Fisher & Paykel VS36 User manual

THE PROFESSIONAL
AND EURO VENT HOOD
VS30, VS36, VS48, VS1236,
ES30, ES36 models
LA HOTTE DE VENTILATION
EUROPÉENNE PROFESSIONNELLE
Modèles VS30, VS36, VS48,
VS1236, ES30, ES36
INSTALLATION GUIDE
GUIDE D’INSTALLATION
US CA

Thank you for selecting this Fisher & Paykel Professional Vent Hood. Because of this appliance’s unique
features we have developed this Installation Guide. It contains valuable information on how to properly
install your new appliance for years of safe and enjoyable cooking. Keep this guide handy, as it will help
answer questions that may arise as you use your new appliance.
For your convenience, product questions can be answered by a Fisher & Paykel Customer Care
Representative by phone: [phone], or email: [email protected].
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.
AMESSAGE TO OUR CUSTOMERS
1
APPROVED FOR INDOOR COOKING APPLIANCES AND RESIDENTIAL USE ONLY.
PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING.
Installation must comply with all local codes.
NOTE: Please write the Model, Code, and Serial Numbers on this page for references (located on the
inner back panel, behind grease filters, below motor assembly)
MODEL NUMBER CODE SERIAL NUMBER
WARNING
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or
death.
Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
DANGER
If You Smell Gas:
■Do not try to light any appliance.
■Do not touch any electrical switch; do not use any phone in
your building.
■Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
■If you cannot reach your gas supplier, call the fire department.
■Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
NOTE:Inspect the product to verify that there is no shipping damage. If any damage is detected,
call the shipper and initiate a damage claim. Fisher & Paykel is not responsible for shipping
damage.
DO NOT discard any packing material (box, pallet, straps) until the unit has been inspected.
Some models listed in this guide may not have the Fisher & Paykel brand or logo displayed on the product.

CONTENTS
2
SAFETY PRACTICES .....................................................................................................................................................3-5
PRODUCTDIMENSIONS ..............................................................................................................................................6
PARTS ........................................................................................................................................................................................7
BEFORE INSTALLING HOOD .................................................................................................................................8-9
INSTALLATION ............................................................................................................................................................10-15
Wall Mount Installation................................................................................................................................10-12
Cabinet Installation........................................................................................................................................13-14
Integral Ventilator Installation..........................................................................................................................15
HOW TO OBTAIN SERVICE........................................................................................................................................16
WARRANTY..........................................................................................................................................................................17
AMESSAGE TO OUR CUSTOMERS
SAFETY WARNING:
Turn off power circuit at service panel and lock out panel, before wiring this
appliance.
Requirement: 120 V AC, 60 Hz. 15 A Branch Circuit
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGETOP
GREASE FIRE, OBSERVE THE FOLLOWING : Turn burner off first. SMOTHER
FLAMES with a close-fitting lid, cookie sheet, or metal tray. BE CAREFUL
TO PREVENT BURNS. If the flames do not go out immediately
EVACUATE AND CALL THE FIRE DEPARTMENT. NEVER PICK UP A
FLAMING PAN - You may be burned. DO NOT USE WATER, including
wet dishcloths or towels - a violent steam explosion will result. Use
an extinguisher ONLY if:
1) You know you have a Class ABC extinguisher, and you already
know how to operate it.
2) The fire is small and contained in the area where it started.
3) The fire department is being called.
4) You can fight the fire with your back to an exit.

SAFETY PRACTICES AND PRECAUTIONS
3
CAUTION:
For general ventilating use only. DO NOT use to exhaust hazardous or
explosive materials or vapors.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS
OBSERVE THE FOLLOWING:
A. Use this unit only in the manner intended by the manufacturer. If you have questions, contact
the manufacturer.
B. Before servicing or cleaning the unit, switch power off at service panel and lock service panel
disconnecting means to prevent power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
C. Installation work and electrical wiring must be done by qualified person(s) in accordance with
all applicable codes & standards, including fire-rated construction.
D.Sufficientair is needed tomaintain proper combustion and safe exhausting of gases through
the flue (chimney) of fuel burning equipment to prevent backdrafting. Follow the heating
equipmentmanufacturers guideline and safetystandards such as those published bythe
National Fire Protection Association (NFPA), the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code authorities.
E. When cutting or drilling intowall or ceiling, do not damage electrical wiring and other hidden
utilities.
F. Ducted systems must always be vented to the outdoors.
CAUTION:
To reduce the risk of fire and to properly exhaust air, be sure to duct air to
outside. Do not vent exhaust air into spaces within walls or ceiling, nor into
attics, crawl spaces, or garages.
WARNING:
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
Install this hood in accordance with all requirements specified.
WARNING:
To reducethe risk of fireor electric shock,do not use this hood with any
external solid state speed control device.

SAFETY PRACTICES & PRECAUTIONS
4
WARNING:
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
A. Never leave surface units unattended at high settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oil slowly on low or medium settings.
B. Always turn hood“ON”when cooking at high heat or when flambeing food (i.e. Crepes Suzette,
Cherries Jubilee, Peppercorn Beef Flambe’).
C. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or filter.
D. Use proper pan size. Always use cookware appropriate for the size of the surface unit.
WARNING:
TO REDUCE THE RISK OF INJURY TO PERSONS, IN THE EVENT OF A RANGE TOP GREASE
FIRE, OBSERVE THE FOLLOWING a:
A. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or other metal tray, then turn off the
gas burner or the electric element. BE CAREFUL TO PREVENT BURNS. If the flames do not go
out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.
B. NEVER PICK UP A FLAMING PAN - you may be burned.
C. DO NOT USE WATER, including wet dishcloths or towels - a violent steam explosion may result.
DO NOT use water on a grease fire. Burning grease and water will explode.
D. Use an extinguisher ONLY if:
1) You know you have a class ABC extinguisher, and you already know how to operate it.
2) The fire is small and contained in the area where it started.
3) The firedepartment is being called.
4) You can fight the fire with your back to an exit.
NOTE: Unit MUST be vented to the outside of the building.
aBased on “Kitchen Firesafety Tips” published by NFPA.
IMPORTANT: Refer to ducting information supplied in this Manual ( Pg. 9)
WARNING:
Toreduce the risk of electrical shock or injury to persons, all vent hoods
must be installed with ventilators that have been approved for use with the
hood.

SAFETY PRACTICES & PRECAUTIONS
5
This Vent Hood system is designed to remove smoke, cooking vapors and odors from the cooktop
area.
WARNING:
All wall and floor openings where the vent hood is installed must be
sealed.
Consult the cooktop or range installation instructions given by the manufacturer before making any
cutouts. MOBILE HOME INSTALLATION - The installation of this Hood must conform to the
Manufactured Home Construction and Safety Standards, Title 24 CFR, Part 3280 (formerly Federal
Standard for Mobile Home Construction and Safety, Title 24, HUD, Part 280). Three wire power supply
must be used and the appliance wiring must be revised. See electrical requirements on page 1.
■DO NOT use 4" laundry-type wall caps.
■Flexible-type ductwork is not recommended.
■DO NOT obstruct the flow of combustion and ventilation air. Be sure a fresh air supply is
available.
■Failure to follow venting requirements may result in a fire.
■Electrical ground is required on this Hood.
■If cold water pipe is interrupted by plastic, non-metallic gaskets or other materials, DO NOT use
for grounding.
■DO NOT ground to a gas pipe.
■DO NOThave a fuse in the neutral or grounding circuit. A fuse in the neutral or grounding
circuit could result in electrical shock.
■Check with a qualified electrician if you are in doubt as to whether the Hood is properly
grounded.
■Failure to follow electrical requirements may result in a fire.
■Be sure all the range and/or cooktop controls are turned off and the appliance is cool before
using any type of aerosol cleaner on or around the appliance. The chemical that produces the
spraying action could, in the presence of heat, ignite or cause metal parts to corrode.
■Clean the ventilator hood and filters above the range or cooktop frequently so grease from
cooking vapors does not accumulate on them.
■Service should only be done by authorized technicians. Technicians must disconnect the power
supply before servicing this appliance.
WARNING:
California Proposition 65 - The burning of gas cooking fuel generates some
by-products which are known by the State of California to cause cancer or
reproductive harm. California law requires businesses to warn customers of
potential exposure to such substances. To minimize exposure to these
substances, always operate this unit according to the instructions
contained in this booklet and provide good ventilation to the room when
cooking with gas.

PRODUCT DIMENSIONS
6
ES30= 29-7/8"
ES36= 35-7/8"
ES30= 29-7/8"
ES36= 35-7/8"
23"
2
12"
6" or 12"
(Duct Cover
Accessory Height)
ES30= 14-15/16"
ES36= 17-15/16"
12"
6"
25"
2
18"
6" or 12"
(Duct Cover
Accessory Height)
VS30= 29-7/8"
VS36/VS1236= 35-7/8"
VS48= 47-7/8"
VS30= 29-7/8"
VS36/VS1236= 35-7/8"
VS48= 47-7/8"
VS30= 14-15/16"
VS36/VS1236= 17-15/16"
VS48= 23-15/16"
12"
6"
EURO VENTHOOD
WALL MOUNT VENTHHOOD

7
PARTS
PARTS INCLUDED WITH YOUR HOOD
■Hood Canopy Assembly with Light Bulbs installed.
■Metal Transition with Back draft dampers (already installed on ES30, ES36, VS30, VS36 models)
■Use & Care /Installation Instructions
■Filters (quantity depending on model and size)
■Screws and Drywall Anchors
■Wooden Strip for Hood Support
■Drip Trays (quantity depending on model and size)
■Filter Trim Bracket (ES36 model only – Install on unit after electrical connections are completed
on page 15)
■Integral Blower
PARTS NOT INCLUDED WITH YOUR HOOD
■Ducting (See Page 9 for duct requirements: 8” or 10” Ø to be used.)
■DuctTape
■1/2" Conduit
■Wire Nuts
■Optional duct cover,6” or 12” height
VDC1230 – 12” Duct cover kit for VS30/ES30
VDC1236 – 12” Duct cover kit for VS36/VS1236/ES36
VDC1248 – 12” Duct cover kit for VS48
VDC630 – 6” Duct cover kit for VS30/ES30
VDC636 – 6” Duct cover kit for VS36/VS1236/ES36
VDC648 – 6” Duct cover kit for VS48
■Optional IR Kit + support bracket (Infrared bulbs included. Use only bulbs mod. 175R-PAR,
175W maximum infrared bulbs).
IR30 – Kit with single 175 W heat lamp for VS30/ES30
IR36 – Kit with two 175 W heat lamp for VS36/VS1236/ES36
IR48 – Kit with two 175 W heat lamp for VS48

8
BEFORE INSTALLING HOOD
1. For the most efficient air flow exhaust, use a straight run or as few elbows as possible. Maximum
duct length is 40 feet, including elbows.
CAUTION:
Vent unit to outside of building only.
2. Two people are necessary for installation.
3. The hood is fitted with Screws and Drywall Anchors suitable for most surfaces. Consult a qualified
installer.
4. Do not use flex ducting.
5. COLD WEATHER installations should have an additional backdraft damper installed to minimize the
back flow of cold air and nonmetallic thermal break to minimize conduction of outside temper-
atures as part of the ductwork. The damper should be on the cold air side (outside wall) of the
thermal break.
The break should be as close as possible to where the ducting enters the heated portion of the
house.
6. Local building codes may require the installation of a make-up air system. Consult your HVAC
professional for specific requirements in your area.
7. Hood installation height above cooktop is the users preference. Lower installation heights will
improve the efficiency of capturing cooking odors, grease, and smoke. This hood has been
approved for installation heights 30” above the cooktop. Taller people may find a 30” installation
height is inconvenient. Fisher & Paykel recommends an installation height between 30” and 36”.
8. ES30 and ES36 hood models are not recommended to be used over indoor range grills.
9. For installation over Fisher & Paykel Range and Cooktop models RGS-364GL or CS-364GL, the
VS1236 model vent is recommended.
10.Make sure your range or cooktop is level.
TYPICAL INSTALLATION
The hood can be installed using a wall mounting system or suspended under existing cabinetry in the
kitchen. Ducting can be configured for both vertical and horizontal discharge.
If an infrared kit was purchased for installation with the hood, assemble the kit to the hood prior to
installation.
For wall mount instllations, duct cover kits can be purchased as spacers between hood and ceiling.
Duct covers are assembled to unit after the hood is installed.

9
ELELCTRICAL
Install a 1/2” conduit from the service panel long enough to reach the hood once it is installed.
Branch circuit requirement is 120V, 60Hz, 15A(minimum).
INFRARED LAMP AND PANEL KIT
Optional infrared lamp and panel kit can be ordered separately and mounted into your vent hood.
Models available: IR30, IR36 and IR48. See instructions supplied with kit for assembly to your hood.
WARNING
To avoid any electrical shock the installation of the IR lamp should be done
by a qualified electrician and before starting the installation of the hood.
DUCTING
Hood models: ES30, ES36, VS30, VS36 are supplied with a starting collar and backdraft damper on top
of the hood for connection to 8”round duct. Models: VS1236 and VS48 are supplied with a 10” round
transition with damper and is assembled as shown in Fig. 3.
Vertical Discharge Figure
Horizontal Discharge Figure
Install ducting long enough to reach the transition once the hood is installed plus 1-1/2 inch to
connect ductwork.
ASSEMBLE TRANSITION TO HOOD (VS1236 and VS48 hoods only)
The transition supplied with the hood mounts tothe top of the
hood, Figure 3.
1. Place the transition piece over the hood exhaust and
securewith 4 screwsprovided (Figure 3).
2. Duct tape connection between transition and hood.
3. Remove tape holding damper
FIG. 3
BEFORE INSTALLING HOOD
6"
FIG. 1
FIG. 2
canopy
canopy
AFOR 900ELBOW A
10” 16”
8” 11”

10
INSTALLATION
WALL MOUNT INSTALLATION
Calculating Installation Height –Installation height for a standard 8 ft high kitchen ceiling is shown
below in Figure X. The minimum installation height allowed is 30”. Typical installations are between
30” and 36”.
Use the following formula to calculate installation height:
Installation Height =(Ceiling Height) – (Height Cooktop Surface) – (Hood Height) –
(DuctCover Height)
(Example: Installation height = 96” – 36”– 18” – 12” = 30”)
Hood Height = 12” for ES30 and ES36 models
18” for VS30, VS36, VS1236 and VS48 models
Duct Cover Height – Duct cover accessories are available in 6” or 12” heights. For taller
ceilings duct covers can be joined together in any combination.
1. Hood Installation Height
After the hood installation height has been determined, draw a horizontal line at a distance above
the cooktop equal to the desired hood installation height plus dimension “E” (see Table on
Figure 4).
This line is the mounting location of the wooden bracket shipped with the hood.
2. Find the centerline of the cooktop. Draw a vertical line along this centerline up to the horizontal line
drawn in step 1.
3. The hood is mounted to the wall using a wooden bracket shipped with the hood. Remove the
bracket from the hood by removing two shipping screws. Mark the centerline of the bracket.
8ft
(96")
30" to 36"
recommended
12" or
18"
12"
36"
Duct Cover Height
Hood Height
Ceiling Height
Cooking Surface Height
Installation Height Figure X
Installation Height

11
INSTALLATION
4. Find studs behind the drywall by tapping the wall or using a stud finder. Locate one stud on either
side of the cooktop centerline to use for mounting the wooden bracket as shown in Figure 4.
5. Align the top of the wood bracket along the horizontal line drawn in step 1. Align the centerlines
of the bracket and cooktop.
6. Drill a 3” deep 1/8” hole through the wooden bracket, drywall and into the stud.
7. Use 2 to 4, 1/4” x 3” flat head wood screws to attach the bracket to the wall as shown in Figure 4.
For support of longer hoods, use three or four studs as available. Countersink the heads to prevent
interference with the hood.
8. On the wood bracket, mark the locations used to hang the hood according to Figure 5 and its Table.
HOOD MODEL DIM. “E”
VS Series 15-1/2”
ES Series 10-3/8”
HOOD MODEL DIM. “F”
VS Series 7-5/8”
ES Series 7-9/16”
COOKTOP
CENTERLINE
DRYWALL
SCREWS
(2 ea. 4.2 x 18)
DIM "F"
TO COOKTOP
SURFACE
DESIRED COOKTOP
HEIGHT + "E"
SCREWS
(2 ea. 1/4" x 3")
STUDS
COOKTOP
CENTERLINE
HEIGHT ABOVE
COOKTOP
DRYWALL
FIG. 4
FIG. 5

12
INSTALLATION
9. Drill a 1/8” hole through the wooden bracket and drywall. These screws do not need to go into
the studs.
10. Screw two #10 X 3/4” pan head wood screws into the wood bracket, leaving 1/4” of the screw
exposed for hanging the hood.
11. Hang the hood using slots I in
Figure 6. Make sure the wood
bracket fits into the recess on the
back of the hood.
12. Level the hood and tighten screws
in slot I.
13. From inside the hood, drive 4 or 6
#10 x 3/4” pan head wood screws
(depending on model) through
holes J into wooden bracket.
14. Fix duct to transition with screws
and seal with ducttape. Screws
must not hamper the damper.
15. Drill a 3/8” hole through the center of the holes K into the wall. Insert two wall plugs into drilled
holes. Tighten hood to wall anchors by installing 2 screws with washers.
ASSEMBLY AND INSTALLATION
OF THE DUCT COVERS:
Optional duct covers shown in Figure 7
maybe used tofill the spacebetween
the hood and ceiling in wall mount
installations.6”and 12”high duct covers
are available and may be ordered
separately.
1. If multiple duct covers are used,
connect the pieces together using
sheet metal screws provided with
chimneys.
2. Attach the duct cover(s) to the hood
using sheet metal screws as shown
in Figure 7.
J
I
K
FIG. 6
Go to page 14 to continue the installation.
Attaching
screws
FIG. 7

13
INSTALLATION
CABINET INSTALLATION
Cabinet Preparation
WARNING:
The cabinet must be structurally joined to the wall studs to support the
weight of this hood.
Cabinet
Vertical
DischargeCutoutWidth
Bottomof
Cabinet or
Soffit
1-1/2" Dia. Holes
Horizontal conduit
option
A
B
C
D
E
F
H
G
I
1-1/2" Dia. Holes
Vertical conduit
option
A)
B)
C)
D)
E)
F)
G)
H)
I)
Min.12"
6"
10"
6-3/4"
1-7/8"
5-3/4"
5-7/8"
1-7/8"
5-1/8"
ES30=30"
ES36=36"
C/L
Cabinet
Vertical
DischargeCutoutWidth
Bottomof
Cabinet or
Soffit
1-1/2" Dia. Holes
Horizontal conduit
option
A
B
C
DE
F
H
G
I
1-1/2" Dia. Holes
Vertical conduit
option
A)
B)
C)
D)
E)
F)
G)
H)
I)
J)
Min.12"
6"
11"
11"
6-3/4"
1-7/8"
5-3/4"
8-3/8"
1-7/8"
5-1/8"
J
C/L
VS30=30"
VS36=36"
VS48=48"
VS1236=36"
ES30/ES36 SERIES HOOD
VS30/VS36 SERIES HOOD
VS1236/VS48 SERIES HOOD

14
INSTALLATION
CABINET INSTALLATION
1. Find the centerline of the cabinet bottom. Draw a line along this centerline from rear to front of
the cabinet.
2. Refer to the top of the hood and Fig. 8. Draw two lines, one at distance ‘K’ from the wall, the other
one at distance‘Z’ from the previous line. NOTE: These lines must be perpendicular to the cabinet
centerline. Mark 4 points , two along each line at a distance of half W from the center line, to
determine the screw locations.
3. Fit four #10 pan head wood screws on cabinet bottom. Do not tighten completely but leave a
space of about 1/2” from cabinet bottom surface and screw heads.
4. Hang the hood on screws through side slots provided on hood top. Tighten the four screws.
Drill a 3/8” hole through the center of the holes K into the wall. Insert two wall plugs into drilled
holes. Tighten hood to wall anchors by installing 2 screws with washers.
5. Attach duct to transition with screws and seal with duct tape. Screws must not hamper the
damper.
C/L
ww
FIG. 8
Knockouts
(junction box)
Side slot for cabinet
bottom mounting
Transition with
Backdraft (Top outlet)
Screw for cabinet bottom
installation
W
Z
K
ZK
CL
W
ES SERIES
KZ W
ES30 2-11/16" 6-7/8" 29-1/16”
ES36 2-11/16" 6-7/8" 35-1/16"
VS SERIES
KZ W
VS30 2-5/8" 7-1/16" 29-1/16"
VS36/VS1236 2-5/8" 7-1/16" 35-1/16"
VS48 2-5/8" 7-1/16" 47-1/16"

15
INSTALLATION
INTEGRAL VENTILATOR INSTALLATION
The Integral ventilator can be mounted to discharge air as shown in Figure 9. From the inside of the
hood, slip motor into the bracket on the left. Rotate motor upwards until it snaps into the spring clip
on the right.
IMPORTANT: Secure the motor to the hood with the machine screw and lock washer.
WIRING THE HOOD:
WARNING:
Turn off electricity at the service panel before wiring the unit.
Branch circuit requirement is 120V, 60Hz, 15A (minimum).
1. Connect the Integral Ventilator molex plug
connector to the connector present inside the
hood as shown in Figure 9 or Figure 10.
2. Remove the j-box cover as shown in Figure 11.
3. Remove 1 of 2 knockouts and install 1/2” conduit
connector in j-box.
4. Run black, white, and green wires (#18 AWG) in
1/2” conduit from power supply to j-box.
5. Connect the black to black (hot line) wire, white to
white(common line) wireand green/yellow wire
to ground in j-box cover.
6. Close j-box cover.
7. For ES36 only: mount the filter trim bracket
supplied on the right side of the hood. Check that
all engage points perfectly match, then fix with 3
screwsas shown in figure 12.
Final installation steps
Replacefilters and grease trays as described in the
Use & Care manual. Turn power on at service panel.
Check operation of the hood.
Bracket
Motor
connector Spring clip
Integral ventilator
fixing point
Power
supply
conduit
From
control
panel
Motor
support
FIG. 11
FIG. 10
FIG. 9
FIG. 12
SCREW
LOCATIONS

16
HOW TO OBTAIN SERVICE
BEFORE YOU CALL FOR SERVICE
■Is the circuit breaker tripped or the fuse blown?
■Is there a power outage in the area?
For warranty service, please contact your local service provider or Fisher & Paykel Customer Care
Representative at [phone]. Before you call, please have the following information ready:
■Model Number (located on the inner back panel, behind grease filters, below motor
assembly)
■Serial Number (located on the inner back panel, behind grease filters, below motor
assembly)
■Code (located on the inner back panel, behind grease filters, below motor assembly)
■Date of installation
■Abrief description of the problem
■Proof of purchase
Your satisfaction is of the utmost importance to us. If a problem cannot be resolved to your satisfaction,
please call, write or email us at:
Write:
Fisher & Paykel Appliances, Inc.
Attention: F&P Customer Care
5900 Skylab Road
Huntington Beach, CA 92647
email: customer[email protected]

17
WARRANTY
LIMITED WARRANTY
When you purchase a new Fisher & Paykel Ventilation Product for personal or consumer use you
automatically receive a One year Limited Warranty covering parts and labor for the entire product,
and a Five year Limited Warranty on the switches and motor (parts only) for servicing within the 48
mainland United States, Hawaii, Washington D.C and Canada. In Alaska the Limited Warranty is the
same except that you must pay to ship the Product to the service shop or for the service
technician’s travel to your home. Products for use in Canada must be purchased through the
Canadian distribution channel to ensure regulatory compliance.
If the Product is installed in a motor vehicle, boat or similar mobile facility, you receive the same One
year Limited Warranty, but you must bring the vehicle, boat or mobile facility containing the Product
to the service shop at your expense or pay the service technician’s travel to the location of the Product.
FISHER & PAYKEL UNDERTAKES TO:
Repair without cost to the owner either for material or labor any part of the Product, the serial number
of which appears on the Product, which is found to be defective. In Alaska, you must pay to ship the
Product to the service shop or for the service technician’s travel to your home. If the Product is installed
in a motor vehicle, boat or similar mobile facility, you must bring it to the service shop at your expense
or pay for the service technician’s travel to the location of the Product. If we are unable to repair a
defective part of the Product after a reasonable number of attempts, at our option we may replace the
part or the Product, or we may provide you a full refund of the purchase price of the Product (not
including installation or other charges).
This warranty extends to the original purchaser and any succeeding owner of the Product for products
purchased for ordinary single-family home use. All service under this Limited Warranty shall be
provided by Fisher & Paykel or its Authorized Fisher & Paykel Service Agent during normal business hours.
HOW LONG DOES THIS LIMITED WARRANTY LAST?
Our liability under this Limited Warranty for the entire product expires One Year from the date of
purchase of the Product by the first consumer. Our liability under this Limited Warranty for the
switches and motor (parts only) expires Five Years from the date of purchase of the Product by the first
consumer.
Our liability under any implied warranties, including the implied warranty of merchantability (an
unwritten warranty that the Product is fit for ordinary use) also expires One Year (or such longer period
as required by applicable law) from the date of purchase of the Product by the first consumer. Some
states do not allow limitations on how long an implied warranty lasts, so this limit on implied
warranties may not apply to you.
THIS WARRANTY DOES NOT COVER:
A. Servicecalls thatarenot related to any defect in the Product. The cost of a service call will be
charged if the problem is not found to be a defect of the Product. For example:
1. Correct faulty installation of the Product.
2. Instruct you how to use the Product.
3. Replace house fuses, reset circuit breakers, correct house wiring or plumbing, or replace light
bulbs.
4. Correctfault(s) caused bythe user.
5. Change the set-up of the Product.
6. Unauthorized modifications of the Product.

WARRANTY
18
7. Noise or vibration that is considered normal, for example, drain/fan sounds, regeneration
noises or user warning beeps.
8. Correcting damage caused by pests, for example, rats, cockroaches etc.
B. Defects caused by factors other than:
1. Normal domestic use or
2. Use in accordance with the Product’s Use and Care Guide.
C. Defects to the Product caused by accident, neglect, misuse, fire, flood or Act of God.
D. The cost of repairs carried out by non-authorized repairers or the cost of correcting such
unauthorized repairs.
E. Travel Fees and associated charges incurred when the product is installed in a location with limited
or restricted access. (i.e. airplane flights, ferry charges, isolated geographic areas).
F. Normal recommended maintenance as set forth in the Product’s Use and Care Guide.
If you have an installation problem contact your dealer or installer. You are responsible for providing
adequate electrical, exhausting and other connection facilities. We are not responsible for
consequential or incidental damages (the cost of repairing or replacing other property damaged if the
Product is defective or any of your expenses caused if the Product is defective). Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
HOW TO GET SERVICE
Please read your Use and Care Guide. If you then have any questions about operating the Product,
need the name of your local Fisher & Paykel Authorized Service Agent, or believe the Product is
defective and wish service under this Limited Warranty, please contact your dealer or call us at:
TOLL FREE 1-888-936-7872 or contact us through our web site: www.fisherpaykel.com.
You may be required to provide reasonable proof of the date of purchase of the Product before the
Product will be serviced under this Limited Warranty.
COMMERCIAL USE
This warranty applies to appliances used in residential applications; it does not cover their use in
commercial situations.
NO OTHER WARRANTIES
This Limited Warranty is the complete and exclusive agreement between you and Fisher & Paykel
Appliances, Inc. regarding any defect in the Product. None of our employees (or our Authorized
Service Agents) are authorised to make any addition or modification to this Limited Warranty.
Warrantor: Fisher & Paykel Appliances, Inc.
If you need further help concerning this Limited Warranty, please call us at the above number, or write
to:
Fisher & Paykel Appliances, Inc.
5900 Skylab Road, Huntington Beach, CA 92647
This Limited Warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
