Fagor SLOW JUICER User manual

SLOW JUICER
EXTRACTOR LENTO DE JUGO
PRESSE-FRUITS LENT
User’s Manual
Manual de Instrucciones • Manuel D’utilisation
Slow Juicer Manual-FINAL.indd 1Slow Juicer Manual-FINAL.indd 1 3/29/12 9:17 PM3/29/12 9:17 PM

Slow Juicer Manual-FINAL.indd 2Slow Juicer Manual-FINAL.indd 2 3/29/12 9:17 PM3/29/12 9:17 PM

1
ENGLISH
Contents
The Slow Juicing Difference ................................................................2
General Safety Regulations..................................................................3
Technical Data .......................................................................................4
Slow Juicer Components .....................................................................5
Operation ...............................................................................................6
Assembly ..........................................................................................6
Using the Slow Juicer...........................................................................8
Slow Juicing Tips ..................................................................................9
Cleaning ...............................................................................................10
For Tough Stains.............................................................................11
Other Cleaning Tips........................................................................11
Trouble Shooting .................................................................................12
Limited Warranty .................................................................................13
Español ................................................................................................15
François ...............................................................................................29
Slow Juicer Manual-FINAL.indd Sec2:1Slow Juicer Manual-FINAL.indd Sec2:1 3/29/12 9:17 PM3/29/12 9:17 PM

2
ENGLISH
The Slow Juicing Difference
Slow Juicing allows you to consume more fruits and vegetables in one glass than
you could eat at one time. There is no oxidation or separation in slow juicing, so
it preserves more of the organic nutrients from the food and keeps it closer to its
natural state. Fresh juice from a slow juicer is absorbed directly into the body,
allowing the intake of important vitamins and nutrients from your food - your
body receives everything it needs for optimum health. In addition, you can create
a wide variety of juice recipes to enjoy from fruits and vegetables you may not
normally enjoy eating whole.
The Fagor Slow Juicer uses a 2-step process in which the juice is extracted
from the fruit or vegetable twice before it enters your glass. The auger, the main
component of the unit, precisely squeezes the food without shredding or grinding
it, helping you to get more juice in your glass.
The Fagor Slow Juicer produces fresh and healthy juice that’s packed with more
vitamins and nutrients needed for everyday living. In addition, the Fagor Slow
Juicer uses less energy, saving you money and helping to lower your carbon
footprint. One glass and you’ll experience first-hand the difference between
store-bought juice and fresh, healthy goodness.
Slow Juicer Manual-FINAL.indd Sec2:2Slow Juicer Manual-FINAL.indd Sec2:2 3/29/12 9:17 PM3/29/12 9:17 PM

3
ENGLISH
General Safety Regulations
When using the electrical appliance, basic safety precautions should always be
followed, including the following:
• Please carefully read the INSTRUCTIONS and COMPONENTS before
operating.
• Make sure the voltage mark (110-120V) on the appliance corresponds to the
voltage in your home before plugging in the power cord in order to avoid
damage to the appliance.
• To protect against electrical shock, do not place cord, plug, or base unit in
water or other liquids. Do not let the cord hang over the edge of the table or
counter, or touch hot surfaces.
• This appliance is intended for household use only.
• Check the strainer every time you want to use the appliance. If you detect any
cracks or damage, do not use the appliance and contact the Fagor Customer
Service: 1-800-207-0806.
• Unplug from outlet when not in use.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• Always securely clamp in place all parts before the motor is turned on. Do not
unfasten while appliance is in operation.
• Avoid contacting moving parts. Make sure the motor stops completely before
disassembling.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• To disconnect, remove plug from the electric outlet. Do not use the appliance
outlet. Do not use the appliance for use other than intended or specified
purposes.
• Do not walk away from the appliance when it is in operation.
• Do not disassemble the base.
• Do not put any foreign materials into the machine.
• Please do not use for more than 20 minutes at a time, allow motor to cool.
SAVE THESE INSTRUCTIONS
Slow Juicer Manual-FINAL.indd Sec2:3Slow Juicer Manual-FINAL.indd Sec2:3 3/29/12 9:17 PM3/29/12 9:17 PM

4
ENGLISH
Technical Data
Rated Voltage 110V-120V
Rated Power 150W
Rated Frequency 60Hz
Speed 80RPM
Slow Juicer Manual-FINAL.indd Sec2:4Slow Juicer Manual-FINAL.indd Sec2:4 3/29/12 9:17 PM3/29/12 9:17 PM

5
ENGLISH
Slow Juicer Components
WARNING
PUSHER
FOOD CHUTE BASE
CLEANING
BRUSH PULP COLLECTOR
As shown below, the Food Chute edge must
point to “close” sign on the base in order
for the machine to operate.
Make sure all parts are securely
in place before operation.
Do not operate without food.
AUGER
TOP SET
STRAINER
ROTATING
BASKET
BOWL
JUICE EJECTOR
PULP EJECTOR
JUICE
COLLECTOR
Slow Juicer Manual-FINAL.indd Sec2:5Slow Juicer Manual-FINAL.indd Sec2:5 3/29/12 9:17 PM3/29/12 9:17 PM

6
ENGLISH
Operation
The Slow Juicer is virtually assembled straight out of the box. We suggest taking
it apart and washing the removable parts in warm water with non-abrasive liquid
detergent before the first use. Rinse thoroughly with warm water and allow to
air dry. This will eliminate any traces of dust or residue from manufacturing or
shipping. Never submerge the Slow Juicer motor base in water or any other
liquid.
Assembly
1. Assemble the bowl to the base. (Figure 1)
a. Make sure the bowl fits all the way into the shell of the base.
b. Align the arrow on the bowl with the arrow on the base, twist clockwise
slightly to lock. (Note: If the bowl is not completely locked onto the base,
the machine will not start.)
1
2. Assemble the Strainer and Rotating Basket to the bowl. (Figure 2)
a. Make sure the red dot on the strainer basket lines up with the red dot on
the bowl.
2
Slow Juicer Manual-FINAL.indd Sec2:6Slow Juicer Manual-FINAL.indd Sec2:6 3/29/12 9:17 PM3/29/12 9:17 PM

7
ENGLISH
3. Place the Auger in the center of the bowl. (Figure 3)
a. Twist the Auger clockwise until it drops into place.
3
4. Place the Food Chute onto the bowl.
a. Make sure the red dot on the top of the Food Chute is aligned with the red
dot on the bowl. (Figure 4)
4
b. Turn the Food Chute clockwise until the lid clicks into the locked position.
(The arrow on the Food Chute will line up with word CLOSED on the motor
base. (Figure 5)
5
Slow Juicer Manual-FINAL.indd Sec2:7Slow Juicer Manual-FINAL.indd Sec2:7 3/29/12 9:17 PM3/29/12 9:17 PM

8
ENGLISH
Using the Slow Juicer
1. Once all parts are securely in place, connect the power cord to an approved
power source.
2. Place one of the collectors under the pulp ejector, and either a glass or the
other collector under the juice spout.
3. The Slow Juicer has 3 settings (Figure 6)
a. ON- this starts the motor for juicing.
b. OFF- this stops operation.
c. REV- this moves the Auger in the opposite direction.
6
4. Before placing food in the Slow Juicer, make sure all foods have been
thoroughly washed, if food has to be peeled, there is no need to wash. Also
make sure to cut all foods to an appropriate size so it easily fits into the Food
Chute, we recommend no more than 3-inch pieces. *Please make sure to
remove any hard seeds or pits, such as cherry or plum pits, as it will not
process in the juicer and can damage the Auger.
5. When placing any food in the Slow Juicer, the Auger will automatically pull in
the food, and begin juicing immediately. DO NOT push, force, or overstuff
the unit. The Pusher provided with the Slow Juicer is only to use when food
obstructs the inside of the Food Chute.
6. It is best to insert all food at a slow pace, allowing all pulp to be extracted
from the fruit or vegetable completely.
7. Reminder: turn off the Slow Juicer when juicing is complete. Do not run the
Slow Juicer without any food inside the unit as this could overheat the motor.
8. The Slow Juicer has a unique cleaning process when switching between
different types of juices. To clean, simply place one of the collectors under the
juice spout and pour water though the Food Chute while the unit is on. This
will rinse out most of the remaining residue from your last juicing. When the
water from the slow juicer begins to run clear, that is an indication the unit is
clean and ready to make a new juice recipe.
NOTE: This process is not an alternative to a complete cleaning of each
disassembled part.
a
b
c
Slow Juicer Manual-FINAL.indd Sec2:8Slow Juicer Manual-FINAL.indd Sec2:8 3/29/12 9:17 PM3/29/12 9:17 PM

9
ENGLISH
Slow Juicing Tips
Please read the instruction manual carefully and follow the below juicing
suggestion for best results, as a slow juicer has different operating instructions
than that of a traditional juicer.
• Carefully drop food into the Food Chute. The Slow Juicer Pusher provided
is only for use if any food obstructs the inside of the Food Chute. Do not
overstuff, shove or force the food down.
• Cut food into pieces that are no larger than 3-inches for best juicing results.
• For best results, insert foods slowly to allow pulp to be extracted, do not over
stuff or rush the juicing process.
• Do not put any frozen fruit, vegetables or ice into the unit.
• Combine leafy greens with a variety of fruit for the best results.
• Please read the enclosed recipes included with the Slow Juicer for other
creative ideas.
NOTE
Under the bowl, there is a silicone pad (Figure 7) that prevents juice from exiting
through the pulp ejector. When using the Slow Juicer, make sure the silicone pad
is firmly in place. When cleaning the bowl, make sure to slide the pad out and run
water through the pulp ejector to remove excess food debris.
7
Slow Juicer Manual-FINAL.indd Sec2:9Slow Juicer Manual-FINAL.indd Sec2:9 3/29/12 9:17 PM3/29/12 9:17 PM

10
ENGLISH
Cleaning
1. Switch the machine off, and disconnect from power source.
2. Turn the Food Chute counterclockwise to unlock. (Figure 8)
8
3. Twist the bowl counterclockwise to the unlock position and lift out the entire
section.
4. Disassemble the upper unit in the following order:
a. Food Chute
b. Auger
c. Strainer
d. Rotating Basket
e. Bowl
5. Using the included Slow Juicer Cleaning Brush, thoroughly clean each of the
disassembled parts using warm soapy water. Remember to move the silicone
pad under the bowl to clean the remaining debris in the pulp ejector.
Please Note:
a. Don’t use an abrasive cloth or abrasive liquids.
b. Do not rinse the Slow Juicer base or submerge the base in water.
c. Dry all Slow Juicer attachments before reusing.
6. Hand washing is recommended for all components of the upper unit. Please
do not place any of the Slow Juicer parts in the dishwasher.
Slow Juicer Manual-FINAL.indd Sec2:10Slow Juicer Manual-FINAL.indd Sec2:10 3/29/12 9:17 PM3/29/12 9:17 PM

11
ENGLISH
For Tough Stains
Because there are many powerful staining properties of the carotenoids that
are found in many vegetables, especially carrots, we suggest using ONE of the
following cleaning procedures:
1. Soak in mild soapy water.
2. Equal parts warm water to cider vinegar.
3. Soak in baking soda, ½ box, and warm water.
4. ½ cup bleach in a sink full of warm water.
Other Cleaning Tips
• Never use strong household cleaners, ammonia or abrasives while cleaning
the Slow Juicer.
• Cleaning the Slow Juicer immediately after each use will also help to reduce
stains on the bowl or upper parts.
Slow Juicer Manual-FINAL.indd Sec2:11Slow Juicer Manual-FINAL.indd Sec2:11 3/29/12 9:17 PM3/29/12 9:17 PM

12
ENGLISH
Trouble Shooting
PROBLEM SOLUTION
Machine does not operate • Check power cord and power source.
• Check that all parts have been assembled
correctly.
Machine jams/ clogs or
stops operating • Check food chute is clear and is not blocked.
• Check that hard seeds have been removed
before juicing and are not stuck in the
machine.
• Turn machine off, and switch to reverse for 3
seconds.
• Disassemble upper section and clear
remaining pulp.
Squeaking noise when
juicing • Squeaking sound is perfectly normal. Please note to not run the juicer without any food.
Leaking from underneath
the bowl • Be sure the silicone pad is tightly in place after cleaning.
Strainer Damage • Refer to operation instruction for proper
usage and juicing tips. Remember not to over
stuff food or force food in the slow juicer.
Too much pulp coming out • Cut food into smaller pieces, especially
fibrous foods to avoid fibers scrapping
around the Auger. Insert food at a slower
pace and allow all food pulp to eject the unit
before adding more.
Bowl is stuck and will not
detach from the base • This is commonly caused by excess food in the bowl. Press reverse button 3-5 seconds.
Repeat process 2-3 times. Then, push bowl
upward while turning.
Food Chute/Lid is stuck • Press reverse button 3-5 seconds. Repeat
process 2-3 times, you can then press down
on top of lid while turning.
Slow Juicer Manual-FINAL.indd Sec2:12Slow Juicer Manual-FINAL.indd Sec2:12 3/29/12 9:17 PM3/29/12 9:17 PM

13
ENGLISH
Limited Warranty
This manufacturer’s product warranty extends to the original consumer purchaser
of the product. Neither the retailer nor any other company involved in the sale or
promotion of this product is a co-warrantor of this manufacturer warranty.
WARRANTY DURATION: All materials and workmanship are warranted to the
original consumer purchaser for a period of FIVE (5) year warranty from the
original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials
or workmanship. This warranty is void if the product has been damaged by
accident, in shipment, unreasonable use, misuse, neglect, improper service,
commercial use, repairs by unauthorized personnel or other causes not arising
out of defects in materials or workmanship. This warranty is effective only if the
product is purchased and operated in the USA and Canada, and does not extend
to any units which have been used in violation of written instructions furnished
by manufacturer or to units which have been altered or modified or to damage
to products or parts thereof which have had the serial number removed, altered,
defaced or rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or
implied and no representative or person is authorized to assume for manufacturer
any other liability in connection with the sale of our products. There shall be no
claims for defects or failure under any theory of tort, contractor commercial law
including, but not limited to, negligence, gross negligence, strict liability, breach
of warranty and breach of contract.
WARRANTY PERFORMANCE: During the above five-year warranty period, a
product with a defect will be either repaired or replaced with a reconditioned
comparable model (at manufacturer’s option). The repaired or replacement
product will be in warranty for the balance of the five years warranty period
and an additional one-month period. No charge will be made for such repair or
replacement.
SERVICE AND REPAIR: If service is required for an appliance, you should first
call toll free 1-800-207-0806 between the hours of 8:30 am and 5:00 pm Eastern
Standard Time and ask for CUSTOMER SERVICE. Please refer to “Fagor Slow
Juicer item #670041650 when you call.
NOTE: Manufacturer cannot assume responsibility for loss or damage during
incoming shipment. For your protection, carefully package the product for
shipment, and insure it with the carrier. Be sure to enclose the following items
with your appliance: your full name, return address and daytime phone number;
a note describing the problem you experienced; a copy of your sales receipt or
other proof of purchase to determine warranty status. C.O.D. shipments cannot
be accepted.
Slow Juicer Manual-FINAL.indd Sec2:13Slow Juicer Manual-FINAL.indd Sec2:13 3/29/12 9:17 PM3/29/12 9:17 PM

Slow Juicer Manual-FINAL.indd Sec2:14Slow Juicer Manual-FINAL.indd Sec2:14 3/29/12 9:17 PM3/29/12 9:17 PM

ESPAÑOL
15
Contenido
La Diferencia de Extraer Jugo Lentamente......................................17
Precauciones Importantes .................................................................18
Datos Técnicos....................................................................................19
Componentes .....................................................................................20
Operación.............................................................................................21
Montaje ...........................................................................................21
Uso del Extractor Lento de Jugo.......................................................23
Consejos Para Hacer Jugo Lentamente...........................................24
Limpieza ...............................................................................................25
Para Manchas Difíciles ...................................................................26
Otros Consejos de Limpieza ..........................................................26
Problemas y Soluciones .....................................................................27
Garantía Limitada................................................................................28
Slow Juicer Manual-FINAL.indd Sec2:15Slow Juicer Manual-FINAL.indd Sec2:15 3/29/12 9:17 PM3/29/12 9:17 PM

ESPAÑOL
16
La Diferencia de Extraer Jugo Lentamente
Extraer jugo lentamente le permite consumir más frutas y verduras en un vaso
de lo que podría comer al mismo tiempo. No hay oxidación o separación en
jugo lento, por lo que conserva más de los nutrientes orgánicos de la comida y
la mantiene más cerca a su estado natural. El jugo fresco de un extractor lento
se absorbe directamente en el cuerpo, lo que permite la ingestión de vitaminas
y nutrientes de los alimentos - su cuerpo recibe todo lo que necesita para una
salud óptima. Además, puede crear una amplia variedad de recetas de jugos
para disfrutar de las frutas y verduras que normalmente no suele comer.
El extractor lento de Fagor utiliza un proceso de dos pasos en el que se extrae el
jugo de la fruta o la verdura dos veces antes de entrar en la copa. La barrena, el
componente principal de la unidad, precisamente exprime la comida sin triturar o
molerla, lo que ayuda a obtener más jugo en su vaso.
El extractor lento de Fagor produce jugo fresco y saludable, que está lleno con
más vitaminas y nutrientes necesarios para la vida diaria. Además, el extractor
lento de Fagor lenta utiliza menos energía, ahorrándole dinero y ayudando a
reducir su huella de carbono. Un vaso y experimentará de primera mano la
diferencia entre el jugo comprado en la tienda y la bondad fresca y saludable.
Slow Juicer Manual-FINAL.indd Sec2:16Slow Juicer Manual-FINAL.indd Sec2:16 3/29/12 9:17 PM3/29/12 9:17 PM

ESPAÑOL
17
Precauciones Importantes
Cuando se utiliza el electrodoméstico, siempre se deben seguir precauciones de
seguridad básicas, incluyendo las siguientes:
• Por favor, lea atentamente las INSTRUCCIONES y COMPONENTES antes de
utilizar.
• Asegúrese de que la marca de voltaje (110-120V) en el aparato corresponde
con el voltaje de su casa, antes de enchufar el cable, para evitar dañar el
aparato.
• Para evitar descargas eléctricas, no coloque el cable, el enchufe, o la base de
la unidad en agua u otros líquidos. No deje que el cable cuelgue de la mesa o
mostrador, ni que toque superficies calientes.
• Este aparato está destinado solo para uso doméstico.
• Revise el filtro cada vez que quiera usar el aparato. Si detecta alguna grieta o
daños, no utilice el aparato y póngase en contacto con el centro de servicio
más cercano.
• Desenchufe el aparato cuando no esté en uso.
• Este aparato no está diseñado para ser utilizado por personas (incluyendo
niños) con capacidades físicas, sensoriales o mentales limitadas, o sin
experiencia o conocimiento, a menos que sean supervisados o que hayan
recibido instrucción sobre el uso del aparato por parte de una persona
responsable de su seguridad.
• Los niños deben ser supervisados para asegurarse de que no jueguen con el
aparato.
• Siempre asegure todas las piezas en el aparato antes de encender el motor. No
las afloje mientras el aparato está en funcionamiento.
• Evite tocar partes del extractor en funcionamiento. Asegúrese de que el motor
se ha detenido completamente antes de desmontar.
• No colocar sobre o cerca de un quemador a gas o eléctrico caliente, o en un
horno caliente.
• Para desconectar, retire el enchufe de la tomada eléctrica. No dé al aparato un
uso o propósito específico diferente del uso o propósito específico para el cual
fue hecho.
• No deje funcionando el aparato cuando usted salga del lugar.
• No desarme la base.
• No coloque ningún material extraño en la máquina.
• Por favor no use por más de 20 minutos seguidos, deje que el motor se enfríe.
GUARDE ESTAS INSTRUCCIONES
Slow Juicer Manual-FINAL.indd Sec2:17Slow Juicer Manual-FINAL.indd Sec2:17 3/29/12 9:17 PM3/29/12 9:17 PM

ESPAÑOL
18
Datos Técnicos
Voltaje 110V-120V
Potencia 150W
Frecuencia 60Hz
Velocidad 80RPM
Slow Juicer Manual-FINAL.indd Sec2:18Slow Juicer Manual-FINAL.indd Sec2:18 3/29/12 9:17 PM3/29/12 9:17 PM
