FLOS WIRERING F9512009 User manual

EN
8
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
WIRERING F9512009
REV. 1
DATE 19/08/2021

9
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Disconnect the plug of the old body lamp from the dimmer unit by rotating it 90°
counterclockwise.
EN
Fig.1
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
WIRERING F9512009

10
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Unscrew and remove the ferrule.
EN
Fig.2
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
WIRERING F9512009

11
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
WIRERING F9512009
Fig.3
Fig.4
Disconnect the body lamp by the ring.
Unfasten the screws and remove the cover of the
lower joint.

12
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Unfasten the screws and remove the cover of the higher joint.
Pull the old cable out.
EN
Fig.5
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
WIRERING F9512009




13
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Connect the new body lamp to the ring respecting the correct installation direction.
EN
Fig.6
WIRERING F9512009
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY

14
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Insert the new body lamp. Fasten the screws, connect the ferrule and fix the cover of
the higher joint.
EN
Fig.7
WIRERING F9512009
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY

15
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
WIRERING F9512009
Fig.8
Fig.9
Position the new body lamp. Fasten the screws,
connect the ferrule and fix the cover of the lower
joint.
MAX Ø3


16
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos - All rights reserved - www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
ADJUSTING THE CABLE TENSION: Pull the cable out of hole (C) then thread it
through the pin (D) so as to increase its tension, then tighten the ferrule. If necessary,
do the same at the bottom, moving the cable from hole (H) to hole (I); then tighten
the ferrule.
Connect the plug of the new body lamp to the dimmer unit by rotating it 90°
clockwise.(Fig.1 page 9)
EN
Fig.10
WIRERING F9512009
REV. 1
DATE 19/08/2021
RF26650
ELECTRICAL MOUNTING BODY ASSEMBLY
C
D
IH
