Flashforge Adventurer 5M Pro User manual

中文P34
1. Please refer to this Guide for initial printer setup.
2. Hot! Avoid touching the heating nozzle in operation.
3. Moving parts in the printer may cause injuries. Do not wear
gloves or other sources of entanglement in operation.
1. 请参照本指南完成打印机的初始准备。
2. 高温危险！打印机喷嘴在工作时会被加热，操作时请避免接触！
3. 可动部件可能会造成卷入挤压和切割伤害。操作机器时请不要
佩戴手套或缠绕物。
Do not power on the printer until installation is completed.
请勿在打印机安装完成之前通电。
安全提示
Safety Notice
用户使用手册
Adventurer 5M Pro / 冒险家5M Pro
User Guide
EN/CN-A01

For more information, you can visit the Flashforge official website.
www.flashforge.com - [Support]

CONTENTS
01
Notice
1. Equipment Introduction
1.1 - Printer Components
1.2 - Printer Parameters
2. Initial Setup
2.1 - Unboxing
2.2 - Packing List
2.3 - Installing the Spool Holder
2.4 - Unlocking the Build Plate
2.5 - First Print
3. Software Introduction & Installation
4. Printing
4.1 - Filament Loading and Changing
4.1.1 - Filament Loading
4.1.2 - Filament Changing
4.2 - Network Connection
4.2.1 - Wireless Network Connection
4.2.2 - Wired Network Connection
4.3 - Printing Methods
4.3.1 - Printing via USB
4.3.2 - Printing via Wi-Fi transfer
4.3.3 - Printing via Cloud
4.4 - Camera Connection
4.5 - Model Removal After Printing
5. Introduction to Auxiliary Functions
5.1 - Leveling and Calibration
5.2 - Air Filtration
5.3 - Other Function Settings
6. Maintenance
6.1 - Suggestions on Platform Plate Usage
6.2 - Suggestions on Nozzle Usage
6.3 - General Maintenance
7. Q&A
8. Help and Support
02
04
04
05
06
06
08
09
10
11
14
19
19
19
19
22
22
22
23
23
23
24
26
27
27
27
28
28
29
29
29
29
30
33

NOTICE
SAFETY NOTICE: PLEASE CAREFULLY READ AND STRICTLY FOLLOW
ALL THE SAFETY WARNINGS AND NOTICES BELOW ALL THE TIME.
WORK ENVIRONMENT SAFETY
Please keep the workspace clean and tidy.
Please ensure the equipment operates away from combustible gases, liquids, and
dust. High temperatures generated during operation may react with combustible
gases, liquids, or airborne dust, potentially causing fires.
Children and untrained individuals should not operate the equipment alone.
Note: Each 3D printer undergoes printing tests before leaving the factory. Filament
residue on the nozzle or slight scratches on the build plate are normal and do
not affect usage.
ELECTRICAL SAFETY
PERSONAL SAFETY
Do not touch the extruder, build plate, etc., during printing.
Do not touch the extruder and build plate after finishing printing to avoid high
temperature burns or mechanical damage.
Do not wear scarves, masks, gloves, jewelry, or other objects that can easily get
tangled into the equipment while operating it.
Do not operate the equipment while you are tired or under the influence of drugs,
alcohol or medication.
Please properly ground the equipment. Do not modify the plug. Ungrounded
equipment/improperly grounded equipment/modified plug will inevitably increase
the risk of electric leakage.
Avoid exposing the equipment to damp or direct sunlight environments. Humidity
will increase the risk of electric leakage. Exposure to sunlight will accelerate the
aging of plastic parts.
Make sure to only use the power cord provided by Flashforge.
Do not use the equipment during thunderstorms.
Please turn off the equipment and unplug it if it is not in use for a long time.
Keep the inside of the equipment clean. Do not drop metal objects into the grooves
at the bottom of the build plate.
Please clean up filament debris in time. It is recommended to operate this outside
the equipment.
Any modification of the equipment by yourself will void the warranty.
Please keep the distance between the extruder and build plate for at least 50mm
during filament loading. Too-close distance may cause nozzle clogs.
Please operate the equipment in a well-ventilated environment.
Do not use the equipment for illegal activities.
Do not use the equipment to make food storage containers.
Do not place printed models into your mouth.
CAUTIONS
02

EQUIPMENT ENVIRONMENT REQUIREMENTS
EQUIPMENT PLACEMENT REQUIREMENTS
COMPATIBLE FILAMENT REQUIREMENTS
FILAMENT STORAGE REQUIREMENTS
LEGAL STATEMENT
The equipment must be placed in a dry and well-ventilated environment.
A distance of at least 35cm must be reserved around the front, back, left and right
sides of the equipment. Recommended storage temperature: 0-40°C
When using this equipment, it's recommended to use Flashforge's filaments.
If non-Flashforge filaments are used, there will be certain differences in material
properties, and print parameters may need adjustments.
Please store filaments in a dry and dust-free environment after unpacking. It is
recommended to use the matching filament dry box for storage.
Room temperature: 15-30℃; Humidity: 20-70RH%
Users are not authorized to make any modifications to this User Guide.
Flashforge shall not be held responsible for any safety incidents resulting from the
disassembly or modification of the equipment by the customer. No one is allowed
to modify or translate this Guide without Flashforge's permission. This Guide is
protected by copyright, and Flashforge reserves the right of the final interpretation
of this Guide.
First Edition (September 2023)
Copyright © 2023 Zhejiang Flashforge 3D Technology Co., Ltd. All Rights Reserved.
03

1
2
3
4
5
9
10
7
8
6
11 12 13
1. Top Cover
2. Extruder
3. Switch Button
4. Touch Screen
5. Front Door
6. Auxiliary Cooling Fan
7. Build Plate
8. USB Port
9. Air Filter
10. Screw Holes for Spool Holder
11. Ethernet Input
12. Power Switch
13. Power Socket
1.Equipment Introduction
1.1 Printer Components
04

Machine Name
Extruder Quantity
Printing Precision
Positioning Accuracy
Layer Thickness
Build Volume
Nozzle Diameter
Printing Speed
Max. Acceleration
Max. Travel Speed
Max. Extruder Temperature
Supported Filament
Power Supply
Device Size
Net Weight
Connectivity
Operating Temperature
Compatible Operating System
Compatible Slicing Software
Max. Platform Temperature
Leveling Method
Filament Run-out Reminder
Power Loss Recovery
Smart Touch Screen
Remote Video Monitoring
Time-lapse Video
Air Filtration
Build Plate
Automatic Shutdown
Adventurer 5M Pro
1
±0.2mm [testing based on 100mm cubes]
X/Y-axis: 0.0125mm; Z-axis: 0.0025mm
0.1-0.4mm
220 x 220 x 220mm
0.4mm [default]; 0.6/0.8/0.25mm [optional]
10-300mm/s
20000mm/s²
600mm/s
280℃
*PLA/*PETG/*TPU [0.4mm nozzle]
ASA/ABS
PLA-CF/PETG-CF [0.6/0.8mm nozzle]
Input: AC 100~240V, 50/60Hz, 350W
380 x 400 x 453mm [excluding the spool holder]
14.6kg
USB/Wi-Fi/Ethernet
15-30℃
Windows 7/8/10/11; Linux: Support version Ubuntu
20.04 or later; Mac OS: Support version 10.9 or later.
FlashPrint 5 / Orca / Prusa / Cura
110℃
One-click auto leveling
√
√
4.3-inch
√
√
Internal circulation + external circulation
[HEPA + activated carbon]
PEI flexible steel plate
√
Note: Materials marked with * are recommended for printing.
1.2 Printer Parameters
05

1. Open the box.
Safety Notice: Do not power on the printer until installation is completed.
2. Remove the upper foam packaging,
Quick Start Guide and After-sales
Service Card.
3. Take out the machine, place it on a
level workspace and remove the
packaging bags and tapes.
4. Open the top cover and remove the
upper protective foam.
5. Remove the filament, power cable, and
accessory box from the chamber protective
foam. Remove the inner protective foam
from the extruder.
2. Initial Setup
2.1 Unboxing
06

7. Remove the foam.
6. Move the extruder and chain according to the arrow direction.
07

3D Printer Filament After-sales
Service Card
Spool Holder
(with 2 screws)
0.6mm Nozzle
Quick Start Guide Grease
Power Cable
USB Disk
Glue
Diagonal Pliers
Allen Wrench
2.0 2.5 3.0
Screwdriver
Unclogging Pin Tool
2.2 Packing List
08

1. Take out the two screws and spool holder
from the accessory box.
2. Install the spool holder at the position shown
in the figure with the two screws.
(Note: Please tighten them using a 2.0mm
Allen wrench.)
2.3 Installing the Spool Holder
09

Please ensure the platform has been cleared up!
Please use a 2.0mm Allen wrench to remove four screws which lock the build plate (as indicated
by the arrow).
Note
2.4 Unlocking the Build Plate
10

1. Connect the power, turn on the power switch, and press the
switch button to turn on the screen.
* The interface layout may change whenever there is an upgrade of firmware.
Power Switch
2. Following the guide on the screen, select
the language.
3. Click [Next] according to screen prompts and the machine will perform the first calibration.
Vibrations and noise during calibration are normal. (Note: Please keep the machine on a
stable surface and do not move it during calibration.)
2.5 First Print
Switch Button
11

4. Load filament following the on-screen startup boot:
a. Cut off the bent part of the filament end.
b. Hang the filament on the spool holder. Pass it through the filament sensor until it’s seen from
the other end of the filament guide tube. Push it forward to the feed roller, until it can not go
further. (*Please use PLA filament for the first print on initial setup).
C1. Click [Load] and select [PLA] for the first print. C2. Wait for the extruder to heat up.
12

6. Click [Print] and the machine starts printing
the built-in file (configured for PLA material).
5. Please clear the filament residues on the nozzle
and platform. Users must apply glue to the
platform so as to improve adhesion for the
first print.
C3. Feeding will begin after heating. Successful filament extrusion from the nozzle indicates
successful loading. Lastly, confirm the filament guide tube is properly inserted.
If no filament is extruded, manually insert the filament into the inlet and click
[Back] to retry. Feel for filament movement until it is extruded.
Note
13

Note
3. Software Introduction & Installation
Before printing 3D model files, you need to configure slicing presets for the corresponding printer.
Recommended slicing software: OrcaSlicer / FlashPrint 5
Before reading the brief instructions, please ensure you have reviewed the Quick
Start Guide and completed the first print.
Slicing Software Instructions for Adventurer 5M Series
Pre-printing Steps:
Obtain the 3D file
(STEP/STL/OBJ)
Download and
install the slicing
software
Use the slicing software
to convert the file into
the machine-readable
format
Import the sliced file via
a USB flash drive or
network transfer to the
printer for printing
This slicing software, created by the open-source community, offers more open configuration
options. Experienced users are recommended to use this slicing software.
1. Download the latest slicing software from the official website:
https://github.com/SoftFever/OrcaSlicer/releases.
2. Find the OrcaSlicer software package on the USB flash drive and install the version that matches
your system.
Files can be imported by project, requiring a click on the project file each time you open it.
Alternatively, configs can be imported, eliminating the need to do so each time, but this may not
be compatible with higher software versions.
Open-source Slicing Software
OrcaSlicer
01 02 03 04
Download and Installation Instructions
Note
14

* The steps are illustrated for one machine type.
How to Use OrcaSlicer (Import Project Files)
1. Open the installed OrcaSlicer. 2. Click [Open Project].
3. The profile should be in .3mf format. You
can find the corresponding file on the USB
flash drive. Drag it directly into OrcaSlicer,
or open it directly (if the machine is not
configured with a USB flash drive, please
download the corresponding profile from
Flashforge's official website).
4. After importing the profile, the software
interface will display the corresponding
printer, and you can select the desired
printing material.
15

* The steps are illustrated for one machine type.
5. Select the model file to be printed. You can
drag it directly into the software, or click
[File] - [Import] to import the model file
(STL/STEP/OBJ/3MF, etc.).
6. Click [Slice all]. Once slicing is completed, click
[Export G-code file], save the file to a USB flash
drive, and then insert it into the printer for
printing.
How to Use OrcaSlicer (Import Configs)
1. Open the installed OrcaSlicer.
3. The config file should be in .json format. You
can find the corresponding files on the USB
flash drive, select all, and open it (if the
machine is not configured with a USB flash
drive, please download the corresponding
config files from Flashforge's official website).
2. Click [File] - [Import] - [Import Configs...].
16

4. After importing, the corresponding printer, available filaments, and recommended parameters
will be displayed.
5. Select the model file to be printed. You can drag it directly into the software, or click [File] -
[Import] to import the model file (STL/STEP/OBJ/3MF, etc.).
6. Click [Slice all]. Once slicing is completed,
click [Export G-code file], save the file to a
USB flash drive, and then insert it into the
printer for printing.
17

The slicing profiles available in FlashPrint 5 are configured based on extensive
testing with various types of filaments. We recommend using the recommended
temperature settings provided in the profiles. If you believe a specific filament
requires a different temperature, you can make minor adjustments and print
smaller objects at the set temperature for testing to ensure smooth operation.
1. Download the latest slicing software from the official website:
https://www.flashforge.com/download-center.
2. Find the FlashPrint 5 software package on the USB flash drive and
install the version that matches your system.
Download Instructions
* The steps are illustrated for one machine type.
FlashPrint 5 is not open-source. It is user-friendly and suitable for users with no 3D printing
experience or those who don't require parameter adjustments.
Flashforge's Official Slicing Software - FlashPrint 5
1. After installing the slicing software, import
the model file.
2. Select the corresponding printer type.
3. Click [Start Slicing].4. After slicing is completed, save the file to a
USB flash drive for printing.
Note
18
