Fluke 106 User manual

June 2013, Rev. 1,10/15
© 2013-2015 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
106/107
Digital Multimeters
Users Manual
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

LIMITED WARRANTY AND LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and workmanship for one year from
the date of purchase. This warranty does not cover fuses, disposable batteries, or damage
from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation
or handling. Resellers are not authorized to extend any other warranty on Fluke’s behalf. To
obtain service during the warranty period, contact your nearest Fluke authorized service
center to obtain return authorization information, then send the product to that Service Center
with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS
FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS
NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY. Since some states or
countries do not allow the exclusion or limitation of an implied warranty or of incidental or
consequential damages, this limitation of liability may not apply to you.
11/99
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

i
Table of Contents
Title Page
Introduction...............................................................................................................1
How to Contact Fluke...............................................................................................1
Safety Information ....................................................................................................2
Instrument Overview.................................................................................................8
Terminals..............................................................................................................8
Display..................................................................................................................9
Auto Power Off .........................................................................................................10
Auto Backlight Off.....................................................................................................11
Measurements..........................................................................................................11
Data Hold .............................................................................................................11
Measure AC and DC Voltage...............................................................................12
Measure AC or DC Current..................................................................................14
Measure Resistance.............................................................................................16
Test for Continuity ................................................................................................16
Test Diodes (107 Only) ........................................................................................18
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

106/107
Users Manual
ii
Measure Capacitance...........................................................................................19
Measure Frequency and Duty Cycle (107 Only) ..................................................19
Maintenance.............................................................................................................20
General Maintenance ...........................................................................................21
Test the Fuse........................................................................................................22
Replace Batteries and the Fuse ...........................................................................22
Service and Parts .....................................................................................................24
General Specifications..............................................................................................25
Accuracy Specifications............................................................................................28
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

1
Introduction
The Fluke 106 and 107 Digital Multimeters (the Product) are 6000-count instruments.
The Product is battery powered with a digital display.
Except where noted, the descriptions and instructions in this Users Manual apply to both the
106 and 107.
Unless otherwise identified, all illustrations show the 107.
How to Contact Fluke
To contact Fluke, call one of the following telephone numbers:
•Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: [phone]
•Japan: [phone]
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

106/107
Users Manual
2
Safety Information
A Warning identifies conditions and procedures that are dangerous to the user. A Caution
identifies conditions and procedures that could cause damage to the Product or the
equipment under test.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Digital Multimeters
Safety Information
3
 Warning
To prevent possible electrical shock, fire, or personal injury:
•Carefully read all instructions.
•Read all safety information before you use the Product.
•Use the Product only as specified, or the protection supplied by the Product
can be compromised.
•Do not use the Product around explosive gas, vapor, or in damp or wet
environments.
•Do not use the Product if it is damaged.
•Disable the Product if it is damaged.
•Do not use the Product if it operates incorrectly.
•Examine the case before you use the Product. Look for cracks or missing
plastic. Carefully look at the insulation around the terminals.
•Use only correct measurement category (CAT), voltage, and amperage rated
probes, test leads, and adapters for the measurement.
•Measure a known voltage first to make sure that the Product operates
correctly.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

106/107
Users Manual
4
•Do not use test leads if they are damaged. Examine the test leads for damaged
insulation and measure a known voltage.
•Do not apply more than the rated voltage, between the terminals or between
each terminal and earth ground.
•Do not use the HOLD function to measure unknown potentials. When HOLD is
turned on, the display does not change when a different potential is measured.
•Do not touch voltages >30 V ac rms, 42 V ac peak, or 60 V dc.
•Keep fingers behind the finger guards on the probes.
•Remove all probes, test leads, and accessories before the battery door is
opened.
•Do not exceed the Measurement Category (CAT) rating of the lowest rated
individual component of a Product, probe, or accessory.
•Remove the input signals before you clean the Product.
•Have an approved technician repair the Product.
•Remove the batteries if the Product is not used for an extended period of time,
or if stored in temperatures above 50 °C. If the batteries are not removed,
battery leakage can damage the Product.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Digital Multimeters
Safety Information
5
•Replace the batteries when the low battery indicator shows to prevent
incorrect measurements.
•Use only specified replacement parts.
•Use only specified replacement fuses.
•Limit operation to the specified measurement category, voltage, or amperage
ratings.
•Do not use test leads if they are damaged. Examine the test leads for damaged
insulation and measure a known voltage.
•Do not use in CAT III or CAT IV environments without the protective cap
installed. The protective cap decreases the exposed probe metal to <4 mm.
This decreases the possibility of arc flash from short circuits.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

106/107
Users Manual
6
Table 1 is a list of the symbols used on the Product and in this manual.
Table 1. Symbols
Consult user documentation. WARNING. RISK OF DANGER.
Static awareness. Static discharge
can damage part(s). WARNING. HAZARDOUS VOLTAGE. Risk of electric shock.
AC (Alternating Current) Earth
DC (Direct Current) Capacitance
Both direct and alternating current Diode
Battery Fuse
Conforms to relevant South Korean
EMC Standards Certified by TÜV SÜD Product Service.
Conforms to European Union
directives. Certified by CSA Group to North American safety standards.
