FLIR DBV533TL User manual

WARNING - A REGULATED UL / CSA APPROVED 12V DC power
supply is REQUIRED for use with this camera. Use of a non-regulated,
non-conforming power supply can damage this product and voids the
warranty.
Product Information
User Manuals Quick Start Guides
Specification Sheets
Video Tutorials & Demos
Latest News
Contents
900 TVL OUTDOOR
IR DOME CAMERA
MODEL: DBV533TL
QUICK START GUIDE
English Version 1.0
www.flirsecurity.com/pro
IT’S ALL ON THE WEB!
www.flirsecurity.com/pro
VISIT
Outdoor IR Dome Camera
Mounting screws x 4
Features
Safety Precautions
• Use an appropriate low voltage power cable to prevent
fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user serviceable parts inside the camera.
Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive cleaning
material. Please use a soft cloth to clean the lens cover.
• 1/3” Sony Exmor™ Megapixel sensor with 960H DSP
• Outstanding image clarity in low light conditions
• Advanced 3D Digital Noise Reduction (3D-DNR)
• 90ft (27m) Smart IR Night Vision
• 3.6mm wide angle lens
• IP66 Weatherproof rating
• 3-Axis design for Wall/Ceiling mounting
• 12V DC operation
* IR Illumination range under ideal conditions. Objects at or beyond
this range may be partially or completely obscured, depending on
the camera application
** Not recommended for submersion in water
FLIR Systems Inc.
Copyright © 2014
As our products are subject to continuous improvement, FLIR Systems
Inc. reserves the right to modify product design, specifications and
prices, without notice and without incurring any obligation. E&OE
1 x Allen key
Drywall anchors x 4

Dimensions
Camera Specifications
Installing the Camera
Setting up the Camera
1. Connect the BNC connector of the camera to
the video cable.
2. DC Power—Power Adapter: Connect a
12V DC Power Adapter (not included) to the
camera. Plug the Power Adapter into a local
power outlet.
• DC Power—Power Pigtail (not included):
Connect a Power Pigtail to the camera.
Connect the terminating wires of the cable
directly to the DC power source.
NOTE: For pigtail connection with 12V DC, make sure
to check polarity specifications on the power adapter.
Image Sensor 1/3” Sony Exmor™ Megapixel CMOS
Video Format NTSC
Effective Pixels H: 1305 V: 1049
Horizontal Resolution 900 TVL
Scan System 2:1 Interlace
Sync System Internal
S / N Ratio 48dB (AGC Off)
Iris AES
AES Shutter Speed 1/60 ~ 1/100,000 sec.
Min. Illumination 0.01 Lux without IR LED
0 Lux with IR LED
Video Output Composite 1.0Vpp @ 75ohm
Lens Focal Length / Type 3.6mm F2.0 / Fixed
FOV (Diagonal) 92°
Termination BNC Type
IR Range / Qty. 90ft / 27m; 24 IR LED’s
Power Requirement 12V DC ±10%
Power Consumption 12V: 340mA Max with IR LED
Operating Temp. Range –4° ~ 122°F / –20° ~ 50°C
Environmental Rating IP66
Dimensions (LxH) 3.7” x 2.8”
93mm x 70mm
Weight (including stand) 0.7lbs / 0.3kg
ATTENTION - Test the camera prior to selecting a permanent
mounting location by temporarily connecting the camera(s) and
cables to the DVR.
ATTENTION - This camera includes an Auto Mechanical IR Cut Filter.
When the camera changes between Day/Night viewing modes, an
audible clicking noise may be heard from the camera. This clicking is
normal, and indicates that the camera filter is working.
1. Use the included Allen key to loosen the screw
on the dome cover. Camera Base
2. Rotate the camera base counterclockwise to
separate it from the ball camera and dome
cover.
3. Use the camera base to drill holes for the
cables and mounting screws.
NOTE: Insert the included drywall anchors if
installing the camera in drywall.
4. Feed the BNC / power cable through the
camera base. Connect the video and power
cable as shown in the next section ‘Setting up
the Camera‘.
5. Mount the camera base to the wall or ceiling
using the included screws.
6. Position the dome cover over the camera and
screw it clockwise halfway onto the camera
base.
7. Move the ball camera to the desired position.
While holding the ball camera firmly in place,
screw the dome cover the rest of the way
to secure it to the camera base. Holding the
camera prevents it from moving while installing
the dome cover.
93mm / 3.7”
70mm / 2.8”
Installing the Camera (Continued)
8. Use the included Allen key to tighten the screw on
the dome cover.
