KI Intellect Book Box User manual

Note: The Intellect book box can be
installed as either a sliding book box
or a fixed, open-front book box.
Each book box requires two sets of
clips for proper assembly (one set per
side). Each set of clips includes a
locking clip and a sliding clip. The
locking clip is cube shaped and has a
small ridge. The sliding clip has a
long and a short lock where the locks
enter into the locking clip.
Important: Orient the small ridge
of the locking clip and the short
lock of the sliding clip toward the
floor during assembly (Figure 1
& Figure 3).
Sliding Book Box Assembly
1. For sliding mode, clips should be
installed into desk prior to
inserting book box. As noted
above, orient the sliding clip to the
inside of the desk and insert the
sliding clip into the desk rail at the
w-channel location. Attach the
locking clip to the sliding clip at
the outside location of the desk rail
and w-channel. Make sure the
pieces snap together (Figure 1).
2. Repeat the steps above at the other
side of the desk, making sure to
orient the sliding clip to the inside
of the desk and the locking clip to
the outside of the desk rail and
w-channel location.
3. Once the clips are assembled at
both sides, insert the book box into
the book box channels and slide it
into place. It will click once if it is
fully inserted. The desk is then
ready to use (Figure 2).
Note: During insertion, flex
sidewalls of box outward to assure
that the outer rails of the box fully
engage the steel tracks of the desk.
Make sure to hold the box level as
it is pushed into the desk tracks so
the outer rails of the box ride under
the guide tabs bent over each track.
4. To remove the book box, pull it out
until it stops. Push up on the
release tabs of the installed sliding
clips and continue to slide the book
box out (Figure 1).
sliding clip
release tab
short lock
desk rail &
w-channel
locking clip
small ridge
Assembly Instructions
Intellect®Book Box
January 2010
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and injury.
1330 Bellevue Street • P. O. Box 8100 • Green Bay, WI 54308-8100 • Tel [phone] • www.ki.com
© 2010 KI All Rights Reserved • Litho in USA • Code KI-61487R3/HT/PDF/0110
book box
book box
channel
Figure 2
Figure 1

locking groove
locking clip
small ridge
desk rail &
w-channel
sliding clip
short lock
Fixed Book Box Assembly
1. First insert the book box into
the desk. As illustrated, orient
the sliding clip with the short
lock down, and positioned at
the outside desk rail and
w-channel location (Figure 3).
Note: During insertion, flex
sidewalls of box outward to
assure that the outer rails of the
box fully engage the steel
tracks of the desk. Make sure to
hold the box level as it is
pushed into the desk tracks so
the outer rails of the box ride
under the guide tabs bent over
each track.
2. From inside the book box, at
the w-channel position, locate
the locking groove of the book
box. At that location, with the
small ridge down, insert the
locking clip into the desk rail
and w-channel location. Snap
the locking clip into the
sliding clip to secure
(Figure 3).
3. Repeat the steps above at the
other side of the desk, making
sure to orient the sliding clip
to the outside of the desk at the
desk rail and w-channel
location and the locking clip to
the inside.
Assemble units as described herein only. To do otherwise may
result in instability. All screws, nuts and bolts must be tight-
ened securely and must be checked periodically after assem-
bly. Failure to assemble properly, or to secure parts may result
in assembly failure and injury.
Intellect®Book Box
Assembly Instructions
Figure 3
