Firesense 61280 User manual

Contents DANGER
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
General Safety Information.......................................
Assembly Instructions………………………………..
Components & Hardware........................................
Additional Requirements........................................
Installation Process…………………………………...
Step1 - Attach Wheel Assemblyto Base..................
Step 2 – Attach Sand Box to Base...........................
Step 3 –Attach L-ShapedBracketsto Base..............
Step 4 – Attach Post to Cylinder Housing Top and
Attach Cylinder Housing to Base….......................
Step 5 – Table
Installation............……………. ........
Step 6 – Attach Reflector Studs to Head Assembly
Step 7 – Attach Head Assembly to Post..................
Step 8 – Install Reflector.........................................
Step 9 – Attach Reflector Assembly to Studs..........
Step 10 – ConnectHose & Regulator to Cylinder...
Leak Check.............................................................
Operation................................................................
Operation Checklist................................................
Troubleshooting......................................................
Maintenance...........................................................
Storage...................................................................
Service....................................................................
Warranty ................................................................
1-3
3-4
4 WARNING
WARNING indicates an imminently hazardous situation
which, if not avoided, could result in death or serious injury.
4
4-5
5
5
5
5
6
6
7
7
8
8-10
10
11
11-12
12
12
CAUTION
CAUTION indicates an imminently hazardous situation
which, if not avoided, may result in minor or moderate
personal injury, or property damage.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vaporand liquids in the vicinity of
this or any other appliance.
WARNING: For Outdoor Use Only
General Safety Information
This manual contains important information about the
assembly, operation and maintenance of this patio heater.
General safety information is presented in these first few
pages and is also located throughoutthe manual.
Keep this manual for future reference and to educate
new users of this product. This manual should be read in
conjunction with the labeling on the product.
Safety precautions are essential when any mechanical
or propane fueled equipment is involved. These
precautions are necessary when using, storing, and
servicing.
The following symbols shown below are used extensively
throughout this manual.
Always heed these precautions as they are essential
when using any mechnical or fueled equipment.
a
f
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Read the instructions
thoroughly before installing or servicing this
equipment.
DANGER
Failure to comply with the precautions and instructions
provided with this heater can result in death, serious bodily
injury and property loss or damage from hazards of fire,
explosion, burn, asphyxiation, and/or carbon monoxide
poisoning.
Only persons who can understand and follow the
instructions should use or service this heater.
1
3
4
13

2
DANGER
• EXPLOSION - FIRE HAZARD
•Keep solid combustibles, such as building materials,
paper or cardboard, a safe distance away from the heater
as recommended by the instructions.
•Provide adequate clearances around air openings into
the combustion chamber.
•Never use the heater in spaces which do or may contain
volatile or airborne combustibles, or products such as
gasoline, solvents, paint thinner, dust particles or unknown
chemicals.
•During operation, this product can be a source of
ignition. Keep heater area clear and free from combustible
materials, gasoline, paint thinner, cleaning solvents and
other flammable vapors and liquids. Do not use heater in
areas with high dust content. Minimum heater clearances
from combustible materials: three (3) feet from the sides &
two (2) feet from the top.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish all open flames.
3. If odor continues, immediately call your gas
supplier.
WARNING
We cannot foresee every use which may be made of our
heaters.
Check with your local fire safety authority if you have
questions about heater use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local authorities
can advise you about these.
If no local codes exist, follow National Fuel Gas Code,
ANSI Z223.1. In Canada, installation must conform to local
codes. If no local codes exist, follow the current National
standards of CANADA CAN/CGA-B 149.2.
DANGER
• CARBON MONOXIDE HAZARD
•This heater is a combustion appliance. All combustion
appliances produce carbon monoxide (CO) during the
combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of CO if used
and maintained in accordance with all warnings and
instructions. Do not block air flow into or out of the heater.
•Carbon Monoxide (CO) poisoning produces flu-like
symptoms, watery eyes, headaches, dizziness, fatigue and
possibly death. You can't see it and you can't smell it. It's
an invisible killer. If these symptoms are present during
operation of this product get fresh air immediately!
•For outdoor use only .
•Never use inside a houseor any other unventilated or
enclosed areas.
•This heater consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid endangering
your life.
CAUTION
• SERVICE SAFETY
•Keep all connections and fittings clean. Make sure
propane cylinder valve outlet is clean.
•Inspect hose before use. Replace if there is evidence of
abrasion or wear.
•During set up, check all connections and fittings for leaks
using soapy water. Never use a flame.
•Use as a heating appliance only. Never alter in any way or
use with any other device.
•Check entire hose at least annually.
WARNING
• BURN HAZARD
•Never leave heater unattended when hot or in use.
•Keep out of reach of children.

Installation process Assembly time: 40 minutes
S
.tep 1 – Attach Wheel Assembly to Base
Line up holes in Wheel Bracket with corresponding
.Finger tighten the bolts.
holes in Base and insert 2 - M8x12 Bolts through holes.
.
Be sure that the Wheel Assembly is parallel to the
base, and fully tighten bolts
Wheel Assembly
2 M8x12 Hex Bolts
 For best stability, fill the sand box with sand.
Step 2 – Attach Sand Box to Base
Additional Requirements
The following items are not included, but are necessary for
.Philips screwdriver w/ medium blade.
the proper assembly of your heater. Do NOT attempt to
.Adjustable opening wrench.
assemble without proper tools.
.Leak Detection Solution (Instructions on how to make .Slip 4 M8 Flat Head Screws through holes of Base.
solution are included onpage 8 )
Note: You must follow all steps to properly assemble
heater. 4 M8 Flat Head Screws 4 M8 Nuts
4
Picture Qty Description Used in
Step(s)
4 M6x12 Hex Bolt 4
4 M6 Flange Nut 4
8 M6x10 Round Head Screw 4
8 M5 Flange Nut 4
9 M6 Cap Nut 8
9 M6x10 Flat Head Screw 8
3 Wing Nut 9
3 Reflector Stud 6
4 Small Bolt
*Pre-inserted in Head Assembly 7
4 Lock Washer
*Pre-inserted in Head Assembly 7
4 M8 Flat Head Screw
*Pre-assembled to base with
sand box
2
6 M8 nut
*4 pcs. pre-assembled to base
with sand box
1/2
6 M8x12 Hex Bolt 1/3
13 M8 Flat Washer 3/6/9
4 L-Shaped Bracket 3
1 Plastic Ring 4
1 Plastic Fastener (optional) 5
1 Wrench As
needed
Hardware
For models with sand box pre-assembled to
the base, skip to Step 3.

Insert Sand Box inside Base and screw on M8 nut.
Tighten with Philips screwdriver.
For best stability, fill the sand box with sand.
Step 3 – Attach L-Shaped Brackets to Base
Attach L-Shaped Brackets loosely to Base with 4 pcs
M8x12 Hex Bolts and 4 pcs M8 Flat Washers. (NOTE:
L-shaped Brackets will be used to help secure the
Cylinder Housing to the Base in Step 4 below)
Step 4
–
Attach Post to Cylinder Housing Top and Attach
Cylinder Housing to base
Slide the post up through the bottom of the Cylinder Housing
and out through the hole on the top of the Cylinder Housing
and attach the post to the Cylinder Housing using 4 pcs
M6x12 Hex Bolts and 4 pcs M6 Flange Nuts. Slide the Plastic
Ring over the Post and secure it on the bolts on the top of the
Cylinder Housing. Attach the Cylinder Housing/Post assembly
to the L-Shaped Brackets on the Base with 8 pcs M5x10
Round Head Screws and 8 pcs M5 Flange Nuts.
Step 5 – Table Installation
Slide part 4 over Post and
down onto Cylinder Housing.
Slide Part 3 down over post
and onto Part 4. Then slide
Table (Part 2) over post and
rest on Part 3.
Now slide Part 1 down over post and through hole
in Table. Hold the Table with your hand and screw
Part 1 into Part 3.
To adjust the height of the Table, loosen the
plastic nut and move Table to desired height.
Tighten plastic nut.
Step 6 – Attach Reflector Studs to Head Assembly
Insert 3 Reflector Studs and 3 Flat Washers onto top of
Head Assembly. Tighten Studs securely.
5
For models without table, skip to Step 6.

Step 7
–
Attach Head Assembly to Post
 Unscrew 4 Small Bolts and 4 Lock Washers
pre-assembled in Head Assembly.
4 Small Bolts
.Load HeadAssemblyby inserting hose into post.
.Insert Head Assembly into post.
9M6x10 Flat Head Screws 9 M6 Cap Nuts
Control
k
nob should be above decal on pos
t
.
 Scre
w
on M6 Cap Nut loosel
y
.
.Attach Head Assembly to post, and loosely install four
small bol
t
s and lock washers.
.Tighten bolts securely. .Slide Reflector Plate .Screw on M6 Cap Nut
Step 8
–
Install Reflecto
r
.Insert one M6x10
onto Reflector Panels. loosely.
Flat Head Scre
w
.
Note: If necessary for proper alignment of reflector .Repeat procedure to completethe assemblyof all four
r
.
etighten after sections are align
.
ed.
sec
t
ions, loosen each scre
w
prior to further assembl
y
and .Fully tighten all of the screws in the rolled edge.
Slide t
w
o Reflector Insert M6x10 Flat Head
Screw. sec
t
ions.
Panels together.
6
WARNING
Remove protective cover before assemble.
4 Lock Washers

S
.tep 9 – Attach Reflector Assembly to Studs
.Support Heater.
The minimum permissible gas supplypressure of
10 W.C. is required for purpose of input adjustment.
Slide 3 M 8 Flat Washers over threaded end of The minimum hourlyof 17000 BTU is required
.The pressure regulator and hose assembly supplied
Reflector Studs. rating for a heater for automaticoperation at ratings
less than full input rating.
.The installation must conform with local codes, or in
3 Wing Nuts
6M8 Flat Washers with the appliance must be used.
.A dented, rusted or damaged propane cylinder may
the absence of local codes, with National Fuel Gas
Code,ANSI Z223.1.
be hazardous and should be checkedby your cylinder
supplier. Never use a propane cylinder with a
damaged valve connection.
The propane cylinder must be constructed and
marked in accordance with the specifications for LP
.
.Place ReflectorAssembly on 3 studs.
Install M8 Flat Washers on studs & securelytighten .Never connectan unregulated propane cylinder to the
wing nuts but do not over-tighten! gas cylinders of the U.S. Department of
Transportation (DOT).
.heater.
Screwregulator onto gas hose. Do not cross-thread.
.
Specifications
Step 10
–
Connect Hose & Regulato
r
to Cylinde
r
T
ighten securel
y
.
Attach regulator to cylinder.
Complete attachment.
Y
ou must provide
and
propane gas
propane c
y
linder. Use a
.cylinder only.
standard 20 lb. propane
Use this heater only
w
ith a propane vapor
w
ithdra
w
al supply
s
y
stem. See Chap
t
er 5
of the Standard fo
r
Storage and Handling
of Liquefied Petroleum
Gas,
ANSI/NFPA 58.
Your local library or
Install c
y
linder.
fire depar
t
ment should have
t
his book.
7
Standard 20 lb. tank
NOT INCLUDED

.Make 2-3 oz. of leak check solution (one part liquid
Hose / Regulator Regulator
/
Cylinder
Connection Connection
.dishwashingdetergentand three parts water). i
.Apply several drops of solution where regulator
Appl
y
several drops of solution
w
here hose attaches
to regula
t
or.
.connects to Cylinder.
.Make sure all Patio Heater & Light valves are OFF.
.
If bubbles appear at any connection, there is a leak.
T
urn C
y
linder Valve ON.
.Turn Cylinder Valve OFF.
.connection and perform another leak test.
If leak is at Hose/
R
egula
t
or connec
t
ion: tighten
If leak is at Regulator/Cylinder Valve connection:
disconnec
t
, reconnect, and perform ano
t
her leak
check. If
y
ou continue
t
o see bubbles af
t
er several
attempts, cylinder valve is defective and should be
returned to c
y
linder’s place of purchase. Caution: Do not attempt to operate unt
i
l
you ha
v
eread
& understand all General Safety Information in thi
s
manual and all assembly is complete & leak check
s
have been performed.
c
.
onnections are secure.
If NO bubbles appear at any connection, the
T
urn C
y
linder Valve OF
F
.
NOTE: Whenever gas connections are loosened or
.
removed, you must perform a complete leak test.
Complete ins
t
allation.
8
DANGER
• EXPLOSION - FIRE
HAZARD
• Never store propane near high heat, open flames, pilot
lights, direct sunlight, other ignition sources or where
temperatures exceed 120 degrees F (49°C).
• Propane vapors are heavier than air and can accumulate
n low places. If you smell gas, leave the area immediately.
• Never install or remove propane cylinder while heater is
lighted, near flame, pilot lights, other ignition sources or
while heater is hot to touch.
• This heater is red hot during use and can ignite
flammables too close to the burner. Keep flammables at
least 2 feet from sides & 3 feet from top. Keep gasoline and
other flammableliquids and vapors well away from heater.
• The propane cylinder must always be stored outdoors in a
well ventilated space. Never store propane cylinder in an
enclosed area (house, garage, etc.). If heater is to be
stored indoors, disconnect the propane cylinder for outdoor
storage.
DANGER
• CARBON MONOXIDE HAZARD
• For outdoor use only. Never use inside a house or any
other unventilated or enclosed areas. This heater
consumes air (oxygen). Do not use in unventilated or
enclosed areas to avoid endangering your life.
WARNING
• Perform all leak tests outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the heater until all connectionshave been leak
tested and do not leak.
OperationLeak Check

.
 Your heater was designed and approved for outdoor
4 Push and releasethe igniter button on the control
panel until flame is visible through Viewing Hole.
Release Control Knob after 30-60 seconds. Pilot
Light will remain lit. If not, return to step 1.
Turn Control Knob to ON. Main Burner will light
immediately. Flame is visible through Viewing Hole. If
not, return to step 1.
Before Turning Gas Supply ON:
5
.any other enclosed area.
use onl
y
. Do NOT use it inside a building, garage, or 6
Make sure surrounding areas are free of combus
t
ible
materials, gasoline, and o
t
her flammable vapors or
.Ensure that there is no obstruction to air ventilation.
liquids.
.leaks.
Be sure all gas connections are tight and there are no
.Be sure the cylinder cover is clear of debris.
Be sure an
y
componen
t
removed during assembly or
servicing is replaced and fastened prior to s
t
arting.
 Heater should be thoroughl
y
inspected before each
.annually.
use, and by a qualified service person at least
.
If relighting a hot heater, al
w
a
y
s
w
ait at least 5
minutes.
Inspect the hose assembl
y
for evidence of If for some reason
y
our igniter fails to deliver a spark,
your heater can be started by inserting a lit match
through the pilot view hole while pushing the control
knob in while in the PILOT position.
abrasion, cuts, or
w
ear. Suspected areas should be
leak tested. If the hose lea
k
s, it must be replaced prior
to operation. Only use the replacement hose
assembly specified by manufacturer.
Lighting:
Note: This heater is equipped with a Pilot Light that allows
for safer startups and shutdowns. Pilot must be lit before
Main Burner can be started.
1
2
3
T
urn Cylinder Valve ON.
Open Viewing Hole by sliding cover to either side.
Push Control Knob IN and rotate to Pilot position. Not
e
:I
f
pilot fails to remain lit, all valves should be closed
and a waiting period of at least 5 minutes should pass
before attempting to light.
Not
e
: For initial start or after any cylinder change, hold
Control Knob IN for 2 minutes to purge air from gas lines
before proceeding.
9
7 To increase the flame, turn the Control Knob counter
clockwise to HI. To decrease the flame, turn the Control
Knob clockwise to LO.
Before Lighting:

If
y
ou experience any ignition problems please
consult “Troubleshooting” on page 11. 
T
urn Control Knob clock
w
ise to Pilot. (Normall
y
,
burner
w
ill ma
k
e a slight popping sound
w
hen
.To extinguish Pilot, depress Control Knob and
Cautio
n
:
A
v
oid
inhal
i
n
g
f
umes
emit
t
ed from the extinguished.) Burner
w
ill extinguish but Pilot
w
ill
heater’s first use. Smoke and odor from the burning of
oils used in manufacturing will appear. Both smoke
and odor will dissipate after approximately 30 minutes.
The heater should NOT produce thick black smoke.
Note: The burner may be noisy when initially turned on. T
o
eliminate excessive noise from the burner, turn the Control
Knob to the Pilot position. Then, turn the knob to the level
of heat desired.
remain ON.
.Turn Cylinder Valve clockwise to OFF and disconnect
con
t
inue to turn it clock
w
ise to OF
F
.
Regula
t
or
w
hen heater is not in use.
Note: After use, some discoloration of the emitter screen is
normal.
For a safe and pleasurable heating experience, perform
this check before each use.
Before Operating:
When heate
r
is ON:
Emitter screen
w
ill become bright red due to intense hea
t
.
The color is more visible at night.
Burner will display tongues of blue and yellow flame. Thes
e
flames should not be yellow or produce thick black smoke,
indicating an obstruction of airflow through the burners. Th
e
flame should be blue with straight yellow tops.
If excessive yellow flame is detected, turn off heater and
consult “Troubleshooting” on page 11.
Re-lighting:
Note: For
y
our safet
y
, Control Knob cannot be
t
urned OFF
t
.
hen rotating it to OFF.
w
ithout first depressing Control Knob in PILOT position and
.
Turn Control Knob to OFF.
.Repeat the “Lighting” steps on prior page.
Wait at least 5 minutes to let gas dissipate before
attempting to religh
t
Pilo
t
.
.
.Gas control is in OFF position.
A
fte
r
Operation:
.Disconnect Gas line.
.Heater is upright in a secure location.
Gas
T
ank valve is OF
F
.
10
WARNING
FOR YOUR SAFETY
Heater will be hot after use. Handle with extreme care.
WARNING
FOR YOUR SAFETY
Be careful when attempting to manually ignite this heater.
Holding in the control knob for more than 10 seconds
before igniting the gas will cause a ball of flame upon
ignition.
Operation Checklist
Shut Down:
I am familiar with entire owner’s manual and understand all
precautions noted.
All Components are properly assembled, intact and
operable.
 No alterations have been made.
 All gas connections are secure and do not leak
 Wind velocity is below 10 mph.
Unit will operate at reduced efficiency below 40◦F.
Heater is outdoors (outside any enclosure.)
There is adequate fresh air ventilation.
Heater is away from gasoline or other flammable liquids
or vapors.
 Heater is away from windows, air intake openings,
sprinklers and other water sources.
 Heater is at least 36” on top and at least 24” on sides from
combustible materials.
 Heater is on a hard and level surface.
 There are no signs or spider or insect nests.
 All burner passages are clear.
 All air circulation passages are clear.
 Children, pets, clothing, flammable materials and
items that can be damaged from radiant heat are
away from heater.
 Children and adults in the area have been alerted to the
high temperature hazards; especially burns and clothing
fires.
 Children and adults in the area have been warned not to
touch heater near engine/head during operation and until
unit has cooled.

.
Keep exterior surfaces clean.
.While cleaning your unit, be sure to keep the area
Use
w
arm soap
y
w
ater for cleaning. Never use
flammable or corrosive cleaning agents.
around the burner and pilot assembl
y
dr
y
at all
times. Do not submerge the control valve
assembly. If the gas control is submerged in water,
do NOT use it. It must be replaced.
Air flo
w
must be unobstruc
t
ed. Keep controls, burner,
and circulatingair passagewaysclean. Signs of possible
blockage include:
T
o enjoy
y
ears of ou
t
standing performance from
y
our
heater, make sure you perform the following maintenance
activities on a regular basis:
11
WARNING
FOR YOUR SAFETY:
• Do NOT touch or move heater for at least 45 minutes
after use.
• Reflector is hot to the touch.
• Allow reflector to cool before touching.
Maintenance
If the problem is: And this condition exists: Then do this
Pilot won’t light
Note: Heater operates at
reduced efficiency below 40ºF
(5ºC)
Cylinder valve is closed Open valve
Blockage in orifice or pilot tube Clean or replace orifice or pilot tube
Air in gas line
Open gas line and bleed it (pressing control
knob in) for not more than 1 - 2 minutes or until
you smell gas
Low gas pressure with cylinder valve
fully open Turn cylinder valve OFF and replace cylinder
Igniter fails
Use match to light pilot; obtain new igniter and
replace
Pilot won’t stay lit
Dirt built up around pilot Clean dirt from around pilot
Connection between gas valve and
pilot assembly is loose Tighten connection and perform leak check
Thermocouple is not operating correctly Replace thermocouple
Burner won’t light
Gas pressureis low Turn cylinder valve OFF and replace cylinder
Blockage in orifice Clear blockage
Control knob is not in ON position Turn control knob to ON
Burner flame is low
Gas pressureis low Turn cylinder valve OFF and replace cylinder
Outdoor temperature is less than 40ºF
and tank is less than 1/4 full Use a full cylinder
Supply hose is bent or kinked Straighten hose
Controlknob fully ON Check burner and orifices for blockage
Carbon build-up Dirt or film on reflector and burner screen Clean reflector and burner screen
Thick black smoke
Blockage in burner
Remove blockage and clean burner inside and
outside
Troubleshooting

.Store heater upright in an area sheltered from direct
.Gas odor with extreme yellow tipping of flame.
.Heater does NOT reach the desired temperature. .If desired, cover heater to protect exterior surfaces
contact with inclement weather (such as rain, sleet,
.Heater glow is excessively uneven.
hail, snow, dust and debris).
.and to help prevent build up in air passages.
Heater makes popping noises.
Never leave LP cylinder exposed to direct sunlight or
excessive heat.
.Spiders and insects can nest in burner or orifices.
Note: Wait until heater is cool before covering.
Service
This dangerous condition can damage heater and
render it unsafe for use. Clean burner holes by using
.clear away smaller particles.
a heavy-duty pipe cleaner. Compressed air may help Repair to gas passages and associated components
should be done only by a qualified service person.
Carbon deposits may create a fire hazard. Clean
dome and burner screen with warm soapy water if Caution:
A
lwa
y
s allow heater to cool before
attempting service.
any carbon deposits develop.
Note: In a salt-air environment (such as near an ocean),
corrosion occurs more quickly than normal. Frequently
check for corroded areas and repair them promptly.
Warranty
TIP:
Use high-quality automobile wax to help maintain the
appearance of your heater. Apply to exterior surfaces from
the pole down. Do not apply to emitter screen or domes.
Storage
B
.
etween uses:
.Turn Control Knob OFF.
.Disconnect LP source.
Store heater upright in an area sheltered from direct
.hail, snow, dust and debris).
contact with inclement weather (such as rain, sleet,
If desired, cover heater to protect exterior surfaces
and to help prevent build up in air passages.
Note: Wait until heater is cool before covering.
.
transporting:
During periods o
f
extended inactivit
y
o
r
when
.Turn Control Knob OFF.
Disconnect LP source and move to a secure,
well-ventilated location outdoors.
12

1 YEAR LIMITED WARRANTY – Customers in the Continental US
All components are warranted for a period of 1 year after date of purchase by the original owner against defects in
materials and workmanship under normal use. This warranty does NOT cover normal wear and weathering, assembly
and/or maintenance OR use in a commercial application if model is not designated as a commercial model. At Well
Traveled Living’s sole discretion, products under warranty will be repaired and/or replaced at no charge to the customer.
Any returns sent back to Well Traveled Living must be sent via prepaid freight and in the original retail packaging.
For warranty service contact Well Traveled Living at the address, phone numbers or internet site and email listed in this
owner’s manual. Be sure to have your sales receipt, date of purchase and catalogue/model numbers available when
calling. All warranty service will be coordinated by the Well Traveled Living’s, Amelia Island, Florida service center.
This warranty is extended only to the original purchaser. Proof of purchase will be required before warranty service is
rendered. The sales receipt is the only valid proof of purchase. This warranty only covers failures due to defects in
materials or workmanship which occur during normal use. Failures and/or damage which result from accident, negligence,
misuse, abuse, neglect, mishandling, alteration or modification, failure to maintain, improper assembly or maintenance,
service by unauthorized agency or use of unauthorized components or damage that is attributable to acts of God are NOT
covered.
***THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED ABOVE***
***PURCHASER ASSUMES ALL RISKS IN THE ASSEMBLY AND OPERATION OF THIS UNIT***
***FAILURE TO FOLLOW WARNINGS AND OPERATIONAL INSTRUCTIONS CONTAINED IN THIS MANUAL CAN
RESULT IN SEVERE PROPERTY DAMAGE AND/OR PERSONAL INJURY***
IN NO EVENT WILL WELL TRAVELED LIVING, OR ITS DIRECTORS, OFFICERS OR AGENTS BE LIABLE TO THE
PURCHASER OR ANY THIRD PARTY, WHETHER IN CONTRACT, IN TORT, OR ON ANY OTHER BASIS, FOR ANY
INDIRECT, SPECIAL, PUNITIVE, EXEMPLARY, CONSEQUENTIAL, OR INCIDENTAL LOSS, COST, OR DAMAGE
ARISING OUT OF OR IN CONNECTION WITH THE SALE, MAINTENANCE, USE, OR INABILITY TO USE THE
PRODUCT, EVEN IF WELL TRAVELED LIVING OR ITS DIRECTORS, OFFICERS OR AGENTS HAVE BEEN
ADVISED OF THE POSSIBILITY OF SUCH LOSSES, COSTS OR DAMAGES, OR IF SUCH LOSSES, COSTS, OR
DAMAGES ARE FORESEEABLE. IN NO EVENT WILL WELL TRAVELED LIVING, OR ITS OFFICERS, DIRECTORS,
OR AGENTS BE LIABLE FOR ANY DIRECT LOSSES, COSTS OR DAMAGES THAT EXCEED THE PURCHASE
PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO THE PURCHASER.
This limited warranty gives you specific legal rights and you may also have other rights which vary from jurisdiction to
jurisdiction. The provisions of the United Nations Convention on Contracts for the Sales of Goods shall not apply to this
limited warranty or the sale of products covered by this limited warranty.
Distributed By:
Well Traveled Living
716 S 8th Street
Amelia Island, FL 32034
Toll Free: 866-WTL-SUPP
Web: www.wtliving.com
Email: [email protected]
***IMPORTANT NOTICE***
-Do NOT return to place of purchase-
For customer service and warranty issues
contact our Customer Service Center at:
(866)-985-7877 OR
Email: [email protected]
Customer Service Hours: Mon. – Fri. 9:00 a.m. – 6:00 p.m. (EST)
Fire Sense®, Mojave Sun ®, and Well Traveled Living® are registered trademarks of Well Traveled Imports, Inc®. All assembly instrucon presentaons are the
property of Well Traveled Imports, Inc.® and are protected by U.S. copyrights and trademarks. All rights reserved.
13
