Fluke i3000s Flex Series User manual

®
i3000s/i2000 Flex
AC Current Probe
Instruction Sheet
Introduction
The i3000s 24 Flex, i3000s 36 Flex, and i2000 Flex AC Current
Probes (hereafter referred to as “the Probe”) are used with
oscilloscopes, digital multimeters, recorders or data loggers. The
i3000s probes can be used to measure AC current up to 3000 A.
The i2000 can be used to measure AC current up to 2000 A. The
flexible measuring head allows current measurements on
conductors that are hard to reach or inaccessible using typical
clamp-on current probes.
The Probes provide a low-voltage (3 V AC for i3000s models,
and 2 V AC for i2000) output that is proportional to the current
being measured. The Probes provide full-scale direct readings for
30 A, 300 A, and 3000 A when using the i3000s models, and 20
A, 200 A, and 2000 A when using the i2000.
Symbols
The following table shows the symbols used on the product
and/or in this manual.
Symbol Description
~Do not dispose of this product as unsorted municipal
waste. Contact Fluke or a qualified recycler for
disposal.
WImportant Information. Refer to the manual.
TDouble/Reinforced insulation.
-Do not apply around or remove from the HAZARDOUS
LIVE conductors.
PComplies with the relevant European standards.
>Conforms to Underwriters’ Laboratory, Inc.
PN 2560447
March 2006
©2006 Fluke Corporation. All rights reserved.

i3000/i2000 English Instruction Sheet
Page 2
Safety Instructions
In this instruction sheet, a Warning identifies conditions and
actions that pose hazard(s) to the user. A Caution identifies
conditions and actions that may damage the calibrator or the test
instruments.
WX Warning
To avoid electric shock or personal injury:
•Use the Probes only if qualified.
•Use caution during installation and use of
the Probe; high voltages and currents may
be present in circuit under test.
•Have maintenance performed by only
qualified service personnel.
•Protect the probe against water and
humidity.
•Wear protective clothing and gloves as
required.
•Do not install this product on live
conductors. Always de-energize the circuit
under test before installing the flexible
measuring head.
•Always inspect the electronics unit,
connecting cable, and flexible measuring
head for damage before using the Probe.
•Do not use the Probe if damaged.
•Always connect Probe to display device
before installing the flexible measuring
head.
•Never change batteries while measurement
head is installed on conductor.
•Never connect or disconnect the external
power supply while the measurement head
is installed on a conductor.
•Use only the provided original or specified
accessories.
•Use the Current Probe only as specified in
the operating instructions; otherwise the
current probe’s safety features may not
protect you.

i3000/i2000 English Instruction Sheet
Page 3
•Adhere to local and national safety codes.
Individual protective equipment must be
used to prevent shock and arc blast injury
where hazardous live conductors are
exposed.
•CAT III equipment is designed to protect
against the transients in the equipment in
fixed equipment installations, such as
distribution panels, feeders and short
branch circuits, and the lighting systems in
large buildings.
Specifications
Electrical Characteristics
Measuring ranges
i3000s (24 and 36 Flex)
i2000 Flex
30 A/300 A/3000 A AC,
switch selectable
20 A/200 A/2000 A AC,
switch selectable
Output sensitivity 100 mV/10 mV/1 mV per A
(AC coupled)
Accuracy (at 25 ºC) ±1 % of range (45 – 65 Hz)
Frequency range
i3000s (24 and 36 Flex)
i2000 Flex
10 Hz to 50 kHz (-3 dB)
10 Hz to 20 kHz (-1 dB)
Phase error <±1° (45 – 65 Hz),
±10° (at 20 kHz)
Linearity ±0.2 % of reading from
10 %
- 100 % of range
Position sensitivity ±2 % of range with cable
>25 mm (1") from the
coupling
External field ±1 % of range with cable
>200 mm (8 in) from the
head
Minimum load 100 kefor specified
accuracy
Noise 8 mV RMS (0.3 % of
range) in 30 A range
2 mV RMS (0.1 % of
range) in 300 A and
3000 A

i3000/i2000 English Instruction Sheet
Page 4
Gain variation ±0.08 %/°C
Operating temperature
i3000s (24 and 36 Flex)
i2000 Flex
-20 to +85 °C (-4 to 185 °F)
0 to 70 °C (32 to 158 °F)
Storage temperature
i3000s (24 and 36 Flex)
i2000 Flex
-20 to +85 °C (-4 to 185 °F)
0 to 70 °C (32 to 158 °F)
Temperature coefficient: ±0.08 % of reading / °C
Operating humidity: 15 to 85 % (non
condensing)C
Altitude: 2000 m
Power supply Two AA NEDA15A,
MN1500, IEC LR6 alkaline
batteries (all probes)
Or an optional Class II
external power supply
(+3 V) (i3000 and i3000s)
Battery life
i3000s (24 and 36 Flex)
i2000 Flex
400 hours typical
200 hours typical
Low battery Indicated by a red LED
General Characteristics
Enclosure IP5X flame retardant
UL94-VO rated
Material Valox 357
Output con.
i3000s (24 and 36 Flex)
i2000 Flex
Coaxial cable with a male
safety BNC connector.
BNC to Banana plug
adaptor (supplied)
0.5 meter cable with 4 mm
safety plugs
Weight 0.19 kg (0.4 lb)
Safety
BS EN 61010-1, 600 V
CAT III Pol. Deg 2
EMC BS EN 61326
Dimensions 116 (l) x 68.5 (w) x 30
(d) mm
4.57 (l) x 2.71 (w) x 1.18
(d) in

i3000/i2000 English Instruction Sheet
Page 5
Measuring Head Characteristics
Cable length
i2000, i3000s 24 Flex 610 mm (24 in), double
insulated
i3000s 36 Flex 915 mm (36 in), double
insulated
Cable diameter 14.3 mm (0.562 in)
Bend radius 38.1 mm (1.5 in)
Output cable 2 m long (78.7 in)
Coupling diameter 22.2 mm (0.875 in)
Material TPE rubber,
Polypropylene, UL94-VO
rated
Operating temperature - 20 °C to +90 °C
(-4 °F to 194 °F)
Storage temperature - 40 °C to +105 °C
(- 40 °F to 221 °F)
Maximum relative
humidity
85 %
Weight 0.18 kg (0.4 Ib.)
Safety BS EN 61010-1, 600 V
CAT III Pol. Deg 2

i3000/i2000 English Instruction Sheet
Page 6
Operating Instructions
Ieb0001.eps
AMeasuring head
BMeasuring head coupling
CHead output cable
DEnclosure
EPower on/Range selector
FBattery low indicator
GPower on indicator
HOutput cable
ISafety BNC connector
JExternal power supply input

i3000/i2000 English Instruction Sheet
Page 7
Battery Installation
XWWarning
To avoid electric shock or personal injury:
•Never replace batteries with the flexible
measuring head installed on the conductor to
be tested or with the output connected to a
display device.
•Never operate the unit without the battery cover
installed.
The Probes require two AA/MN1500/LR6 alkaline batteries for
operation. The battery compartment is accessed from the rear
end of the electronic enclosure.
The batteries must be replaced when the LED is lit continuously
or when it fails to light up. Ensure that the Probe is away from
any current carrying conductor and also that the output is
disconnected from other equipment.
To install the battery:
1. Use a coin or a similar tool to turn the battery lock (¼
turn) until the dot aligns with the unlock symbol.
2. Remove the battery cover.
3. Install the batteries ensuring that correct polarity is
observed.
4. Replace the battery cover and turn the battery lock until
the dot aligns with the lock symbol.
External Power Supply (i3000s Models)
An optional Class II external power supply is available from
Fluke. The power supply is designed to ensure that the Probe
continues to meet its specified safety standards. The usage of a
power supply from another vendor is not recommended.
XWWarning
To avoid electric shock or injury, never connect or
disconnect the external power supply with the
flexible measuring head installed on the conductor
or with the output connected to a display device.

i3000/i2000 English Instruction Sheet
Page 8
Measuring Current
XWWarning
•To avoid electric shock or injury, read Safety
Instructions before operating this product
•Ensure that the conductor to be tested is de-
energized
To measure current:
1. Connect the output of the electronics to the input of an
oscilloscope or other data recording device.
XWWarning
To avoid electric shock or injury, the flexible current
probe is not for use on conductors with a potential
of over 600 V.
2. Wrap the flexible measuring head around the conductor
to be tested in a close coupling manner.
3. Energize the circuit under test.
4. For most accurate measurement, centre the flexible
head around the conductor.
5. Locate coupling away from the nearby conductors.
WX Warning
To avoid electric shock or injury:
•Do not use the flexible current probe to
measure bare conductors unless wearing
protective clothing suitable for high voltage
work.
•Always use appropriate equipment for personal
protection. When installed on bare
conductors/busbars, the product must be within
a suitable enclosure.
Ieb0001.eps

i3000/i2000 English Instruction Sheet
Page 9
Operation
To activate the unit, move the switch from ‘Off’ position to the
required measuring range. If the value of current being measured
is unknown, select the 3000 A (i3000s models) or 2000 A (i2000)
current range and then reduce accordingly.
Battery Status
Battery status is indicated by an LED on the front of the probe.
This LED will flash one time when the unit is activated. The
length of time the LED is lit will increase as battery life
decreases. Momentary lighting of LED indicates batteries are
good. Continuous lighting of LED indicates low battery and
requires replacement at the earliest. No lighting of LED indicates
batteries are dead and require replacement immediately.
Maintenance
WX Warning
To avoid electric shock or injury, do not use Probe if
damaged.
Always inspect the electronics unit, connecting cable, and flexible
measuring head for damage before use.
To avoid electric shock, keep the probes clean and free of
surface contamination. Use Isopropyl alcohol to clean the
electronics unit and measuring head. Make sure that the flexible
measuring head, connecting cable, and electronic enclosure are
dry before further use.

i3000/i2000 English Instruction Sheet
Page 10
LIMITED WARRANTY AND LIMITATION OF
LIABILITY
This Fluke product will be free from defects in material and
workmanship for one year from the date of purchase. This
warranty does not cover fuses, disposable batteries, or damage
from accident, neglect, misuse, alteration, contamination, or
abnormal conditions of operation or handling. Resellers are not
authorized to extend any other warranty on Fluke’s behalf. To
obtain service during the warranty period, contact your nearest
Fluke authorized service center to obtain return authorization
information, then send the product to that Service Center with a
description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT
LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM
ANY CAUSE OR THEORY. Since some states or countries do
not allow the exclusion or limitation of an implied warranty or of
incidental or consequential damages, this limitation of liability
may not apply to you.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
