PatioHeater
Model: PH09-S/ PH09-SS
Item #: 01338, 01337, 01347, 60789, 60790
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately
call gas supplier.
PLEASE retain this manual for
reference.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
a
pp
liance.
Instruction Manual & Parts List
INSTALLER: Please leave this manual for the consumer.
CONSUMER: Please retain this manual for future reference.
Manufacturer: Changzhou Wellife Furnace Co., Ltd.
WARNING: For outdoor use only.

- 2-
DANGER CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
WARNING:
For Outdoor Use Only
LPG cylinders to be used must be constructed and
marked in according with US DOT specifications
Storage indoors is permissible only if the LPG
cylinder is removed.
NOTE:
Use only 20lb LP-Gas tank with size of
18.1in / 46cm(Height)*12.5in / 32cm (Width).
Do not use if the environment temperature is
below 40°F / 4.4°C.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause injury
or property damage. Read the installation,
operating and maintenance instructions thoroughly
before installing or servicing this equipment.
Tools needed:
●Open end wrench 10&12mm
(included)
NOT included:
●Adjustable opening wrench 8’’
long
●Slip joint 9’’ long
●Philips screwdriver w/ medium
blade
●Spray bottle of soapy solution
for leaking test
TOOLS AND PARTS NEEDED FOR ASSEMBLY

- 3-
NOTE: PLEASE READ THE FOLLOWING SAFETY RULES
WARNING:
PRECAUTIONS
This heater must only be used outdoors. Using this product in an enclosed
area may cause injury, death or property damage.
Only use in a well-ventilated space. Do not use in a building, garage, or any
other enclosed area.
Read the instructions before use. This heater must be installed in
accordance
with local codes or, in the absences of local codes, with the National Fuel
Code, ANSI Z223.1. If applicable, the appliance, when installed, must be
electrically grounded in accordance with local codes or, in the absence of
local codes, with The National Electrical Code, ANSI/NFPA70.
Do not use the heater in an explosive atmosphere. Keep the heater away
from areas where gasoline or other flammable liquids or vapors are stored.
Prior to use, check for damaged parts such as hoses, regulators, pilot or
burner.
Turn off and disconnect LPG cylinder before moving the heater.
Do not attempt to alter this heater in any manner. EXAMPLE: Using the
heater without the mesh guard or radiant screen.
Do not use the heater in basements or below ground level. It must always
be placed on a solid and level surface.
Always ensure there is ample fresh air ventilation. This heater if for
OUTDOOR use ONLY.
Never replace or substitute the regulator with any regulator other than the
factory suggested replacement.
Do not clean the heater with cleaners that are combustible or corrosive.
Do not paint radiant screen, control panel or mesh guard.
All leak tests should be done with a soapy solution. NEVER USE AN OPEN
FLAME TO CHECK FOR LEAKS.
The LPG cylinder should be turned off when the heater is not in use.
At least once a year, the heater should be inspected for the presence of
spiders, spider webs or other insects.

- 4-
CHECK THE HEATER IMMEDIATELY IF ANY OF THE FOLLOWING EXIST:
1. The smell of gas in conjunction with extreme yellow colored tips of the burner
flames.
2. The heater does not reach temperature.
3. The burner makes a popping noise during use (a slight popping noise is
normal when the burner is extinguished after using).
Children and adults should be aware of the hazards of high surface
temperature, and should stay away to avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the area of the
heater.
Clothing or other flammable material should not be hung from the heater, or
placed on or near the heater.
Any guard or other protective device removed for servicing the heater must be
replaced prior to operating the heater.
Installation and repair should be done by a qualified service person. The
heater should be inspected before use and cleaning may be required at least
once a year, or as necessary. It is imperative that the control compartment,
burner, and circulating passageways of the heater be kept clean.
Keep the heater area clear of combustible materials such as gasoline and other
flammable vapors and liquids.
Do not obstruct the flow of combustion and air ventilation. Keep the ventilation
opening of the cylinder enclosure free and clear of debris.
Storage of the heater indoors is permissible only if the LPG cylinder is turned off,
disconnected, and removed from the heater.
Cylinders must be stored outdoors in a well-ventilated area out of the reach of
children. Disconnected cylinders must have threaded valve plugs tightly installed,
and must not be stored in a building, garage, or any other enclosed area.
。
PRECAUTIONS

-5 -
PARTS LIST
1. Burner assembly
2. 4 pcs mesh guard
3. Handle with 2 pcs M6 nuts
and 2 pcs flat gaskets
4. Back panel
5. 5 pcs M4x10mm bolts, 5 pcs
M4 flat gaskets, and 5 pcs M4
nuts to connect the burner
assembly with back panel
6. Regulator with gas hose
7. Door panel
8.
9. Wheels with 2 pcs M8x16mm
bolts and 2 pcs M8 nuts
10. 6 pcs M6x12mm bolts and
6 pcs M6 nuts for connection
of 3 cylinder brackets with
base and 3pcs M8x25mm
bolts for securing the LPG
cylinder
11. Base
ASSEMBLY
10 pcs M5x12mm bolts and
10pcs M5 nuts for connection
of 5 brackets with back
panel,5pcs M8x16mm bolts
to connect the back panel
with base

- 6-
WARNING: This appliance requires installation by a competent person.
Proper assembly is the responsibility of the installer.
Step 1
Step 2
Attach the handle to the back
panel with 2 pcs M6 nuts and
2 pcs flat gasket.
Use 6 pcs M6x12mm bolts and
6 pcs M6 nuts to connect 3
cylinder brackets on the base.
The brackets will allow LPG
cylinder to rest securely on
base.
ASSEMBLY

Use 10 pcs M5x12mm bolts and 10pcs
M5 nuts to connect 5 brackets with
back panel, Attach the back panel on
the base with 5 pcs M8x16mm bolts.
-7 -
Step 3
Step 4
Attach the burner assembly to
back panel with 5 pcs M4x10mm
bolts, 5 pcs M4 flat gaskets, and
5 pcs M4 nuts.
ASSEMBLY

- 8-
Step 5
Attach the door panel to the
back panel.
Step 6
Attach the regulator to the burner
assembly (see picture to the right) and tighten.
Attach the regulator to the LPG cylinder (see below).
Warning: Always make sure to check the connection for
leaks before using the heater (see page 10).
ASSEMBLY

- 9-
Step 7
Attach mesh guards (4 pcs)
to burner assembly as shown
(see picture to right).
ASSEMBLY

- 10 -
To check for leaks:
Your patio heater has been checked at all factory connections for leaks, but you
should always check when you attach the LPG cylinder. To check for leaks, follow
these instructions:
--Assemble all gas connections.
--Connect regulator assembly to the propane tank.
--Make sure the heater valve is turned OFF.
1) Make soapy solution by mixing 1 part liquid dish soap and 3 parts water.
2) Open the propane tank valve.
3) Spoon several drops (or use squirt bottle) of the soapy solution onto the gas
hose /regulator and regulator/cylinder connection.
4) Inspect the connections and look for bubbles.
5) If no bubbles appear the connection is safe.
6) If bubbles appear, there is leakage. Close the propane tank valve, and
loosen and re-tighten this connection.
7) Check for leakage again.
8) If bubbles still appear, close the propane tank valve and contact your gas
supplier. If a leak is detected, DO NOT attempt to use the heater.
MAKE SURE TO CHECK ALL THREE CONNECTIONS BETWEEN THE LPG
CYLINDER AND GAS LINE.
ASSEMBLY AND OPERATION

- 11 -
NOTE:
1) The cylinder must be provided with a shut off valve terminating in a LPG
supply cylinder valve outlet specified, as applicable, for connection NO 510 in
the standard for compressed gas cylinder valve outlet and inlet connections,
ANSI/CGA-v-1.
2) The cylinder supply system must be arranged for vapor withdrawal.
3) The cylinder used must include a collar to protect the cylinder valve.
Annually check operation:
A. Open the door panel.
B. Open the propane tank valve.
C. Spoon several drops (or use squirt bottle) of the soapy solution onto gas hose
connection and pilot connection.
D. Inspect the connections and look for bubbles.
E. If no bubbles appear, the connection is safe.
F. If bubbles appear, there is a leak. Close the propane tank valve and loosen and
re-tighten this connection.
G. Check for leaks again.
H. If bubbles still appear, close the propane tank valve and call you gas
supplier. DO NOT attempt to use the heater.
WARNING: DO NOT attempt to operate the heater until you have read
and understand all precautions. Failure to do so can result in serious
personal injury, death or property damage.
Before Turning Gas Supply ON:
Your heater was designed and approved for OUTDOOR USE ONLY. DO NOT use
it inside a building or any other enclosed area.
Make sure surrounding areas are free of combustible materials such as gasoline
and other flammable vapors or liquids.
Ensure that there is no obstruction to air ventilation.
Be sure all gas connections are tight and there are no leaks
Be sure the access panel is clear of debris.
Be sure any component removed during assembly or servicing is replaced and
fastened prior to starting.
ASSEMBLY AND OPERATION
OPERATION

- 12 -
Before Lighting:
Heater should be thoroughly inspected before each use. Have a qualified service
person inspect the heater at least annually. If relighting a hot heater, always wait
at least 5 minutes. This heater has been tested for quality assurance
LIGHTING INSTRUCTIONS
TO TURN ON THE HEATER.
1. Turn the control knob “OFF”.
2. Slowly open the gas cylinder valve fully.
3. Press and turn the control knob to
“HI” position ( counter-clockwise 90°).
4. Check for flame at the burner. If burner
does not light immediately, turn control
knob to “OFF” position and repeat from
Step 2. Allow 30 seconds between ignition
attempts for gas to dissipate. Several
attempts may be necessary.
5. Once the burner is lit, keep control knob depressed for 15 seconds.
6. For lowest heat, push in and turn the control knob to “LOW.” For highest
heat, push in and turn the control knob to “HI.”
Note: If the pilot flame does not light or it goes out, repeat Step 3
above.
NOTE:
· If a new tank has just been connected, please allow
at least one minute or more for the air in the gas
pipeline to purge out through the pilot hole.
· When lighting the pilot flame make sure that the
Variable control knob is continuously depressed while
pressing the igniter button. Variable control knob can
be released after the pilot flame has been lit
for 20~30 seconds.
· Pilot flame can be watched and checked from the
peephole located on the base of burner.
·If the pilot flame does not light or it goes out, repeat
Step 3. If the burner flame goes out accidentally or it is
blown out by wind, turn off the heater and wait at least 5
minutes or more to let the gas dissipate before relighting to avoid possible gas
explosion. Repeat steps 2 to 4.
·WARNING: Failure to follow this lighting procedure may result in flame
roll out beyond the emitter grid.
WARNING
FOR YOUR SAFETY
If at any time you are
unable to light burner
and smell gas, wait 5
minutes to allow gas to
dissipate before
attempting to light
heater. If after 1
minute , you are
unable to light the
burner, wait 5 minutes
and allow flammable
vapors to dissipate
before attempting to
li
g
ht heater a
g
ain.
OPERATION

- 13 -
TO TURN OFF THE HEATER.
1. Press and turn the control knob to “OFF” position.
2. Turn off the valve on the LPG cylinder and disconnect the cylinder from
the heater.
OPERATION

- 14 -
CAUTION: Avoid inhaling fumes emitted from the heater’s first use.
Smoke and odor from the burning of oils used in manufacturing will
appear. Both smoke and odor will dissipate after approximately 30
minutes. The heater should not produce thick black smoke.
Note:
The burner maybe be noisy when initially turned on. To
eliminate excessive noise from the burner, turn the control
knob to the “LOW” position, then turn the knob to the level
of heat desired.
Warning : White smoke may appear around the radiant
head during the first minutes of the initial firing.
When heater is ON:
Emitter screen will become bright red due to intense heat. The
color is more visible at night. Burner will display tongues of blue
flame. These flames should not be yellow or produce thick black
smoke, indicating an obstruction of airflow through the burners.
If the flame is very small, this indicates the supply pressure is not enough.
Relighting the heater:
1) Turn the control knob to “OFF” position.
2) Wait five (5) minutes before attempting to relight pilot.
3) Repeat steps beginning with step 2 on page 12.
Before leaving the heater unattended:
1) Turn the control knob to “OFF” position and turn LPG
cylinder to “OFF”position.
2) Never leave the patio heater unattended while in use.
Shut down instructions:
1) Push in and turn control knob clockwise to “OFF” position.
2) Turn LPG cylinder valve clockwise to “OFF” position when heater is not in use.
NOTE: After use, some discoloration of the emitter screen is normal.
If you suspect gas leakage:
1) Turn the control knob to “OFF” position.
2) Turn LPG cylinder valve to “OFF” position.
3) Wait 5 minutes to allow gas to dissipate.
4) If odor continues, immediately call gas supplier. DO NOT use the heater.
Warning: Heater will be hot after use. Handle with extreme care until completely
cooled.
OPERATION

- 15 -
CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT UNDER THIS
HEATER WHILE IN USE THEY WILL BE SUBJECT TO RADIANT HEAT AND
COULD BE SERIOUSLY DAMAGED.
This heater is to be used for the heating of outdoor patios, decks, spas, pool, and
open working areas. This heater is for OUTDOOR USE ONLY.
Always make sure that adequate fresh air ventilation is provided and follow the
spacing tolerances shown in the picture below. The minimum clearances must be
maintained at all times.
This heater must be placed on level, firm ground.
Never operate in an explosive atmosphere. Keep away from areas where gasoline
or other flammable liquids or vapors are stored or used.
LOCATION OF HEATER WHILE IN USE

- 16 -
CLEANING AND MAINTENANCE
To enjoy years of outstanding performance from your
Heater, make sure you perform the following
maintenance on a regular basis:
1. Keep exterior surfaces clean. Use warm soapy water
for cleaning. Never use flammable or corrosive cleaning agents. While cleaning
your heater, be sure to keep the area around the burner and pilot assembly dry
at all times. If the gas control is exposed to water in any way, DO NOT try to
use it--it must be replaced.
2. Keep the heater area free and clean from combustible materials, gasoline or
other flammable vapors and liquids. Visually check burner flames.
Visually check the hose assembly inside the panels and check for cracks or worn
sections.
1) Unscrew gas hose and regulator hose with 3/4’’ inch open end wrench and
adjustable wrench.
2) Check if there are cracks or worn sections on hose. If yes, contact your gas
supplier to replace the hose.
3) At least once a year, the unit should be inspected for the presence of spiders,
spider webs or other insects.
Air flow must be unobstructed. Keep controls, burner, and circulating air
passageways clean. Signs of possible blockage include:
1. Gas odor with extreme yellow tipping of flame.
2. Heater does not reach the desired temperature
3. Heater glow is excessively uneven.
4. Heater makes uneven popping noise.
Spiders and insects can nest in burner or orifices. This dangerous condition can
damage the heater and render it unsafe for use. Clean burner holes by using a
heavy-duty pipe cleaner. Compressed air may help clear away smaller particles.
MAINTENANCE
WARNING
FOR YOUR SAFETY:
ALLOW HEATER TO
COMPLETELY COOL
BEFORE MOVING.

- 17 -
Carbon deposits may create a fire hazard. Clean dome and engine with warm
soapy water if any carbon deposits develop.
NOTE:
In a salt-air environment (such as near an ocean), corrosion occurs
more quickly than normal. If the heater is exposed to this type of
environment, you should frequently check for corroded areas and
repair them promptly
MAINTENANCE

- 18 -
Problem Problem cause solution
Pilot will not light Gas valve may be OFF Turn the gas valve ON
Tank fuel empty Refill LPG tank
Air in supply system Purge air from lines
Loose connection Check all fittings
Pilot will not stay on Debris around pilot Clean dirty area
Loose connection Tighten connection
Thermocouple bad Replace thermocouple
Gas leak in line Check connections
Lack of fuel pressure Fuel tank is near empty
Burner will no light Pressure is low Fuel tank is near empty
Control valve not ON Turn valve to ON
Thermocouple bad Replace thermocouple
Pilot light assembly bent
or not in correct location
Place pilot in proper position
and retry
Manufacturer:
Changzhou Wellife Furnace Co.,Ltd
Tel: [phone]
Fax: [phone]
www.globalwellife.com
Distributed By:
Well Traveled Living
P.O. Box 4
Amelia Island, FL 32034
800-766-9633
www.wtliving.com
TROUBLESHOOTING

- 19 -
1YEARLIMITEDWARRANTY–CustomersintheContinentalUS
Allcomponentsarewarrantedforaperiodof1yearafterdateofpurchasebytheoriginalowneragainstdefectsin
materialsandworkmanshipundernormaluse.ThiswarrantydoesNOTcovernormalwearandweathering,assembly
and/ormaintenanceORuseinacommercialapplication.AtWellTraveledLiving’ssolediscretion,productsunder
warrantywillberepairedand/orreplacedatnochargetothecustomer.AnyreturnssentbacktoWellTraveledLiving
mustbesentviaprepaidfreightandintheoriginalretailpackaging.

ForwarrantyservicecontactWellTraveledLivingattheaddress,phonenumbersorinternetsiteandemaillistedinthis
owner’smanual.Besuretohaveyoursalesreceipt,dateofpurchaseandcatalogue/modelnumbersavailablewhen
calling.AllwarrantyservicewillbecoordinatedbytheWellTraveledLiving’s,AmeliaIsland,Floridaservicecenter.

Thiswarrantyisextendedonlytotheoriginalpurchaser.Proofofpurchasewillberequiredbeforewarrantyserviceis
rendered.Thesalesreceiptistheonlyvalidproofofpurchase.Thiswarrantyonlycoversfailuresduetodefectsin
materialsorworkmanshipwhichoccurduringnormaluse.Failuresand/ordamagewhichresultfromaccident,
negligence,misuse,abuse,neglect,mishandling,alterationormodification,failuretomaintain,improperassemblyor
maintenance,servicebyunauthorizedagencyoruseofunauthorizedcomponentsordamagethatisattributableto
actsofGodareNOTcovered.

***THEREARENOEXPRESSWARRANTIESEXCEPTASLISTEDABOVE***

***PURCHASERASSUMESALLRISKSINTHEASSEMBLYANDOPERATIONOFTHISUNIT***

***FAILURETOFOLLOWWARNINGSANDOPERATIONALINSTRUCTIONSCONTAINEDINTHISMANUALCANRESULT
INSEVEREPROPERTYDAMAGEAND/ORPERSONALINJURY***

INNOEVENTWILLWELLTRAVELEDLIVING,ORITSDIRECTORS,OFFICERSORAGENTSBELIABLETOTHEPURCHASER
ORANYTHIRDPARTY,WHETHERINCONTRACT,INTORT,ORONANYOTHERBASIS,FORANYINDIRECT,SPECIAL,
PUNITIVE,EXEMPLARY,CONSEQUENTIAL,ORINCIDENTALLOSS,COST,ORDAMAGEARISINGOUTOFORIN
CONNECTIONWITHTHESALE,MAINTENANCE,USE,ORINABILITYTOUSETHEPRODUCT,EVENIFWELLTRAVELED
LIVINGORITSDIRECTORS,OFFICERSORAGENTSHAVEBEENADVISEDOFTHEPOSSIBILITYOFSUCHLOSSES,COSTS
ORDAMAGES,ORIFSUCHLOSSES,COSTS,ORDAMAGESAREFORESEEABLE.INNOEVENTWILLWELLTRAVELED
LIVING,ORITSOFFICERS,DIRECTORS,ORAGENTSBELIABLEFORANYDIRECTLOSSES,COSTSORDAMAGESTHAT
EXCEEDTHEPURCHASEPRICEOFTHEPRODUCT.

SOMEJURISDICTIONSDONOTALLOWTHEEXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIAL
DAMAGES,SOTHEABOVELIMITATIONOREXCLUSIONMAYNOTAPPLYTOTHEPURCHASER.

Thislimitedwarrantygivesyouspecificlegalrightsandyoumayalsohaveotherrightswhichvaryfromjurisdictionto
jurisdiction.TheprovisionsoftheUnitedNationsConventiononContractsfortheSalesofGoodsshallnotapplytothis
limitedwarrantyorthesaleofproductscoveredbythislimitedwarranty.
DistributedBy:
WellTraveledLiving
716S8thStreet
AmeliaIsland,FL32034
TollFree:866‐WTL‐SUPP
Web:www.wtliving.com
Email:[email protected]
***IMPORTANTNOTICE***
‐DoNOTreturntoplaceofpurchase‐
Forcustomerserviceandwarrantyissues
contactourCustomerServiceCenterat:
(866)‐985‐7877OR
Email:[email protected]
CustomerServiceHours:Mon.–Fri.9:00a.m.–6:00p.m.(EST)
FireSense®,MojaveSun™,andWellTraveledLiving®areregisteredtrademarksofWellTraveledImports,Inc®.Allassemblyinstruction
presentationsarethepropertyofWellTraveledImports,Inc.®andareprotectedbyU.S.copyrightsandtrademarks.Allrightsreserved.
