Fimco BB-308 User manual

Page 1
Technical Specifications
 Pistol-Grip Handgun
 25’ x 3/8” Handgun Hose
 150 p.s.i. Maximum Working Pressure
 Handgun Holder Bracket and mounting hardware
 Brass valve for ON/OFF control to spray line
Assembly
See Page 3 for assembly instructions
NOTE:
This handgun kit is designed to adapt to models LG-27-3PT
and LG-55-3PT Fimco 3-Point Sprayers
Model: BB-308
(5300675)
Handgun Kit
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: [phone] : Toll Free Fax: [phone]
[5004388 (11/18)]
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
handgun kit.
Retain a copy of your receipt for your unit,
as it will be required to validate any warranty service
Products are warranted against manufacturer or workmanship
defects for one year from date of purchase for home owner
usage and 90 days for commercial usage.
For technical assistance, visit our website @
www.fimcoindustries.com or call: TOLL FREE @ 1-800-831-0027
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information…
 Correct Part Description and/or part number
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER’S MANUAL

Page 2
Exploded View/Parts List:
BB-308 Handgun Kit
5300675
28”

Page 3
Assembly
1. This kit is to be installed between the directo
-valve and the pressure relief valve
2. Loosen the hose clamp on the bypass hose
near the pressure relief valve. Remove the
hose from that fitting
3. Remove the pressure relief valve from the
directo-valve
4. Thread the close nipple and the tee fitting
onto the directo-valve
5. Assemble the brass valve, fittings, hose and
handgun onto the tee fitting, as shown in
exploded view above
6. Reassemble the pressure relief valve to the
tee fitting and reconnect the bypass hose to
the fitting
7. Use the hose and gun holder shown to
support the handgun on the 3-point unit
Directo-Valve Pressure Relief Valve
Testing The Sprayer
It is best to test the completed handgun sprayer with plain
water before actually spraying chemicals. This will enable you
to determine if the assembled unit has any plumbing leaks. It
is best to start your handgun sprayer under little or no pres-
sure. After starting the sprayer at low pressure, it is best to
increase pressure in steps to the desired operating pressure.
Conditions of weather and terrain must be considered when
setting the sprayer. Do not spray on windy days. Protective
clothing must be worn in some cases.
Handgun Operation
Squeezing the lever allows the handgun to spray. Adjustable
from a cone pattern to a straight stream pattern.
WARNING: Some chemicals will damage the plumbing com-
ponents if allowed to soak untreated for a length of time!
ALWAYS flush the system after each use.
If handgun nozzle needs cleaning, remove from the handgun
and soak in warm soapy water. Clean with a soft bristled
brush or toothpick if necessary. Never use a metal object.
Even the slightest damage can change the flow rate and
spray distribution. Water rinse and dry the tips before storing.
Proper care and maintenance will prolong the life of your
sprayer. Follow your sprayer’s maintenance and winter
storage instructions.
NOTES:

Page 4
LIMITED WARRANTY FOR NEW FIMCO, IND. EQUIPMENT
WHO MAY USE THIS LIMITED WARRANTY. This limited warranty (the “Limited Warranty”) is provided by Fimco, Ind. to the original purchaser
(“you”) of the Equipment (as dened below) from Fimco, Ind. or one of Fimco, Ind.’s authorized dealers. This Limited Warranty does not apply to
any subsequent owner or other transferee of the Equipment. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
WHAT THIS LIMITED WARRANTY COVERS AND FOR HOW LONG. Fimco, Ind. warrants that any new Equipment will be free from defects in
material and workmanship for a period of one (1) year (homeowner), 90 days (commercial user), aer delivery of the Equipment to you (the
“Warranty Period”). The Warranty Period is not extended if Fimco, Ind. repairs or replaces the Equipment.
WHAT IS NOT COVERED BY THIS LIMITED WARRANTY. This Limited Warranty does not apply to: (1) used Equipment; (2) any Equipment that has
been altered, changed, repaired or treated since its delivery to you, other than by Fimco, Ind. or its authorized dealers; (3) damage or deprecia-
on due to normal wear and tear; (4) defects or damage due to failure to follow Fimco, Ind.’s operator’s manual, specicaons or other wrien
instrucons, or improper storage, operaon, maintenance, applicaon or installaon of parts; (5) defects or damage due to misuse, accident or
neglect, “acts of God” or other events beyond Fimco, Ind.’s reasonable control; (6) accessories, aachments, tools or parts that were not manu-
factured by Fimco, Ind., whether or not sold or operated with the Equipment; or (7) rubber parts, such as res, hoses and grommets.
HOW TO OBTAIN WARRANTY SERVICE. To obtain warranty service under this Limited Warranty, you must (1) provide wrien noce to Fimco,
Ind. of the defect during the Warranty Period and within thirty (30) days aer the defect becomes apparent or the repair becomes necessary, at
the following address: Fimco, Ind., 1000 Fimco Lane, North Sioux City, SD 57049; and (2) make the Equipment available to Fimco, Ind. or an
authorized dealer within a reasonable period of me. For more informaon about this Limited Warranty, please call: 800-831-0027.
WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the condions set forth above are fullled and the Equipment or any part
thereof is found to be defecve, Fimco, Ind. shall, at its own cost, and at its opon, either repair or replace the defecve Equipment or part.
Fimco, Ind. will pay for shipping and handling fees to return the repaired or replacement Equipment or part to you.
LIMITATION OF IMPLIED WARRANTIES AND OTHER REMEDIES. THE REMEDIES DESCRIBED ABOVE ARE YOUR SOLE AND EXCLUSIVE REMEDIES,
AND FIMCO, IND.’S SOLE LIABILITY, FOR ANY BREACH OF THIS LIMITED WARRANTY. TO THE EXTENT APPLICABLE, ANY IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIM-
ITED IN DURATION TO THE WARRANTY PERIOD, AND THE REMEDIES AVAILABLE FOR BREACH THEREOF SHALL BE LIMITED TO THE REMEDIES
AVAILABLE UNDER THIS EXPRESS LIMITED WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. IN NO EVENT SHALL FIMCO, IND.’S LIABILITY UNDER THIS LIMITED WARRANTY EX-
CEED THE ACTUAL AMOUNT PAID BY YOU FOR THE DEFECTIVE EQUIPMENT, NOR SHALL FIMCO, IND. BE LIABLE, UNDER ANY CIRCUMSTANCES,
FOR ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL OR PUNITIVE DAMAGES OR LOSSES, WHETHER DIRECT OR INDIRECT. SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
Warranty Info
