Focal Point Ivory Guide

INSTALLATI N & USER INSTRUCTI NS
All instructions must be handed to the user for
safekeeping.
M DELS C VERED BY THESE INSTRUCTI NS
Avonbury Cube LED Electric Complete Suite Ivory
Avonbury Cube LED Electric Complete Suite ak
FL R M UNTED ELECTRIC FIRE
1
Revision C - 11/13
©2013 Focal Point Fires plc.
Avonbury
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: [phone]
Fax: [phone]
www.focalpointfires.co.uk
Email: [email protected].uk
GB IE
Please note: Except where otherwise stated, all rights,
including copyright in the text, images and layout of this
booklet is owned by Focal Point Fires plc. You are not
permitted to copy or adapt any of the content without
the prior written permission of Focal Point Fires plc.
Questions or problems with your appliance?
Don’t take it back to the store
just give us a call on 01202 588601 we’re here to help
lines open between 9am and 5pm, Monday to Friday

IMP RTANT - THESE INSTRUCTI NS SH ULD BE READ CAREFULLY AND RETAINED F R FUTURE
REFERENCE.
When using this electrical appliance, basic precautions should be followed to reduce the risk of fire, electric shock and injury to person,
including the following:
• This heater must be used on an AC supply only and the voltage marked on the heater’s rating label must correspond to the supply volt-
age.
• Do not switch the appliance on until it is properly installed as described in this manual.
• The heater must not be located immediately above a socket outlet.
• eep furniture, curtains and other fabric material away from the appliance.
• Do not leave the appliance unattended during use.
• From time to time, check the cord for damage. Never use the appliance if the cord or any part of the appliance shows signs of damage.
A damaged cord must only be replaced by a qualified person.
• Do not operate this appliance with a damaged plug or cord, after a malfunction or after being dropped or damaged in any way.
• Repairs to electrical appliances should only be performed by a qualified electrician. Improper repairs may place the user at serious risk.
• Do not run the mains cable under carpets, rugs etc.
• Do not cover or obstruct the heater in any way. Overheating will result if it is accidentally covered.
• Never immerse the product in water or any other liquids.
• Do not use this heater where it may come into contact with water e.g. in bathrooms, shower rooms etc.
• Do not use the appliance outdoors.
• Before cleaning the appliance, ensure it is unplugged from the power and that it is completely cool.
• Do not clean the appliance with abrasive chemicals.
• Never use accessories that are not recommended or supplied by the manufacturer. It could cause danger to the user or damage to the
appliance.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsi-
ble for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not lift the appliance by the decorative fascia.
• CAUTION! In order to avoid a hazard due to inadvertent resetting of the thermal cut out, this appliance must not be supplied through
an external switching device such as a timer or connected to a circuit that is regularly switched on and off by the utility.
• Do not insert or allow foreign objects to enter the inlet or outlet vents as this may result in electric shock, fire or damage to the appli-
ance.
• Do not install the fire using an extension cord.
• Unplug from the mains supply if the appliance is not to be used for long periods.
The appliance is supplied with a pre-wired three pin plug (13 Amp fuse rated) and 1.8 metres of electrical cable. It is therefore
necessary for a suitable electrical socket to be located within this distance and be easily accessible. This appliance is designed to
be wall hung, using the wall fixtures/fixings provided. DO NOT recess any part of appliance into the wall. This appliance is suit-
able for installation in static holiday/park homes.
Supply Voltage: 220~240V AC, 50Hz Fuse Rating: 13 Amp
Heating Elements: 1800W Lighting: LED
Weights: 32kg Dimensions: H855 X W850 X D235 (mm)
This fire is fitted with LED’s (Light Emitting Diode) in place of conventional bulbs. LED’s generate the same light levels as con-
ventional bulbs, but use a fraction of the energy consumed. LED’s are maintenance free and will not require replacing during the
life of the product.
I N S TA L L AT I N & U S E R I N S T R U C T I N S
©2013 Focal Point Fires plc.
2
GB IE
SectionContents Page No.
1.0 Important Notes 2
2.0 Appliance Data 2
3.0 Electrical Installation Requirements 2
4.0 Site Requirements 3
5.0 Clearances to Combustible Materials 3
6.0 Unpacking the Appliance 3
SectionContents Page No.
7.0 Component Checklist 3
8.0 perating the Appliance 3
9.0 Safety Cut- ut System 4
10.0 Cleaning and Maintenance 4
11.0 Servicing 4
2.0 INSTALLATI N REQUIREMENTS
3.0 APPLIANCE DATA
1.0 IMP RTANT N TES

The appliance is designed to be floor mounted only. D N T RECESS ANY PART F THE APPLIANCE.
The appliance is supplied with a pre-wired three pin BS1363 plug (13 Amp fuse rated), and 1.8 metre cable. A standard switched
outlet/wall socket, (including earth provision), must therefore be located within this distance, and be easily accessible in order
to isolate the supply for maintenance and cleaning. This socket must not be mounted behind or above the appliance.
IMP RTANT: THIS APPLIANCE MUST BE EARTHED.
Caution: This appliance is heavy. Always seek assistance whilst unpacking and/or during installation.
Read all the instructions before continuing to unpack or install this appliance. Carefully remove the appliance from its packag-
ing. Check that the remaining packaging contents correlate with the component checklist below. Please dispose of all packaging
with care at your local recycling centre.
QUANTITY DESCRIPTI N
1 Fire suite
1 Remote control handset
1 Instruction Booklet
It should be noted that the appliance creates warm convected air currents. These currents move heat from the room surround-
ings to, and up the wall surfaces adjacent to the heater.
The appliances are designed to be floor mounted. It is not necessary to secure the surround to the wall, provided it is sited on
a firm level surface.
Operating the heater where impurities in the air, (such as tobacco smoke) exist, may slightly discolour wall finishing. Once the
suite is in the desired location check that it is level and it sits firmly on the floor, i.e. does not rock in any direction, and fits square-
ly against the wall.
Note: Skirting boards may need to be cut in order to fit the rear of the suite snugly against the wall, Provision must be made in
the wall, either behind the suite, or in one of the sides of the suite to allow the power supply cable to exit.
D N T -mount on a wall.
-recess any part of the appliance into the wall.
- site in a position where curtains or drapes could cover the appliance.
-site in a position where other soft materials could cover e.g. below a coat rack.
-site behind an opening door where mechanical impact/damage could occur.
-site where the supply cable would become a trip hazard.
-sit, stand or forcefully pull on the appliance.
-obstruct, cover or force items into the openings.
-use the heater to dry clothes.
- site/use in an outdoor location(s).
-run the supply cable under carpets.
3.0 ELECTRICAL INSTALLATI N REQUIREMENTS
©2013 Focal Point Fires plc.
3
GB IE
4.0 UNPACKING THE APPLIANCE
5.0 C MP NENT CHECKLIST
6.0 SITE REQUIREMENTS

©2013 Focal Point Fires plc.
4
It is important that the following clearances are maintained from the appliance to combustible materials and are dependant on
the desired mounting location as defined below.
This appliance is designed to be floor mounted only.
The minimum distance from the top of the appliance to a ceiling is 500mm.
The minimum distance to the sides of the appliance is 100mm.
The minimum distance to the front of the applaince is 500mm.
The control panel is located underneath the decorative frame on the bottom right hand side of the appliance.
C NTR L PANEL
POWER ON/OFF
FLAME BRIGHTNESS (5 settings)
Press to adjust the brightness level
FULL (5) - HIGH (4) - MEDIUM (3) - LOW (2) - DIM (1) - (LOOP)
HEATING (7 settings)
Press ∧ /∨ to adjust the temperature level
60℃/99°F - 30℃/86°F - 28℃/82°F - 26℃/78°F - 24℃/75°F - 22℃/71°F - OFF -
(LOOP) Press button for 10s to convert between ℃and ℉(model dependent)
EMBER/FUELBED EFFECT
Press to select the dynamic fuelbed effect
All of the appliances features can be operated by the remote control.
Check that the fan outlet, mounted underneath the appliance, is not covered or obstructed in any way. Ensure the power to
the fire is switched ON.
REM TE C NTR L
POWER - ON/OFF
OFF will cancel the OFF TIMER and the flame brightness slowly fades to OFF.
FLAME BRIGHTNESS (5 settings)
Press ∧ /∨ to adjust the brightness level
FULL (5) - HIGH (4) - MEDIUM (3) - LOW (2) - DIM (1)
HEATING (7 settings)
Press ∧ /∨ to adjust the temperature level
60℃/99°F - 30℃/86°F - 28℃/82°F - 26℃/78°F - 24℃/75°F - 22℃/71°F - OFF -
(LOOP)
OFF TIMER
Press to set the OFF TIMER
10m - 20m - 30m - 40m - 50m - 1H - 2H - 3H - 4H - 5H - 6H - 7H - 8H - 9H -
(LOOP)
EMBER/FUELBED EFFECT
Press to select the dynamic fuelbed effect
7.0 CLEARANCES T C MBUSTIBLE MATERIALS GB IE
8.0 PERATING THE APPLIANCE

This appliance has a safety cut-out system fitted which will activate if the air inlets or heater outlets are obstructed. For safety
reasons the fire WILL NOT switch on again automatically. NOTE: The LED display panel will remain operational if the cut-out is
activated, only the fan heater elements are prevented from operating.
The following procedure must be carried out before the fire can be operated again:
1. Unplug the power supply cable at the outlet socket and place all switches to off at the appliance.
2. Leave the fire OFF for a period of not less than 10 minutes, ensuring any obstructions are removed.
3. Plug in the power supply cable at the outlet socket, and then switch on at the appliance.
If an attempt to switch on is made before the safety cut-out has reset, the heaters may cut-out for a further period of time. If the
sequence has been followed correctly and the heaters still fail to function, check the power supply cable plug is plugged in at the
outlet socket. If this is not the cause, call an electrician.
ALWAYS DISC NNECT THE APPLIANCE FR M THE MAINS SUPPLY UTLET
S CKET BEF RE UNDERTAKING ANY CLEANING R MAINTENANCE!
For general cleaning use a soft clean duster - never use harsh abrasive or cleaners. The plastci viewing screen should be cleaned
carefully with a soft cloth or using a suitbale
If in doubt consult a qualified electrician. Refer to Section 3.0 Appliance Data for fuse specification. Excluding fuses, use only
genuine manufacturers spare parts available from your supplier.
Replacing the remote control battery:
When the battery becomes weak, the range of the remote control becomes shorter. Replace the battery with a new CR2025
lithium battery.
Note: eep the lithium battery out of the reach of children.
There are no internal user serviceable parts.
Check security of supply cable and connections. If the supply cable becomes damaged, it must be replaced by a service agent or
competent person, such as a qualified electrician.
The wires in the cable are coloured in accordance with the following code:
LIVE - Brown
NEUTRAL - Blue
EARTH - Green/Yellow
Refer to Section 2.0, Appliance Data for fuse specification. Excluding fuses, use only genuine manufacturers spare parts available from your sup-
plier.
10.0 CLEANING AND MAINTENANCE
9.0 SAFETY CUT- UT SYSTEM GB IE
11.0 SERVICING
©2013 Focal Point Fires plc.
5

The 3 year guarantee only covers products purchased on or after 1st February 2009. For all gas fires purchased the 3 year
guarantee commences from the date of purchase, provided that the following 3 terms and conditions are adhered to:
Registration is not required.
1. For any claim to be made within the 3 years from date of purchase you will be required to provide and supply us with your
proof of purchase.
2. Your gas fire must have been commissioned by a CORGI/Gas Safe* registered installer, evidence of which you must provide
together with the CORGI/Gas Safe* registration number.
3. Your appliance must have been serviced annually, irrespective of use, by a CORGI/Gas Safe* registered installer, evidence of
which must be provided, such as the receipt.
Please note all consumable items such as any ceramics including; coals, pebbles, the matrix, front strips, side cheeks, rear panels
and tapered rear panels are not covered by the 3 year guarantee. For all Electric fires purchased the 3 year guarantee com-
mences from the date of purchase, providing that you can supply the proof of purchase. This does not cover consumable items
such as pebbles, coals or light bulbs.
Making a claim is easy.
If you wish to make a claim under our 3 year guarantee and all the terms and conditions for your product have been met then
please submit the following information for the attention of the 3G Service Department to the address below. Alternatively, you
can email or fax.Please note that this does not affect your statutory rights.
Focal Point Fires plc, 3G Service Department, Reid Street, Christchurch, Dorset, BH23 2BT.
Alternatively email: [email protected].uk or fax. [phone].
Details required:
1. Name, full address including post code and contact telephone number.
2. Receipt of purchase or credit card statement.
3. Original installers CORGI/Gas Safe* registration number (gas fires only).
4. Annual service receipt for every 12 months (gas fires only).
*Gas Safe Register replaced CORGI as the gas registration body in Great Britain and the Isle of Man on 1st April 2009.
6©2013 Focal Point Fires plc.
As our policy is one of continuous improvement and development, we therefore hope that you will understand we must retain the right to amend details and/or specifica-
tions without prior notice.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice.
F861229
12.0 GUARANTEE - TERMS AND C NDITI NS
