FCI MagicMoon User manual

MagicMoon Touchless Soap Dispenser
User’s Manual
Thank you for choosing the automatic faucet soap dispenser. Please read the instruction carefully before installation. This manual is
for your reference only.

Features
Hands free sensor operation improves hand washing hygiene.
Easy installation and low-cost maintenance
Modular one-piece construction with chrome-plated cast brass spout and black
throat plate
Available with hardwired or battery power
Specifications
Power
6V
(4 x Alkaline
D batteries
)
Sensing Range
5
–
15 cm
Foam Vol per Drop
4
–
25 ml (4 ml factory default setting)
Soap Bottle Volume
1500 ml
Ambient Temperature
1
–
55
o
C
Before Installation
Locate position of soap dispenser.
Ensure that soap dispenser does not interfere with anything above or below the
lavatory/counter top area
Pay special attention so that the sensor surface is not flawed or scratched during
the installation process.
Before installing on the wall, check that no other piping and wiring is running
behind hole locations. Wall should be sufficiently reinforced or risk failure due to
foam tank case unit falling.
Do not place other devices that use an inverter or infrared sensor near the
faucet, as this may cause the faucet to malfunction.
Tools You will Need
Adjustable wrench
Power drill with 25 – 30 mm counter top drill bit
Phillips screwdriver
Utility knife
Hammer
Ruler/tape measure

Part List
Faucet Body Assembly
Control Box Assembly
1
Sensor
1
Sensor
cable female
2
Nozzle assembly
2
Control box cover
3
Hex screw
3
Control box base
4
Spout
4
Push button
5
O Ring
5
Hose clip
6
Tapered washer
6
Power cable
7
Nut
7
Fixed frame
8
Tube clip
8
Suction tube
9
Clear tubing
9
Bottle cap
10
Brass
shank
10
Soap bottle
11
Male sensor cable

Construction / Installation Diagram
1. Faucet Soap Assembly
i.
Soap Dispenser oftentimes can be mounted in the left or right hole of a
100 m or 200 mm center-set sink. The ability to do this is contingent upon
the width of the faucet spout and accessibility to the unit on the underside
of the sink (the Motor and Soap Bottle cannot interfere with the water or
drain lines). When such interference above or below the sink occurs, the
Soap Dispenser must be installed through the countertop to the side of the
sink as shown in figure 1.
ii.
Drill a 25 – 30 mm hole into the counter.
iii.
Slide the plastic gasket onto the brass shank making certain that the hole
in gasket is positioned over the washer in the base of the spout.
iv.
Guide the brass shank, tubes and the sensor cable through the hole in the
counter.
v.
Position spout to direct soap into the sink
vi.
Screw the flange nut onto the shank and tighten.
2. Control Box Assembly (Including Battery Box)
i.
Determine a temporary position for mounting the foam tank & battery case
units.
ii.
Make sure foam tank unit is within reach of the liquid soap and air tube
from the foam soap dispenser.
iii.
Use the mounting grey plastic bracket as a guide, mark where holes need
to be drilled. Important: Make sure bracket and foam tank case unit is
mounted level. Repeat for battery case unit.
iv.
When installing onto a concrete wall, drill holes 30 mm deep using a 6 mm
masonry drill bit. Insert wall anchors into the holes and mount the
dispenser using screws.
v.
When installing onto a wood wall, drill holes using a 3 mm drill bit and
attach the dispenser bracket using screws provided.
vi.
Remove the battery case cover and install 4 D size batteries. Assemble
back the cover and tighten the cover using the four supplied Philips
screws. Guide the male battery box cable through the bottom opening and
place the case.

3. Connect Foam & Air Tubes
Connect the foam soap tube and air tube from the foam soap dispenser into
the soap tube fitting and air tube fitting found on top of the foam tank case
unit, respectively.
i. Check soap tube tags and align with correct fittings as indicated on
the fitting’s connection label.
ii. Cut the soap tube and the air tube at suitable lengths. Ends should
be cut at right angles and tubes should be free of kinks and bends
when connected.
iii. Insert soap tube and air tube into respective fittings and secure with
tube clamps.

Fill / Refill Soap
1.
Lift the soap bottle and horizontally pullout the bottle.
2.
Remove the plastic bottle cap.
3.
Fill the bottle with 2 parts water & one-part soap concentrate. Avoid overfilling the
bottle.
4.
Return the bottle back into the case unit (fixture frame).
5.
Push the green button on the controller to release trapped air & prepared the
dispenser for use.
Operations
As the user’s hands enter the beam’s effective range, the beam is reflected back into
the sensor receiver and activates the solenoid valve allowing a single soap application
to flow from the spout.

Soap Volume Adjustment
No adjustments are required for most settings. Factory default soap volume is 4 ml. The
factory setting should be satisfactory for most installations.
To adjust the volume, aim the remote control at sensor eye. Press the plus “Time +” to
increase the soap volume and “Time – “to reduce the volume. The LED will flash three
times when the maximum or minimum dispense volume has been reached.
Soap Dispensing Range Adjustments
To adjust the dispensing range:
1. On the remote press the auto adjust button.
2. Place hand at the desired distance. The LED will flash for 1 sec then stays on for
3 secs to confirm setting.
Battery Replacement
1. Disconnect the power cables.
2. Remove the black battery holder from the case unit
3. Using a Philips screw driver, remove the two Philips screws, plastic cover and
the four D size batteries.
4. Replace with 4 new batteries, place back the cover and tighten the assembly.
5. Place back holder onto the case unit and connect the power cables.

Troubleshooting
1. Unit does not operate
i. Check battery power cables are connected. Connect power cables.
2. Soap does not dispense
i. Soap bottle needs refill. Refill 2:1 water & soap.
ii. Check soap dispensing nozzle for clog. Clean nozzle with soft cloth.
3. Liquid soap is not in foam state
i. Soap bottle needs refill. Refill 2:1 water & soap.
Care & Cleaning
DO NOT USE abrasive or chemical cleaners (including chlorine bleach) to clean faucet
that may dull the luster and attack the chrome or special decorative finishes. Use ONLY
mild soap and water, then wipe dry with clean cloth or towel. While cleaning the
bathroom tile, protect the dispenser from any splattering of cleaner. Acids and cleaning
fluids will discolor or remove chrome plating.
