Omron R3 Intellisense User manual

EN
FR
DE
IT
ES
NL
• Instruction Manual
• Mode d’emploi
• Gebrauchsanweisung
• Manuale di istruzioni
• Manual de instrucciones
• Gebruiksaanwijzing
•
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
RU
Wrist Blood Pressure Monitor
Model R3 Intellisense
IM-HEM-6021-E-01-06/05
HEM6021-E.book Page 1 Friday, July 22, 2005 11:08 AM

2
Contents
Introduction ..................................................... 3
Important Safety Information ......................... 4
1. Overview ..................................................... 5
2. Preparation ................................................. 7
2.1 Installing/Replacing the Batteries ............ 7
2.2 Setting the Date and Time ...................... 9
3. Using the Unit ........................................... 11
3.1 Applying the Wrist Cuff .......................... 11
3.2 Correct Posture ..................................... 13
3.3 Taking a Reading .................................. 14
3.4 Using the Memory Function .................. 16
4. Quick Reference Guide ............................ 19
5. Handling Errors and Problems ............... 20
5.1 Error Messages ..................................... 20
5.2 Troubleshooting .................................... 21
6. Maintenance and Storage ........................ 23
7. Technical Data .......................................... 25
8. Some Useful Information about Blood
Pressure .................................................... 27
HEM6021-E.book Page 2 Friday, July 22, 2005 11:08 AM

3
ENEN
Introduction
Thank you for purchasing the OMRON R3 Intellisense Wrist
Blood Pressure Monitor.
This remarkable, compact and easy to use instrument is ideal for
people who frequently monitor their own blood pressure. The
small, pre-formed wrist cuff is very convenient and easy to apply.
With a push of a button the OMRON Wrist Blood Pressure
Monitor measures your blood pressure and pulse and displays
the reading on a clear digital panel. Perfect for quick, easy
readings at home, at work, and while travelling. It also stores up
to 42 sets of measurements in memory and displays an average
reading based on the three most recent measurements taken
within 10 minutes of the last reading. (If there are only two
readings in memory for that period, the average will be based on
two readings. If there is one reading in memory for that period,
the average will be based on one reading.)
The OMRON Wrist Blood Pressure Monitor uses the
oscillometric method of blood pressure measurement. This
means the unit detects the pulse wave vibrations in the artery of
your wrist and converts the oscillations into a digital reading.
Clinical research has proven a direct relationship between blood
pressure in the wrist and blood pressure in the arm. Changes in
wrist blood pressure reflect changes in arm blood pressure
because the arteries in the wrist and the arm are connected.
Frequently measuring the blood pressure in your wrist will
provide you and your doctor with an accurate indication of
changes in your true blood pressure.
Please read this instruction manual thoroughly before
using the unit. For specific information about your own
blood pressure, CONSULT YOUR DOCTOR.
HEM6021-E.book Page 3 Friday, July 22, 2005 11:08 AM

4
Important Safety Information
Consult your doctor during pregnancy, arrhythmia and
arteriosclerosis.
You should never change the dosage of medication prescribed
by your doctor.
People with poor peripheral circulation may find that results for
measurements taken at the wrist vary from those taken on the
upper arm.
Use the OMRON R3 Intellisense only for yourself.
Caution:
• Self-diagnosis of measured results and treatment are
dangerous. Please follow the instructions of your doctor.
• Do not leave the unit unattended with infants or persons who
cannot express their consent.
• Do not use the unit for any purpose other than measuring
blood pressure.
• Do not use a cellular phone, or other devices that emit
electromagnetic fields, near the unit. This may result in
incorrect operation of the unit.
• Do not operate unit in a moving vehicle (car, airplane).
• Do not disassemble the unit or wrist cuff.
• Battery liquid may leak and damage the main unit. Please
observe the following points.
- Do not insert the batteries with their polarities incorrectly aligned.
- When you are not going to use the unit for a long period of time
(approximately three months or more), take out the batteries.
- Replace old batteries with new ones immediately.
- Do not use batteries of a different type together.
- Do not use new and used batteries together.
• Do not take measurements when the cuff is not wrapped
around your wrist.
• Do not expose the unit to strong shocks or vibrations. Do not
drop the unit.
Save these instructions for future reference.
HEM6021-E.book Page 4 Friday, July 22, 2005 11:08 AM

5
ENEN
1. Overview
Main Unit
A. Display
B. Battery compartment
cover
C. Wrist cuff
D. MEM (Memory) button
E. O/I START button
F. SET button
A
B
C
D
E
F
HEM6021-E.book Page 5 Friday, July 22, 2005 11:08 AM

6
1.Overview
Display
Package contents
G. Systolic blood pressure
H. Diastolic blood pressure
I. Average value symbol
(Displayed when viewing
value for the last three
measurements.)
J. Memory value symbol
(Displayed when viewing
values stored in memory)
K. Battery low symbol
L. Heartbeat symbol
(Flashes during
measurement)
M. Pulse
N. Deflation symbol
O. Date/Time
P. Two “AAA” alkaline (LR03)
batteries Q. Storage case
• Blood pressure pass
• Blood Pressure Monitor unit • Instruction manual • Guarantee card
G
L
N
O
M
H
I
K
J
P
Q
HEM6021-E.book Page 6 Friday, July 22, 2005 11:08 AM

7
ENEN
2. Preparation
2.1 Installing/Replacing the Batteries
1. Remove the battery compartment cover by pulling it off in
the direction of the arrow.
1) Grasp both ends of the
battery cover.
2) Pull the cover off the
main unit.
2. Insert two identical 1.5V “AAA” alkaline (LR03) batteries in
the battery compartment.
Make sure their polarity (+/-) is aligned with the polarity
(+/-) as indicated in the battery compartment.
1
12
HEM6021-E.book Page 7 Friday, July 22, 2005 11:08 AM

8
2.Preparation
3. Put the battery cover back in place.
Note: Be sure to set the date and time after installing or
replacing the batteries. Refer to “2.2 Setting the
Date and Time”.
The measurement values continue to be stored in
memory even after the batteries are replaced.
Battery Life & Replacement
If the battery low symbol ( ) appears on the display,
replace both batteries at the same time.
- When the battery low symbol ( ) starts to blink, you will
still be able to use the unit for a short while. You should
replace the batteries with new ones ahead of time.
- When the symbol ( ) remains lit, the batteries were
exhausted. You should replace the batteries with new
ones at once.
• Turn the unit off before replacing the batteries.
• Remove the batteries if the unit will not be used for three
months or more.
• If the batteries are removed, the Date/Time setting will
need to be reset. See “2.2 Setting the Date and Time” for
details.
• Dispose of batteries according to applicable local
regulations.
• Two new identical 1.5V “AAA” alkaline batteries will last
for approximately 300 measurements, when used to take
two measurements a day.
• Since the supplied batteries are for monitoring use only,
they may have a shorter life and not last for 300
measurements.
HEM6021-E.book Page 8 Friday, July 22, 2005 11:08 AM

9
2.Preparation
EN
2.2 Setting the Date and Time
Your blood pressure monitor automatically stores up to 42
measurement values in its memory and calculates an average
value based on the three most recent measurements taken
within 10 minutes of the last reading. (If there are only two
readings in memory for that period, the average will be based on
two readings. If there is one reading in memory for that period,
the average will be based on one reading.) To make use of the
memory and average value function:
• Set the unit to the correct date and time before taking a
measurement for the first time.
• If the batteries have been removed, the date and time setting
will need to be reset.
• When the batteries are installed and the unit is turned on for
the first time, the year digits (2005) will flash on the display.
• The range for the year setting is 2005 to 2030. If the year
reaches 2030, it will return to 2005.
1. To set or reset the date and time, press the SET button
until the setting you want to adjust appears on the display.
2. Press the MEM button to
advance the digits one at a
time.
Note: If you hold down the
MEM button, the digits
will advance rapidly.
3. Press the SET button to confirm the setting when the
desired number appears on the display.
The year setting is set and the month digits will flash.
2
3
HEM6021-E.book Page 9 Friday, July 22, 2005 11:08 AM

10
2.Preparation
4. Repeat steps 2 and 3 to set the month and day.
5. Repeat steps 2 and 3 to set the hour and minutes for the
time.
After all settings are completed the display may still be
flashing. To confirm settings and shut off the unit press O/I
START button.
Note:
The unit will automatically turn itself off after you press the
SET button to confirm the minute setting when the
batteries are installed for the first time.
HEM6021-E.book Page 10 Friday, July 22, 2005 11:08 AM
