Flashforge Inventor User manual

SZ14-ZN/EN-A06
P18
Inventor 发明家
This guide is only applicable to FLASHFORGE Inventor 3D printer
本指南仅适用于闪铸科技发明家3D打印机

1. Open the carton and take out lid on top of the
printer. On the lid, there is one quick start, one
after-sales service, one SD card, one leveling
card and two build tapes.
3. Lift the printer out of the carton.
5. Tear off tapes at the printer bottom, remove
bubble bag outside the printer.
6. Take out the foam on the top of the printer.
4. You will find a tool bag and one USB cable.
2. Take the power cable out. Remove two top foam
sheets.
01

10. Remove the foam from the back of the logo
board.
11. Hold both sides of the printer, lift up the printer
slowly, thus removing filament under build
plate easily. Do not make build plate collide
with extruder.
8. Remove bubble bag outside the extruder, put
extruder on the extruder mounting base.
Notice: The extruder should be put as is shown
(extruder fan should towards the front of the
printer)
7. Open the paper box on the top of the printer,
there is an extruder, two side panels and an
extruder's accessory kit inside. Take the
extruder and the paper box out, notice that
the cable bunch connected with extruder is
short, do not hang the extruder in the air.
02
9. Shear three ties off on both sides of X-axis guide rod.

12. Take out the paper board. 13. Take out filament first and then remove foam.
15. Finally press build plate slowly to printer
bottom.
14. Notice: Do not miss either filament spool
holder on two pieces of foam.
16. Inventor unboxing completed.
Suggest keeping packing materials well for
follow-up storage and shipping.
03

Tool Bag Contents:
Graver / Tweezer / Scraper / Accessories box
( contents: Thumb screw / PTFE tubes*2 /
M3x16 Bolt / Nut ) / Tool bag ( contents: Allen
wrenches*2 / Phillips screwdriver /
Unclogging pin tool / Wrench / Grease)
Extruder’s Accessory Kit Contents:
M3x8 Bolts*2 / M3x6 Bolts / Turbofan baffle
Tool Bag
04

05
Getting to know Your Inventor
5. Build Plate
19. USB Cable Input
8. Thumb Screw

06
bag

07

08
into

For putting filament through guide tube easily, please install filament in a proper way.
1. Take out PLA filament, remove vacuum packing and put it beside the left fixed seat of the build plate.
Install Filament
2. For putting PLA filament through guide tube
easily, please install filament in a proper way.
3. Put filament through guide tube.
Filament
Guide tube
09
Filament
Guide tube
Filament
Guide tube
Correct Wrong
Correct
Filament
Guide tube
Left side
Wrong
Filament
Guide tube
Right side

Press here
Filament Intake
5. Press the left spring presser, put filament vertically into the left filament intake to the bottom.
4. Take out filament spool holder. As is shown above, put spool holder through round hole, and
insert it into fixed seat. Rotate the spool holder 90° to fix it.
Left side Right side
Attention: Lock filament on the left side, rotate spool holder anticlockwise 90°
Lock filament on the right side, rotate spool holder clockwise 90°
10

Password lock
Disable
Password lock
Disable
How to change language
3. After language setting completed, tap return arrow to go back.
2. Plug the other end of power cable into socket,
turn on the power switch.
Follow steps above if you need to do language setting.
Leveling
1. Take power cable out and plug it into power
input on the right side of the printer.
11
02
03
01
04

Please adjust the front thumb screw under
Platform when stop.
Next
4. Tap [Level].5. Extruder starts to move to the first leveling
point. When moving stops, level the first
leveling point.
Filament Level Home
Setting Status About
Manual
Rotate thumb screw clockwise
Rotate thumb screw anticlockwise
How to use the thumb screw
Build plate goes up
Build plate goes down
12
Berfore leveling, let's learn the funciton of thumb screw.

Start the adjustment process
with the right nozzle, then use
the distance between the right
nozzle and build plate as a
reference.
Attention: Leveling would affect print effect directly, if print result is unsatisfactory,
please do leveling again.
6. Take leveling card out, on the basis of right side extruder, put leveling card between right
nozzle and build plate. Slide leveling card back and forth and adjust thumb screw in the
meantime.
If you can move leveling card easily, please rotate thumb screw clockwise to reduce the
distance between build plate and nozzle. Otherwise, rotate thumb screw anticlockwise to
increase the distance between build plate and nozzle.
If you feel slight friction sensitivity when moving leveling card, the distance between extruder
and leveling card is proper, thus adjustment compeleted.
7. After the first leveling point completed, tap [Next]. The extruder will move to the second leveling
point. Adopt same method to adjust. After three leveling points (above knobs of three leveling
points) completed all, leveling completed. Tap [Finish] to end leveling process, tap return
arrow to go back to home screen.
8. Press build plate slowly to printer bottom.
13

1. Tap [Tools].
3. Tap [Load Left].4. Extruder starts to heats.
2. Tap [Filament].
Load Left
Unload Left
Load Right
Unload Right Cancel
L Extruder 25℃ / 230℃
16%
Done
L Extruder 230℃ / 230℃
Loading begins, push filament vertically into
extruder, and press [Done] when you see
filament come out of extruder
100%
Filament Loading
Print
Filament Level Home
Setting Status About
Manual
Preheat
5. Once heated, filament will be drawn through the extruder. Continue extruding until the extruder
provides a steady flow of filament. Tap [Done], go back. Tap return arrow to go back to home
screen.
14
Attetion: If extruder can not unload in a long time, please check if you have inserted filament
into the bottom of extruder.

Happy3D Software软件安装包
User Guide 说明书
FlashPrint 切片软件
Test Files测试文件
40mmCUBE-L-PLA
Print
Print Preheat Tools
Copy
Delete
40mmCUBE-L-PLA
0:00
25℃ / 210℃
25℃
25℃ / 50℃
Print Time
L Extruder
R Extruder
Platform
Print Time: 1:02
2. Tap [Print].
1. Insert SD card into SD card slot on the right
side of the printer.
3. Tap [SD card].
4. Tap [Test Files]. 5. Choose [40mmCUBE-L-PLA].
Attention: Make sure that PLA filament installed
on the left extruder.
First Print
7. The extruder starts to heat, once heated, the
printer will start to print.
6. Tap [Print].
15
1. Ensure that the build plate has been leveled
before printing.
2. Ensure that the filament has been loaded in
an appropriate approach.
3. Load the filament for a while to extrude all
the melted filament you printed last time out
of the extruder.
4. Print with ABS filament, install top cover, close
the front door. Print with PLA filament, remove
top cover, open the front door.
5. Please clean extruder before printing.
6. Do not leave the printer unattended during
operation.
40mmCUBE-L-PLA
40mmCUBE-R-PLA
Hillbert_Cube-PLA

Press here
Finish
L Extruder 230℃ / 230℃
Unload begins, press down spring presser
and withdraw filament
100%
Cancel
L Extruder 25℃ / 230℃
16%
Load Left
Unload Left
Load Right
Unload Right
Please follow steps below if you need to unload filament in
daily use.
1. Tap [Tools]. 2. Tap [Filament].
3. Tap [Unload Left (or right)]. 4. Extruder start to heat.
Unloading Filament
Print Preheat
Filament Level Home
Setting Status About
Manual
16
Push Filament down
through for 3 seconds
5. When heating to target temparture, press
spring presser and push filament down through
for 3 seconds, until you see steady filament
coming out from nozzle.

17
Press here
Withdraw
Filament
6. Then pull out vertically quickly and release spring presser.
Tap [Finish], go back. Tap return arrow to go back to home screen.

1. 打开纸箱取出顶部的打印机顶罩。顶罩上放
有一本快速启动指南、一份售后服务卡、一
张SD卡、一张调平卡片和两张平台贴纸。
4. 在箱子底部还有USB线和工具袋。 3. 从纸箱中取出打印机。
5. 撕开打印机底部的胶带，去除包裹打印机
的气泡袋。
6. 取出打印机顶部的泡沫。
18

7. 打开打印机顶部的纸盒，纸盒中装有喷头、
两块机身侧窗盖板和一个喷头安装包。取出
喷头并取出喷头纸盒，注意连接喷头的束线
管较短，不要让喷头悬挂在空中。
9. 剪断X轴两侧的扎带，一共三根。
10. 取出logo板背后的泡沫块。 11. 双手托住打印平台两侧，缓缓抬起打印平台，
以便于取出打印平台下方的耗材。注意不要
让打印平台与喷嘴相碰。
8. 去除包裹喷头的气泡袋，将喷头放置在安装
喷头的中塑件上。注意，喷头的摆放位置应
当如图所示（喷头扇热风扇应当朝向打印机
前方）。
19
