Fein KBM 32Q User manual

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
Starting page
KBM 32 Q

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
Contents
1. Technical data
2. Maintenance
3. General inspection
4. Disassembly
5. Assembly
6. Tools
7. Lubricants
8. Modifications
Spare design and parts list available on the Internet (www.fein.com)

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
Order reference 7 270 27
Model KBM 32 Q
Power consumption Watt 700
Power output Watt 650
Speed at full load 1/min 440
Type of current 1 ~
Safety class 1
Cable length with plug m 4
Weight kg 10
Drill - Ø Steel max.
Core drill mm 12-32
Twist drill (with drill chuck) mm 13
Tapping drill M 12
Chuck QuickIN
Magnetic holding force N 9000
Height (drill jigs) mm 373
Cam (adjustable) mm 135-260
Magnetic foot measurement mm 160 x 80 x 45
1. Technical data

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
2. Maintenance
Check power cable for damage
Vent motor using dry compressed air
Check carbon brushes
General functional control
Carbon brush replacement:
The drill motor has carbon brushes with automatic switch-off.
The replacement should be done by an electrician, prior in
an authorised FEIN - workshop.
During the insertion of the new carbon brush observe free movement in the carbon brush holder.
New carbon brushes have to run in for 15 min in no load speed.
Only use original Fein - carbon brushes and Fein - replacement parts


Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
3. General inspection
3.1. General functional test
3.2. Test data
3.3. Testing devices and aids
3.4. Connection plan
3.5. Security inspection after completed repair
For a detailed troubleshooting and inspection possibilities
see Excel - file at the end of the presentation !


Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
3.1 General functional test
Self-start lock and magnetic foot:
Switch on the main switch (magnet) and motor switch, then connect the machine to the main power
- The motor may not start
- Magnetic foot attaches
- Check power input (0.30 A)
Switch off motor switch
- Magnetic foot remains on
- Power input has to sink to half the amount (0.15A)
Motor test:
Turn on and load motor
- Measure idle speed
- Speed is adjusted when loaded
- at approx. 1100 Watt strong speed reduction
Overload cut-out:
Heavily load or block motor
- after 10 - 16 sec. automatic cut-out ( overload protection )

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
3.2. Test data
Nominal voltage 220 - 240 V 110 V / 120 V
Test voltage / 2 % Nominal voltage
No-load current / 10 % (1,44-1,76A) 1,6 A 3 A
No-load speed / 10% (486 - 594 U/min) 540 U/min
Main switch on
Voltage at X7,X8 10% (90-110V/DC) 100 V / DC 50 V / DC
Current consumption 0,15 A 0,25 A
Main switch on, motor on
Voltage at X7,X8 10% (180-220V/DC) 200 V / DC 100 V / DC
Current consumption 0,30 A 0,60 A
Resistance of magnetic base 5% bei 25°C (627-693 Ohm) 660 Ohm 160 Ohm
Minimum drilling force min. 2700 N
Test voltage on motor without electronics 180 V / AC 86 V / AC

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
3.3. Testing devices and aids
Multimetre for effective measuring (voltage, current, resistance)
Speed gauge
Force measurement tin for measurement of pressing force up to approx. 5000 N
Smoothed steel plate ( ST 37 - approx. 500x250x25 mm )
Adjustable isolating transformer (inspection motor without electronics with 145 V)

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
3.4. Connection plan

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
3.5. Security inspection after completed repair
(directly after approx. 15 min. of breaking in)
Attention!
Basis for
the security
inspection are the
specifications of the
current
DIN VDE 0701 Part 1
(Appendix "E" for
electr. tools).
Test steps
Test type
1.
Pressing off force
1. Place KBM on smoothed steel plate (St 37).
2. Attach mains power cable to mains socket
3. Motor switch on, only then main switch on
4. Pressing off force, min 4500N (new) or min 4050N (used), measure
with force measurement tin
2.
Self-start lock
1. Connect KBM 50Q to 230 V/50 Hz
2. Main switch and then motor switch "on"
3. If machine runs, then pull mains plug
4. Connect mains plug into the mains socket again
= Machine must not start again
3.
protective earth
conductor test
1. Activate
Measuring points: Gear head against PE on the plug
Open circuit voltage on the measuring device: 4 V - 24 V, AC or DC
Measurment current: min. 0.2 A
Testing time: 3 sec
PE resistance: max. 0.3 Ohm with 4 m long mains power cable
4.
Insulation
resistance
measurement
1. Activate
2. Connect L1 and N to plug
3. Main switch and motor switch "ON"
Measuring points: Gear head and screws (270) against L1/N
Testing time: 3 sec
Testing voltage: 500 V DC
Insulation resistance: min 2.0 M Ohm
5.
High voltage test
1. Activate
2. Connect L1 and N to plug
3. Main switch and motor switch "ON"
Measuring points: Gear head and screws (270) against L1/N
Testing time: 3 sec
Testing voltage: 1000 V AC
Trip circuit: 5mA > overload relay must not respond

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4. Disassembly
4.1. Preparation
4.2. Drill motor - remove drill rig
4.3. Drill motor - remove gear
4.4. Dismantling chuck
4.5. Dismantling gear
4.6. Dismantling motor
4.7. Dismantling drill rig

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.1. Preparation
1. Disconnect device from mains
2. Switch in "OFF" - position
3. Remove mounted tools

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
1. Remove screws and detach cover.
2. Remove cable (circle) from the circuit board.
3. Unscrew top flat-headed screw.
4. Release clamp lever and remove drill motor with cover and motor lead.
4.2. Drill motor - remove drill rig
Tools:
- Screwdriver
Torx 20
- Screwdriver
Slotted

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.3. Drill motor - remove gear
1. Remove cylinder head screw and detach outside bearing.
2. Clean gear free of grease Tools:
- Allen key SW4
- Plastic hammer

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.4. Dismantling chuck
1. Remove clamping lever, circlip insert part, gear wheel and spur gear
2. Dismantle circlip, locking sleeve, spring and ball
3. Dismantle spring bearing for centering pin Tools:
- Circlip pliers
outside, straight
inside, straight
- Plastic hammer
- Flat pliers

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.5. Dismantling gear
1. Remove circlip, drive out gear wheel and composite spur gear with light
strokes from the hammer
2. Remove the ball bearing from the spur gear with the pull-off device, remove
the circlip on the drill shaft
3. Press out the drill shaft from the outer bearing
4. Remove circlip and press out ball bearing
Tools:
- Circlip pliers
(outside, straight)
- Plastic hammer
- Mandrel press
- Pull-off device
Ø 19 mm, 22 mm
- Pull-off cap

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.6. Dismantling motor
1. Release screws and carefully remove the cover with motor lead
2. Release plug connection from the field magnet on the connection plate
and remove the connection plate
3. Remove carbon brushes from the collector
4. Release screws in the intermediate bearing sign
5. Disconnect field magnet and armature with light strokes from the hammer Tools:
- Screwdriver (phillips) PH2
- Cable hook
- Plastic hammer
- Flat pliers

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.6. Dismantling motor - armature
1. Drive out armature from the intermediate bearing with light strokes from the hammer
2. Pull off ball bearing and sealing ring with device Tools:
- Plastic hammer
- Pull-off device
Ø 19 and 26 mm
- Pull-off cap

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.6. Dismantling motor - field magnet
1. Remove carbon holder with carbon brush out of the motor case
2. Remove air management ring and release the screws from the field magnet
3. Drive out field magnet from the motor case with light strokes from the plastic hammer
The cables may not get caught anywhere - danger of tearing !!!!!
Tools:
- Screwdriver
phillips PH 2
- Plastic hammer

Sahre/MVK 03/07
All rights reserved by FEIN, in particular as these apply to trademarks. FEIN
retains all powers of disposition such as copying and right of transfer.
FRT: KBM 32 Q
4.7. Dismantling drill rig
1. Remove all plugs and sockets from the circuit board, unscrew ground contact
2. Unscrew the magnetic foot from the case stand
3. Dismantle the closing plate with the magnetic switch and mains power cable,
dismount the motor switch and circuit board
Tools:
- Screwdriver
Torx 20
- Plastic hammer
- Flat pliers
- Hexagon socket
4 mm
