place the Auger in the center of the Dessert Drum. (Figure 2)
a. Twist the Auger clockwise until it drops into place.
2
4. Place the Food Chute onto the Bowl.
a. Make sure the white dot on the top of the Food Chute is aligned with the
red dot on the Bowl. (Figure 3)
3
b. Turn the Food Chute clockwise until the lid clicks into the locked position.
The arrow on the Food Chute will line up with the arrow on the Base.
(Figure 4)
4

11
ENGLISH
Making Sorbet with the Platino Plus
1. Once all parts are securely in place, connect the power cord to an approved
power source.
2. Place either a cup or a collector under the Sorbet/Pulp Ejector and close the
drip stopper on the Juice Ejector.
3. The Platino Plus has 3 settings (Figure 5)
a. ON- this starts the motor for sorbet making.
b. OFF- this stops operation.
c. REV- this moves the Auger in the opposite direction.
5
4. Before placing frozen fruits in the Platino Plus, make sure you thaw for at least
8 minutes or as needed. Make sure to remove all pits/seeds, cores, peels/
skins from the fruit and any other remnants you do not want in your sorbet
before freezing. Be sure to then cut the fruit into slim, 3-inch pieces and then
freeze.
5. Make sure the unit has been switched to ON before placing any food in the
Platino Plus, the Auger will automatically pull in the food and begin making
sorbet. DO NOT push, force, or over-stuff the unit. The Pusher provided
with the Platino Plus is the only utensil that should be used when food gets
caught inside the Food Chute.
6. It is best to insert all food at a slow pace.
7. Turn the Platino Plus off when you finish making sorbet. Do not run the Platino
Plus without any food inside the unit as this could overheat the motor.
8. To clean the Platino Plus after making sorbet, please disassemble removable
parts and wash thoroughly with warm water and soap. Do NOT submerge the
base containing the motor into water, as this will damage the unit. If the base
is dirty, simply wipe the base down with a damp cloth.
a
b
c

12
ENGLISH
Sorbet Making Tips
Please read the instruction manual carefully and follow the below sorbet making
suggestions for best results.
• Before freezing fruits, please be sure to remove all fruit peels/skins, cores,
seeds/pits and any other remnants that you do not want in your sorbet. Be
sure to cut the fruits into slim, 3-inch pieces before freezing.
• Carefully drop food into the Food Chute. The Pusher provided is only for use
if any food obstructs the inside of the Food Chute. Do not over-stuff, shove
or force the food down into the Food Chute.
• Insert foods slowly, do not over stuff or rush the sorbet making process.
• Do not put nuts, fruit with pits or ice into the unit.
• To prevent the fruit from spoiling or getting freezer burn, please place freshly
cut fruit in well sealed freezer bags or tempered containers before placing
fruits in the freezer.
• Please read the enclosed recipes included with the Platino Plus for other
creative ideas.
• For a more detailed fruit thawing chart, visit our website at
www.fagoramerica.com.
NOTE: If the Platino Plus jams/clogs or stops operating, turn it off, and switch to
reverse (REV) for 3-5 seconds. Switch to ON to continue making sorbet. Repeat
this process if necessary. While operating in reverse, the Food Chute may come
loose; this is perfectly normal.

13
ENGLISH
Cleaning
1. Switch the Platino Plus off, and disconnect from power source.
2. Turn the Food Chute counterclockwise to unlock. (Figure 8)
8
3. Firmly grasp the Bowl and lift to dislodge the entire upper unit.
4. Disassemble the upper unit in the following order:
a. Food Chute
b. Auger
c. Strainer/Dessert Drum
d. Rotating Basket (skip this step if you have been making sorbet)
e. Bowl
5. Using the included Platino Plus Cleaning Brush, thoroughly clean each of the
disassembled parts using warm soapy water. Remember to open the silicone
pad under the Bowl to clean the remaining debris in the Sorbet/Pulp Ejector.
Please Note:
a. Do not use any abrasive cloths or liquids.
b. Do not rinse the Platino Plus Base or submerge it in water.
c. Dry all Platino Plus attachments before reusing.
6. Hand washing is recommended for all components of the Platino Plus. Please
do not place any of the parts in the dishwasher.
7. Remember to thoroughly clean the small fins on the Rotating Basket as small
food particles might get stuck on them.
8. Remember to place the silicone pad back into position once you have finished
washing the Bowl.

14
ENGLISH
For Tough Stains
Because there are many powerful staining properties of the carotenoids that
are found in many vegetables, especially carrots, we suggest using ONE of the
following cleaning procedures:
1. Soak in mild soapy water.
2. Equal parts warm water to cider vinegar.
Other Cleaning Tips
• Never use strong/abrasive household cleaners or ammonia while cleaning the
Platino Plus.
• Cleaning the Platino Plus immediately after each use will also help to reduce
stains on the Bowl and upper parts.

15
ENGLISH
Troubleshooting
PROBLEM SOLUTION
Unit is not operating. • Check power cord and power source.
• Check that all parts have been assembled
correctly.
Unit jams/clogs or stops
operating. • Ensure Food Chute is clear and not blocked.
• Check if hard seeds have been removed before
juicing/making sorbet and are not stuck in the
unit.
• When making sorbet, thaw fruits prior to feeding
the machine. Do NOT use ice.
• Turn the unit off, and switch to reverse for 3
seconds. Switch back on to continue juicing/
making sorbet. Repeat this process if necessary.
• Disassemble upper section and clear remaining
pulp and/or food debris.
Squeaking noise when
running unit. • A slight squeaking sound is perfectly normal. Please remember not to run the Platino Plus
without any food.
Leaking from underneath the
Bowl. • Be sure the silicone pad on the underside of the Bowl is tightly in place after cleaning.
Strainer/Dessert Drum
damage. • Refer to operation instruction for proper usage and tips. Remember not to over stuff food or
force food in the Platino Plus.
Too much pulp coming out. • Cut food into smaller pieces, especially fibrous
foods, to avoid fibers scrapping around the
Auger. Insert food at a slower pace and allow all
pulp to eject from the unit before adding more.
Bowl is stuck and will not
detach from the Base. • This is commonly caused by excess food in the Bowl. Switch to reverse for 3-5 seconds. Repeat
process 2-3 times. Then, pull the Bowl upward.
Food Chute/Lid is stuck. • Switch to reverse for 3-5 seconds. Repeat
process 2-3 times. You then press down on the
Food Chute while turning counterclockwise.
The Bowl shakes. • It’s normal for the Bowl to shake when juicing or
operating the Platino Plus in reverse.
The Food Chute, Bowl,
Strainer/Dessert Drum,
Rotating Basket and silicone
parts get stained.
• Vegetables such as kale, collards, carrots
and spinach contain beta carotene, which is
responsible for the discoloration.
• Clean all parts of the upper unit immediately after
use.

16
ENGLISH
PROBLEM SOLUTION
There is no juice pouring out
of the Bowl. • Open the drip stopper.
My sorbet is very soupy/
gooey. • You have thawed your food for too long. Place your food back in your freezer until frozen, and
then thaw for less time.
My sorbet is very
crystalized and icy. • You have not thawed your food for long enough. Let your foods thaw for a few
additional minutes.
The components won’t
detach after making sorbet. • Run the Platino Plus in reverse for 3-5 seconds to dislodge any jams. Attempt to disassemble
or repeat as needed.
My frozen food is not being
processed by the auger. • Your food is not sufficiently thawed. Detach the Food Chute and remove any unprocessed
foods from the bowl.
The Auger, Strainer/Dessert
Drum, Rotating Basket
and Bowl are jammed after
using the Platino Plus.
• Put the food chute back onto the unit, hit
reverse (Rev) for 3 to 5 seconds. This process
should dislodge all components. Repeat as
needed.

17
ENGLISH
Limited Warranty
This manufacturer’s product warranty extends to the original consumer purchaser
of the product. Neither the retailer nor any other company involved in the sale or
promotion of this product is a co-warrantor of this manufacturer warranty.
WARRANTY DURATION: All materials and workmanship are warranted to the
original consumer purchaser for a period of FIVE (5) year warranty from the
original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials
or workmanship. This warranty is voided if the product has been damaged by
accident, in shipment, unreasonable use, misuse, neglect, improper service,
commercial use, repairs by unauthorized personnel or other causes not arising
out of defects in materials or workmanship. This warranty is effective only if the
product is purchased and operated in the USA and Canada and does not extend
to any units which have been used in violation of written instructions furnished
by manufacturer or to units which have been altered or modified or to damage
to products or parts thereof which have had the serial number removed, altered,
defaced or rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or
implied and no representative or person is authorized to assume for manufacturer
any other liability in connection with the sale of our products. There shall be no
claims for defects or failure under any theory of tort, contractor commercial law
including, but not limited to, negligence, gross negligence, strict liability, breach
of warranty and breach of contract.
WARRANTY PERFORMANCE: During the above five-year warranty period, a
product with a defect will be either repaired or replaced with a reconditioned
comparable model (at manufacturer’s option). The repaired or replacement
product will be in warranty for the balance of the five years warranty period
and an additional one-month period. No charge will be made for such repair or
replacement.
SERVICE AND REPAIR: If service is required for an appliance, you should first
call toll free 1-800-207-0806 between the hours of 8:30 am and 5:00 pm Eastern
Standard Time and ask for CUSTOMER SERVICE. Please refer to the Platino Plus
Slow Juicer/Sorbet Maker Item #670041910 when you call.
NOTE: Manufacturer cannot assume responsibility for loss or damage during
incoming shipment. For your protection, carefully package the product for
shipment, and insure it with the carrier. Be sure to enclose the following items
with your appliance: your full name, return address and daytime phone number;
a note describing the problem you experienced; a copy of your sales receipt or
other proof of purchase to determine warranty status. C.O.D. shipments cannot
be accepted.
