Fisher & Paykel RS60 User manual

INSTALLATION GUIDE/USER GUIDE
UK IE
SLIDE-IN WINE CABINET
RS60 model

3
CONTENTS
Introduction 5
Safety and warnings 6
Installation instructions 9
Operating instructions – Internal control panel 15
Operating instructions – Special functions 16
Interior and exterior features 17
Storing your wine 18
Loading your wine bottles 19
Cleaning care – Exterior 20
Cleaning care – Interior 21
User warnings and sounds 22
Troubleshooting 23
Manufacturer’s Warranty 25
Customer Care 27
European Directive 2012/19/EU on
Waste Electrical and Electronic Equipment (WEEE) 28
Registration
To register your product visit our website: fisherpaykel.com/register

5
INTRODUCTION
Thank you for purchasing a Fisher & Paykel Wine Cabinet to store your treasured
wine, you’ve made a great choice.
Having purchased our dual-zone cabinet you can rest assured that your red and
white wines are well cared for, over short term and long term periods.
Wine generally matures at a steady temperature between 11°Cto13°C, and for ready
to drink wines they are best served at their ideal drinking temperatures (see ‘Storing
your wine’ section). Temperature control is critical for the maturation of wines, as
significant daily or weekly temperature fluctuations can denature wines. If storage
temperatures are excessively high this can reduce the wine’s aromatic potential and
can speed up maturation. This can cause some wines to take on a ‘spoiled fruit’
flavouring. If storage temperatures are excessively low, this can have the opposite
effect and stunt a wine’s natural maturation process. This can prevent a wine’s flavour
from developing to full potential.
Optimum humidity levels are also important for the storage of cork-enclosed wines,
especially for long term storage. Dry surroundings can lead to dried out corks
encouraging wine evaporation, as well as oxygen permeation leading to oxidised
wine. As for extremely humid conditions, there is a potential of damaging wine labels
and the growth of mould on bottles.
Light is known to be damaging to wines, particularly UV light as it creates hydrogen
sulphide compounds in wine affecting the tannins and colour. Therefore our
Wine Cabinets are designed to eliminate this threat by incorporating a double
UV-tempered glass door, dark interiors and dimmed LED lighting.
Other golden rules of excellent wine storage that your Wine Cabinet offers are
frequent air circulation, condensation eliminator and minimal vibrations with the low
noise compressor.
RS60 model
Double UV-tempered glass door
Top zone carbon filter
Top zone roller shelf
Internal control panel
Bottom zone carbon filter
Safety lock
Safety latch
Bottom zone roller shelves

6
SAFETY AND WARNINGS
!WARNING!
Electric Shock Hazard
Failure to do so can result in death, electric
shock, fire or injury to persons.
• Read and follow the safety and warnings
outlined in this user guide before operating this
appliance.
R600a
Risk of fire/flammable material
• This refrigerator contains flammable refrigerant
isobutane (R600a).
READ AND SAVE THIS GUIDE
WARNING!
Read entire manual. Failure to follow all guides and rules could cause personal injury or
property damage. When using this appliance, always exercise basic safety precautions
inlcuding the following:
General use
zThis product has been designed for use in a normal domestic (residential) environment.
zChildren aged 3 to 8 years may load and unload this appliance under supervision.
zChildren should be supervised to ensure that they do not play with the appliance.
zCleaning and user maintenance shall not be undertaken by children without supervision.
zThis appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
zThe manufacturer’s installation instructions for product and cabinetry ventilation must
be followed when installing the appliance.
zKeep ventilation openings, in the appliance enclosure or the built-in structure, clear
of obstruction.
zDo not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
zDo not damage the refrigerant circuit.
zIn case of damage to the refrigerant circuit, ventilate the area by opening all windows.
zDo not operate electrical equipment or any other equipment that may produce arcs,
sparks or flames in the area. Contact your Fisher & Paykel trained and supported
service technician immediately to arrange for the appliance to be repaired.
zThis refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 38 °C. The product performance may be compromised when operating
outside of this temperature range.
zThis refrigerating appliance is not intended to be used as a built-in appliance.

7
SAFETY AND WARNINGS
Food safety
zThis appliance is intended to be used exclusively for the storage of wine.
zDo not store food and milk products in the Wine Cabinet. The interior temperature may
not be cool enough to prevent spoilage in food, and the expiry dates stated on the
food packaging may be invalid.
zThis refrigerating appliance is not suitable for freezing foodstuffs.
Electrical
zThis appliance must be installed in accordance with the installation instructions before
use.
zAlways grip the plug firmly and pull straight out from the outlet.
zDo not plug in any other appliance at the same power point as your Wine Cabinet.
zRepair or replace immediately all electric service cords that have become frayed or
otherwise damaged. Do not use a cord that shows cracks or abrasion along its length,
or at either the plug or appliance end.
zIf the power supply cord is damaged, it must only be replaced by your Fisher & Paykel
trained and supported service technician.
zWhen moving your appliance, be careful not to roll over or damage the power cord.
zDo not use electrical appliances inside the Wine Cabinet.
zDo not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
zWhen positioning the appliance, ensure the power cord is not trapped or damaged.
zDo not locate multiple portable socket-outlets or portable power supplies at the rear of
the appliance.
Servicing
zYour Wine Cabinet is designed to operate without the need for regular service
checks. However, if your Wine Cabinet is malfunctioning, have it attended to by your
Fisher & Paykel trained and supported service technician as soon as possible.
zThe LED light cannot be serviced by the user. Contact your Fisher&Paykel Dealer or
Fisher&Paykel trained and supported service technician.
Cleaning
zMany commercially available cleaning products contain solvents which may attack
plastic components of your Wine Cabinet and cause them to crack. Please refer to the
‘Cleaning care’ section of this user guide for further advice.
Disposal and recycling
zExtreme care must be taken when disposing your old appliance to avoid hazards:
zThe flammable refrigerant gas must be safely removed.
zThe thermal insulation foam contained in this appliance is produced by flammable
blowing gases, any exposed foam may be highly flammable and must be carefully
treated during disposal.
zWARNING: Risk of child entrapment. Before you throw away your old refrigerator or
freezer, the doors and panels should be removed and the racks left in place so that
children may not easily climb inside.
zConsult your local energy authority or local codes as to the best way to dispose of
your old appliance.

8
SAFETY AND WARNINGS
Storing wine
zDO NOT store explosive substances such as aerosol cans with a flammable propellant in
this appliance.
zNever store volatile or flammable materials in your Wine Cabinet as they may explode.
Light source information – EU/UK only
zThis product contains a light source of energy efficiency class F. The light source used
in this appliance is not suitable for room illumination.

9
INSTALLATION INSTRUCTIONS
Power failure
zIn the event of a power interruption, the Wine Cabinet will automatically save the
current temperature settings. When power is recovered, the Wine Cabinet will revert to
the current temperature settings only.
zMost power failures are corrected within a short period of time. 1–2hours loss of
power will not affect the Wine Cabinet’s temperatures.
zTo avoid sudden change of temperature while the power is off, you should avoid
opening the door. For longer periods of power failure, do take steps to protect your
wine.
INSTALLATION INSTRUCTIONS

10
INSTALLATION INSTRUCTIONS
Please follow the installation steps below to ensure your appliance operates correctly.
Power
● The appliance must be installed so the plug is accessible.
● To ensure that the appliance is not accidentally switched off, connect your Wine Cabinet
to its own power point. Do not plug in any other appliance at this power point.
● For power requirements, please refer to the serial plate located on the rear of the
cabinet.
● It is essential that the appliance is properly grounded (earthed).
● Connect the appliance to the electrical supply (220V–240V50Hz) with the fitted
plug and lead.
● Connections to the mains supply should be in accordance with local regulations.
Location
● Your Wine Cabinet should not be located in direct sunlight or next to any heat
generating appliance such as a cooktop, oven or dishwasher.
● The appliance should not be located in garages or on carpeted floors.
● This refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 38 °C.
● For optimum performance, it is recommended to control the ambient temperature
betwen 16°C and 25°C.
Ventilation and installation
To ensure adequate ventilation for your Wine Cabinet, see ‘Product and cabinetry
dimensions’.

11
INSTALLATION INSTRUCTIONS
Product installation
● Your Wine Cabinet will arrive with the front feet raised to make moving the product into
its final location a simple task.
● Avoid moving the product in a sideways direction as this may damage the floor
covering/surface.
● Move the Wine Cabinet into its final position making sure there are correct clearances
between the product and surrounding cabinetry.
Levelling your Wine Cabinet
● It is important that all four corners of
the WineCabinet base are supported
firmly on the floor to eliminate any
cabinet movement.
● Installing the appliance on a soft or
uneven/unlevelled floor may result
in twisting of the cabinet and poor
sealing of the door.
● This Wine Cabinet has four adjustable
feet, which can be used to level the
appliance.
● The front levelling foot on the hinge
side should take majority of the
cabinet’s weight and be stable, ie the
cabinet should not rock or wobble.
Before placing wine in your Wine Cabinet
● Remove all internal packaging.
● Clean the inside of the appliance to remove manufacturing and transportation dust.
Please refer to the ‘Cleaning care’ section of this user guide for further advice.
● Allow the Wine Cabinet to run empty for 1–2hours, this allows the appliance to
acclimatise and remove any residual odours before making temperature adjustments.
Energy efficiency
For the most energy efficient use of your appliance:
● Ensure your Wine Cabinet has adequate ventilation as recommended in the installation
instructions.
● Avoid overcrowding shelves, as this reduces airflow.
● Keep door openings to a minimum.
Counter-clockwise
to raise feet
Clockwise to
lower feet

12
INSTALLATION INSTRUCTIONS
Product and cabinetry dimensions
AD
B C O
E
K
O
F
Q
P
L
G
K
O
H
R
M
I
K
O
J
N
AD
B C O
E
K
O
F
Q
P
L
G
K
O
H
R
M
I
K
O
J
N
Flush with Wine Cabinet chassis
– full door rotation
AD
B C O
E
K
O
F
Q
P
L
G
K
O
H
R
M
I
K
O
J
N
Flush with Wine Cabinet door
– full door rotation
Flush with Wine Cabinet door
– 90° door rotation
AD
B C O
E
K
O
F
Q
P
L
G
K
O
H
R
M
I
K
O
J
N
S
Power plug to
power wall socket

13
INSTALLATION INSTRUCTIONS
RS60
PRODUCT DIMENSIONS mm
AOverall height of product 830
BOverall width of product 595
COverall depth of product (excludes handle, includes back cover) 580
CABINETRY DIMENSIONS (Including minimum air clearances) mm
DInside height of cavity 835
Flush with Wine Cabinet chassis – full door rotation
EInside width 600
FInside depth 565
Flush with Wine Cabinet door – full door rotation
GInside width 600
HInside depth flush to flat door (when not plugged at rear of product) 600
Flush with Wine Cabinet door – 90° door rotation
(for full shelf access, the door needs to be open past 90°)
IInside width 688
JInside depth flush to flat door 600
MINIMUM CLEARANCES mm
KSide clearance 2.5
LSide clearance – hinge side flush with chassis – full rotation 2.5
MSide clearance – hinge side flush with door – full rotation 2.5
NSide clearance – hinge side flush with door – 90° rotation 90.5
ORear clearance (includes back cover) 20
PTop clearance – above Wine Cabinet 5
QDoor clearance – hinge side flush with chassis – full rotation 155
RDoor clearance – hinge side flush with door – full rotation 155
MINIMUM POWER PLUG DIMENSIONS mm
SPower plug depth 30

14
INSTALLATION INSTRUCTIONS
If your Wine Cabinet is turned off for any reason, wait 10minutes before turning it back
on. This will allow the refrigeration systems pressures to equalise before restarting.
Moving your appliance
● Turn off the appliance and unplug from the power point. Remove all wine bottles.
● Turn the adjustable feet counter-clockwise to lower the product, making sure the feet
are wound up into the product.
● Ease the appliance out of its position. Tape the power cord to the back of the Wine
Cabinet, tape the shelves in place and tape the door closed.
● Always move the appliance vertically. Do not transport the product lying down, this
potentially damages the sealed cooling system.
● Relocate and install. If the appliance has been left on its side for any length of time,
leave it standing upright as long as possible (at least a few hours) before turning it on.
● If the product has been transported upright then it can be switched on after 10minutes.
Storing your Wine Cabinet
● When storing your cleaned appliance, leave the door open. This allows air to circulate
and prevents the build-up of bacteria and moulds.
● Before using again, clean well using liquid dishwashing detergent dissolved in warm
water. Rinse with clean water and dry with a lint-free cloth.
Holiday time
We recommend you leave your Wine Cabinet operating while you are on holiday.

15
OPERATING INSTRUCTIONS – INTERNAL CONTROL PANEL
The control panel enables you to view and modify all the features and options on your
Wine Cabinet.
Temperature control
● When the Wine Cabinet is turned on for the first time, the control panel will display the
actual temperature of the cabinet.
● The system will automatically cool both zones to their default temperature setting of
12°C (ideal for long term storage). This will take between 1 – 2 hours.
● The temperature zones are independently controlled and do not change with the
temperature or humidity of the surrounding; whether summer or winter.
● The Wine Cabinet can be set to any temperature between 5°C and 20°C in each zone to
accommodate your wine storage requirements.
● If you wish to alter the temperature of either zone, this can be easily done by using the
internal control panel.
Internal control panel
Adjusting the temperature of each zone
1Press and hold the ‘Temp Zone’ button for 3seconds. The zone temperature blinking
on the display will indicate whether the upper or bottom zone is selected.
2To change zones press the ‘Temp Zone’ button once.
3The temperature may be altered by pressing the or buttons. One press on either
of these buttons will increase or reduce the temperature by one °C or °F.
When the desired temperature is displayed, wait 5 seconds, the blinking will stop and
the temperature will be set.
4To switch between temperature units of °C and °F, press and hold the ‘Light’ icon for
3seconds.

16
OPERATING INSTRUCTIONS – SPECIAL FUNCTIONS
Special functions
LED lighting
When the Wine Cabinet door is open the light automatically illuminates both zones.
When the door is closed the light will automatically turn off. For maximum energy
savings, it is recommended to leave the light off when not viewing your collection.
To keep the light illuminated at all times (on door opening and closing):
● Press the ‘Light’ button once.
● To deactivate the light from illuminating when not viewing your collection, press the
‘Light’ button once.
Power
This model is equipped with Standby mode and may be activated when the cabinet is
not in use. Before activating this mode ensure all wine bottles are removed.
● To activate press the ‘Power’ button once. The internal control panel and LED lights
will no longer illuminate.
● To deactivate Standby mode press the ‘Power’ button once. The internal control
panel and LED lights will illuminate, and revert to the current temperature settings only.
Door alarm
A continuous alarm will sound if the cabinet door has been left open for longer than
60seconds. The alarm will stop only when the door is closed.
● For times when you require the door to be opened longer than normal eg rotating your
wine bottles or loading more wine, the door alarm can be temporarily muted.
● To mute the door alarm, press the ‘Temp Zone’ button once. When the cabinet door is
closed, alarm mute will deactivate and the door alarm will revert to normal.
IMPORTANT!
When the cabinet door is left open for long periods of time wine quality may be
compromised.

17
INTERIOR AND EXTERIOR FEATURES
Interior features
Shelving
The oak shelves have been designed to allow for even air distribution around your wine
bottles. Easy access is possible with telescopic runners.
This model has three roller shelves and two fixed shelves.
Activated carbon filters
Air quality is critical for preserving wine. The
activated carbon filters help to remove stale,
unwanted odours and replenish with fresh air.
● The filters are fitted to the rear wall on the
right-hand side of the upper and bottom zone.
● We recommend that you replace your activated
carbon filters once every five years. Replacement
filters are available from your Fisher & Paykel trained
and supported service technician.
● To remove the filter hold by the handle, and turn
counter-clockwise (refer to A) until fully loosened.
Pull towards you to remove (refer to B).
● To replace the filter hold by the handle, insert and
turn clockwise to fully secure.
Exterior features
Door lock
The Wine Cabinet is equipped
with a door lock located at the
bottom of the cabinet door.
● To lock the cabinet, insert the key
and turn 90°counter-clockwise.
● To unlock the cabinet, insert the
key and turn 90°clockwise
90° counter-clockwise
to lock
90° clockwise
to unlock
AB

18
STORING YOUR WINE
Short-term storage/serving
● This Wine Cabinet is perfect for short-term storage such as entertaining.
● Red wines are best served at warmer temperatures and white wines are best served at
cooler temperatures.
● The ideal serving temperature of your wine is crucial for your taste and enjoyment.
The following are recommended serving temperatures for different wines.
SPARKLING WINES AND SWEET WHITE WINES
Non-vintage Champagne and Sparkling Wine 6°C
Vintage Champagne and Sparkling Wine, Riesling and Gewürztraminer 8°C
DRY WHITE WINES
Sauvignon Blanc, Chenin Blanc, Bordeaux Blanc 9°C
Chardonnay and White Burgundy, Rosé 10 – 12°C
LIGHT TO MEDIUM-BODIED RED WINES
Young Boredaux, Young Cabernet, Pinot Noir, Merlot 14 – 16°C
FULL-BODIED RED WINES
Cabernet Sauvignon, Red Burgundy 17°C
Shiraz, Zinfandel, Vintage Port 18°C
Long-term storage
● This Wine Cabinet is also perfect for long-term storage/cellaring of wines.
● The ideal temperature for long-term storage of red and white wines is between
11°Cto13°C.
Storing red and white wine
● When storing a combination of red and white wines, we recommend storing same
case wines together. For example red wine in the bottom zone and white wine in the
upper zone.
● Depending on the number of wine bottles and functions selected, it may take
24hours for the Wine Cabinet temperatures to stabilise.
● Not all wines stored will improve/mature over time. Some wines are best consumed at
an early stage, while others have remarkable ageing capabilities. Check with your wine
merchant for more information.

19
LOADING YOUR WINE BOTTLES
When loading your Wine Cabinet please keep in mind our loading capacities are based
on standard 750ml Bordeaux bottles.
DOs DON’Ts
● Before loading wine into the cabinet
confirm that all shelves are secured
andstable.
● Roller shelves are designed for holding
6wine bottles only.
● Fixed shelves are designed for holding
only two tiers of wine bottles.
● When storing a combination of red and
white wines, we recommend storing
same case wines together. For example
red wine in the bottom zone and white
wine in the upper zone.
● Do not load more than the
recommended number of wine bottles
on roller shelves and fixed shelves.
● Do not remove any roller shelves to
allow the shelf below to hold more
than the recommended number of
wine bottles.
Upper zone roller shelf
This shelf is designed to hold
6wine bottles only.
Upper zone fixed shelf
This shelf is designed to hold
9wine bottles only.
Bottom zone fixed shelf
This shelf is designed to hold
11wine bottles only.
Bottom zone roller shelf
This shelf is designed to hold
6wine bottles only.

20
CLEANING CARE – EXTERIOR
Stainless steel exterior door
● Use only liquid dishwashing detergent dissolved in warm water and a soft lint-free cloth
to clean the exterior door surface.
● Rinse with clean water and dry with a clean, lint-free cloth.
● The use of any abrasive or stainless steel cleaners and solvents will damage the door
surface.
Other exterior surfaces
● Clean all other exterior surfaces with liquid dishwashing detergent dissolved in warm
water and a soft lint-free cloth.
● Rinse with clean water and dry with a clean, lint-free cloth
Door gasket
● It is recommended to clean the magnetic door gasket every three months with an old
toothbrush, and liquid dishwashing detergent dissolved in warm water.
● Gasket must be kept clean and pliable to assure a proper seal.
● Petroleum jelly applied lightly on the hinge side of the gasket will keep the gasket
pliable and assure a good seal.
IMPORTANT!
● Many commercially available cleaning products contain solvents which may attack
plastic components of your Wine Cabinet and cause them to crack.
● Avoid using anti-bacterial cleaning products on the interior or exterior of the Wine
Cabinet, as they may cause rusting of metal components and cracking of plastic
components.
