TView PresoCard
User’s Manual
FOCUS Enhancements, Inc.

FCC NOTICE
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the installation
manual, may cause harmful interference to radio commu-
nications. However, there is no guarantee that interference
will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or televi-
sion reception, which can determined by turning the
equipment off and on, the user is encouraged to try to cor-
rect the interference by on or more of the following mea-
sures:
• This unit was tested with shielded cable, therefore, for
continued compliance, use the shielded cables provided
with the unit.
• Reorient or relocate the unit.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit differ-
ent form that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV techni-
cian for help.
You may find the following booklet, "How to Identify and
Resolve Radio-TV Interference Problems" (stock number
004-000-000345-4) helpful. It is available form the U.S.
Government Printing Office, Washington DC 20402.
FOCUS Enhancements TView PresoCard User’s Manual
ii

COPYRIGHT
This document and the software described in it are copy-
righted under United States Copyright Laws. No part of
this document or software may be copied without prior
written consent from FOCUS Enhancements, Inc. except in
the normal use of the software as described in this docu-
ment. All printed circuits, their physical implementation
on printed circuit boards including the LCA program's
configuration bit streams, and associated software are
copyrighted with all rights reserved. Under the copyright
laws, the printed circuit board, or the software programs
provided may not be copied in whole or in part, without
written consent of FOCUS Enhancements, Inc. except in
the normal use of the software programs to make a back-
up copy. This exception does not allow copies to be made
for others, whether sold or not, but all of the material may
be sold, given, or loaned to another person. Under the law,
copying includes translating into another language or for-
mat.
Microsoft Windows, Windows 95, and Microsoft are
trademarks of Microsoft Corporation. All other products
named are trademarks of their respective manufacturers.
© 1994-7 FOCUS Enhancements, Inc. All Rights Reserved.
FOCUS Enhancements TView PresoCard User’s Manual
iii

FOCUS Enhancements TView PresoCard User’s Manual
iv

Section 1: Installation
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Section 2: Software Configuration
PresoCard Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
PC Driver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Section 3: Connecting to Your Television
The TView PresoCard Cable . . . . . . . . . . . . . . . . . . . . . . . .11
Television Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Section 4: Reference
Basic Tips for Advanced Presentations . . . . . . . . . . . . . . . . .19
VCRs, RF Modulators, and You . . . . . . . . . . . . . . . . . . . . . .20
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . .22
Troubleshooting Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Technical Support and Warranty Repair . . . . . . . . . . . . . . .27
Table of Contents
v

FOCUS Enhancements TView PresoCard User’s Manual
vi

INTRODUCTION
The TView PresoCard from FOCUS Enhancements puts
PC-to-TV video conversion technology into the smallest
and lightest form factor available on a personal computer.
The PresoCard PC-to-TV video converter fits into any PC
laptop Type II or Type III PC Card slot for unparalleled
mobility. Because every ounce makes a difference when
you travel, the PresoCard is ideal for the mobile exhibitor.
It delivers big screen impact without the size and weight
associated with presentation monitors and portable pro-
jection devices.
The TView PresoCard offers the ultimate in portability.
No power adapters, no cable collection, no carrying case.
And you’ll stay in control of the image positioning, filter-
ing and video output of your PC through an easy to use
software control panel. But that isn’t the only way the
PresoCard is good for your image. Custom image stabi-
lization techniques and 3-line averaging make you look as
brilliant as the 16.7 million colors on your television.
PACKING LIST
The TView Presocard is shipped with the following items:
• TView Presocard PCMCIA card
• User’s Manual with registration card
• Proprietary adapter cable
• Quick Start Card
• TView PresoCard diskette
To receive future updates, please fill out and return the
registration card on the back cover of this manual immedi-
ately. You can also register online by visiting our Website
at http://www.focusinfo.com.
Section 1: Installation
1

OPTIONAL ACCESSORIES
• Audio Patch Cable
• S-Video patch cable
• TView Commander
• Infrared Keyboard
• Carrying Case
SET-UP
Compatibility
The TView PresoCard works with any IBM PC
Compatible laptop computer which supports video VGA
output of 640 x 480, 60Hz. This includes most PC laptop
systems under the DOS, Windows 3.X, and Windows 95
operating systems. NOTE: Some PC laptops may not dis-
play in Presentation Mode.
Televisions and VCRs need an S-Video, Comp. Video, or
RF input port. If you have an RF input but no other inputs,
you must utilize a VCR with Comp. Video or S-Video
input. If you do not have a VCR with Comp. Video or S-
Video input, you must obtain an RF Modulator from
Radio Shack (part number 15-1283, see “VCRs, RF
Modulators, and You” in the Reference section at the end
of this manual).
FOCUS Enhancements TView PresoCard User’s Manual
2

Windows 95 Installation
Your TView PresoCard requires software to operate.
Please follow the instructions below for Windows 95
setup. If you have any trouble with this setup, use the
built-in help features of Windows 95 to initiate the instal-
lation process with the Windows Hardware Wizard.
Step 1: Insert the TView PresoCard into the PCMCIA
slot of your computer.
• A window titled “New Hardware Found” will appear.
FOCUS Enhancements TView PresoCard User’s Manual
3
The PresoCard can be inserted in either the upper or
lower PC card port, if you have more than one port.

Step 2: Install the PresoCard software.
• Select the option “Driver from disk provided by hard-
ware manufacturer” with your mouse.
• Insert the TView PresoCard software diskette into your
floppy drive.
• Click OK.
Step 3: Complete installation.
• Follow the Windows 95 prompts to complete the instal-
lation.
Windows 3.1 Installation
Step 1: Insert the TView PresoCard software diskette into
your disk drive.
Step 2: From within the Windows 3.1 Program Manager,
select Run... from the File menu.
Step 3: Type a:\setup and press ENTER. Follow the
installer prompts and insert your TView PresoCard
when instructed to complete the installation.
FOCUS Enhancements TView PresoCard User’s Manual
4

PRESOCARD CONTROLLER
After installing the TView PresoCard software, you’ll find
a new control panel that looks like this:
Initial Setup
There are two settings which need be configured only
once for any given combination of television and the
TView PresoCard. The last values for these settings are
recorded in the applications initialization file (INI file) and
automatically restored when the Preso card is next
plugged in. The two settings are the TV Operation Mode
(NTSC for example) and the Clock Phase and are both set
from the Setup menu.
FOCUS Enhancements TView PresoCard User’s Manual
5
The PresoCard controller window has five menus:
File, Position, Filter, Setup, and Help.
Section 2: Software Configuration

File Menu Commands
The File menu offers the following commands:
Reset
This operation will reset the Preso PC Card to the default
operating mode.
Key shortcut: ALT-F+ALT-R
Exit
Use this command to end your Preso Controller session.
You can also use the Close command on the application
Control menu. Preso Controller prompts you to save doc-
uments with unsaved changes.
Mouse shortcut: Double-click the application's Control
menu button.
Key shortcut: ALT+F4
Position menu commands
The Position menu offers the following commands:
Up
This operation moves up the computer screen image on
your TV screen.
Key shortcut: ALT-P+ALT-U
Down
This operation moves down the computer screen image on
your TV screen.
Key shortcut: ALT-P+ALT-D
Left
This operation moves the computer screen image to the
left on your TV screen.
Key shortcut: ALT-P+ALT-L
FOCUS Enhancements TView PresoCard User’s Manual
6

Right
This operation moves the computer screen image to the
right on your TV screen.
Key shortcut: ALT-P+ALT-R
Filter menu commands
The Filter menu offers the following commands:
No Filter
This operation will apply no flicker filter.
Key shortcut: ALT-F+ALT-N
2-Line
This operation will apply 2-line filter to reduce flicker.
This filter is usually best for display with small characters.
Key shortcut: ALT-F+ALT-2
3-Line
This operation will apply 3-line filter to reduce flicker.
This filter is usually best for graphic display without small
characters.
Key shortcut: ALT-F+ALT-3
Color Bars
This operation will display color bars for testing and cali-
bration.
Key shortcut: ALT-F+ALT-C
FOCUS Enhancements TView PresoCard User’s Manual
7

Setup menu commands
The Setup menu offers the following commands:
NTSC
This is the television broadcast signal standard in the
United States, Canada and Mexico. If your television
operates with television broadcast signals in these locales,
select this mode.
Key shortcut: ALT-S+ALT-N
NTSC-Japan
This is the television broadcast signal standard in Japan. If
your television operates with television broadcast signals
in Japan, select this mode.
Keys: ALT-S+ALT-J
PAL 640x480
PAL is the television broadcast signal standard in Europe
and in some parts of Central and South America. If your
television operates with television broadcast signals in
these locales, and if your computer monitor resolution is
set to 640x480, select this item.
Key shortcut: ALT-S+ALT-P
PAL 800x600
PAL is the television broadcast signal standard in Europe
and in some parts of Central and South America. If your
television operates with television broadcast signals in
these locales, and if your computer monitor resolution is
set to 800x600, select this item.
Key shortcut: ALT-S+ALT-A
PAL/M
This is the television broadcast signal standard in Brazil.
If your television operates with television broadcast sig-
nals in Brazil, select this item.
Key shortcut: ALT-S+ALT-L
FOCUS Enhancements TView PresoCard User’s Manual
8

Clock Phase 1 and Clock Phase 2
The Setup menu contains the two clock phase entries.
The current selection is indicated with a check mark. To
change the clock phase, select the item which is not cur-
rently selected.
The clock phase setting need be set only once for any
given Preso card. The last selection will be saved in the
application initialization file and automatically restored
when the Preso card is next plugged in. There are two
clock phase selections, Clock Phase 1 and Clock Phase 2.
Try each phase and select the one which appears to give
the least amount of noise and jitter on the TV screen.
Key shortcut: ALT-S+ALT-1
Key shortcut: ALT-S+ALT-2
Help menu commands
The Help menu offers the following commands, which
provide you assistance with this application:
Index command
Use this command to display the opening screen of Help.
From the opening screen, you can jump to step-by-step
instructions for using the TView PresoCard as well as var-
ious types of reference information.
Using Help command
Use this command to display the opening screen of Help.
From the opening screen, you can jump to step-by-step
instructions for using the TView PresoCard and various
types of reference information.
About command
Use this command to display the copyright notice and ver-
sion number of your copy of PresoCard Controller.
FOCUS Enhancements TView PresoCard User’s Manual
9

DRIVER SETUP
NOTE: Your computer’s video driver must be set to a VGA-com-
patible setting.
CRT Activation Key
When using the TView PresoCard, you should use the
CRT Activation key combination specific to your comput-
er. Most Laptop computers have an “F” key (such as F1,
F6, F12 - each model is different) with "CRT" marked on
the side facing you. Others have an icon of a monitor.
Find this key and press it in combination with the "Fn" key
to activate the CRT output of your Laptop. If you cannot
find the CRT Activation F-key on your Laptop, consult
your Laptop manual for more information about connect-
ing an external (CRT) monitor.
Windows 95
Open the Control Panel, then the Display Icon. Click the
Settings Tab. Click Change Display Type, and make sure
that your Display type is set to VGA Standard 640x480. If
the signal is still distorted, repeat the previous steps and
set the Adapter Type to Standard VGA.
NOTE: Whenever changing your control panel settings, be sure
to write the previous settings down on a piece of paper,
just in case you need to change it back.
Windows 3.1x
Use the Windows Setup program (located in the Main
Program Group) to specify your Display Driver.
Recommended Windows 3.1 drivers include: VGA,
Super VGA-640x480, VGA 3.0, GD5434 640x480x256, and
GD5434 640x480x64K.
FOCUS Enhancements TView PresoCard User’s Manual
10

THE TVIEW PRESOCARD CABLE
Your TView PresoCard includes a special, proprietary
cable that only works with the PresoCard.
This cable connects between your PresoCard and the 15-
pin VGA port on the back of your laptop computer.
Section 3: Connecting the Television
PresoCard interface
S-Video and Composite
Video Out ports
11
VGA Pass-through
(to optional computer monitor)
VGA Input
(from laptop VGA port)
Top ViewSide View

FOCUS Enhancements TView PresoCard User’s Manual
12
Connecting the TView PresoCard
Cable
This cable can only be attached one way.
• Attach the cable’s VGA Input port to your laptop’s
VGA Monitor Out port and tighten the thumbscrews.
• Attach the PresoCard Interface connector to the
PresoCard. Press this connector into the card’s match-
ing port until you feel its latches engage.
• If you wish to use a separate VGA or Multisync moni-
tor while using the PresoCard, attach the monitor’s 15-
pin cable to the VGA Pass-through connector on the
PresoCard cable.
TView PresoCard provides two
major connection-types:
S-video
A high-quality video connection used by some video cam-
eras and VCRs. The connector on an S-video cable has a
round plug with several small metal pins and plug into
the S-video output port on the back of the computer.
S-video output port
S-video cable (not included)S-video
S-video connector
S-video
out

To determine whether or not your television or VCR sup-
ports S-video look for a port on your device that matches
the S-video output port on the back of the computer. This
port on your external device may or may not be labeled as
S-video in. S-video is recommended for external video dis-
play because of its higher picture quality capability.
WARNING: The S-video connector resembles other computer connec-
tors such as those used for a printer, modem, mouse, or
keyboard. When using an S-video cable make sure to plug
it only into the S-video output port. Connecting an S-
video device to the wrong port may damage your equip-
ment.
Composite video
A connection type used by most televisions, VCRs,
laserdisc players, and certain LCD panels. The connectors
on a composite video cable have an RCA-type plug with a
long metal pin projecting from the center of the plug and
plug into the composite video out port on the back of your
computer.
FOCUS Enhancements TView PresoCard User’s Manual
13
Composite video
output port
Single RCA cable (not included)RCA
RCA-type plug
RCA
out

FOCUS Enhancements TView PresoCard User’s Manual
14
To determine whether or not your television or VCR sup-
ports composite video look for a port that matches the
composite video out port on the back of your computer.
This port on your television or VCR may or may not be
labeled as video in.
NOTE: Your computer may have also come with hardware that
allows you to input video from an external source. In this
case additional ports for S-video input and composite
video input will also be provided. Make sure not to mis-
take these input ports for the ones used for Video Out.
