LED STATUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . 12
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . 13
DISPOSAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SUOMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2
INTRODUCTION
USER GUIDE
IMPORTANT: If you are installing this product for
use by others, you must leave this manual (or a
copy of it) for the end user.
Wi-Safe 2 is the very latest in wireless technology from
Sprue Safety Products. It provides a network of wireless
radio frequency (RF) communication which can trigger
Wi-Safe 2 Alert products to alarm in the event of danger.
For use with Wi-Safe2 smoke, Heat and Carbon
Monoxide Alarms.
PLEASE READ THIS GUIDE IN FULL BEFORE USING
YOUR WTSL-F CONTROL UNIT.
Battery powered control unit with Test, Silence and
Locate function, non-replaceable 3V DC battery.
W2 module contained within product independently
tested to RF standard ETSI EN 300 220-2 V2 3 2 (2010-
02) by TRaC Global Ltd.

3
INSTALLATION GUIDE
FEATURES:
• Wi-Safe 2® technology, enabling wireless interlinking
between other Wi-Safe 2 products.
• Test / Silence ( ) button, allowing you to regularly test
all wirelessly interlinked alarms on a network Pressing
the silence button will reduce the sensitivity of alarms
for up to 10 minutes, unless carbon monoxide has
been detected, in which case you can use the ‘Locate’
function below to nd the source alarm.
• Locate button ( ), allowing you to silence all alarms but
the initiating alarm, during an alarm condition During a
fault condition, this feature will allow you to locate the
alarm in fault, in a similar way.
• Alarm memory function - allows you to investigate
previous alarm events.
• 10 year sealed for life battery
• 5 year warranty
• Fault indicator
• Carbon monoxide alarm indicator
• Test / Silence button
• Smoke/Heat alarm indicator
• Locate button
POSITIONING:
This Alarm Control Unit is suitable for use in domestic
premises only It should be installed at an accessible point
on the wall, in a location where it will not be accidentally
operated or knocked.

4
INSTALLATION ACTIVATING THE ALARM
CONTROL UNIT
• Ensure this Alarm Control Unit is installed by a
competent person who feels able to install it according
to the instructions
• Read all installation instructions prior to installing this
product
WARNING: To prevent injury, this Alarm Control Unit
must be securely attached to the wall in accordance
with the installation instructions.
To mount the bracket onto a wall:
Please ensure that you use the screws provided, as they
were chosen specically for use with this product. Drill
holes into the wall and insert supplied wall plugs. Screw
the bracket in place
The Alarm Control Unit has a sealed-in nonreplaceable
battery. To activate the control unit remove the
disabling tab. Upon activating the control unit all three
LED’s should simultaneously  ash twice, to indicate
that they are working.
Once the alarm is activated it can then be learnt into a
Wi-Safe 2 network, before securing to the wall bracket.
WIRELESS INTERLINK
The Alarm Control Unit is designed to be used as a
remote interface on a network of up to 49 products
within the Wi-Safe 2 range. The Alarm Control Unit can
be used to test, silence or locate any alarms on the Wi-
Safe 2 network. It is not designed to communicate with
wireless alarms from other ranges or manufacturers.
The control unit needs to be ‘learned-in’ or interlinked,
in order to communicate within the network.

5
Wi-Safe 2 enables wireless communication with any
other product with Wi-Safe 2 technology inside .
When one alarm detects smoke / heat / carbon
monoxide, the wireless module inside sends a signal
to all the connected alarms, ensuring almost
instantaneous reaction across the network.
HOW TO ‘LEARN-IN’ THE ALARM CONTROL
UNIT TO A WI-SAFE 2 NETWORK:
1 Using a ballpoint pen, briey push and release the
‘learn button’ on the back of the control unit. The red
LED next to the learn button will ash briey then
light up for approximately 5 seconds.
2 During these 5 seconds you need to briey press the
test button on an alarm already in the network, to
wirelessly interlink the two. The alarm will sound its
audible test pattern.
3 The red LED on the back of the control unit will ash
to indicate that it has been‘learned-in’successfully.
If the test button is not pressed quickly enough, the
‘learnin’process will fail If this happens, repeat
the process. Your Alarm Control Unit counts as one unit
within the network If it is installed retrospectively,
then the existing network cannot exceed 49 units
in size.
4 To complete the installation simply slide the control
unit onto the bracket. The control unit is now part
of the whole network. The method above assumes
you have already installed your alarm network, prior
to installing your Alarm Control Unit. If you want to
install your Alarm Control Unit rst, you can learn
your smoke, heat and CO alarm into it by following
the instructions in your alarm manual, using the
Alarm Control Unit as alarm 1.
MAKING THE ALARM CONTROL UNIT TAMPER PROOF
Do not complete this action until you have wirelessly
interlinked all of your alarms. The Alarm Control Unit
is provided with an anti-tamper feature, ensuring,
where needed it cannot be removed from the wall.
To make use of this feature you will need to push out
the two blanking plates on the top right-hand

6
side of the bracket, using a small screwdriver, being
careful to support the bracket fully whilst doing so.
Once the rest of the installation is complete, and the
control unit is xed to the bracket it can only be
removed using the following method:
Insert a small screwdriver into the hole on the top
right-hand corner of the control unit, until it stops,
this will disengage the lock, then gently ease the
control unit up to release it from the bracket.
TESTING THE ALARM SYSTEM
Press the Test / Silence ( ) button to conrm that the
control unit is operating properly. This will instigate
a three minute test. All networked alarms should
sound. To stop the test (earlier than 3 minutes),
simply press the Test / Silence ( ) button again. This
test should be performed on a weekly basis.
PRODUCT FUNCTIONALITY
Test button:
This allows you to test all wirelessly interlinked alarms
from one centralised location.
Silence button:
This will silence all wirelessly interlinked smoke and
heat alarms and reduce the system sensitivity for up
to 10 minutes.
Locate button:
In an alarm event this will silence all wirelessly
interlinked alarms except the initiating alarm which
has sensed Carbon Monoxide/Smoke.

7
Smoke/heat alarm indicator:
This indicates that a smoke / heat alarm has been
activated.
Carbon monoxide indicator:
This indicates that a carbon monoxide alarm has
been activated.
Fault indicator:
This indicates a fault with the control unit or one of
the alarms within the network.
LOCATE BUTTON
If the alarms are sounding and an alarm indicator is
ashing, but there’s no obvious hazard, pressing
the ‘Locate’ button ( ) will silence all wirelessly
interlinked alarms except for the initiating alarm
which has sensed smoke / heat or carbon
monoxide.
Within two minutes the system will return to
normal operation and the alarms will continue to
sound if smoke / heat or carbon monoxide is still
present. To make locating the alarm easier, the
control unit can be removed from its bracket and
carried around the property (providing the tamper
proof function has not been engaged), allowing
you to press the ‘Locate’ or ‘Test’ button whilst
moving from room to room.

8
ALARM MEMORY
If one of the alarm indicators is ashing every 10
seconds this indicates that a smoke alarm, heat alarm or
carbon monoxide alarm has previously been activated.
Pressing the ‘Locate’ button ( ) will clear the LEDs and
sound the source alarm so you can investigate this
further. You can press the ‘Locate’ button ( ) repeatedly
until the source alarm is identied.
Please Note: Only the most recent alarm event will
be visible. If both a CO and smoke / heat alarm have
previously been activated, both LED’s will show but the
CO alarm will always take precedence, and this is the
alarm which will sound. Never ignore an alarm. If there
is evidence of an alarm event, be sure to investigate
further.
SILENCE BUTTON
If the alarms are sounding and the smoke / heat alarm
indicator is ashing, but there’s no obvious hazard,
pressing the ‘Silence’ button ( ) will silence all wirelessly
interlinked alarms and reduce the system sensitivity for
up to 10 minutes. However if excessive smoke is sensed
the silence function will be overridden. The indicator
will continue to ash unless the smoke disappears.
Please Note:
An alarm cannot be silenced using the Alarm Control
Unit if carbon monoxide has been detected,
however the ‘Locate’ function will allow you to nd out
which of the CO alarms is the initiating alarm.

9
FAULT DETECTION
A. In case you need to locate the unit again, please wait
for 2 minutes before trying to locate for the SOS pattern.
Take down the alarm which is sounding. Unlearn the
alarm from the network using a ball point pen in the
circular ‘learn-in’ hole in the back of the alarm. Briey
push and release and then push and hold the ‘learn-in’
button. The red LED will remain illuminated during this
process. When the red LED goes out, release the button,
it will then ash twice, followed by three further ashes
to illustrate that the alarm has successfully been ‘un-
learnt’ from the network.
Reorganise the network as detailed in the next
paragraph. The LEDs indicating a fault should now
have stopped ashing and the faulty alarm can now be
replaced with a new alarm if required.
B. Check to see that all alarms are on their base plate
and activated. If all alarms are activated, clear the fault
by pressing the locate button twice.
REORGANISING A NETWORK
If you have un-learnt and replaced or removed any
alarms, you can ‘reorganise’ in order to optimise the
network performance. To do this you will need to press
and hold the ‘Locate’ button for 5 seconds. The Alarm
Control Unit will then enter ‘Reorganisation Mode’,
during which time you will see a series of ashes from
the LEDs. The time taken for this process to complete
will depend on the number of units in the network.
If successful, once the reorganisation is complete, the
Control Unit should return to standby mode, with no
LEDs ashing.
If the reorganisation is not successful, and LEDs are
still ashing (all 3 LED’s ash together (+ +) 3times,
then a fourth ash (+ only) occurs, repeatedly), you will
need to exit ‘Reorganisation Mode’. To do this hold the
‘Locate’ button for 5 seconds, wait for 5 minutes and
then repeat the process above. Prior to performing
network reorganisation, test the network by pressing
the test button on one of the randomly selected units
and ensure that all units chirp/ash in response. This is
essential to make sure that all the units are communi-

10
open.
• Ring your gas or other fuel supplier on their emergency
number; keep the number in a prominent place.
LED INDICATORS
• Red CO LED
• Red Smoke / Heat LED
• Amber Fault LED
LED STATUS
• Flashing for 10 seconds, every hour. The Alarm
Control Unit is not part of a network. Please refer to
the ‘Wireless Interlink’ section to ‘learnin’ the control
unit to the network.
• Flashing rapidly every second, Alarm: A carbon
monoxide leak has been detected. Keep calm
and open the doors and windows to ventilate the
property.
• Flashing rapidly every second:
cating with each other and ensures network
reorganisation does not delete wanted units. In case
one of the working units is out of range for networking,
please check the installation position of the units and
adjust/install an additional unit to help with the routing
of messages.
WHEN AN ALARM SOUNDS
Never ignore an alarm. If there is a re evacuate the
premises and call the re brigade. If the source of
the alarm is not immediately apparent check which
indicator is ashing on the control unit.
If the CO indicator is ashing:
• Keep calm and open the doors and windows to
ventilate the property.
• Stop using all fuel-burning appliances and ensure, if
possible, that they are turned o󱐯.
• Evacuate the property leaving the doors and windows

11
Alarm - A carbon monoxide leak has been detected.
Keep calm and open the doors and windows to
ventilate the propert.
• Flashing rapidly every second:
Alarm: Smoke / heat has been detected. Either the
carbon monoxide indicator or the smoke / heat
indicator or both, are ashing every 10 seconds.
This indicates that one of the alarms has previously
been activated. Please refer to the ‘Locate’ section of
this manual. Either the carbon monoxide indicator or
the smoke / heat indicator or both, are ashing.
• Double ashing every second:
An alarm on the network has developed a fault. Please
refer to the‘Fault Detection’section of this manual.
• All 3 LED’s ash together (CO + ! + ^ ) 3 times, then a
fourth ash (CO + ^ only) occurs. This ash pattern
is repeated. This indicates that the‘Reorganisation
Mode’has been unsuccessful. To exit ‘Reorganisation
Mode’hold the ‘Locate’ button for 5 seconds
,wait a couple of minutes and then press and hold the
‘Locate’ button for 5 seconds to start ‘Reorganisation
Mode’again
• Flashing once every 5 seconds: Low battery condition
or the end of the product life. The control unit should
be replaced as soon as possible.
• Flashing rapidly: This indicates an internal fatal radio
failure. Please contact technical support.

12
TROUBLESHOOTING
Indication:
• No lights come on when I press any of the buttons on
the Alarm Control Unit.
This may indicate that the control unit has not been
successfully activated, see section ‘Activating the Alarm
Control Unit’ If the unit still fails to activate please
contact Technical Support.
• When pressing the test button nothing is happening.
This indicates that the control unit has not been
successfully activated,

13
• Do not attempt to repair the control unit.
• Do not attempt to change the battery.
• Do not remove any screws or open the main casing
of the control unit Any attempt to do so may cause
malfunction and will invalidate the warranty.
DISPOSAL
Waste electrical products should not be disposed of
with your other household waste. The Alarm Control
Unit is ideally suited for disposal within the waste
electronic and electrical equipment (WEEE) recycling
scheme. Please recycle where facilities exist. Check
with your local authority, retailer or contact our
Technical Support team for recycling/disposal advice,
as regional variations apply.
WARNING: Do not burn or dispose of in re.
WARNING: If your Alarm Control Unit is dropped or
damaged, as a precaution, it should be removed
from the building and you should contact Technical
Support: 0800 141 2561.
see section ‘Activating the Alarm Control Unit’.
• Unable to remove the control unit from its bracket.
You need to disengage the locking pins. Refer to the
‘Making the Alarm Control Unit Tamper proof’ section.
MAINTENANCE
This Alarm Control Unit will act as a remote interface
between the alarms in your home when maintained
properly. To ensure the reliability of the control unit:
• Keep the control unit free from dust by gently
vacuuming the case with a soft brush attachment every
3 months.
• Never use cleaning solutions on the control unit,
simply wipe with a damp cloth.
• Do not paint the control unit
• Do not spray aerosols on or near the control unit.
• Do not use any solvent based products near the
control unit.

14
WARRANTY
Sprue Safety Products Ltd warrants to the original
purchaser that the enclosed WTSL-F Alarm
Control Unit be free from defects in materials and
workmanship under normal residential use and
service for a period of ve years from the date of
purchase. Provided product is sent back to Sprue
Safety products with proof and date of purchase,
SprueSafety Products Ltdherebywarrantsthatduring
the ve year period commencing from the date of
purchase Sprue Safety Products Ltd, at its discretion,
agrees to replace the unit free of charge. The warranty
on any replacement WTSL-F Alarm Control Unit, will
last for the remainder of the period of the original
warranty in respect of the unit originally purchased
– that is from the date of original purchase and not
from the date of receipt of the replacement product
Sprue Safety Products Ltd reserves the right to o󱐯er
an alternative product similar to that being replaced
if the original model is no longer available or in stock
This warranty applies to the original retail purchaser
from the date of original retail purchase and is not
transferable Proof of purchase is required.
This warranty does not cover damage resulting
from accident, misuse, disassembly, abuse or lack of
reasonable care of the product, or applications not in
accordance with the user guide It does not cover events
and conditions outside of Sprue Safety Products Ltd’s
control, such as Acts of God (re, severe weather etc)
It does not apply to retail stores, service centres or any
distributors or agents. Sprue Safety Products Ltd will
not recognise any changes to this warranty by third
parties Sprue.

15
SISÄLTÖ
Tämä käyttöohje on saatavana myös muissa muodoissa. Soita
numeroon [phone] saadaksesi lisätietoja.
ESITTELY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
KÄYTTÄJÄN OHJEET . . . . . . . . . . . . . . . . . . . . . . . 16
ASENNUSOHJE . . . . . . . . . . . . . . . . . . . . . . . . . . 17
PAIKANNUKSEN . . . . . . . . . . . . . . . . . . . . . . . . . 17
ASENNUS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
OHJAUSYKSIKÖN AKTIVOINTI . . . . . . . . . . . . . . . . . 18
MITEN “OPETAN”
OHJAUSYKSIKÖN WI-SAFE 2 -VERKKOON. . . . . . . . . . 19
OHJAUSYKSIKÖN“PEUKALOINTISUOJAUS”. . . . . . . . . . 19
HÄLYTYSJÄRJESTELMÄN TESTAAMINEN. . . . . . . . . . . . . 20
TUOTTEEN TOIMINTA . . . . . . . . . . . . . . . . . . . . . . . 20
PAIKANNA-PAINIKE . . . . . . . . . . . . . . . . . . . . . . . 21
MYKISTYSPAINIKE . . . . . . . . . . . . . . . . . . . . . . . . 22
HÄLYTYSMUISTI . . . . . . . . . . . . . . . . . . . . . . . . . 22
VIKATILAN HAVAITSEMINEN. . . . . . . . . . . . . . . . . . 23
VERKON UUDELLEENORGANISOINTI. . . . . . . . . . . . . 23
KUN VAROITIN HÄLYTTÄÄ . . . . . . . . . . . . . . . . . . . 24
LED TILA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
VIANETSINTÄ . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
YLLÄPITO JA HUOLTO. . . . . . . . . . . . . . . . . . . . . . 27
TUOTTEEN HÄVITTÄMINEN . . . . . . . . . . . . . . . . . 27
TAKUU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

16
ESITTELY
KÄYTTÄJÄN OHJEET
TÄRKEÄÄ: Jos asennat tätä tuotetta muiden
käyttöön, sinun on poistettava tämä käsikirja (tai kopio
siitä) loppukäyttäjälle.
Wi-Safe 2 on Sprue Safety Productsin viimeisin langaton
tekniikka. Se tarjoaa langattoman radiotaajuisen (RF)
tiedonsiirtoverkon, joka voi laukaista Wi-Safe 2 Alarm
-tuotteet hälytykseen vaaratilanteessa.
Käytetään Wi-Safe 2-palo-, lämpötila- ja
häkävaroittimien kanssa
LUE TÄMÄ OHJEKIRJA, ENNNENKUIN ALAT KÄYTTÄÄ
WTSL-F OHJAUSYKSIKKÖÄ
Akkukäyttöinen ohjausyksikkö, jossa testi-, mykistys- ja
paikannustoiminto. Kiinteä 3 V akku.
Yksikkö sisältää W2-moduulin, jonka (2010-02) TRaC
Global Ltd on puolueettomasti testannut RF-standardin
ETSI EN 300 220-2 V2 3 2 mukaisesti.

17
ASENNUSOHJE
OMINAISUUDET:
• Wi-Safe 2®-tekniikka, joka mahdollistaa langattoman
yhteyden muiden Wi-Safe 2 -tuotteiden välillä.
• Testi- / mykistys () -painike, jonka avulla voit testata
säännöllisesti kaikki langattomasti toisiinsa liitetyt
varoittimet verkossa. Mykistyspainikkeen painaminen
vähentää varoittimien herkkyyttä 10 minuutin ajaksi,
ellei hiilimonoksidia ole havaittu, jolloin voit käyttää
alla olevaa “Paikannus” -toimintoa varoittimen
paikantamiseksi.
• Paikannuspainike (), jonka avulla voit mykistää
hälytystilanteessa kaikki muut varoittimet, paitsi
sen varoittimen, joka on laukaissut hälytyksen.
Vikatilanteessa tämä ominaisuus antaa vastaavasti
mahdollisuuden paikantaa varoittimen, joka on
laukaissut vikahälytyksen.
• Hälytysmuistitoiminto - voit tutkia aiempia
hälytystapahtumia.
• Kiinteä 10 vuoden akku.
•
• 5 vuoden takuu
• Vikailmaisin
• Häkävaroittimen hälytysilmaisin
• Testi- / mykistyspainike
• Palo- / lämpötilavaroittimen hälytysilmaisin
• Paikannuspainike
PAIKANNUKSEN:
Tämä ohjausyksikkö sopii käytettäväksi vain kotitalouksissa.
Se tulisi asentaa seinälle sellaiseen paikkaan, jossa se on
helposti ulottuvilla, mutta samalla suojassa tahattomalta
käytöltä ja kolhiintumiselta.

18
ASENNUS OHJAUSYKSIKÖN AKTIVOINTI
• Varmista, että tämän ohjausyksikön asennuksen
suorittaa pätevä henkilö, joka noudattaa annettuja
asennusohjeita.
• Lue kaikki asennusohjeet ennen tämän tuotteen
asentamista.
VAROITUS: Vahinkojen välttämiseksi varmista, että
ohjausyksikkö asennetaan seinään asennusohjeiden
mukaisesti.
Kiinnitä pidike seinälle seuraavasti:
Varmista, että käytät toimitettuja ruuveja, koska ne on
valittu nimenomaan käytettäväksi tässä asennuksessa.
Poraa reiät seinään ja aseta mukana toimitetut
seinätulpat reikiin. Ruuvaa kannatin paikalleen.
Ohjausyksikössä on sisäänrakennettu kiinteä akku.
Ohjausyksikön aktivoimiseksi on poistettava akun
suojaliuska. Ohjausyksikköä aktivoitaessa kaikki kolme
LEDiä välähtävät samanaikaisesti kaksi kertaa. Tämä
osoittaa, että ne toimivat normaalisti. Kun yksikkö on
aktivoitu, sitä voidaan opettaa toimimaan Wi-Safe 2
-verkossa, ennen kuin se kiinnitetään seinätelineeseen.
LANGATON YHTEYS
Ohjausyksikkö on suunniteltu toimimaan kauko-
ohjattavana käyttöliittymänä verkossa, jossa voi olla
enintään 49 Wi-Safe 2 -tuella varustettua tuotetta.
Ohjausyksikköä voidaan käyttää testaamaan,
mykistämään tai paikantamaan varoittimia. Wi-Safe
2-verkko ei ole yhteensopiva muiden langattomien
tuotesarjojen tai toisten valmistajien tuotteiden kanssa.
Jotta ohjausyksikkö toimisi Wi-Safe 2-verkossa se on
ensin “opetettava” tai linkitettävä yhteen verkkoon
kuuluvien muiden tuotteiden kanssa.
