On-Screen Display Guide
C336ZC1 HD PTZ Camera

On-Screen Display
Guide
C336ZC1 HD PTZ
Camera
#LX400048; r. 1.0/23171/23171; en-US iii

Thank you for purchasing this product. FLIR is committed to providing our customers with a high quality,
reliable security solution.
This manual refers to the following models:
C336ZC1
For the latest online manual, downloads and product updates, and to learn about our complete line of
accessory products, please visit our website at:
www.flirsecurity.com/pro
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RICK OF ELECTRIC SHOCK DO NOT REMOVE
COVER. NO USER SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF THE PLUG
TO THE WIDE SLOT AND FULLY INSERT.
#LX400048; r. 1.0/23171/23171; en-US iv

Using the On-Screen Display
(OSD) Menu for C336ZC1
1
You can configure the camera’s advanced settings on a FLIR MPX DVRs using the OSD
menu. Use the OSD menu to correct imperfections in the camera image as well as config-
ure automated PTZ functions like preset locations, patterns, and tours.
NOTE
If you have made changes in the OSD menu and you are not happy with the outcome, see 1.3.20 Camera
Factory Defaults, page 19 to reset all items in the Camera Setting menu to their default values. See 1.1.3
Restore Factory Defaults, page 3 to reset all other items in the OSD menu.
To access the OSD menu:
1. In Live View, double-click the channel that has the PTZ camera connected to open in
full-screen.
2. Right-click and click Pan/Tilt/Zoom. Enter the system user name and password if
prompted. The PTZ menu opens.
3. Click the arrow in the PTZ control window to show advanced controls.
4. Click . The OSD menu appears over the camera image.
5. Use the on-screen controls to configure menu items:
•Up / down arrows: Select menu items.
•Left / right arrows: Change values for menu items.
•Esc: Exit the OSD menu.
•Enter: Confirm selection.
1.1 System Settings
Use the system settings menu to configure basic system information.
System Settings — Menu Structure:
#LX400048; r. 1.0/23171/23171; en-US 1

Using the On-Screen Display (OSD) Menu for C336ZC1
1
SYSTEM INFORMATION ADDR Displays the camera address.
BR Displays the camera baud rate.
PARITY Displays the communication parity.
PTZ VER Displays the PTZ firmware version.
CAM VER Displays the camera firmware version.
ADDR INFORMATION ADDR TYPE •HARD
•SOFT
ADDR-HARD 1–255
ADDR-SOFT 0–255
SET NORTH Set the current viewing angle as the benchmark angle for the camera.
LANGUAGE Set the language for the OSD menu.
FACTORY DEFAULT Restore the camera system settings to their original, out-of-the-box state.
Exposure settings are not affected when you restore the camera system
settings.
RESTART Reboot the PTZ camera. OSD settings are not affected when you reboot
the camera.
1.1.1 System Information
NOTE
The information in this section is for service purposes only.
The system information menu displays the PTZ protocol information, including the camera
address, baud rate, parity, and firmware version numbers. The information in this section
is for reference and cannot be configured through the OSD menu.
1.1.2 Address (ADDR) Information
NOTE
The information in this section is for service purposes only.
The address information menu lets you choose how the camera address is determined.
The camera address is how standard definition DVRs identify PTZ cameras. Under ADDR
TYPE, select HARD to have the address determined by the DIP switches inside the cam-
era housing, or SOFT to select the address using the software (select the address value
under ADDR-SOFT).
#LX400048; r. 1.0/23171/23171; en-US 2

Using the On-Screen Display (OSD) Menu for C336ZC1
1
1.1.3 Restore Factory Defaults
Restore the camera module to its out-of-the-box state. This will reset all menu items ex-
cept those in the CAMERA SETTING menu back to their default values.
CAUTION
This step cannot be undone.
To restore camera factory defaults:
1. Use the on-screen arrow keys to navigate to SYSTEM SETTING and click Enter.
2. Select FACTORY DEFAULT and click Enter.
1.1.4 Camera System Restart
Restarts the camera system. The camera powers off and then resumes normal function.
NOTE
Restarting the camera system does not affect OSD menu settings.
#LX400048; r. 1.0/23171/23171; en-US 3

Using the On-Screen Display (OSD) Menu for C336ZC1
1
To restart the camera module:
1. Use the on-screen arrow keys to navigate to SYSTEM SETTING and click Enter.
2. Select RESTART and click Enter.
1.2 Display Settings
Use the display settings menu to choose what information appears over the camera image.
Display Settings — Menu Structure:
PRESET ON / OFF
AZIMUTH DISP ON / OFF
POSITION ON / OFF
INSIDE TEMP •°C
•°F
•OFF
To configure the display settings:
1. Use the on-screen arrow keys to navigate to DISPLAY SETTING and click Enter.
2. Under PRESET, select ON to show the preset title on the video display, or select OFF
to hide.
3. Under AZIMUTH DISP, select ON to show the camera’s coordinates on the video dis-
play, or select OFF to hide.
4. Under POSITION, select ON to show the angle between the camera’s current position
and the benchmark position on the video display (for details on setting benchmark po-
sition, see 1.1 System Settings, page 1), or select OFF to hide.
5. Under INSIDE TEMP, select °F or °C to show the camera’s internal temperature on the
video display, or select OFF to hide.
1.3 Camera Settings
Use the camera settings menu to adjust the camera image.
Camera Settings — Menu Structure:
#LX400048; r. 1.0/23171/23171; en-US 4

Using the On-Screen Display (OSD) Menu for C336ZC1
1
WB SETTING WB MODE •AUTO
•ATW
•INDOOR
•OUTDOOR
•OUTDOOR AUTO
•NA LAMP
•NA LAMP AUTO
•MANUAL
R GAIN 0–100
B GAIN 0–100
EXPOSURE
SETTING
AE MODE •AUTO
•MANUAL
•IRIS PRIO
•SHUTTER PRIO
GAIN SETTING 1–16
SHUTTER 1/4 – 1/30,000
IRIS SETTING 1–18
EXPOSURE
COMP
1–15
BLC ON / OFF
NEXT PAGE SLOW
SHUTTER
ON / OFF
SLOW
SHUTTER
LIMIT
1/1 – 1/30
AGC GAIN
LIMIT
1–3
NR 1–16 or OFF
CAMERA
3D NR
1–16 or OFF
HIGH
LIGHT
REDUCE
•HIGH
•LOW
•OFF
NEXT
PAGE
AE RECOVERY •5M
•15M
•30M
•1H
•2H
•OFF
WDR SETTING WDR MODE >
ON / OFF
DAY/NIGHT
SETTING
DAY/NIGHT •DAY
•NIGHT
•AUTO
TYPE •ELECTRON
•MECHANISM
THRESHOLD 1–8
#LX400048; r. 1.0/23171/23171; en-US 5

Using the On-Screen Display (OSD) Menu for C336ZC1
1
FOCUS
SETTING
FOCUS MODE •AUTO
•MANUAL
•SEMIAUTO
FOCUS LIMIT •10CM
•1M
•2M
•3M
•5M
•AUTO
AF
SENSITIVITY •LOW
•MID
•HIGH
IR
CORRECTION •ON
•OFF
•AUTO
ADJUST
HUE 1–100
BRIGHTNESS 1–100
SATURATION 1–100
CHROMA
SUPPRESS
1–4
GAMMA 1–16
CONTRAST 1–100
STYLE •STANDARD
•SOFT
•NATURAL
ZOOM SPEED 1–8
NEXT PAGE APERTURE 1–16
APERTURE
RESTRAIN
1–16
DIGITAL ZOOM ON / OFF
PICTURE FLIP ON / OFF
LENS INIT Performs a lens initialization.
MODE •720P / 25
•720P / 30
•720P / 50
•720P / 60
NEXT PAGE CAMERA
FACTORY
DEFAULT
Restores the camera to its original, out-of-the-box
settings.
CAMERA
RESTART
Restarts the camera.
1.3.1 White Balance Settings
The white balance setting menu is used to correct color appearance in the camera image.
