UK - 22 -
Index
BEFORE USING THE APPLIANCE ..................................................................... 23
Safety Instructions ............................................................................................... 23
Recommendations ............................................................................................. 24
Switching On the Appliance ................................................................................ 25
HOW TO OPERATE THE APPLIANCE ............................................................... 26
Thermostat Setting .............................................................................................. 26
FOOD STORAGE IN THE APPLIANCE............................................................... 27
CLEANING AND MAINTENANCE ........................................................................ 27
Defrosting the Refrigerator ................................................................................. 28
Replacing the Light Bulb ..................................................................................... 28
BEFORE CALLING YOUR AFTER SALES SERVICE ......................................... 29
PARTS OF THE APPLIANCE AND THE COMPARTMENTS .............................. 31

UK - 23 -
PART 1. BEFORE USING THE APPLIANCE
Safety Instructions
• If the model contains R600a-see name plate under refrigerant (the coolant isobutane),
naturals gas that, is very environmentally friendly but also combustible. When
transporting and installing the unit care must be taken to ensure that none of the
refrigeration circuit components become damaged. In the event of damage avoid
naked flames or ignition sources and ventilate the room in which the unit is placed
for a few minutes.
Warning: Keep ventilation openings in appliance enclosure or in structure for building
in, clear of obstruction.
• Do not use mechanical devices or other artificial means to accelerate the defrosting
process.
• Do not use electrical appliances in the refrigerator or freezer compartment of the
appliance.
• If this appliance is to replace an old refrigerator with a lock; break or remove the lock
as a safety measure before storing it, to protect children while playing might lock
themselves inside.
• Old refrigerators and freezers contain insulation gases and refrigerant, which must
be disposed of properly. Entrust the disposal of a scrap unit categorically to
competence of your local waste disposal service and contact your local authority or
your dealer if you have any questions. Please ensure that the pipe of work of your
refrigerating unit does not get damaged prior to being picked-up by the relevant waste
disposal service.
Important note:
Please read this booklet before installing and switching on this appliance. The
manufacturer assumes no responsibility for incorrect installation and usage as described
in this booklet.
Your appliance is compliant with European Directives as well as their modifications.
ENVIRONMENTAL PROTECTION
This appliance's packaging material is recyclable. Help recycle it and protect the envi-
ronment by dropping it off in the municipal receptacles provided for this purpose.
Your appliance also contains a great amount of recyclable mate-
rial. It is marked with this label to indicate that in countries that are a
members of the European Union the used appliances should not be
mixed with other waste. This way, the appliance recycling organised
by your manufacturer will be done under the best possible conditions,
in compliance with European Directive 2002/96/EC on Waste Electri-
cal and Electronic Equipment. Contact your town hall or your retailer
for the used appliance collection points closest to your home.
We thank you doing your part to protect the environment.

UK - 24 -
Recommendations
Warning: Do not use mechanical devices or other artificial means to accelerate the
defrosting. process. Do not use electrical appliances in the food storage of the appliance.
Keep the appliance ventilation openings free. Do not damage the refrigerator’s refriger-
ant circuit.
• Do not damage the refrigerant circuit.
• Do not allow children to play with the appliance. Children must
never sit in the drawers or hang from the door.
• Do not use adapters or shunts, which could cause overheating
or burning.
• Do not plug old, warped power supply cables.
• Do not twist and bend the cables, and keep them away from hot
surfaces.
• Do not plug the power supply with wet hands.
• Your old appliances contain insulation gases and refrigerant
that must be disposed of properly. Please ensure that the
refrigerant circuit is not damaged before the appliance is taken
away for disposal.
• After installation make sure that the power cable is not trapped
underneath appliance.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they don’t play with the appliance.
• If the supply cord is damaged it must be replaced by the
manufacturer or service agent or appointed qualified person.
• Do not defrost the appliance with other electrical devices (i.e. hair dryer) or other
artificial means.
• Do not operate any electrical appliances inside the refrigerator.
• Do not touch the cooling surfaces while the appliance operates, especially with wet
hands, because the skin may stick to cold surfaces.
• The appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety. Children should be supervised to ensure that
they don’t play with the appliance.
• If the supply cord is damaged it must be replaced by the manufacturer or service
agent or appointed person.

UK - 25 -
Warning: Do not use mechanical devices or other artificial means to accelerate the
defrosting process. Do not use electrical appliances in the food storage of the appliance.
Keep the appliance ventilation openings free. Do not damage the refrigerator’s refrigerant
circuit.
Switching On the Appliance
• Before switching on, place the appliance on upright position
and wait at least three hours without moving the appliance. This
will give the refrigerant circuit time to settle and operate
efficiently.
• Clean the appliance thoroughly, especially in the interior, before use (See Cleaning
and Maintenance).
• Installation of the appliance and electrical connections must be
carried out by a qualified technician, in accordance with the
Installation Manual and local regulations.
• Installation procedure into the kitchen unit is given in the
Installation Manual. This product is intended to be used in
proper kitchen units only.
• The appliance must be connected with a properly installed fused
socket. Power supply (AC) and voltage at the operating point
must with the details on the name plate of the appliance (name
plate is located on the inside left of the appliance).
• Insert the plug into a socket with an efficient ground connection.
If the socket has no ground contact or the plug does not match,
we suggest you to call an authorized electrician for assistance.
• Manufacturer is not responsible for failure to complete the
ground connection as described in this booklet.
• There can be an odor when you first switch on the appliance. It will disappear after
the appliance starts to cool.
• The plug must be accessible after installation.

UK - 26 -
PART 2. HOW TO OPERATE THE APPLIANCE
Thermostat Setting
• Thermostat automatically regulates the inside temperature of the refrigerator
compartment and freezer compartment. By rotating the knob from position 1 to 5,
colder temperatures can be obtained.
• The “ 0 “ position shows thermostat is closed and no cooling is available.
• For short-term storage of food in the freezer compartment, you can set the knob
between minimum and medium position (1-3).
• For long-term storage of food in the freezer compartment, you can set knob medium
position.(3-4)
• Note that; the ambient temperature, temperature of the freshly stored food and
how often the door is opened, affects the temperature in the refrigerator and
freezer compartments. If required, change the temperature setting.
• When you first switch on the appliance, you should ideally try to run it without any
food in for 24 hours and not open the door. If you need to use it straight away, try not
to put much food inside.
• If the unit is switched off or unplugged, you must allow at least 5 minutes before
restarting in order not to damage the compressor.

UK - 27 -
PART 3. FOOD STORAGE IN THE APPLIANCE
Refrigerator compartment is used for storing fresh food for few days.
• Do not place food in direct contact with the rear wall of the refrigerator compartment.
Leave some space around food to allow circulation of air.
• Do not place hot food or evaporating liquid in the refrigerator.
• Always store food in closed containers or wrapped.
• To reduce humidity and avoid formation of frost, never place liquids in unsealed
containers in the refrigerator.
• Meat of all types, wrapped in packages, is recommended to be placed on the glass
shelf just above the vegetable bin, where the air is colder.
• You can put the fruits and vegetables into crisper without packing.
• To avoid the cold air escaping, try not to open the door too often, and not leave the
door open for a long time.
PART 4. CLEANING AND MAINTENANCE
• Disconnect the appliance from the power supply before cleaning.
• Do not pour water over the appliance.
• The refrigerator compartment should be cleaned peri-
odically using a solution of bicarbonate of soda and
lukewarm water.
• Clean the accessories separately with soap and water.
Do not put them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After
washing, rinse with clean water and dry carefully. When
the cleaning operations have been completed, reconnect
the plug with dry hands.

UK - 28 -
Defrosting the Refrigerator
• Defrosting occurs automatically in refrigerator during operation; the defrost water is
collected by the evaporating tray and evaporates automatically.
• The defrost water drain hole should be cleaned periodically with defrost drain plug to
prevent the water from collecting on the bottom of the refrigerator instead of flowing
out.
• You can also pour ½ glass of the water to drain hole to clean inside.
Replacing the Light Bulb
When replacing the bulb of the refrigerator;
1. Unplug the unit from the power supply.
2. Press the hook in front of the light cover such as Figure 1 and remove the light
cover.
3. Change the present light bulb with a new one of not more than 15 W.
4. Replace the light cover and after waiting 5 minutes plug the unit.
Figure 1 Figure 2

UK - 29 -
PART 5.
If your refrigerator is not working properly, it may be a minor problem, therefore check
the following.
The appliance does not operate,
Check if;
• There is a power failure,
• The mains plug is not properly plugged in, or is loose
• The thermostat setting is on position “0”,
• The socket is defective. To check this, plug in another appliance that you know which
is working into the same socket.
The appliance performs poorly;
Check if;
• You have overloaded the appliance,
• The doors are not closed perfectly,
• There are not enough ventilation ducts on the kitchen unit as mentioned in the
Installation Manual.
If there is noise;
The cooling gas which circulates in the refrigerator circuit may make a slight noise
(bubbling sound) even when the compressor is not running. Do not worry, this is quite
normal. If these sounds are different check if;
• The appliance is installed firmly as described in the Installation Manual.
• The objects on the appliance are vibrating.
If there is water in the lower part of the refrigerator;
Check if;
The drain hole for defrost water is not clogged (use defrost drain plug to clean the
drain hole).
BEFORE CALLING YOUR AFTER SALES SERVICE

UK - 30 -
If your fridge is not cooling enough;
Your fridge is designed to operate in the ambient temperature intervals stated in the
standards, according to the climate class stated in the information label. We do not
recommend operating your fridge out of stated temperatures value limits in terms of cooling
effectiveness.
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
(*) Tropical class is designated for temperatures between 16°C and 43°C according
to TS EN ISO 15502 standards.
IMPORTANT NOTES:
• In case of a sudden power loss or disconnecting and reconnecting of the plug to the
electrical socket, the compressor protective thermal element will be opened as the
pressure of the gas in the cooling system of your refrigerator has not yet been
balanced. 4 or 5 minutes later, your refrigerator will start to operate; this is normal.
• If you won’t be using your refrigerator for a long time (such as on summer holidays),
please disconnect the plug from the socket. Clean your refrigerator as per Part 4 of
this document and leave the door open to prevent any humidification or odor
formation.
If there is still a problem with your refrigerator although you have followed the
instructions in this book, please consult your nearest authorized service center.
The life cycle of this product as determined and proclaimed by the Ministry of Industry
(the period for making spare parts available for the product to be able to fulfill its functions)
is 10 years.

UK - 31 -
PART 6. PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1) REFRIGERATOR SHELF
2) CRISPER COVER(SAFETY GLASS)
3) CRISPER
4) THERMOSTAT BUTTON
5) BOTTLE SHELF
6) BUTTER SHELF
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
2
1
4 5
6
3
