Forest garden APEX PREMIUM User manual

FIXING PACK CONTENTS :
PREMIUM 4X6 SINGLE DOOR APEX SHED - ASSEMBLY INSTRUCTIONS
DRILL
POZI DRIVE SCREWDRIVER
SHARP KNIFE TO
CUT ROOF FELT
SPIRIT LEVEL
TAPE MEASURE
HAMMER
M6x30mm SCREW
F PPOLGS
FELT x 1
X 14
1
7 PER HINGE
A) FASTEN EACH OF THE TWO HINGES TO THE LEFT HAND SIDE OF PTGVDR1672 (DOOR) USING 30mm SCREWS. SCREWS MUST SECURE INTO THE
TWO HORIZONTAL BRACES ON THE BACK OF PTGVDR1672.
B) LAY ABQ46DEV2 (DOOR END) FACE UP ON GROUND. POSITION PTGVDR1672 (DOOR) ON ABQ46DEV2 (DOOR END) OF SHED ENSURING THAT
THE PTGVDR1672 (DOOR) IS SQUARE WITH EQUAL GAPS TO LEFT AND RIGHT AND SECURE EACH HINGE TO ABQ46DEV2 (DOOR END) WITH 30mm
SCREWS.
30mm NAIL
FELT NAIL
PANEL PIN T-HINGE x 2
M8x50mm SCREW
SHOULD YOU REQUIRE ANY ADDITIONAL GUIDANCE WITH THE ASSEMBLY OF YOUR SHED PLEASE CONTACT OUR
TECHNICAL HELP LINE ON 0844 248 9853.
PLEASE NOTE: ALL SCREWS AND NAILS
SHOWN BELOW AND IN INSTRUCTIONS
ARE TO SCALE TO ASSIST IN
IDENTIFICATION OF REQUIRED FIXINGS.
REQUIRED TOOLS : (NOT SUPPLIED)
Thank you for choosing this garden building manufactured by the UK's largest manufacturer of timber garden products. In order to gain the most benefit from it, please note the following:
- Exercise particular care and follow instructions whilst cutting the roofing felt. If it is cut incorrectly, additional roofing felt can be purchased from most good DIY retailers or garden centres.
- Most buildings are pre-treated with a factory base coat for protection during storage and transit. We recommend that you treat your new building as soon as possible after assembly, using a wood
preservative treatment. Apply in accordance with the manufacturers instructions.
- If there are any technical queries with the product, please contact our customer help line on 0844 248 9853 between the hours of 8.30 am and 5.00 pm Monday to Friday.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance and this may affect the remedies you are entitled to. If the
product is not constructed in accordance with the instructions, or is altered in anyway (eg painted), the manufacturer cannot be held liable for any resulting damage.
- Timber is a natural material. It will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- This product must be placed on a solid base.
- The roof of this product is not a load bearing structure.
LOOSE ITEMS (ABQ46V2L)
ABQ46PEV2
(PLAIN END)
ABQ46WSV2
(WINDOW SIDE)
ABQ46DEV2
(DOOR END)
6X4SHEDBRDFL
(BOARDED FLOOR)
18206958
(OSB ROOF) Qty 2
PTGVDR1672
(DOOR)
ABQ46PSV2
(PLAIN SIDE)
PARTS INCLUDED LIST
15120585DTR
(GLAZING STRIP 15x12x585DTREAT QTY 3)
70080730A1DTR
(BARGE BOARD 70x8x730 A1 DTREAT QTY 4)
45151660DTR
(CORNER STRIP QTY 4)
85009
(PVC TRIM QTY 1)
45281784
(BATTEN 45x28x1784 QTY 1)
28281820
(BATTEN 28x28x1820 QTY 2)
Pw610610
(PVC WINDOW QTY 1)
ABQ46DEV2
IMPORTANT :
ASSEMBLY OF THIS
SHED REQUIRES TWO
PEOPLE
ISSUE 0113
24
100
12
20
85008
FPPOLGS
RETAIN FOR FUTURE REFERENCE :READ CAREFULLY
70 PAD BOLT x 1
PAD BOLT RECEIVER
x 1
Forest Garden Ltd, Units 291 & 296 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
FPPOLGS

PLACE ONE 18206958 ( OSB ROOF) ON TOP OF A 28281820 (BATTEN).
ENSURING THAT EDGES OF 28281820 (BATTEN) AND 18206958( OSB
ROOF) ARE FLUSH, SECURE 18206958 (OSB) TO 28281820 (BATTEN)
WITH 30mm NAILS PLACED AT 300mm INTERVALS. REPEAT
PROCEDURE FOR SECOND ROOF SECTION.
5
3
6X4SHEDBRDFL
ABQ46PEV2
X 3
2
POSITION ABQ46PEV2 (PLAIN END) OF SHED ONTO FLOOR SO THAT THE LEFT
AND RIGHT HAND EDGES OF THE PANEL ARE FLUSH WITH THE EDGES OF THE
FLOOR. PLACE THE ABQ46PSV2 (PLAIN SIDE) ONTO THE FLOOR AND PLACE UP
AGAINST ABQ46PEV2V (PLAIN END) PANEL. SECURE ABQ46PSV2 (PLAIN SIDE)
TO ABQ46PEV2 ( PLAIN END ) USING 3 x 50mm SCREWS PLACED AS SHOWN TO
LEFT.
DO NOT SECURE THE PANELS TO THE FLOOR AT THIS POINT.
SIDE PANEL
BACK PANEL
USING PROCEDURE OUTLINED IN STEP 3, POSITION AND SECURE THE
REMAINING ABQ46WSV2(WINDOW SIDE) AND ABQ46DEV2 ( DOOR
34
X 10
X 9
ABQ46DEV2
ABQ46WSV2
ONCE ALL FOUR OF THE PANELS ARE IN PLACE AND FASTENED TOGETHER,
SECURE THEM TO THE FLOOR USING 50mm SCREWS. EACH OF THE
ABQ46PSV2 (PLAIN SIDE)AND ABQ46WSV2 (WINDOW SIDE) PANELS
REQUIRE 3 SCREWS AND ABQ46PEV2 (PLAIN END) AND ABQ46DEV2 (FRONT
END) PANELS REQUIRE 2.
IT IS VITAL THAT ALL SCREWS ARE POSITIONED SO THAT THEY LOCATE
INTO FLOOR BEARERS.
18206958
28281820
ISSUE 0113
ABQ46PSV2
6X4SHEDBRDFL

45281784
50mm SCREW
6
PLACE 45281784 (BEARER) INTO OPENING
AT THE TOP OF EACH END. PRE-DRILL
A PILOT HOLE IN POSITION SHOWN
ABOVE AND SECURE 45281784 (BEARER)
IN PLACE AT BOTH ENDS WITH 1 x 50mm
SCREW.
PLACED AT 300mm INTERVALS
7
PLACE ONE OF THE ASSEMBLED 18206958
(ROOF) SECTIONS ON TOP OF THE SHED.
WHEN IN PLACE, THE 18206958 (ROOF)
SECTION SHOULD OVERHANG BY EQUAL
AMOUNTS AT EITHER END OF THE SHED
AND SHOULD BE POSITIONED SO THAT
WHEN BOTH 18206958 (ROOF) SECTIONS ARE
IN PLACE THEY MEET AT A POINT. SECURE
IN PLACE WITH 30mm NAILS PLACED AT
300mm INTERVALS INTO THE FRAMEWORK
OF THE SIDES OF THE SHED.
8
FELT NAIL PLACED AT
150mm INTERVALS
CUT THE FELT INTO TWO EQUAL LENGTHS.
PLACE THE FIRST PIECE OF FELT ON THE ROOF SO
THAT IT OVERLAPS EQUAL AMOUNTS AT EITHER
END OF THE SHED, AND BY APPROXIMATELY
40mm AT THE EAVE SIDE OF THE ROOF. SECURE
FELT TO ROOF WITH FELT NAILS PLACED AT
150mm INTERVALS. CUT AND FOLD
FELT AT CORNERS AND SECURE FOLD WITH A
FELT NAIL
REPEAT PROCEDURE FOR OPPOSITE SIDE OF
ROOF.
ISSUE 0113

X 3 PER CORNER STRIP X 3 PER BARGE BOARD
910
SECURE A 45151660DTR (CORNER
STRIP) TO EACH OF THE FOUR
CORNERS WITH 3 x 30mm NAILS PER
STRIP. NAILS SHOULD BE PLACED
APPROXIMATELY AS SHOWN TO
LEFT. THE BOTTOM OF
45151660DTR (CORNER STRIP)
SHOULD BE IN LINE WITH BOTTOM
OF CLADDING ON SIDE PANELS.
POSITION 70080730A1DTR (BARGE BOARDS) ON BOTH ENDS OF SHED SO
THAT THE TOP EDGE OF THE 70080730A1DTR (BARGE BOARD) IS IN LINE
WITH THE TOP EDGE OF THE ROOF AND THE POINT OF 70080730A1DTR
(BARGE BOARD) MEETS UP WITH THE HIGHEST POINT OF THE ROOF.
SECURE EACH 70080730A1DTR (BARGE BOARD) IN PLACE WITH 3 x 30mm
NAILS PLACED AS SHOWN ABOVE. TRIM OFF ANY EXCESS FELT THAT
IS SHOWING BELOW THE BARGE BOARDS.
45151660DTR
70080730A1DTR
12
SECURE PAD BOLT TO
OUTSIDE OF PTGVDR1672
(DOOR) USING 6x30mm
SCREWS. THE SCREWS MUST
LOCATE INTO THE SHORT
HORIZONTAL BATTEN ON
THE INSIDE OF THE
PTGVDR1672 (DOOR).
SECURE PAD BOLT RECEIVER
TO ABQ46DEV2 (DOOR END)
OF SHED USING 2x 30mm
SCREWS.
DOOR
DOOR END
PAD BOLT
RECIEVER
X 6
4 FOR PAD BOLT 2 FOR RECEIVER
11
PLACE 85009 (PLASTIC “Z” STRIP) ACROSS BOTTOM OF THE WINDOW
OPENING. THE LONG FACE OF THE Z SHOULD FACE DOWN ON THE
OUTSIDE OF THE ABQ46WSV2PTR WINDOW SIDE. SECURE IN
PLACE WITH 3 PANEL PINS. PLACE Pw610610 (WINDOW) INTO
WINDOW OPENING FROM INSIDE THE SHED. THE BOTTOM OF THE
Pw610610 (WINDOW) SHOULD SIT ON TOP OF THE 85009 (PLASTIC “Z”
STRIP). PLACE A 15120585PTR (GLAZING STRIP) ALONG THE BOTTOM
OF THE Pw610610 (WINDOW) ON THE OUTSIDE OF THE SHED AND
SECURE IN PLACE WITH 3 PANEL PINS. PLACE A 15120585PTR
(GLAZING STRIP) TO THE LEFT AND RIGHT OF THE PW610610
(WINDOW) AND SECURE EACH IN PLACE WITH 3 PANEL PINS.
.
GLAZING STRIPS 15120585PTR x 2
ON INTERIOR OF SHED
INTERIOR OF SHED
STYRENE WINDOW
GLAZING STRIP 15120585PTR x 1
ON EXTERIOR OF SHED
PLASTIC Z STRIP 85009 x 1
ON EXTERIOR OF SHED
X3 FOR PLASTIC “Z” STRIP
x3 FOR EACH GLAZING STRIP
ISSUE 0113
