Fisher & Paykel WB24 Series User manual

COMPANION PRODUCTS
Warming Drawer WB24
Coee Maker EB24
Steam Oven OS24N
models
INSTALLATION GUIDE
US CA
591496B 07.18

CONTENTS
IMPORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country,
please go to our website fisherpaykel.com or contact your local Fisher & Paykel dealer.
Warming drawer 1
1 Safety and warnings 2
2 Parts supplied 3
3 Prior to installation 3
4 Product dimensions 4
5A Cabinetry dimensions – underbench
(ie installed with F&P single oven) 5
5B Cabinetry dimensions – wall mounted
(ie installed with a F&P compact oven) 6
5C Cabinetry dimensions – wall mounted
(ie installed with a F&P coffee maker) 7
5 Cabinetry dimensions – wall mounted
(standalone) 8
6 Discard packaging responsibly 9
7 Mark and pre-drill the holes for securing
the warming drawer 9
8 Connect the warming drawer to the mains supply 9
9 Secure the warming drawer to the cabinetry 10
10 Secure the anti-tip bracket
(optional depending on cabinetry configuration) 10
11 Final checklist 11
Coffee maker 13
1 Safety and warnings 14
2 Parts supplied 15
3 Prior to installation 15
4 After installation 15
5 Product dimensions 16
6A Cabinetry dimensions
(18 1/8” (460mm) high cavity) 17
6B Cabinetry dimensions
(18 7/8” (480mm) cavity trim kit) 18
7 Installation instructions 19
8 Final checklist 20
Steam oven 21
1 Safety and warnings 22
2 Prior to installation 23
3 After installation 23
4 Product dimensions 24
5A Cabinetry dimensions
(18 1/8” (460mm) high cavity) 25
5B Cabinetry dimensions
(18 7/8” (480mm) cavity trim kit) 26
6 Electrical hook-up 27
7 Secure the oven to the cabinetry 27
8 Final checklist 28

WARMING DRAWER
WB24 models

WARMING DRAWER INSTALLATION GUIDE |3
3PRIOR TO INSTALLATION
● The cavity is square and level, and of the required dimensions.
● The installation will comply with all clearance requirements and applicable standards and regulations.
● The power switch will be easily accessible to the customer when the warming drawer is installed.
● The warming drawer (and any product on top of it) will rest on a surface that can support its weight.
● The height from the floor suits the customer.
● You consult local building authorities and by-laws if in doubt regarding installation.
If installing with a companion product
IMPORTANT!
● If installing with a companion product please refer to the installation instructions of that product to ensure the installation requirements of BOTH products are met.
● When installing products on top of the warming drawer, the weight of the product should be distributed across the edges of the warming drawer.
● Products above which rest on ‘feet’ may only be installed if the feet of the product lie within 2 3/4” (70mm) of the sides of the warming drawer, as this area is reinforced.
Failure to do this may result in damage to the warming drawer and companion product.
Screws (4) Anti-tip bracket (1) Oven support brackets (2)
Warming Drawer can withstand
a maximum weight of 132lb (60kg)
2 3/4”
(70mm)
2 3/4”
(70mm)
Feet
2PARTS SUPPLIED

COFFEE MAKER
EB24 models

COFFEE MAKER INSTALLATION GUIDE |15
5PRODUCT DIMENSIONS
FRONT
TOP SIDE
PRODUCT DIMENSIONS EB24 MODELS
inches (mm)
AOverall height of product 18” (458)
BOverall width of product 23 1/2” (596)
COverall depth of product (excluding dials) 18 7/8” (480)
DHeight of chassis 17 1/2” (445)
EWidth of chassis 22 1/16” (560)
FDepth of chassis 18 1/8” (460)
GDepth of coffee maker frame and control panel 13/16” (20)
HStepdown control panel to chassis 1/2” (13)
IHeight of control panel 4” (100)
B
E
A
CF D
I
H
