for Living L-GG032PST-C User manual

Product No. 085-1244-2
Model No. L-GG032PST-C
IMPORTANT: Please read and understand this manual before proceeding with assembly.Before
beginning assembly of product, make sure all parts are present . Compare parts with package
contents list.
Assembly Instructions

When it comes to products for your home,
it’s essential they stand up to the realities of
everyday family life. Designed with your family
in mind, forLIVING™ products combine timeless
style and family-friendly features. Now you can
focus on what’s important – creating lasting
memories with your family.
Imported for Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8

3
Table of ContentsImportant Safety Instructions
Table of Contents 3
Important Safety Instructions 3
Part List 4-5
5
Cleaning and Maintenance
Technical Data
Warranty
13
13
Warning!
14
Assembly instructions
Assembly preparation
6-12
To reduce the risk of serious injury, read the followingsafety instructions before
assembling and using the gazebo.
NOTICE:
•Read andfollow the instructions in this manual to ensure correct assembly of this product.
• Keep children and pets away from assembly area unless they are supervised.
• Keep assembly area at least6' feet from any obstruction such as a fence, garage, house,overhanging
branches, laundry line, or electrical wires.
• Some parts may have sharp edges. When assembling and usingthis product, basic safety precautions
should always be followed to reduce the risk of personal injury and damage tothe product.
• Assemble on level ground.
• Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
• This unit is heavy. Do not assemble this item alone.
Step 1
Step 3
IMPORTANT: KEEP FOR FUTURE REFERENCE,AND READ CAREFULLY.
Step 2

4Product No. 085-1244-2 •Model No. L-GG032PST-C
Part List
A I 3
B J
C K1
D1 K2
D2 L
E M1
F1 M2
F2 M3
F3 M4
G N
H1 P
H2 Q
H3 AA
I 1 BB
I 2 Z
Roof vent - 2
Base - 4
Base cover - 4
Support bar 1 - 2
Support bar 2 - 2
Top bar - 1
Top beam 1 - 2
Top beam 2 - 2
Top beam 3 - 4
Hook - 1
Roof cladding (2) - 2
Roof cladding (1) - 2
Roof cladding (3) - 2
Roof cladding (1) - 2
Roof cladding (2) - 2
Roof cladding (3) - 2
Roof cap - 1
Post (1) - 2
Post (2) - 2
Slanting support - 4
Countertop - 2
Ceramic tile (pre-assembled) - 14
(pre-assembled) - 24Press panel 1
(pre-assembled) - 8
Press panel 2
Frame - 2
Screen - 2
Press panel - 6
M6X20 bolt - 80PCS
M6 flat washer - 138PCS
M6 Wrench - 2PCS

5
Caution!
•Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
•Keep children away during assembly.
This product contains small parts which can be swallowed by children.
•Keep fingers away from the places where they can be pinched or trapped.
•Do not attempt to assemble the gazebo if any parts are missing.
Place all parts from the box in a cleared area and position them on the floor in front of
you. Remove all packing materials and place them back into the box. Do not dispose
of the packing materials until assembly is complete. Read each step carefully before
beginning any assembly and make sure you understand each step.
You will need the following for assembly:
tsiLstraPnoitaraperPylbmessA
M6X15 bolt - 48 PCS
M6X40 bolt - 2 PCS
M6X35bolt - 8 PCS
Φ8*180 stake - 16 PCS
M4*10 screw (pre-assembled) - 32 PCS
CC
DD
EE
I I
JJ

6
Product No. 085-1244-2 •Model No. L-GG032PST-C
Assembly Instructions
Step 1
Fig.3
Fig.2
Fig.1
Fig.4
Fig.6
Fig.5
A
D1
D2
A
D2
D1
F1
F2
F3
E
F3
F3 F3
Fig.1 - requires D1(D2), A, F2,AA,BB
Insert support bars ( D1 ) and ( D2 ) into roof vent ( A ) ,
then secure top beam 2 ( F2 ) by bolt ( AA ) and flatwasher
( BB ).
Fig.2 - requires E, G
Attach hook ( G ) to top bar ( E ).
A
BB AA
D1
E
G
D2 F2
AA
AA
BB
BB

7
Assembly Instructions
F3, A, AA, BB
Fig.5 - requires AA, BB, D1 ( D2) , F3
Fig.3 - requires
Fig.4 - requires
E,A,AA,BB
Attach top bar ( E ) to roof vent ( A ) by bolt ( AA )
and washer ( BB ).
Attach top beam 3 ( F3 ) to roof vent ( A ) by
bolt ( AA ) and washer (BB) .
Attach top beam 3 ( F3 ) to support bars ( D1 ) and
( D2 ) by bolt ( AA ) and washer ( BB ) .
F2
AA
AA E
A
BB
BB
A
AA
BB
D2 F3
D1 D2
AA
BB
F3

8
Assembly Instructions
Product No. 085-1244-2 •Model No. L-GG032PST-C
AA
AA F1
Step.2
Fig.9
Fig.8
Fig.7
Fig.7 - requires H1, H2,H3,Q,CC,BB
Fig.6 - requires AA,BB,D1&D2,F1
Secure roof cladding ( H1/ H 2/ H 3 )
with press panel b y bolt ( Q ) ( CC )
Attach top beam 1 ( F1 ) to support bars ( D1 ) and ( D2 )
by bolt ( AA ) and washer ( BB ).
and washer ( BB ) .
D1D2
BB
BB
A
I 1
I 2
I 3
I 1
I 2
I 3
H1
H2
H3
H1
H2
H3
D1
H3
O
Q
H2
H1

9
Assembly Instructions
I1,I2,I3,Q,CC,BB
BB, DD, J
Cover roof cladding ( I1/ I2/ I3 ) , then
secure them withpress panel ( Q ) by
bolt ( CC ) a ndwasher ( BB ).
Secure roof cap ( J ) by bolt ( DD ) and washer ( BB ).
Fig.8 - requires
Fig.9 - requires
J
I1
I2 I3
Q

10
Assembly Instructions
Product No. 085-1244-2 •Model No. L-GG032PST-C
Step 3
Fig.10 - requires B, C,K1&K2,BB,CC
Attach base cover ( C ) to post, then attach base ( B )
to posts ( K1 ) and ( K2 ) by bolt ( CC ) and washer ( BB )
Fig.11
Fig.15 Fig.17
Fig.14
Fig.16
Fig.10
Fig.12
Fig.13
Fig.11 - requires AA,BB,K1&K2
Raiseupthe large roof, then insert the posts into the roof
and secure them by bolt
( AA ) and washer ( BB ) .
C
C
C
C
L
N
L
P
M1
K1
K1
P
M1
K2 K2
K1 K2
C
BCC
CC
BB BB
AA
AA
BB
BB
K1 K2

11
Assembly Instructions
Fig.12 - requires N , AA , BB, K1&K2
Secure frame ( N ) to the posts ( K1 ) and ( K2 ) by bolt
( AA ) andwasher ( BB )
Fig.13 - requires L, K1 & K2, D1 & D2, AA, BB
Attach one end of slanting support ( L ) to posts
( K1 ) and ( K2 ) , and the otherend to support bars
( D1 ) and ( D2 )
by bolt ( AA ) and washer ( BB )
Fig.14 - requires
Fig.15 - requires
P,K1 & K2, EE, BB
M1, K1 & K2, P, AA,BB
Attach screen ( P ) to posts ( K1 ) and ( K2 ) by bolt ( EE ) and
Put countertop ( M1 ) on screen ( P ) , then secure
countertop ( M1 ) to posts ( K1 ) and ( K2 ) ,by bolt ( AA )
and flatwasher ( BB ) .
washer ( BB ) .
AABB
BB
K1 K2
AA
K1
BB
EE
K1 K2
P
EE
BB
BB AA
K1 K2
M1
AA
AA
D1 D2
BB
BB
K2

12
Assembly Instructions
Product No. 085-1244-2 •Model No. L-GG032PST-C
Fig.16 - requires
Pre-assembly fig - requires
Pre-assembly fig:
II
Attach the gazebo securely to the ground. If using
on soil or grass, the ground stakes ( II ) should be used.
Place ceramic tiles ( M2 ) into the empty frame of countertop
( M1 )
, thensecure them with screw ( JJ ) andpress panels ( M3 ) and ( M4 ).
M1,M2,M3,M4,JJ
I I I I
I I
M1
M4 M4
M3
M3 M2 M2
JJ
JJ JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
JJ
C

13
Technical Data Care and Maintenance
IMPORTANT: Please take down the gazebo during strong winds. The
Care and Maintenance
manufacturer or retailer is not liable for any loss of the product or other
items due to the failure to take down the gazebo during strong winds. Please
sweep the snow / ice when in extreme weather.
Steel components of garden accessories and furniture are treated with
rust-inhibiting paint to protect them from rust. However, due to the nature of
steel,surface oxidation (rusting) will occur if this protective coating is scratched.
This is normal. To minimize this condition, it is recommended that care be
takenwhen assembling and handling the product to prevent the paint from
beingscratched. Surface rust can be removed easily using a very light
application of cooking oil. If surface oxidation (rusting) occurs and no
measures are taken to correct it, the oxidation may drop onto the deck or patio,
which may cause damaging stains that will be difficult to remove.
Dimensions (L x W x H) 244 x 152.5 x 250 cm
96 x 60 x 98 1/2"
74 kgthgiewtcudorP
163 lb

Warrant
y
14
This For Living™product carries a one (1) year warranty against defects in workmanship and materials.
Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period,
when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear
or breakage due to misuse and/or abuse.
Product No. 085-1244-2 •Model No. L-GG032PST-C
Warranty
Made in China
Imported by
Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
