FOR-A P20 User manual

1
Owner’s Manual
Manual del Propietario
BLOOD PRESSURE MONITORING SYSTEM
Sistema de Vigilancia de Presión Arterial
P20

2

3
Dear System Owner:
Thank you for purchasing the FORA P20 Blood Pressure Monitoring
System. This manual provides important information which helps
you to operate this system properly. Before using this product,
please read the following contents thoroughly and carefully.
According to the clinical studies from American Diabetes Associa-
tion, elevated blood pressure often accompanies adult diabetes
patients. These studies also suggest that diabetes patients could
reduce the risk of cardiovascular diseases by managing their blood
pressure. With the use of this FORA P20 Blood Pressure Monitoring
System, you can easily monitor your blood pressure by yourself. In
addition, this system can help you and your healthcare profession-
als to monitor and adjust your treatment plans, and keep your blood
pressure under control.
If you have other questions regarding this product, please contact
the place of purchase.
Version 4.0 2015/10 311-3132000-006
English
P20

4
IMPORTANT SAFETY INSTRUCTIONS
READ BEFORE USE
1.
Use this device ONLY for the intended use described in this
manual.
2.
Do NOT use accessories which are not specified by the
manufacturer.
3. Do
NOT
use the device if it is not working properly or damaged.
4. Do
NOT
use under any circumstances on neonates or infants.
5. This device does
NOT
serve as a cure for any symptoms or
diseases. The data measured are for reference only. Always
consult your doctor to have the results interpreted.
6. Keep the equipment and its flexible cord away from hot surfaces.
7. Do NOT apply the cuff to areas other than the place directed.
8. Use of this instrument in a dry environment, especially if
synthetic materials are present (synthetic clothing, carpets
etc.) may cause damaging static discharges that may cause
erroneous results.
9. Do not use this instrument in close proximity to sources of
strong electromagnetic radiation, as these may interfere with
the accurate operation.
10. Proper maintenance and periodic calibration are essential
to the longevity of your device. If you are concerned about
your accuracy of measurement, please contact local
customer service for help.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE

5
TABLE OF CONTENTS
BEFORE YOU BEGIN 06
Intended Use 06
Test Principle 06
Contents of System 07
Monitor Overview 08
Screen Display 09
Speaking Function 10
SETTING THE MONITOR 13
TESTING YOUR BLOOD PRESSURE 17
Before Measurement 17
Taking Measurements 20
MONITOR MEMORY 24
Reviewing Test Results 24
DOWNLOADING RESULTS 25
Data Transmission Via Cable (For FORA P20v only) 26
Data Transmission Via Bluetooth (For FORA P20b only) 27
MAINTENANCE 29
Battery 29
Using AC Adapter 31
Caring for Your Monitor 32
SYSTEM TROUBLESHOOTING 33
Error Messages 33
Troubleshooting 34
DETAILED INFORMATION 35
Reference Values 35
SPECIFICATIONS 36
FEDERAL COMMUNICATIONS COMMISION (FCC) STATEMENT 37

6
Intended Use
The FORA P20 Blood Pressure Monitoring System is intended to be
used to measure the systolic and diastolic blood pressure and pulse
rate by using a non-invasive technique in which an inflatable cuff is
wrapped on the upper arm. This system should only be used for the
testing of people who are 18 years old or older.
This monitor has some speaking function but is not intended for use
by the visually impaired.
Test Principle
Blood pressure is measured non-invasively at the arm based on oscil-
lometric method. Blood pressure measurements determined with this
device are equivalent to those obtained by a trained observer using
the cuff/stethoscope auscultation method, within the limits prescribed
by the American National Standard, Electronic or automated sphygmo-
manometers.
This device is NOT able to take measurements in the presence of
common arrhythmia, such as arterial or ventricular premature beats or
arterial fibrillation. It may produce reading error.
BEFORE YOU BEGIN

7
Contents of System
Your new FORA P20 system kit includes:
NOTE
If any items are missing from your kit or opened before use, please contact
local customer service or place of purchase for assistance.
6
Batteries
Protective Wallet
1
4
5
3
2
Monitor
Owner’s Manual
Pressure Cuff (arm type)
Quick Start User Guide /
Warranty Card
1 432
5 6

8
Monitor Overview
Front
Back
Right Side Left Side
Pressure Cuff
Display Screen
Repeat Button
(for FORA P20v only)
Press to repeat the voice
instructions.
Repeat/Pairing Button
(for FORA P20b only)
Press to repeat the voice
instructions/pair with
personal device.
S Button
M Button
On/Off Button
Down Button
1
2
3
4
5
9
10
7
8
12
13
14
15
16
11
6
18
9
10
7
6
5
2
34
14
15
16
Up Button
Data Port
(for FORA P20v only)
Earphone Jack
DC Adapter Port
Air Plug
Air Tube
Pressure Cuff
Air Jack
BT Indication Light
Battery Compartment
11
12
13

9
Screen Display
Date and Time
Volume Symbol
Systolic Pressure Symbol
Systolic Pressure Value
Unit of Measurement
Battery Symbol
Diastolic Pressure Symbol
Diastolic Pressure Value
Memory Mode Symbol
Three Time Average
Stethoscope Symbol
Pulse Rate
User Number
Pulse Rate Symbol
1
6
9
4
7
5
8
3
2
10
13
14
12
11
1
8
4
2
10
12
11
13 14
9
7
6
5
5
3

10
Speaking Function
FORA P20 “speaks”aloud with step-by-step instructions to guide you
through the process of using the meter. The following table tells you
when and what the monitor “speaks”.
WHEN does the monitor
say?
WHAT does the monitor say?
Setting up the monitor
Setting the year You are now in setting mode.
The year is (number).
Setting the month The month is (month).
Setting the date The date is the (number)th.
Setting the hour format The time is (12/24) hour mode.
Setting the hour The hour is (number) PM/AM.
Setting the minutes The minutes are (number).
Setting the blood pressure
unit
Blood pressure unit is
(millimeters of mercury / kilopascals).
Setting the voice volume Voice volume is (number) / Voice is
turned off.
Deleting the memory
1. Delete memory record function.
Press memory key to clear all records.
2. Are you sure you want to clear all
records? Press memory key again to
clear all records.
3. All memory records have been
deleted.

11
Selecting language Thank you for using FORA TeleHealth
products.
At the end of monitor
setting
Today's date is (day) (month) (date)th,
(year). The time is (hour minute) AM/
PM. Blood pressure unit is
(millimeters of mercury / kilopascals).
Voice volume is (number). Have a nice
day.
Using the monitor
When turning on the
monitor
Thank you for using FORA TeleHealth
products. The user’s number is (num-
ber). Please select user’s number.
After selecting the user
number.
The user’s number is (number).
Please relax during measurement.
When the test is
completed.
(result appears on display)
Your systolic blood pressure is
(number) (millimeters of mercury/
kilopascals). Your diastolic blood
pressure is (number) (millimeters of
mercury/ kilopascals). Your heart rate
is (number) beats per minute.

12
Recall the Stored Test
Results
1. Thank you for using FORA Tele-
Health products. Today’s date is (day)
(month) (date)th, (year). The time is
(hour minute) AM/PM.
You are now
in memory mode.
The user’s number
is (number).
Please select user’s
number.
2. The user’s number is (number).
3. Memory record for (month) (date)
th, (year), (hour minute) AM/PM. Your
systolic blood pressure was (number)
millimeters of mercury/kilopascals.
Your diastolic blood pressure was
(number) millimeters of mercury/kilo-
pascals. Your heart rate was (number)
beats per minute.
If no results stored in
memory No memory record available.
When the monitor is turned
off Have a nice day.
When entering the trans-
mission mode. Connecting to your computer.
NOTE
If you prefer to listen to the voice messages by earphone, plug a pair of ear-
phones into the earphone jack on the side of your meter.

13
Before using your monitor for the first time, check and update these
settings. Make sure you complete the steps below and save the
desired settings.
► Entering the setting mode
Start with the monitor off. Press Suntil
the monitor turns on.
Setting the date.
With the year flashing, press to
select the correct year. Press Sto set.
With the month flashing, press to
select the correct month. Press Sto set.
SETTING THE MONITOR
Step 1

14
With the day flashing, press to
select the correct day. Press Sto set.
Set the time format.
Press to select the desired
time format --- 12h or 24h. Press
Sto set.
Set the time
With the hour flashing, press to
select the correct hour. Press Sto
set.
With the minute flashing, press
to
select the correct minute appears. Press
S
to set.
Step 2
Step 3

15
Set the unit of measurement.
Press to select mmHg or Kpa. Press Sto set.
Setting the speaking volume.
There are seven (7) speaking volume options you can choose from.
Press to select the desired speaking volume. Press Sto set.
Volume 0 indicates that the speaking function is turned off, and will
not display “”. Volume 1 to 7 indicates speaking volume from low to
high, and “”will be displayed during testing.
Step 4
Step 5

16
Delete the memory.
While “dEL”and a blinking “”symbol appear on the display, if you do
not wish to delete the saved results, press
S
to skip this step.
If you wish to delete ALL the results, press
twice. “”and “”” are
displayed on the monitor, which indicates that all results have been deleted.
Choosing a language.
Press to select L1/L2.The default language for the monitor is
L1, which is English. Press S.
Then the monitor will turn off automatically or you can press to
turn off the monitor. The monitor repeats all your settings before
shutdown.
Congratulations! You have completed all settings!
NOTE
• These parameters can ONLY be changed in the setting mode.
• If the monitor is idle for 3 minutes during the setting mode, it will turn off
automatically.
Step 6
Step 7

17
TESTING YOUR BLOOD PRESSURE
This monitor provides you three different ways to measure your blood
pressure. Select from the operations below:
• Single measurement
Perform an individual blood pressure measurement.
• Averaging measurement
Automatically perform three (3) consecutive blood pressure measure-
ments and display the average result at the end.
• Auscultatory measurement
Only trained health-care professionals may use this mode to measure
blood pressure manually with a stethoscope by listening to the Korot-
koff sound.
• Avoid caffeine, tea, alcohol and tobacco for at least 30 minutes
before measurement.
• Wait for 30 minutes after exercising or bathing before measurement.
• Sit or lie down for at least 10 minutes before measurement.
• Do not measure when feeling anxious or tense.
• Take a 5-10 minute break between measurements. This break can
be longer if necessary, depending on your physical conditions.
• Keep the records for your doctor as reference.
• Blood pressure varies between each arm. Always measure your
blood pressure on the same arm.
Before Measurement

18
► Fitting the Cuff Correctly
Connect the air plug of the tubing to the air
jack of the monitor.
Assemble the cuff as shown on the
right. The smooth surface should be
inside the cuff loop and the metal
D-ring should not touch your skin.
Stretch your left (right) arm in front of you
with your palm facing up. Slide and place
the cuff onto your arm with the air tube
and artery mark region (in red) toward
the lower arm.
Leave a little free space between the arm and the cuff, you should be
able to fit 2 fingers between them. Clothing must not restrict the arm.
Remove all clothing covering or constricting the measurement arm.
Wrap and tighten the cuff above your elbow. The red line on the edge
of the cuff should be approximately 0.8 to 1.2 inches (2 to 3 cm)
above your elbow. Align the tube over the main arteries on the inside.
2~3cm
(0.8”~1.2”)
Sewn Hook Material
INDEX
RED LINESHOULD BE AT THE INSID
INDEX MUST
Pile Side Material
Step 1
Step 2
Step 3
Step 4

19
► Proper Measurement Position
Sit down for at least 10 minutes before measuring.
Place your elbow on a flat surface. Relax your hand with the palm
facing up.
Make sure the cuff is about the same height
as the location of your heart.
Press . Remain still and do not talk or move
during the measurement.
Measurement is in progress.
After the monitor is turned on, the cuff will begin to inflate automatically.
Press the hook material firmly against
the pile material. The top and bottom
edges of the cuff should be tightened
evenly around your upper arm.
►The range index of cuff should
fall into this range.
WARNING
If the cuff is relatively lower/higher than the heart, the obtained blood
pressure value could be higher/lower than the actual value. A 15 cm
difference in height may result in an error around 10 mmHg.
Step 1
Step 2
Step 3
Step 4
Step 5
INDEX
RED LINESHOULD BE AT THE INSID
INDEX MUST

20
NOTE
• If you press during measurement, the monitor will be turned off.
• If the pulse rate symbol is shown as “”instead of “”, this
indicates that the monitor has detected an irregular heart beat.
Always apply the pressure cuff before turning on the monitor.
Taking Measurements
The heart symbol “ ” will flash when a pulse is detected during the inflation.
After the measurement, the monitor displays the systolic pressure,
diastolic pressure and pulse rate.
Press to switch off. Or it will switch off automatically after left idle
for 3 minutes.
Press . All the LCD symbols will appear. Press to select user
“”(numbers from 1 to 4) whose test reading will be stored in
memory. Then the cuff will begin to inflate automatically.
Step 1
Step 2
Step 3
Step 4
► Taking a Single Measurement
Other manuals for P20
1
Table of contents
Languages:
Other FOR-A Blood Pressure Monitor manuals
