Fisher & Paykel HC60CGX1 Mounting instructions

NZ AU EU
Installation instructions
and User guide (EN)
Instrucciones para la instalación
ysu uso (ES)
Einbauanleitung wartung
und gebrauch (DE)
Conseils d’installation
et guide d’utilisation (FR)
Istruzioni per l’installazione
eguida per l’utente (IT)
Installatievoorschriften
en gebruiksaanwijzing (NL)
Installationsanvisninger
og brugsanvisning (DA)
Asennusohjeet ja käyttöopas (FI)
Installationsinstruktioner
och användarmanual (SV)
Installasjonsanvisninger
og brukerhåndbok (NO)
Οδηγίες εγκατάστασης
και οδηγίες χρήσης (EL)
Designer wall canopy
HC90CGX1 & HC60CGX1 models

EN
EN English
Installation instructions Page 4 – 12 Page 1 – 3
ES Español
Instrucciones para la instalación Pág 13 – 16 Pág 1 – 3
DE Deutsch
Einbauanleitung wartung Seite 17 – 23 Seite 1 – 3
FR Français
Conseils d’installation Page 24 – 29 Page 1 – 3
IT Italiano
Istruzioni per l’installazione Pagina 30 – 35 Pagina 1 – 3
NL Nederlands
Installatievoorschriften Pagina 36 – 41 Pagina 1 – 3
DA Dansk
Installationsanvisninger Side 42 – 47 Side 1 – 3
FI Suomi
Asennusohjeet Sivu 48 – 53 Sivu 3 –5
SV Svenska
Installationsinstruktioner Sidorna 54 – 59 Sidorna 3 –5
NO Norsk
Installasjonsanvisninger Side 60 – 65 Side 1 – 3
EL Ελληνικά
Οδηγίες εγκατάστασης Σελίδα 66 – 71 Σελίδα 1 – 3
IL Hebrew
Üzembehelyezési Page 72 – 75 Page 1 – 3

1
EN
Installation instructions
3 4
1
2
Model 60 cm 70 cm 90 cm
A420 420 580

2
EN
Installation instructions
7 8
5 6

3
EN
Installation instructions
11 12
910

4
EN
Contents
Important!
SAVE THESE INSTRUCTIONS
The models shown in this User Guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.
Safety and warnings 5
Preparing to install 7
Operating your wall canopy 8
Cleaning and maintenance 9
Manufacturer’s Warranty 10
Customer Care 11

5
EN
Safety and warnings
WARNING!
Electrical Shock Hazard
All electrical work must be done in accordance with local and/or national
electrical codes as applicable. For safety, this product must be earthed. If
you are unfamiliar with methods of installing electrical wiring, employ the
services of a qualified electrician. Turn off power at service entrance before
installing wiring or servicing this product.
WARNING!
14.8 kg
(HC60)
17.2 kg
(HC90)
14.8 kg
17.2 kg
Weight Hazard
The wall canopy is heavy. Please ensure adequate care is taken when
installing the wall canopy to prevent personal injury. The wall canopy must
be installed onto a solid wall, stud, beam or truss. Weight of the product is
14.8 kg (HC60) / 17.2 kg (HC90).
Important safety precautions
Please read the entire set of instructions before installing the wall canopy.
Ducting accessories are not supplied. All ducting must comply with local requirements and
building codes.
Before connecting any pipes, consult municipal ordinances to ensure that any applicable
regulations concerning the discharge of exhaust air are adhered to and request permission from
the person in charge of the building.
Exhaust air must not be discharged into an existing flue that is used for exhausting fumes from
appliances burning gas or other fuels.
There must be adequate ventilation of the room when the wall canopy is used at the same time
as appliances burning gas or other fuels. (A partial vacuum in the room could result in too high a
concentration of gas in the air).
When the canopy is turned on at the same time as other appliances powered by energy other
than electricity, the air outlet must not be greater than 4 Pa (4x10-5 bar).
The minimum distance between the cooktop surface and the filters of the wall canopy shall be
600 mm, or 650 mm if installed over a gas cooktop (except for wall canopy availed to Australia
market, 600mm).
Stainless steel is very easily damaged during installation if abraded or knocked by tools. It
is recommended to protect the top of the canopy with cardboard or polystyrene during the
installation to minimise the risk of damage occurring.
To comply with electrical safety regulations, this canopy must be plugged into a socket near the
appliance. The socket must be accessible, or have an accessible isolating switch, to enable the end
user to isolate the canopy from the power for the purpose of internal cleaning or maintenance.
A power outlet should be within 750 mm of the motor assembly and can be either on the wall,
behind the chimney or in the ceiling.

6
EN
Safety and warnings
Always switch the power off prior to installation, servicing or cleaning the wall canopy.
If the supply cord of this equipment is damaged it must only be replaced by the manufacturer,
its service agent or similarly qualified person in order to avoid a hazard.
Children must be supervised to ensure that they do not play with the hood.
This canopy is not designed to be used by people (including children) with reduced physical,
sensorial or mental capacity, or who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the hood by someone who is responsible for their safety.
You must read the details concerning the method and frequency of cleaning.
There is a fire risk if cleaning is not carried out in accordance with the instructions.
Never leave frying food unattended since grease can overheat and catch fire. The risk of fire is
even greater in the case of used oil.
Do not flambé under the wall canopy.
Never use the wall canopy without the filters in place.
During climatic conditions causing electrical interference, it is possible that the device may stop
working. By switching the device OFF and ON the device will resume normal operation safety.
During an electrostatic discharge (ESD) it is possible that the device will stop working. By
switching the device OFF and ON the device will again work as intended. There will be no risk
hazard presenting in the product.
CAUTION: Accessible parts may become hot when used with cooking appliances.

7
EN
Preparing to install
Please read this instruction manual carefully in order to obtain the best results from the use of
the wall canopy.
If you need any technical help or would like more information about our products, please do
not hesitate to contact your local Fisher & Paykel retailer.
Preparing the wall canopy for installation
Before installing your wall canopy:
Please read the instructions carefully.
Unpack the canopy and check that all functions are working.
Ensure that the voltage (V) and the frequency (Hz) indicated on the serial plate match the
voltage and frequency at the installation site.
Check that the area behind the installation surface to be drilled is clear of any electrical cables
or pipes, etc.
The stainless steel and glass surfaces of the canopy are very easily damaged during installation if
grazed or knocked by tools. Please take care to protect the surfaces during installation.
Protect the cooktop surface below with cardboard, or the like, to prevent damage occurring
whilst the wall canopy is being installed above.
The manufacturer shall not be liable for failure to observe all safety regulations in force for the
correct and normal operation of electrical parts.
Ducting options
Recirculation
To recirculate your wall canopy, please purchase a recirculation kit (part no. 791820). The
recirculation kit is required to channel the air out through the side-vents at the top of the flue.
Note: a ducting hole is not required in the wall or ceiling if a recirculation kit is fitted.
Ducting
For ducted installation, it is recommended that you use 150 mm diametre, rigid or semi-rigid
ducting. This will require a 160 mm (min) round hole in the ceiling, which the decorative
chimney will cover. Care should be taken to align the canopy with the decorative chimney
allowing sufficient clearance to accommodate the ducting.
For optimal efficiency, use smooth-wall, solid galvanized or plastic ducting for reduced noise
and increased airflow. Flexible ducting should only be used as a last resort (ie in difficult
installations) and if used, ensure that it is pulled tight.
The smoother, straighter and shorter the ducting the quieter and more efficient the wall canopy
will perform.
All ducting must comply with local requirements and building codes.

8
EN
Operating your wall canopy
Soft touch button control panel
Light button On/Off (ref. A).
Power button On/ Off (ref. B).
Fan speed decrease button (ref. C).
Display screen (ref. D).
Indicates the fan speed setting.
Fan speed increase button (ref. E).
Max fan speed button (ref. F).
The fan will automatically increase to highest fan speed setting.
Timer button (ref. G).
The fan will operate for 5 minutes at the current speed and 5 minutes at each of the lower
speeds before automatically switching off.
Fig.1 Touch control panel
A B C D E F G
