Fisher & Paykel HP36ILTX1 User manual

Installation Instructions
Contents of Packaging
Ventilation hood (1) Installation
instructions User
guide manual (1)
Power
connection
box (1)
6” (152mm) diameter
Ducting adapter with back
draft damper (1)
3/8” (10mm) Self tapping screw (4)
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
1

Product and Cabinetry Cutout Dimensions
Product Dimensions HP24
inches (mm)
HP36
inches (mm)
A. Overall height of product 13 3/4” (350) 13 3/4” (350)
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
2

Product Dimensions HP24
inches (mm)
HP36
inches (mm)
B. Overall height of product (with power connection box) 18 1/4” (463) 18 1/4” (463)
C. Overall width of product 20 7/8” (530) 32 11/16” (830)
D. Overall depth of product 11” (280) 11” (280)
E. Thickness of flange 1/16” (2) 1/16” (2)
F. Width of chassis 19 3/8” (492) 31 3/16” (792)
G. Depth of chassis 10 1/16” (255) 10 1/16” (255)
H. Height of side of chassis 7 11/16” (195) 7 11/16” (195)
I. Width of top surface of chassis 11 3/4” (298) 11 3/4” (298)
J. Length of angled surface of chassis 6 7/8” (175) 11” (280)
K. Distance from center of ducting outlet to back of chassis 3 1/8“ (80) 3 1/8” (80)
L. Distance from center of ducting outlet to side of chassis 9 5/8” (245) 15 9/16” (395)
M. Diameter of ducting outlet 6” (152) 6” (152)
N. Distance between center of lights 14 3/4” (375) 26 9/16” (675)
O. Distance from center of light to front of product 1 9/16” (40) 1 9/16” (40)
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
3

Cabinetry Cutout Dimensions HP24
inches (mm)
HP36
inches (mm)
Overall width of cutout 19 11/16" (500) 31 1/2" (800)
Overall depth of cutout 10 1/4" (260) 10 1/4" (260)
P. Base of brackets/clips to bottom
chassis
min. 9/16" - max. 1 9/16" (min. 15 -
max. 40)
min. 9/16" - max. 1 9/16" (min. 15 -
max. 40)
• Actual product dimensions may vary by ± 1/16” (2 mm).
• Please read the entire instructions before installing the ventilation hood.
Height of Ventilation Hood
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
4

Minimum Clearances inches (mm)
Q. Height top of cooktop to base of product min. 26” – max. 30” (min 660 – max. 762)
This ventilation hood must be installed no lower than the minimum height indicated in the table above. Minimum
installation height may be greater if required by the cooktop manufacturer or safety and warning section of this user
guide. Installation at the minimum height will improve the efficiency of capturing cooking odors, grease and smoke.
Installation at the maximum height improves user ergonomics by offering increased head room.
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
5

• To reduce the risk of fire, use only metal ductwork. Do not use flexible plastic ducting
• To reduce risk of fire and to properly exhaust air, be sure to duct air outside – do not vent
exhaust air into spaces within walls or ceilings or into attics, crawl spaces, or garages.
Venting Options
Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air are fulfilled.
The ventilation hood can be installed to operate with the exhaust air ducted externally from the kitchen.
Ducted
For ducted installation it is recommended that 6” (152 mm) diameter, rigid or semi-rigid ducting is used. This will require
a 6 5/16” (160 mm) (min) round hole in the ceiling or wall. Care should be taken to position the hole correctly.
For optimal efficiency use the shortest and straightest duct route possible and use rigid or semi-rigid ducting for reduced
noise and increased airflow. Flexible metal ducting should only be used as a last resort (ie in difficult installations) and if
used ensure that it is straight and smooth and extended as much as possible.
•This appliance is heavy and requires two persons for unpacking and installation
•Installation work and electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards.
•Failure to install the screws or fixing device in accordance with these instructions may
result in electrical hazards
Wear gloves to protect against sharp edges.
The manufacturer is not liable for any damage caused by not following these instructions.
Installation
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
6

1. Prepare for Installation
Before installing your ventilation hood:
• Please read the instructions carefully.
• Unpack the ventilation hood and check that all functions are working.
• Ensure that the voltage (V) and the frequency (Hz) indicated on the serial plate match the voltage and frequency
at the installation site.
• The stainless steel surfaces of the ventilation hood are very easily damaged during installation if grazed or
knocked by tools. Please take care to protect the surfaces during installation.
• Protect the cooktop surface below with cardboard, or the like, to prevent damage occurring whilst the ventilation
hood is being installed above.
2. Attach ducting adapter and power connection box to the ventilation hood
• Place the ducting adapter onto the ventilation hood and screw
it in place using 3/8” (10 mm) screws.
• Place the power connection box onto the ventilation hood and
screw it in place using 3/8” (10 mm) screws.
• Follow wiring instructions described in the ‘Electrical
connection’ section.
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
7

3. Provide an opening on the underside of the cupboard (see product and cabinetry cutout
dimensions).
• It is also recommended that the cupboard has a door or service
panel that can be easily opened to access the power connection
box
4. Remove the filters and face plate of the ventilation hood.
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
8

5. Lift the ventilation hood and fit through the opening of the cupboard till the spring loaded
brackets / clips hold the product in place.
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
9

6. Secure ventilation hood while tightening the 4 brackets / clips.
Electrical wiring must be done by qualified person(s) in accordance with all applicable
codes and standards and the unit must be grounded.
7. Electrical Connection
• Run three wires, two for the power supply and
one for the ground wire, from the power
connection box on the ventilation hood to a
power connection point near the installation.
• Open the power connection box on the
ventilation hood and secure the power conductor
with a cULus listed strain relief (not included).
• Connect the power conductors to the conductors
for the ventilation hood, black to black and white
to white.
• Connect the grounding wire (green or bare) to
the ground conductor (green) of the ventilation
hood power connection box.
• Secure all the connections with cULus listed wire
nuts.
• Replace the power connection box cover.
https://producthelp.fisherpaykel.com/us/Cook/Ventilation/Built-In_Integrated/HP36ILTX1/User_Guide_HP36ILTX1/03_installati…
Updated: Thu, 02 Apr 2020 06:40:38 GMT
Powered by
10
