Fisher & Paykel HP24IDCHX4 User manual

CONTEMPORARY
HP24IDCHX4, HP0IDCHX4, HP6IDCHX4 models
INSERT RANGE HOOD
INSTALLATION GUIDE
US CA

2
SAFETY AND WARNINGS
WARNING!
Fire Hazard
Failure to follow this advice may result in
serious burns or death.
• Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low
or medium settings.
• Do not vent exhaust air into spaces within walls or
ceilings or into attics, crawl spaces, or garages.
• Always turn hood ON when cooking at high heat
or when flambéing food.
• Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan or filter.
• Use proper pan size. Always use cookware
appropriate for the size of the surface element.
READ AND SAVE THESE INSTRUCTIONS
WARNING!
When using this appliance always exercise basic safety precautions includingthe following:
Installation
z Please read the entire set of instructions before installing or using this appliance.
z Please make this information available to the person installing the appliance – doing so
could reduce your installation costs.
z Ducted hoods must always be vented to the outdoors.
z Always switch the power off prior to installation, servicing or cleaning of theappliance.
z This appliance must be installed and connected to the mains power supply only by a
suitably qualified person according to these installation instructions and in compliance with
any applicable local building and electricity regulations. Failure toinstall the appliance
correctly could invalidate any warranty or liability claims.
z Ducting accessories are not supplied. All ducting must comply with local requirements and
building codes.
z Attention should be given to ensure that any applicable regulations concerning the
discharge of exhaust air are fulfilled.
z Before connecting any pipes, consult municipal ordinances to ensure that any applicable
regulations concerning the discharge of exhaust air are adhered to and request permission
from the person in charge of the building.
z Exhaust air must not be discharged into an existing flue that is used for exhausting fumes
from appliances burning gas or other fuels.
WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• Installation and electrical wiring must be
completed by qualified person(s) in accordance
with all applicable codes and standards, including
fire-rated construction.
• Always disconnect the appliance from the mains
power supply before carrying out any maintenance
or repairs.
• Improper grounding can result in a risk of electric
shock
WARNING!
Weight Hazard
Failure to follow this advice may result in
damage or personal injury.
• The appliance is heavy. Please ensure adequate
care is taken when installing the appliance.
• The appliance must be installed onto a solid wall,
stud, beam or truss.
• Product weight: HP24: 22lb (10kg), HP30: 22lb
(10kg), HP36: 26lb (12kg).
WARNING!
Cut Hazard
Failure to use caution could result in injury.
• Take care: some edges are sharp.
• Wear gloves to protect against sharp edges.

3
SAFETY AND WARNINGS
z There shall be adequate ventilation of the room when the range hood is used at the same
time as appliances burning gas or other fuels.
z The minimum distance between the supporting surface for cooking vessels on the cooktop
and the lowest part of the range hood shall be 24” (610mm).
z Stainless steel is very easily damaged during installation if abraded or knocked by tools.
It is recommended to protect the top of the range hood with cardboard or polystyrene
during the installation to minimise the risk of damage occurring.
z To reduce the risk of damage occurring to the cooktop, it is recommended that the surface
of the cooktop is protected with cardboard or a similar object during installation of the
range hood.
z This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning the use of the appliance by a person
responsible for their safety.
z Children should be supervised to ensure they do not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
z You must read the details concerning the method and frequency of cleaning.
z There is a fire risk if cleaning is not carried out in accordance with the instructions.
z Never leave frying food unattended since grease can overheat and catch fire. The risk of
fire is even greater in the case of used oil.
z Do not flambé under the range hood.
z Never use the range hood without the filters in place.
z During an electrostatic discharge (ESD) it is possible that the device will stop working. By
switching the device off and on the device will again work as intended.
z CAUTION: accessible parts may become hot when used with cooking appliances.
z Remove all packaging, including protective wrappings, before use.
z WARNING – TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE
TOP GREASE FIRE, OBSERVE THE FOLLOWING:
z SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn off the
burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately,
EVACUATE AND CALL THE FIRE DEPARTMENT.
z NEVER PICK UP A FLAMING PAN – You may be burned.
z DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion
will result.
z Use an extinguisher ONLY if:
z You know you have a Class ABC extinguisher, and you already know how to operate
it.
z The fire is small and contained in the area where it started.
z The fire department is being called.
z You can fight the fire with your back to an exit.

4
*length dependant on installation
COMPONENTS REQUIRED
z Keep all packing materials until the unit has been inspected.
z Inspect the product to ensure there is no shipping damage. If any damage is detected
contact the dealer or retailer you bought the product from to report the damage.
z Fisher & Paykel is not responsible for shipping damage.
Supplied
PARTS TOOLS
Range hood (1) Safety guide (1)6" (150mm) diameter
ducting adapter (1)
Phillips screws (2)
Not supplied
793599 Carbon filter (2) Ducting 6" (150mm) (1)* Internal grill (1)
Recirculation Installation
Duct out Installation
6" (150mm) rigid
ducting (1)*
Duct outlet (Soffit, wall,
roof) (1)
Not supplied
Phillips screwdriver (1) Aluminium tape (1) Electric drill (1) Jigsaw (1)
Pencil (1) Ruler (1) Tape measure (1) String & weight (1)
Warranty guide (1)
Straps (1)

5
PRODUCT DIMENSIONS | HP24IDCHX4
Product Dimensions
in
mm
A Overall height of range hood without ducting adapter
12 7/16"
16
B Overall height of range hood with ducting adapter
15 11/16"
98
C Overall width of range hood
20 7/8"
50
D Overall depth of range hood (excl. cabinetry front panel)
11"
280
E Diameter of ducting adaptor
6"
150
F Width of range hood chassis
19 /8"
492
G Depth of range hood chassis
10 /16"
258
H Thickness of flange
1/16"
2
I Distance from ducting outlet center to rear of chassis
 1/4"
82
J Height adjustability of clip that secures cooker hood (cabinet
base panel thickness)
min 9/16"
max 1 9/16"
min 15
max 40
K Distance from rear to center of light
9 15/16”
25
L Distance from back of chassis to hard wiring box
8 9/16"
217
M Distance from center of product to hard wiring box
 1/4"
82
Cavity Dimensions Standard Installation
in
mm
Width of cutout
19 11/16”
500
Depth of cutout
10 1/4"
260
Minimum distance above cooktops
in
mm
Minimum height from top of cooktop to base of product
24"
610
Minimum height may be greater if required by your cooktop. Refer to cooktop installation guide for details.
Note: We recommend the cabinet has a door or service panel that can be easily opened to access the power
connection.
INDICATES PRODUCT DATUM -------------------------------------------
INDICATES CABINETRY CLEARANCES --------------------------------
Dimensions may vary by 1/16”(±2mm).
201050
PLAN VIEW
FRONT VIEW
BOTTOM VIEW
PROFILE VIEW
NOT TO SCALE
MAX
MIN
DATUM: BOTTOM OF CABINET
D
JH
B
A
K
C
F
G
EM
I
L
Inches
Millimetres

6
PRODUCT DIMENSIONS | HP30IDCHX4
INDICATES PRODUCT DATUM -------------------------------------------
INDICATES CABINETRY CLEARANCES --------------------------------
Dimensions may vary by 1/16"(±2mm).
Product Dimensions
in
mm
A Overall height of range hood without ducting adapter
12 7/16"
16
B Overall height of range hood with ducting adapter
15 7/16"
92
C Overall width of range hood
28 /4"
70
D Overall depth of range hood (excl. cabinetry front panel)
11"
280
E Diameter of ducting adaptor
6"
150
F Width of range hood chassis
27 5/16"
694
G Depth of range hood chassis
10 /16"
258
H Thickness of flange
1/16"
2
I Distance from ducting outlet center to rear of chassis
 1/4"
82
J Height adjustability of clip that secures cooker hood
(cabinet base panel thickness)
min 9/16"
max 1 9/16"
min 15
max 40
K Distance from rear to center of light
9 15/16
25
L Distance from back of chassis to hard wiring box
8 5/16"
211
M Distance from center of product to hard wiring box
2 7/8"
7
Cavity Dimensions Standard Installation
in
mm
Width of cutout
27 9/16
700
Depth of cutout
10 1/4"
260
Minimum distance above cooktops
in
mm
Minimum height from top of cooktop to base of product
24"
610
Minimum height may be greater if required by your cooktop. Refer to cooktop installation guide for details.
Note: We recommend the cabinet has a door or service panel that can be easily opened to access the power
connection.
PLAN VIEW
FRONT VIEW
BOTTOM VIEW
PROFILE VIEW
NOT TO SCALE
MAX
MIN
D
JH
B
A
K
C
F
G
EM
I
L
DATUM: BOTTOM OF CABINET
Inches
Millimetres

7
PRODUCT DIMENSIONS | HP36IDCHX4
INDICATES PRODUCT DATUM -------------------------------------------
INDICATES CABINETRY CLEARANCES --------------------------------
Dimensions may vary by 1/16”(±2mm).
Product Dimensions
in
mm
A Overall height of range hood without ducting adapter
12 7/16"
16
B Overall height of range hood with ducting adapter
15 11/16"
98
C Overall width of range hood
2 11/16"
80
D Overall depth of range hood (excl. cabinetry front panel)
11"
280
E Diameter of ducting adaptor
6"
150
F Width of range hood chassis
1 /16"
792
G Depth of range hood chassis
10 /16"
258
H Thickness of flange
1/16"
2
I Distance from ducting outlet center to rear of chassis
 1/4"
82
J Height adjustability of clip that secures cooker hood
(cabinet base panel thickness)
min 9/16"
max 1 9/16"
min 15
max 40
K Distance from rear to center of light
9 15/16”
25
L Distance from back of chassis to hard wiring box
8 9/16"
217
M Distance from center of product to hard wiring box
 1/4"
82
Cavity Dimensions Standard Installation
in
mm
Width of cutout
1 1/2”
800
Depth of cutout
10 1/4"
260
Minimum distance above cooktops
in
mm
Minimum height from top of cooktop to base of product
24"
610
Minimum height may be greater if required by your cooktop. Refer to cooktop installation guide for details.
Note: We recommend the cabinet has a door or service panel that can be easily opened to access the power
connection.
PLAN VIEW
FRONT VIEW
BOTTOM VIEW
PROFILE VIEW
NOT TO SCALE
Inches
Millimetres
MAX
MIN
DATUM: BOTTOM OF CABINET
D
JH
B
A
K
C
F
G
EM
I
L

8
CUTOUT DIMENSIONS
A
b
CUTOUT DIMENSIONS
HP36 MODELS
INCHES MM
A Overall width of the cutout 31 1/2 800
B Overall depth of the cutout 10 1/4 260
CUTOUT DIMENSIONS
HP30 MODELS
INCHES MM
A Overall width of the cutout 27 9/16 700
B Overall depth of the cutout 10 1/4 260
CUTOUT DIMENSIONS
HP24 MODELS
INCHES MM
A Overall width of the cutout 19 11/16 500
B Overall depth of the cutout 10 1/4 260
24" MODELS 30" MODELS 36" MODELS
A
b
A
b

9
INSTALLATION HEIGHT
A
HEIGHT DIMENSIONS IN MM
A Height top of cooktop to base of product min 24” min 610
This range hood must be installed no lower than the minimum height indicated in the table
above. Minimum installation height may be greater if required by the cooktop, refer to your
cooktop installation instructions.
Installation at the minimum height will improve the efficiency of capturing cooking odours,
grease and smoke.
Induction cooktop considerations
z Induction cooktops use energy efficient technology that only heats the contents of a
cooking pot.
z Unlike gas or traditional electric cooktops, the surrounding air does not get heated when
using an induction cooktop. As a result, range hood filters, splashbacks and surrounding
cabinetry do not get warmed up, increasing the likelihood of condensation on these cooler
surfaces.
z Other factors like ambient temperature, humidity, natural ventilation of the room, size of the
cookware and how the induction cooktop is being used also influence condensation. For
example, aggressive boiling on high cooktop heat settings like PowerBoost increases the
rate at which water is evaporated, increasing the likelihood of condensation.
z It is important to understand that neither the range hood nor the induction cooktop are
faulty as a result of this phenomenon.
Condensation can be minimised by:
z Using the range hood on a lower speed setting when boiling.
z Using the induction cooktop on a lower heat setting when boiling.
z Switching the range hood on 5minutes before cooking and letting it run for at least
5minutes after cooking. Refer to the ‘your user guide for details of how to use the
timer function.
z NOTE: recirculation does not remove moisture.

10
VENTING REQUIREMENTS
ELECTRICAL REQUIREMENTS
Attention should be given to ensure that any applicable regulations concerning the
discharge of exhaust air are fulfilled.
Before connecting the range hood to the power supply, ensure the voltage and frequency
indicated on the rating plate match that of the installation location:
Vent installation types:
Vent through roof Vent through exterior wall Recirculate with carbon filters
INSTALL PREPARATION / CONSIDERATIONS
1
Recirculation installations only:
Additional accessories required:
Recirculation outlet.
Carbon filters.
3Ensure the cavity is set up to the
correct specifications. Refer to ‘cutout
dimensions’ for details.
2
Externally vented options:
Duct to roof and out external wall or
soffit.
Duct to external wall and out.
MODEL FREQUENCY VOLTAGE
HP24IDCHX4,
HP30IDCHX4,
HP36IDCHX4
60HZ 120V

11
INSTALL PREPARATION / CONSIDERATIONS UNPACK PRODUCT
15
Open carton and remove all packaging.
Carefully lift the products out of the
cartons.
Place on a protected surface.
Ensure the top of the range hood remains
accessible via the cavity throughout the
installation.
3Inspect product for any damage. Connect
to power and test.
26 Dispose of packaging responsibly.
Recycle where possible.
Refer to cooktop specifications to ensure
adequate clearances are maintained.
CHECK MATERIALS AND PARTS
1Ensure the ducting is the correct length
and compatible to the range hood.

12
PREPARE CABINETRY
Ensure the cabinetry can support the weight of the range hood and ducting. z Not relevant for externally vented options.
z Venting directly into the cabinet with no ducting and louvered vent is not permitted.
z Note: Placement of the louvered vent on the top of your cabinetry is not recommended. This
should only be done if objects can be prevented from falling through the louvers into the
blower.
NON PRECUT CABINETRY
PRECUT CABINETRY
RECIRCULATION INSTALLATION
1
Centre range hood over cooktop
and prepare cutout to the required
specifications. Refer to dimensions and
cabinetry cutout pages.
2
1
Prepare the ducting route.
Prepare the ducting route.
2
Create a cutout in your cabinet to fit the
6” (150mm) vent. Place the vent on the
hole created and secure.
Note that shapes and sizes of louvred
vents can vary. Refer to your vent
selected for details.
1
Determine the desired location of the 6”
(150mm) vent on your cabinetry.
The vent can be placed on the side or
front of your cabinet provided there is
sufficient clearance from the surrounding
cabinetry to enable ventilated air to
recirculate back into your kitchen.
3
Connect the blower outlet to the vent
with a length of 6” (150mm) rigid
ducting, and secure the joints with
aluminium tape.
Ensure there is no slack in the ducting.

13
z Not relevant for recirculation installation.
z Vent representative in the following rigid ducting steps.
RIGID DUCTING
INSTALL DUCTING
11
Ensure the ducting is the correct length
and size for your range hood and that all
required bends are present.
Do not reduce the duct diameter as this
will increase noise.
2
Install external venting as required:
Weather proofing requirements depend
on the cladding/roofing type.
Soffit external venting
3Cut ducting to length.
5Tape ducting to seal.
4Route ducting and assemble.
6If required, secure ducting within ceiling.
Wall external venting
Roof external venting

14
INSTALL DUCTING
RIGID DUCTING
7Fit ducting to the external vent and
secure.
PREPARE HOOD
1
Ensure that there is an air gap between
the mounting brackets and the hood
chassis. The mounting brackets can be
adjusted to achieve this if needed.
2
Fit the duct adapter to the range hood
using two supplied Phillips screws.

15
INSTALL HOOD
1 5
Lift range hood into cavity until all
four mounting brackets clip in. Check
brackets have safely engaged on the
cabinetry before releasing range hood.
Ensure power cable remains free and
unobstructed during this process.
Refit perimeter plate and secure using
the screws removed in step 3.
3On one side of the perimeter plate,
loosen the two screws shown, and slide
perimeter plate out.
2 6
Unclip filters to remove. Ensure filters are oriented correctly
before clipping back into place.
4
From below the rangehood, secure all
four brackets using Phillips screwdriver.
Tighten until flange is flush against
cabinetry.

16
SECURE DUCTING
1
Attach ducting to adapter.
Secure using tape, cable ties or metal
straps as required.
2
Recirculation only:
Install the carbon filters onto the blower.
Rotate the filter until secure.
CONNECT POWER
2
3
Remove the electrical knock-out. Install
a UL listed 1/2” (12.7mm) wiring conduit
and strain relief in the junction box.
Run three wires through the conduit from
the power supply to the junction box.
Connect the power supply wires to the
range hood wires using suitable UL listed
wire nuts:
Black to black.
White to white.
Green/yellow to green/yellow.
Replace the junction box cover and
secure.
1Remove the junction box cover by
unscrewing both screws as shown.

17
INSTALLER CHECKLIST
TO BE COMPLETED BY THE INSTALLER
All packaging has been removed.
Range hood is correctly installed.
All connections are secure.
The ducting is not bent or crushed in any areas .
Range hood suction has been checked.
External vent is sealed appropriately.
All local regulations have been met. If required, the maximum flow can be reduced to
300CFM to meet local codes and regulations. Contact a Fisher & Paykel trained and
supported service technician or Customer Care for more details.
Operation has been tested (refer to user guide).
No unusual noises present.
AFTER POWER CONNECTION
1Remove film from all surfaces of the
range hood.
Complete and keep for safe reference:
Model
Serial no.
Purchase date
Purchaser
Dealer address
Installer’s name
Installer’s signature
Installation company
Installation date

106074A 01.24
FISHERPAYKEL.COM
© Fisher & Paykel Appliances 2024. All rights reserved.
The models shown in this guide may not be available in all markets
and are subject to change at any time.
The product specifications in this guide apply to the specific products and
models described at the date of issue. Under our policy of continuous product
improvement, these specifications may change at any time.
For current details about model and specification availability in your country,
please go to our website or contact your local Fisher&Paykel dealer.
