TView Gold
User’s Guide
Rev. 5/02Thi page is blank

FCC NOTICE
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the installation manual, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment on and off, the user is encouraged to try to correct the
interference by one or more of the following measures:
•This unit was tested with shielded cable. Therefore, for
continued compliance, use the shielded cables provided with the
unit.
•Re-orient or relocate the unit or receiving antenna.
•Increase the separation between the computer/converter and
television.
•Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
You may find the following booklet helpful:
How to Identify and Resolve Radio-TV Interference Problems (stock
number 004-000-000345-4)
To order the booklet, write to:
The U.S. Government Printing Office
Washington D.C. 20402

COPYRIGHT
This document and the software described in it are copyrighted under
United States Copyright Laws. No part of this document or software
may be copied without prior written consent from FOCUS
Enhancements, Inc. except in the normal use of the software as
described in this documentation. All printed circuits, their physical
implementation on printed circuit boards, including the LCA
program’s configuration bit streams, and associated software are
copyrighted with all rights reserved. Under the copyright laws, the
printed circuit board, or the software programs provided may not be
copied in whole or part, without written consent of FOCUS
Enhancements, Inc., except in the normal use of the software
programs to make a backup copy. This exception does not allow
copies to be made for others, whether sold or not, but all of the
material may be sold, given, or loaned to another person. Under the
law, copying includes translating into another language or format.
Microsoft Windows, Windows 95, 98, 2000, ME, NT, XP and
Microsoft are trademarks of Microsoft Corporation. All other products
named are trademarks of their respective manufacturers.
©2002 FOCUS Enhancements, Inc. All Rights Reserved

This is a blank page
Table of Contents
FCC NOTICE ii
COPYRIGHT iii
TABLE OF CONTENTS IV
About the User’s Guide 1
Notation Conventions 2
Ordering Information 2
INTRODUCTION 3
Features 3
Modes of Operation 4
Suggested Uses for the TView Gold 5
Specifications 6
HARDWARE INSTALLATION 7
System Requirements 7
Pre-Installation Procedures 8
Connecting the TView Gold to an IBM PC or
Macintosh Computer 9
Connecting the TView Gold to a Television 15
Connecting to the Television Using an RF Modulator 19
Connecting the TView Gold to a VCR 20
IMAGE CONTROL 23
Overview 23
On-Screen Display 24

Using the Remote Control 25
Configuring Your PC or Laptop Video Output 28
Changing Screen Resolutions 28
TUNING YOUR TELEVISION 31
Using Your Television’s Video Settings 31
TROUBLESHOOTING 33
Returning a Damaged or Failed TView Gold Unit 35

TView Gold User’s Guide
Preface 1
About the User’s Guide
The TView Gold User’s Guide is designed to help you to
quickly and easily connect the hardware and install the
software for this product. The guide is divided into the following
chapters:
Chapter 1: Introduction: which describes the key features
and functionality of the product and some of its many uses.
The chapter also discusses the notation conventions used in
the guide.
Chapter 2: Installing the Hardware: which describes the
information you should know before installing and connecting
the TView Gold hardware, and the steps required to perform
the installation.
Chapter 3: Image Control: describes the location and
functions of the control buttons on the TView Gold Unit, the
buttons on the remote control, and how to use the remote to
adjust the image. It also describes the steps involved in
configuring your PC or laptop video output.
Chapter 4: Tuning Your Television: this chapter describes
the methods you can use to tune the image on your television.
Chapter 5: Troubleshooting: describes possible problems
that you might encounter and ways to solve them.

TView Gold User’s Guide
About This Guide 2
Notation Conventions
This user’s guide uses the following conventions to specify
certain types of information.
Warns you about potential problems and hazards
during the installation or use of the product. Read
these warnings carefully, and be sure you
understand how they relate to the installation
procedures before proceeding.
Note: Points out important or useful information.
Ordering Information
To get information on the reseller nearest to you or to order
replacement parts, contact one of the following:
Worldwide headquarters
1370 Dell Avenue
Campbell, CA 95008
408-866-8300
800-338-3348 (U.S. Only)
On-line
http://www.FOCUSinfo.com
e-mail: [email protected]

TView Gold User’s Guide
Chapter 1 3
Chapter 1
Introduction
The TView Gold converts the video output from your computer
into video that can be displayed on a television or recorded to
a VCR. . The result is a high quality, flicker-free television
display from your computer.
Features
The TView Gold includes the following features:
•Screen position controls
•Easy plug-and-play installation for any computer with a
VGA output and the following platforms: Windows95™,
98, 2000, ME, NT , XP and MacOS Systems 7.1 or higher
•Compatibility with any size television monitor (NTSC/PAL)
with an RCA (composite) or S-Video input connector.
•Support for screen resolutions up to 1600x1280
•Support for 24-bit color
•2x image zoom with pan control
•9 Position area Zoom control
•Highlight, Spotlight, and Pointer Controls
•2 Dimensional Flicker reduction filter with six preset
modes
•Brightness, Sharpness, Contrast adjustments
•Kensington® Microsaver Lock Port
•Infrared remote control

TView Gold User’s Guide
Introduction 4
Modes of Operation
The TView Gold has ability to operate in three separate
modes:
1. Presentation Mode: Display the same image on your
computer VGA (or compatible) monitor and television
simultaneously.
Figure 1-1: Presentation Mode
2. Television Only Mode: Use the television as your only
display.
Figure 1-2: Television Only Mode

TView Gold User’s Guide
Chapter 1 5
3. Video Record Mode: Record your video image directly to
videotape.
Figure 1-3: Video Record Mode
Suggested Uses for the TView Gold
The TView Gold can be used for many purposes. For example:
•Bring sales or other multimedia presentations from a
laptop to a large TV
•Create training tapes or outfit a training room
•Demonstrate a new software package using a large
screen TV
•Project computer games onto a TV screen
•Cruise the Internet on any television
•Conferencing via TV
•E-Mail
•Collaborating with others on computer-based projects

TView Gold User’s Guide
Introduction 6
Specifications
Table 1: TView Gold Specifications.
Computer
Compatibility
•Any . Window 95™, 98™, 2000, ME
,NT, XP and MacOS™ 7.1 or higher
computer with VGA output
Television
Compatibility
•Works with any size television monitor
(NTSC/PAL) with an RCA (composite)
or S-Video input connector. For
television receivers or televisions
without composite or S-Video inputs,
an RF Modulator is required (Radio
Shack #15-1283)
Color Modes and
Resolution
•Supports up to 16,777,216 colors (24-
bit), and up to 1600x1280
Power Supply •Maximum consumption 5 volt DC,
700 MA
Unit Weight •11 ounces (without cables)
Unit Dimensions •8.2" x 3.6" x 1.7"

TView Gold User’s Guide
Chapter 2 7
Chapter 2
Hardware Installation
This chapter describes the information you should know before
installing and connecting the TView Gold hardware, and the
steps required to perform the installation.
System Requirements
Before installation, the following are system requirements for
the operation of the TView Gold :
IBM (or compatible)
•Personal or multimedia computer with a 486 or higher
processor
•Microsoft Windows 95, 98, NT, 2000, XP or ME
•VGA, SVGA, XGA, SXGA, and UXGA desktop resolution
Macintosh (or compatible)
•Any Macintosh with VGA output (older Mac’s may require
a DB-15 to HD-15 VGA adapter kit)
•MacOS System Software 7.1 or higher
•VGA, SVGA, XGA, SXGA, and UXGA desktop resolution
•A TV/Monitor, VCR or any video device that can display or
record NTSC video

TView Gold User’s Guide
Hardware Installation 8
Pre-Installation Procedures
Before installing the hardware, you must unpack and inspect
the equipment. This section discusses the steps for unpacking
and inspecting the equipment.
Checking the Packing List
Check the packing list that is included in this manual. Compare
the list with the equipment you have purchased. Be sure that
you have received everything that is on the list. If anything is
missing, contact FOCUS Enhancements Customer Service
department by calling 1-800-338-3348.
Packing List
Your TView Gold includes the following items:
•TView Gold
•Power adapter 5V DC@ 700mA
•S-Video cable
•Composite video cable or SCART adapter cable (SCART
In Europe Only)
•UniViewermonitor cable
•Infrared remote control
•User’s guide and Quick Start Guide (on CD ROM)

TView Gold User’s Guide
Chapter 2 9
Inspecting the Equipment
Before installing and connecting the hardware, inspect it for
any damage which may have been incurred during shipment.
Perform a thorough inspection, looking for dents, scratches, or
loose parts. Look for anything that appears unusual or out-of-
the ordinary. If any of the equipment is damaged, contact
FOCUS Enhancement’s Customer Service department by
calling 1-800-338-3348.
Connecting the TView Gold to an IBM
PC or Macintosh Computer
This section describes the steps to connect your TView Gold to
a television or VCR. The following sections describe how to
connect to IBM PCs, Macintosh PCs, IBM PC laptops and
Notebooks, and Macintosh PowerBook’s.
Notes: 1. Before performing the steps to connect the
TView Gold to a laptop computer, you must enable
the external video connector. This is accomplished
by using a particular key sequence (hot key) on the
keyboard (for example, FN + F11) or through the
BIOS setup program. Refer to your laptop owner’s
manual to determine how the external video
connector is enabled.

TView Gold User’s Guide
Hardware Installation 10
2. Not all Macintosh PowerBook computers have a
VGA connector for an external monitor. Some
PowerBook’s require a special cable to output VGA
Video. Refer to your PowerBook owner’s manual
or Apple’s web site for more information.
Perform the following steps to connect the TView Gold to
a PC or Macintosh Desktop or Laptop:
1. Turn the computer and monitor off.
The computer must be off when connecting the
TView Gold. Connecting with the power on could
result in static damage to your computer and video
equipment.
2. Disconnect the current monitor cable from the "monitor
out" port at the rear of the computer.
3. Connect the male DB-15 end of the supplied UniViewer
cable to the port at the rear of the TView Gold labeled
"Video In."
4. For an IBM PC, compatible and Macintosh, connect the
pass-through end of the UniViewercable to the "monitor
out" port at the rear of the computer, the same port from
which you disconnected the current monitor cable in step
2.
Note: Steps 5 and 6 facilitate the use of the TView Gold in
the Presentation Mode.

TView Gold User’s Guide
Chapter 2 11
5. Connect the male end of your computer’s monitor cable to
the video pass-through port on the UniViewercable.
This port is located on the UniViewercable itself, at the
end of the cable that is connected to the “Monitor out” port
on the computer.
6. Connect the female end of the monitor cable to the
monitor.
7. Connect the power adapter to the rear of the TView Gold.
Plug the adapter into the nearest wall outlet. The red
power LED at the front of the unit will illuminate, indicating
the TView Gold is ON.
Is it possible to have a Apple G4 Desktop
work with a Focus Enhancements TView
Gold in Video Mirroring Mode?
This depends on which model G4 computer (Figure
1) you have as well as what type of Monitor Display
you are using. If using a standard Mutisync VGA
Monitor or a Apple Studio Display 17 or 21 with
any G4 model listed below then there are no issues.
Note: See Figure 2 and Figure 3 for Monitor
Display Connector.
Figure 1
Mac G4 Model With VGA Monitor With ADC/DVI

TView Gold User’s Guide
Hardware Installation 12
Monitor
CI Yes N/A
AGP Graphics Yes *Requires second PCI
video Card for video
mirroring
Gigabit Ethernet Yes *Requires second PCI
video Card for video
mirroring
Digital Audio Yes *Requires second PCI
video Card for video
mirroring
Cube Yes *Requires second PCI
video Card for video
mirroring
Quicksilver Yes
*Requires second PCI
video Card for video
mirroring or optional
Nvidia Gforce 3 Twin
View card.
*You can still attach the scan converter to the VGA port but
you cannot use Video Mirroring.
Figure 2
VGA DVI ADC

TView Gold User’s Guide
Chapter 2 13
Figure 3
Note: for more information regarding models and
display types visit Apples web site at
http://docs.info.apple.com/article.html?artnum=252
21

TView Gold User’s Guide
Hardware Installation 14
Figure 2-1: Connecting the TView Gold to an IBM or Macintosh
PC
Note: Some Mac models also have a ADC or DVI connector for
use with some Apple Studio or Cinema Displays. Simply use
the VGA to connect the TView Gold. Also note that Video
Mirroring may not be available when using both the VGA and
ADC/DVI connectors. Consult your computers owner manual for
more information on Video Mirroring.
