1.1 Safety information
1.1.1 A word to the technician
Read and understand the safety section in this
service manual before operating or servicing the
machine. Read and understand the safety sections
in the manuals for all attachments before
operating or servicing attachments. The technician
has the key to safety. Good safety practices
protect everyone.
Study the safety information in this service
manual. Make the safety information a working
part of the safety program. The safety information
in this service manual applies specifically to this
type of machine. Always do all other usual and
customary safe working precautions. Remember -
The technician has the responsibility for safety.
Good safety practices can prevent serious injury or
death.
The safety section points out some basic safety
situations that can occur during the operation and
maintenance of the machine. The safety section
also suggests possible ways to deal with these
situations. The safety section does not replace
safety practices in other parts of this service
manual.
Practice good safety to help prevent injury or
death.
Learn how to operate the machine and how to use
the controls correctly.
Do not let other persons operate the machine
without instruction and training.
Follow all safety precautions and instructions in
the manuals and on safety signs affixed to the
machine and all attachments.
Use only approved attachments and equipment.
Make sure the machine has the correct equipment
needed by the local regulations.
WARNING:
An operator should not use alcohol or
drugs which can affect their alertness
or coordination. An operator on
prescription or 'over the counter'
drugs needs medical advice on
whether or not they can properly
operate machines. If any attachments
used on this equipment have a
separate Operator Manual, see that
manual for other important safety
information.
GUID-AC91CCF6-1FF8-4A85-97A1-2D1562806825-high.jpg [High]
Fig. 1
[V]
GUID-3C35D58D-1F5D-4B85-A915-C7BB48F47262 [V1]
1. General
Rubber Track Tractor 1-3
79037272A
Find manuals at https://best-manuals.com

1.1.2 Service manual
WARNING:
Some pictures in the manual show the shields removed to permit a clearer view. Never
operate the machine with any shields removed.
This service manual has been prepared with the latest service information available at publication. Read
and understand the service manual carefully before doing any service on the machine.
Right-hand and left-hand, as used in this manual, are determined by facing the direction of machine travel
when in use.
Photos, illustrations, and data used were current at the time of printing, due to possible production
changes, the machine can vary slightly. The manufacturer reserves the right to redesign and change the
machine as necessary without notification.
1.1.3 Safety symbol
The safety symbol tells you about a dangerous
area!
Look for the safety symbol in this manual and on
the machine. The safety symbols tell you that
there is important safety instructions in the
manual.
GUID-4C201302-DBD2-4BFB-8D98-1DDED263BD6E-high.jpg [High]
Fig. 2
1.1.4 Safety messages
The words DANGER, WARNING or CAUTION are
used with the safety symbol. Learn these safety
messages and obey the recommended
precautions and safety instructions.
DANGER:
If you do not obey the recommended
precautions and safety instructions,
DEATH OR INJURY will occur.
WARNING:
If you do not obey the recommended
precautions and safety instructions,
DEATH OR INJURY can occur.
CAUTION:
If you do not obey the recommended
precautions and safety instructions,
INJURY can possibly occur.
GUID-73F05026-C37B-415A-8140-AD939A283378-high.jpg [High]
Fig. 3
1.1.5 Information messages
The words important and note are not related to personal safety, and are used to give information about
the operation and servicing of the machine.
GUID-96F0DBC2-FDAB-4BE2-A442-8D57B94A81B4 [V1]
GUID-5D9F270E-D748-4741-82B1-BE49B78685F2 [V4]
GUID-E54F7740-C021-42A8-8784-4287BE4356C8 [V4]
GUID-9A909F52-D57E-4C30-8CC7-6FDB6D7E9982 [V3]
1. General
1-4 Rubber Track Tractor
79037272A
Find manuals at https://best-manuals.com

IMPORTANT: Identifies special instructions or procedures which, if not followed, can cause damage to the
machine, the process, or the area around the machine.
NOTE: Information to make procedures easier.
1.1.6 Safety signs
WARNING:
Do not remove the safety signs. Replace safety signs that you cannot read, are damaged, or are missing.
Clean the machine surface with a weak soap and water solution before you replace the safety signs.
Replacement safety signs are available from your dealer.
Always make sure that safety signs are in the correct locations and that you can read the safety signs.
Illustrations of safety sign locations are at in this section.
Keep the safety signs clean. If necessary, use a weak soap and water solution.
1.1.7 Important safety information
IMPORTANT: Any Modifications to the machine or systems not authorized by AGCO will void the AGCO
Warranty. This includes, but is not limited to hitches.
WARNING:
When replacement parts are required for this product, AGCO recommends using AGCO
replacement parts or parts with equivalent specifications including, but not limited to,
physical dimensions, type, strength and material. Failure to heed this warning can get
untimely failures, product damage, personal injury or death.
Failure to obey basic safety rules and precautions can cause personal injuries during product operation,
maintenance, or repair. Know dangerous situations before an injury occurs.
A person must be alert to possible dangers. This person must also have the necessary training, skills and
tools to do these operations correctly.
Incorrect operation, lubrication, maintenance or repair of this product can be dangerous and can result in
injury or death.
Read and understand all the information about the operation, lubrication, maintenance, and repair before
operating on this machine.
The product and this manual give safety precautions and warnings. Bodily injury or death can occur to you
or to other persons if all warnings are not heeded.
Not every possible circumstance that can involve a potential danger can be anticipated. The warnings in
this publication and on the product are, thus, not all inclusive. If a tool or procedure, not recommended by
AGCO, is used, make sure they are safe for everyone.
An operator must make sure the product will not be dangerous or damaged by the operation, lubrication,
maintenance or repair procedures selected. Information, specifications, and illustrations in this publication
come from information available at the time of publication production.
Specifications, torques, pressures, measurements, adjustments, illustrations, and other items can change
at any time. These changes can change the service that is given to the product. Get the complete and
most current information before starting a job. AGCO dealers have the most current information available.
GUID-2FB17168-6A01-47C5-B298-234AF171520B [V5]
GUID-F9D59F68-8014-4549-B346-3FE8D9739D94 [V2]
1. General
Rubber Track Tractor 1-5
79037272A
Find manuals at https://best-manuals.com

1.1.8 General safety instruction
CAUTION:
Carefully read the operator manual
before operating the machine. See all
instructions and safety rules when
operating or doing maintenance.
GUID-FE6A41D4-536F-4C0D-BE60-FA0CCDEEB171-high.jpg [High]
Fig. 4
Do not start the engine until the area is free of
personnel. Honk the horn two times to tell others.
This will help prevent personal injury because
machine movement can occur.
Know the width of the equipment to keep the
correct clearance when operating near fences or
near boundary blockage.
Wear a hard hat, protective glasses, and other
protective equipment, as necessary.
Do not wear loose clothing or jewelry that can
catch on controls or on other parts of the machine.
Make sure that all protective guards and all covers
are attached in position on the machine.
GUID-6CB742A7-222E-47ED-9806-1887BFD0CF24-high.jpg [High]
Fig. 5
Keep the machine free from unwanted material. Remove unwanted material, oil, tools, and other items
from the deck, from walkways, and from steps.
Make sure lunch boxes, tools, and other loose items that are not a part of the machine are attached.
Know the applicable work location hand signals and the personnel that are approved to give the hand
signals. Get hand signals from one person only.
Do not put maintenance fluids into glass containers. Drain all liquids into an approved container.
Discard all drained fluids and discard all filters. Refer to local regulations.
Use all cleaning solutions with precaution.
Record all necessary repairs.
Do not let untrained or not approved personnel on the machine.
Do not smoke when doing work an air conditioner. Also, if there is refrigerant gas around, do not smoke.
Breathing the fumes that are released from a flame that touches air conditioner refrigerant can cause
bodily injury or death.
Breathing gas from air conditioner refrigerant through a lighted cigarette can cause bodily injury or death.
Do the following before completing maintenance unless receiving other instructions:
•Parked the machine on level ground.
• Lower the implements to the ground.
• Park the machine.
GUID-5D629BA7-D659-48B8-A7B0-3B99F135B7BA [V1]
1. General
1-6 Rubber Track Tractor
79037272A
Find manuals at https://best-manuals.com

• Stop the engine.
•Remove the switch key.
• Cool the machine.
Use other precautions if the conditions and environment make it necessary.
For operating this machine in forestry or loader operations:
This machine does not have a falling-object protective structure and must not be used in forestry or loader
operations.
1.1.9 Pressurized air
Air under pressure can cause personal injury. When pressurized air is used for cleaning, wear a protective
face shield, protective clothing and protective shoes.
The maximum air pressure for cleaning purposes must be below 205 kPa (30 psi).
1.1.10 Asbestos information
AGCO equipment and replacement parts are asbestos free. AGCO recommends the use of only correct
AGCO replacement parts.
1.1.11 Electrical storm injury prevention
When lightning is striking in the vicinity of the machine, the operator should not attempt to dismount or
mount the machine.
If you are in the operator's station during an electrical storm, stay in the operator's station. If you are on the
ground during an electrical storm, stay away from the machine.
1.1.12 Mount and dismount the machine
Mount the machine and dismount the machine only at locations that have steps and/or hand holds. Before
mounting the machine, clean the steps and the hand holds. Inspect the stairs and hand holds. Make any
necessary repairs.
When dismounting the machine, descend the steps backwards, and maintain a three-point contact with
the steps and hand holds. Three-point contact is two feet and one hand or one foot and two hands.
Never mount a moving machine. Never dismount a moving machine. Never jump off the machine except
in an emergency.
Do not carry tools or supplies when you try to mount the machine or when you try to dismount the
machine. Use a hand line to pull equipment onto the platform.
Do not use any controls as hand holds when you enter the operator compartment or when you exit the
operator compartment.
GUID-774BCA83-ABC1-43DB-B35A-A04E184CA5F8 [V1]
GUID-DABC7CAA-9A08-4236-A20C-E92972E9FAB3 [V1]
GUID-8A44CF3B-7FC0-4A49-8BDF-71575A27E588 [V1]
GUID-0C2DDCD0-EBC4-429D-9582-2E6B1E2DC763 [V2]
1. General
Rubber Track Tractor 1-7
79037272A
Find manuals at https://best-manuals.com

1.1.13 Before you start the engine
Start the engine only from the operator
compartment. Never short across the starter
terminals or batteries. Shorting can damage
electrical system or cause unexpected machine
movement.
Adjust the seat so full pedal travel can be achieved
with operator's back against seat back.
Make sure the machine is equipped with a lighting
system sufficient for job conditions. Make sure all
machine lights are working properly.
Before starting the engine or moving the machine,
make sure no one is under, around or on machine.
Make sure area is free of personnel.
To honk horn the key must be turned to “run” to
enable the horn. As a warning honk horn twice, to
alert others.
GUID-6CB742A7-222E-47ED-9806-1887BFD0CF24-high.jpg [High]
Fig. 6
1.1.14 Engine starting
Move all hydraulic controls to the hold position before starting the engine.
Make sure the machine is in park.
Diesel engine exhaust contains material of combustion which can be dangerous. Always operate the
engine in an open area. If in a closed in area, send the exhaust out.
WARNING:
Turning the steering wheel with the transmission in the neutral position and the engine at
idle speed will turn the machine.
WARNING:
Do not use ether. Ether will cause engine damage and/or personal injury.
Do not start the engine until the area is free of personnel to prevent personal injury because of unexpected
machine movement.
1.1.15 Before operation
Clear all personnel from around the machine and the area.
Clear all obstacles from machine's path. Be careful of dangers, (electrical power lines, ditches, etc).
Make sure all the windows are clean and attached in the closed position.
Adjust the rearview mirrors for best visibility near the machine. Make sure the horn, backup alarm (if
equipped) and all other warning devices are working correctly.
On the drawbar-towed implements, fasten a transport chain of sufficient capacity between the machine
drawbar support and implement. Give only enough slack in the chain to permit turning.
Only one instructor must be permitted to ride in the machine cab. Instructor must be seated in the
instructor seat with the seat belt fastened.
1.1.16 Operating procedures
The machine will turn with the transmission control lever in the neutral position when the engine is
operating and the steering wheel is turned.
GUID-344A454E-7D26-49D5-9AB4-3FEEFA88AFD5 [V3]
GUID-2E3C7B6F-A752-44EE-B844-B55CE068E322 [V1]
GUID-86EB8255-6A7F-48A0-9673-C9A47A0DB5E9 [V3]
GUID-D067D7D0-F186-4274-857C-255352F3AF1A [V1]
1. General
1-8 Rubber Track Tractor
79037272A

Only operate the machine while in the operator's seat. Securely connect the seat belt while operating the
machine. Only operate the controls while the engine is operating.
Do a check for the correct operation of all the controls and the protective devices.
As a warning operate the horn two times to tell others in the area to prevent personal injury because of
machine movement.
During operation of the machine, record damage and make necessary repairs.
A rollover of the machine can occur when doing work on hills, banks, or slopes. A rollover of the machine
can also occur when operating across ditches, ridges, or other unanticipated blockages.
Hold the implement approximately 40 cm (16 in) above the ground level while operating the machine. Do
not operate the machine near an overhang, near the edge of a cliff, or near edge of an excavation.
If the machine starts to sideslip on a grade, immediately decrease the load and turn machine downhill.
Be careful to prevent ground conditions which will cause the machine to rollover.
Keep the machine in control. Do not overload the machine more than the capacity.
Make sure the towing devices are sufficient for the work.
Make sure the components on the 3-point linkage are sufficient for the work.
Connect the trailing equipment only to a drawbar or hitch.
Do not straddle a wire cable.
When maneuvering to connect equipment, make sure no personnel are between machine and trailing
equipment. Hold up the hitch of trailing equipment to align equipment with drawbar.
Know the maximum dimensions of the machine.
When operating on icy or muddy roads, decrease the travel speed to prevent the loss of control of
machine.
After operating in muddy conditions, let sufficient time for tracks to reject unwanted material and moisture
before making high speed maneuvers. Belts that are wet and belts that are muddy can impede machine's
steering.
Decrease travel speed if the stability of the machine is noticeably reduced.
Slow the machine to a speed that controls the machine when declining a hill.
Use the service brakes if necessary, to control machine speed. Do not coast down a hill with transmission
in neutral.
Do not steer machine when crossing ditches. Ditches that are wide and/or ditches that are deep can let
the guide blocks sag below midwheels. This can cause the belt to come off.
Do not let passengers anywhere on the machine but on an approved passenger seat. Instructors must
have the instructor seatbelt securely connected during all operation.
1.1.17 Parking
Make sure to park the machine on a solid, level surface. Move the drive lever to the neutral position. Wait
a time for the park brake to automatically engage or press the park brake switch on the multifunction
armrest. Lower all implements to the ground. Move the throttle control lever to low idle and wait a time to
let the turbocharger cool. Stop the engine and take the key with you.
1.1.18 Operator station
Do not drill holes or weld on the cab rollover protective structure. (ROPS)
Any modifications to the inner operator station must not extend into the operator space.
Any item brought into the cab must not extend into defined operator space. Secure loose items. Objects
must not pose an impact hazard in rough terrain or if there is a rollover.
GUID-4571C9DD-C7B0-45F6-B234-9FFCE6DC789B [V1]
GUID-8E29B67F-A956-4F31-997B-8035E2F7CE16 [V2]
1. General
Rubber Track Tractor 1-9
79037272A

1.1.19 Cut and crush prevention
Support the equipment correctly when performing work below the equipment. Do not rely on the hydraulic
cylinders to hold up the equipment. An implement can fall if a control lever is moved or if a hydraulic line
breaks.
Never start the machine engine by shorting across the starter solenoid terminals. Machine movement can
occur causing runovers .
Never make adjustments while the machine is moving or while the engine is operating.
Whenever there are attachment control linkages, the clearance in the linkage area will change with
movement of the attachment.
Stay clear of all rotating parts and all moving parts.
Keep objects away from moving fan blades. The fan blades will throw objects and the fan blades can cut.
Do not use a wire tow cable that is kinked or frayed. Wear gloves when touching wire cable.
When hitting a retainer pin, the retainer pin can fly out causing personal injury. Make sure that there are no
people in the area when hitting a retainer pin. To prevent eye injury, wear protective glasses when hitting a
retainer pin.
Chips or other debris can fly off objects when hitting the objects. Make sure that others are clear of the
area before hitting any object.
1.1.20 Rollover protective structure
Do not make any modifications to the rollover
protective structure (ROPS) as this will change
protection provided. Do not change structure by
welding, cutting, adding weight, or drilling holes
into structure.
Any change not specifically authorized by AGCO
invalidates AGCO certification for ROPS. The
protection offered by ROPS will be impaired if
ROPS has structural damage or alteration. Damage
to structure can be caused by a turn over or by
falling objects.
Do not mount items (fire extinguishers, first aid
kits, work lights, etc.) by welding brackets or
drilling holes in ROPS. See dealer for mounting
guide lines.
TRHJA0110319901
Original art: ~/Desktop/Graphics/ST4/ACW3549100-1-ECN220604-.pdf
GUID-7998C354-06FC-455A-8D67-77F8F85E1A45-low.svg [Low]
Fig. 7
GUID-C5B3B243-B184-48C6-9CF2-F4FF44F55F30 [V4]
GUID-E9465583-03E5-41F2-90E8-26F033848D5D [V3]
1. General
1-10 Rubber Track Tractor
79037272A

1.1.21 Burn prevention
Do not touch any part of an operating engine.
Other components such as the transmission, the
axles and the oil reservoir can also be hot. Let the
engine cool before performing any maintenance
on the engine. Release all pressure in air, oil,
lubrication, fuel and cooling systems before
disconnecting any line fittings or related items.
GUID-81A39ABC-001C-4617-A089-FC6F702EF934-high.jpg [High]
Fig. 8
1.1.22 Coolant
When the engine is at operating temperature, the
engine coolant is hot. The coolant is also under
pressure. The radiator and all the lines to the
heater or engine contain hot coolant.
Any contact with hot coolant or with the steam
can cause severe burns. Allow the cooling system
components to cool before the cooling system is
drained.
Check the coolant level only after the engine has
been stopped.
Make sure the filler cap is cool before removing.
The filler cap must be cool enough to touch with a
bare hand. Remove the filler cap slowly to relieve
the pressure.
The cooling system conditioner contains alkali.
Alkali can cause personal injury.
Do not allow alkali to contact skin, eyes or mouth.
GUID-E5F20227-CB94-4A55-AD74-BE92B2949578-high.jpg [High]
Fig. 9
1.1.23 Oils
Pressurized hot oil and hot components can cause personal injury. Do not allow hot oil to contact skin. Do
not allow hot components to contact skin.
Remove the hydraulic tank filler cap only after the engine has been stopped.
The filler cap must be cool enough to touch with a bare hand. Follow the standard procedure in this manual
to remove the hydraulic tank and transmission filler caps.
1.1.24 High pressure lines
Do not bend or strike the high pressure lines. Do not install any lines that are bent or damaged.
Repair any loose or damaged lines. Leaks can cause fires. Consult your dealer for repair or for replacement
parts.
GUID-1527F9B5-890D-4E6F-AA25-C4A364C27BA9 [V2]
GUID-E3CEA189-D1EB-4633-BA3E-54F5758B4404 [V2]
GUID-BDBCD281-B073-40B0-A37C-9716BF8A6468 [V1]
GUID-B7B70DD9-7061-425E-B140-A2AAF9C49070 [V1]
1. General
Rubber Track Tractor 1-11
79037272A

DANGER:
Diesel fuel or hydraulic fluid under pressure can penetrate the skin or eyes. This can cause
serious personal injury, blindness, or death.
1.1.25 Fluid penetration
Always use a board or cardboard when checking
for a leak. Leaking fluid under pressure can
penetrate the body tissue. Fluid penetration can
cause serious injury and possible death. A pin hole
leak can cause severe injury. If fluid is injected into
the skin, get treatment immediately. Get
treatment from a doctor familiar with this type of
injury.
Check the lines, the tubes and the hoses carefully.
Do not use your bare hand instead, use a board or
cardboard to check for leaks. Tighten all
connections to the recommended torque.
Replace the hose if any of the following conditions
are present:
•End fittings are damaged or leaking.
• Outer coverings are rubbed or cut.
• Wires are showing.
• Outer coverings are ballooning.
• The flexible part of the hose has a kink.
• Outer coverings have embedded armoring.
• The end fittings are displaced.
IMPORTANT: Take care to contain fluids during
the performance of the inspection, the
maintenance, the testing, the adjusting, and the
repair of the machine. Have a suitable container
large enough ready to collect the fluid before
opening any compartment or disassembling any
component containing fluids. See the local
regulations and mandates when discarding fluids.
GUID-9A83C5CD-95EC-445B-A3A7-1DCF8FACFE45-high.jpg [High]
Fig. 10
1.1.26 Batteries
A lead acid battery generates flammable and
explosive gases. Keep sparks and flames away
from the battery.
WARNING: WARNING: Sulfuric acid in battery
electrolyte is poisonous. The acid is strong enough
to burn skin, eat holes in clothing and cause
blindness if got into eyes.
If acid contacts skin or clothing, flush with water
immediately. If acid contacts eyes get immediate
medical aid.
GUID-D371D878-EDE6-4896-BD8F-EA36F3639BB6-high.jpg [High]
Fig. 11
GUID-E76BB0CD-67F0-40CD-A4CC-D6B27E9CDCCE [V2]
GUID-074A76CF-7A49-411A-B5E5-757091C83001 [V1]
1. General
1-12 Rubber Track Tractor
79037272A

Wash hands after touching batteries and
connectors.
WARNING: WARNING: Batteries contain
electrolyte which is an acid that can cause
personal injury. Do not let the electrolyte contact
the skin or eyes. Always wear protective glasses
for servicing batteries.
GUID-6942F6BB-021E-47D8-8B36-8FB6CB6088DB-high.jpg [High]
Fig. 12
Never check battery charge by placing a metal
object across the terminal posts. Use a voltmeter
or a hydrometer.
WARNING: WARNING: Gases from a battery can
explode. Keep open flames or sparks away from
the top of the battery. Do not smoke in the battery
charging areas.
Incorrect jumper cable connections can cause an
explosion causing an injury.
To prevent an explosion, never charge a frozen
battery.
GUID-979CB295-E0EB-4004-99BA-74DDD900220E-high.jpg [High]
Fig. 13
1.1.27 Exhaust fumes
Always work in a correct ventilated area.
Engine exhaust fumes can cause sickness or
death. If necessary to run engine in a closed area,
use correct equipment to safely remove exhaust
fumes from area.
Always open the doors and get outside air into
area.
GUID-14D1976F-1E03-40BF-8B7E-EBFFE3E03995-high.jpg [High]
Fig. 14
GUID-7F41C7C3-DACC-46D2-ADC7-531D148964D3 [V2]
1. General
Rubber Track Tractor 1-13
79037272A

1.1.28 Noise prevention
Wear proper hearing protective devices such as
earmuffs or earplugs to prevent loss of hearing
due to high noise levels.
GUID-48B1B90D-20EB-42DB-A016-3CA0AB8AC168-high.jpg [High]
Fig. 15
1.1.29 Fire and explosion prevention
Use caution when refueling a machine. Do not
smoke while refueling and do not refuel near open
flames or sparks. Always stop engine before
refueling. Fill fuel tank outdoors.
All fuels, most lubricants, and some coolant
mixtures are flammable.
Flammable fluids leaking or spilled onto hot
surfaces or electrical components can cause a fire.
Fire may cause personal injury and property
damage.
Remove all flammable materials such as fuel, oil,
and debris from machine.
Do not let any flammable materials to accumulate
on machine.
Store fuels and lubricants in correctly identified
containers away from not approved persons. Store
rags with oil and any flammable materials in
protective containers.
Do not smoke in areas used for storing flammable
materials.
Do not operate machine near any flame.
Do not weld on lines or tanks that contain
flammable fluids. Do not flame cut lines or tanks
containing flammable fluid. Clean any such lines or
tanks fully with a nonflammable solvent before
welding or flame cutting.
Check all electrical wires daily. Repair any wires
loose or frayed before operating machine. Clean
and tighten all electrical connections.
Dust generated from repairing nonmetallic hoods
or nonmetallic fenders can be flammable and/or
GUID-8FDCA67C-244A-40BA-967B-3FA4E7667A7E-high.jpg [High]
Fig. 16
GUID-99732186-65C2-4EC3-8EDB-760F7ABE29B7 [V1]
GUID-43C214E0-CE68-4B1B-9480-B36317FC1602 [V3]
1. General
1-14 Rubber Track Tractor
79037272A

explosive. Repair such components in a well
ventilated area away from open flames or sparks.
Inspect all lines and hoses for wear or for
deterioration and replace if necessary.
Route hoses correctly. Lines and hoses must have
sufficient support and secure clamps. Tighten all
connections to recommended torque.
1.1.30 Fire extinguisher
An optional (1) mounting bracket can be installed
on the right front frame rail. The bracket is
designed to hold a 4.5 kg (10 lb) fire extinguisher.
Make sure that all clamps, guards, and heat
shields are installed correctly to prevent vibration,
rubbing and too much heat during the machine
operation.
Do not weld the bracket onto the cab ROPS frame
to install the fire extinguisher. Do not drill holes in
the cab ROPS frame to mount the fire
extinguisher.
GUID-E30F5D1A-50FD-4D6D-9D0E-9385BE099107-high.jpg [High]
Fig. 17
Make sure that a fire extinguisher is available and
be familiar with the operation. Inspect and service
the fire extinguisher regularly. Obey the
recommendations on the instruction plate.
GUID-C7689359-B5FD-4447-AA0C-F06C1C065EF4-high.jpg [High]
Fig. 18
1.1.31 Public road transportation
Always walk around and visually examine the machine before moving on a public road. As a warning to
others in the area, honk the horn two times before starting engine. Do a check for damage and/or
defective components that can make a dangerous condition. Make sure all machine systems operate
correctly including (but not limited to):
•front road lamps
• tail and brake lamps
• amber hazard lights
• parking brake
• horn
• windshield wiper and washer
• rear view mirrors
• etc.
Repair or replace a component not in correct operating order.
GUID-6722D2A5-CFD1-4EC0-9681-E8C8ED018312 [V1]
GUID-83333B29-DD08-4E83-9040-BB07F2BF96DE [V3]
1. General
Rubber Track Tractor 1-15
79037272A

Do not drive at a speed causing machine to lose control.
Obey all traffic rules. Operate the machine with hazard lights on, unless prevented by law. The operation of
work lamps while driving on public roads is prohibited. Use of road lamps while moving on public roads is
the operator's responsibility.
NOTE:
When the Speed Indication Symbol (SIS) is installed in the rear window, be sure to close the rear window
when transporting the machine on the road.
1. General
1-16 Rubber Track Tractor
79037272A

1.2 Machine identification information
GUID-B4C4B3E4-103B-4436-AA92-69EC893E09B9-high.jpg [High]
Fig. 19
GUID-50F4664B-3C1F-4977-8F2C-B14B939DD001 [V2]
1. General
Rubber Track Tractor 1-17
79037272A
