Forest garden OPP64NWM User manual

FIXING PACK CODE: MSFP2
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland
4 x 50mm Screws
QTY: 41
4 x 40mm Screws
QTY: 22
4 x 45mm Screws
QTY: 19
3.5 x 30mm Screws
QTY: 123
3.5 x 25mm Screws
QTY: 43
Felt Tacks
QTY: 154
Flush Hinges
QTY: 2
Hasp & Staple
QTY: 1
Z-Brackets (45mm)
QTY: 4
SHED INSTRUCTIONS
PENT SHEDS (6x4, 7x5, 8x6, 10x6)
FIXING PACK CONTAINS:
B
Thank you for purchasing your shed from Forest Garden. No matter what size garden, a shed is the most practical
of garden structures. Simply follow these step by step instructions and our top tips and you’ll be enjoying your
shed for many years to come. If you have any questions or need advice, our friendly team is here to help.
ISSUE: 0223
Making British gardens great
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
3 x 16mm Screws QTY: 2
Forest Badge QTY: 1

BEFORE YOU START
Please read through these instructions to familiarise yourself with your shed. We recommend that you
check all the components using the lists found on the front and back pages before you start to build.
All of our sheds are constructed in the same way. They simply come with different components depending
on the type of shed you have. Don’t worry if your xing pack contains some spare items at the end of the
build (you haven’t missed a bit!) we have sent you a generic xing pack to suit the shed range.
2
REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
Tape Measure Sharp Knife PZ2 Pozidriv
Screwdriver
Drill & 2-6mm
Drill Bits
Hammer Fit For Purpose
Ladder
Spirit Level
Timber Base
Self-constructed/
Buy pre-made
Concrete
Concrete surface/
Concrete slabs
Pro Shed Base
Interlocking
eco-friendly base
Soil
A base of soil or
grass only
Broken Slabs/Gaps
Uneven slab sizes
with no cement
It is vital that you build your new shed on a solid, level base. Timber or Plastic Shed Bases are ideal, as is
solid concrete or concrete slabs.
We recommend using the following tools (not supplied):
If you have an existing base and think it is suitable for your new shed to be sited on, it is important you
check that it is level and does not deviate by any more than 15mm from edge to edge. If this is not the
case the building will twist, causing gaps to appear in the sections and the roof, doors, and windows to
misalign.
There is more information on base preparation on our website www.forestgarden.co.uk
BASE PREPARATION
TOOLS NEEDED
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
CHECK AND TIGHTEN ALL THE FIXINGS APPLIED TO THIS PRODUCT ON A REGULAR BASIS
We recommend getting everything aligned properly before screwing together and that the screw holes
are pre-drilled at this stage to avoid splitting the timber. We do not provide pre-drilled holes due to the
nature of expanding and shrinking timber, which can cause pre-drilled holes to misalign.

MOVEMENT, TWISTING & WARPING
Wood contains a natural level of moisture so decreasing humidity levels in the surrounding air may cause panels to change their
shape as the porous bres shrink. This can be exaggerated during prolonged periods of dry weather. Movement and gaps in
timber products are normal, in most cases the wood will revert to its original form once the high temperatures subside and there is
more moisture content in the air. Similarly, in the winter months, the opposite may occur with wood swelling.
EXPANSION, CONTRACTION, SPLITS & CRACKS
All timber will expand and contract according to its environment. As a result of this expansion and contraction, it is very common
to see splits and cracks developing in the wood. Splits are common during the spring and summer months as the wood begins to
dry out. The outer surface dries rst and contracts, contracting over a still expanded core of the wood. The result of this is that
splits and cracks appear along the grain of wood. These splits are not a fault and do not affect the structural integrity of a product.
MOULD & BLUE STAIN
Mould is a surface-dwelling fungus that feeds on the nutrients and debris contained in the surface cells of timber. The most
common problems associated with mould are discoloured timber and an increase in permeability of the timber. Blue stain is part
of the same family but penetrates deeper into the surface layers of the timber. It stains the timber a dark blue, whereas mould is
usually black. These do not cause the timber to rot. Keep the building well ventilated to avoid mould.
CARE & ATTENTION
To help you get the most out of our products it is useful to know a little more about the properties of timber,
what is normal and how your shed may behave as the seasons change. Wood is an extremely durable material for
construction but as a natural product when used outdoors it is susceptible to changes in the environment.
3
POSITION YOUR SHED IN THE BEST LOCATION IN YOUR GARDEN
Avoid areas where water pools and which are constantly wet. Position away from trees and cut back any overhanging foliage which can
cause moisture to be trapped against the walls and debris to collect on the roof.
1
RAISE YOUR SHED OFF THE GROUND
Ideally, any concrete base should be the same footprint as the shed to allow surface water to run off without pooling. A timber base can
also be used. Raise your shed 50mm above ground level.
2
SEAL THE BEARERS
If using a wooden base, we recommend treating it with a treatment containing wax or oil. Also coat the bearers that meet the ground to
prevent moisture rising.
3
USE AN END-GRAIN PROTECTOR
To protect the corners and panel joins, an end grain protector can be applied.
4
SEAL THE PANELS & WINDOWS
Use a exible silicone sealant around windows to prevent water ingress. This can also be used where two sections of the shed join
together. Apply internally.
5
CONSIDER ADDING GUTTERS
Adding guttering around the fascia of the shed will redirect rainwater away from the shed’s foundation.
6
KEEP VENTILATED
Good airow around the perimeter of the shed and regular ventilation inside the shed will help prevent mould and mildew.
7
CONSIDER A WATER SEALANT
You may want to consider painting your shed with a water sealant at least once a year. This will help reduce the risk of water ingress. We
would recommend using ‘Bostik Cementone Water Seal’ of which can be purchased from multiple DIY stores.
8
THINGS THAT YOU MIGHT SEE IN YOUR PRODUCT
8 TOP TIPS TO ENSURE YOUR SHED IS FULLY WATERPROOF
ADVICE ON FELT HANDLING & USAGE
Roong felt is exible at temperatures above 5°C. In cold temperatures extra care must be taken when handling and installing to prevent
cracking and damage to the felt. The felt should not be rolled, folded, or used in temperatures lower than 5° C. In cold temperatures the felt
should be stored above 10°C (indoors) for 24 hours prior to use. Felt must be lifted, not dragged, and should be stored on its end on a dry
surface.

Cut-Resistant
Gloves
Protective Glasses Protective Boots Protective Mask Working At
Height
4
Dip Treatment
Pressure Treatment
Pressure treatment is to provide protection against rot
Dip treatment is to provide protection against fungal decay
Pressure treated sheds do not need to be re-treated every year
Dip treated sheds MUST be re-treated every year
10 year guarantee
25 year guarantee
We strongly recommend that PPE (Personal Protective Equipment) is used throughout your build to ensure you are
protected from any potential health and safety risks. Do not exempt yourself from wearing PPE.
THE ROOF OF THIS BUILDING IS NOT A LOAD BEARING STRUCTURE
Check you have all your parts prior to assembly.
Timber is a natural material of which will shrink and swell because of varying moisture content.
Assembly of damaged parts may be deemed to be acceptance, and this may affect the remedies you are entitled to.
If the product is not constructed in accordance with the instructions, or is altered in anyway (e.g. painted), the
manufacturer cannot be held liable for any resulting damage.
If you are organising a third party to install your shed, it is best not to schedule this immediately on receipt of your
order, to give you time to check your delivery.
Treated timber contains biocidal products for control of wood destroying organisms.
Active Ingredients - Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated Sheds)
Propiconazole, Tebuconazole, IPBC, Permethrin, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated Sheds)
• Wear gloves when handling.
• Avoid inhalation of sawdust.
• Do not use in contact with drinking water or food.
• Do not use for animal bedding or in sh ponds.
• Dispose of treated wood responsibly.
• Treated products cannot be recycled as the wood is no longer in its original virgin state.
• Once the treatment has dried there is no risk of toxic contamination. The risk would come from the treatment
before it is added to our products.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
Please carefully unpack your shed and loose components as they may have moved during transportation.
The treatment applied to your shed is to ensure longevity and protection against fungal decay and rot.
This may leave colour variations, but these will even out as the moisture content stabilises.
Use the ‘waterproong top tips’ to increase the longevity of your shed.
See our website for more information at www.forestgarden.co.uk /guide-to-our-products/
HEALTH & SAFETY
TREATMENT INFORMATION
DISCLAIMER

PENT SHED
KEY
IDENTIFY YOUR SHED
From the oor plans below, identify your shed based on the width, depth and shed code provided.
You will need this to identify the side panel positions before assembling your shed. Use the key as a guide.
Assembly of your chosen shed will slightly differ throughout the steps based on the size of your shed. This
will be mentioned throughout the instructions for guidance.
5
D
D
E
F
FPENT
6’
4’
I
OPP64M, OPP64NWM,
SDP64M, SDP64NWM
H
GD
C
C
A
A
PENT
7’
5’
I
OPP75M, OPP75NWM,
SDP75M, SDP75NWM
G
G
H
C
C
C
C
PENT
8’
6’
J
OPP86M, OPP86NWM,
SDP86M, SDP86NWM
C
C
C
C
DD G
HB
PENT
10’
6’
J
OPP106M, SDP106M
C
C
C
C
DD G
EE
PENT
10’
6’
J
OPP106NWM, SDP106NWM
A2ft Panel (590 x 1603mm)
B2ft Panel (590 x 1945mm)
C3ft Panel (885 x 1603mm)
D3ft Panel (885 x 1717mm)
PLEASE NOTE
The sheds are made up of multiple
sections where same size panels
are interchangeable.
SINGLE DOOR
The door is exible
for all shed types
and can be hinged
onto either side.
E3ft Panel (885 x 1945mm)
(With & without windows)
F4ft Panel (1180 x 1603mm)
G4ft Panel (1180 x 1717mm)
H4ft Panel (1180 x 1945mm)
(With & without windows)
I3ft Door Panel (885 x 1945mm)
J4ft Door Panel (1180 x 1945mm)
Indicates the panel orientation during construction.
This will apply to all of the corners for your chosen shed.

EG. DOOR FRAME
EG. INSIDE CORNER
1a
1b
1c
CONSTRUCTION
1
Start at a back corner. See the section
layout on page 5 to conrm position.
Secure the corner as shown below.
Repeat the process for remaining panels and
secure panels together. Make sure that the
bottom frame of the wall panel rests on the outer
edge of the oor.
Secure the panels into place by screwing into
the oor. Screw into the door frame in the door
panel into the oor to keep secure.
Attach the Triangular Pent Section by screwing to the wall panel. Also screw from the front panel into the Triangular Pent Section to keep
it more secure as shown below. Repeat for the other Triangular Pent Section.
6
EG. INTO FLOOREG. SIDES
Layout the panels around your shed base. We recommend to start in a back
corner then work from the back panels
to the front panels for assembly.
FLOORS & SIDES PRE-DRILL
WITH 2MM BIT
FOR ALL STEPS
BELOW.
Position the oor in your desired location. The 6x4 shed will
only have one oor. For the 7x5, 8x6 and 10x6 sheds, butt the
adjoining bearers together. 7x5, 8x6 and 10x6 will have two oors.
Use the oor plans as a guide for your oor positions.
7X5, 8X6 & 10X6 SHEDS
6X4 SHED
SIDE PANEL
BACK PANEL

3
WINDOWS
2
Secure windows by screwing through the window cover strips and window into the panel frame (30mm screws). Screw into the top and
bottom of the window and into the interior sill to keep secure (25mm screws). Make sure the window is centralised for all window frames
as shown below.
WINDOW POSITIONING
7
WINDOW
SITS ONTO
INTERIOR SILL
OUTSIDE INSIDE
PRE-DRILL
WITH 2MM BIT
FOR ALL STEPS
BELOW.
OUTSIDE
COVER AND DOOR STRIPS
Secure the door weather strip
onto the side you want the hinges,
and ensure it’s ush to the oor
and against the face of the wall
panel framing.
SLAMMING STRIP(28 x 12 x 1637)COVER STRIPS(See pages 9-10
for measurement for chosen shed)
Attach the cover strips onto
the corners. Ensuring they are
ush to the bottom edge of the
panels as shown below.
Attach the cover strips onto the
adjoining panels. Ensuring it is
ush to the bottom edge of the
panels as shown below.
Attach the slamming strip onto the
opposite side you want the hinges,
onto the wall panel shown below.
DOOR WEATHER STRIP
(38 x 12 x 1710)
OUTSIDE INSIDE INSIDE
PLEASE
NOTE
Screwing the
door weather
strip onto the
wall panel
determines
the side of
your hinges.
PRE-DRILL
WITH 2MM BIT
FOR ALL STEPS
BELOW.
OUTSIDE
SIDE
PANEL
FRAME
DOOR
WEATHER
STRIP
4a
ROOF
1032.5mm
885mm
6x4 MEASUREMENTS
7x5 MEASUREMENTS )
(
715.8mm
783mm
715.8mm
942mm
931mm
931mm
8x6 MEASUREMENTS
10x6 MEASUREMENTS )
(
4
Z-BRACKET
Attach the Z-brackets with screws
onto the top face at each end of the
beam(s).
For the 6x4 and 7x5 sheds, you will have only
one beam. Screw the Z-brackets to the centre of
the front and back panels (measurements shown
below). Ensure the Z-brackets are facing the right
way as shown below.
For the 8x6 and 10x6 sheds, you will have two
beams. Use the measurements below to space them
across the front and back panels and screw as shown
below. Ensure the Z-brackets are facing the right way
as shown below.
6X4 & 7X5 SHEDS 8X6 & 10X6 SHEDS
PRE-DRILL
WITH 2MM BIT
FOR ALL STEPS
BELOW.

4b
4c
50mm
TOP TIP: Use measuring tape to measure out
equal lengths & cut with a sharp knife. Hammer the
tacks into the felt. Add the tacks at 150mm intervals.
1375mm
(6x4 Measurement)
1688mm
(7x5 Measurement)
2032mm
(8x6 & 10x6 Measurement)
Before screwing the OSB roof sheets onto the roof,
screw the roof support strips to the OSB roof
sheets. Ensure they are ush to the edges. Repeat
this for both sides. The measurements shown below
are to show the orientation of the sheets. The strip(s)
will be the same length as the 2 edges when joined
together as shown below.
8X6 & 10X6 SHEDS
6X4 & 7X5 SHEDS
For the 6x4 and 7x5 sheds, screw the
shorter roof support strips central onto
the sheets. For the 8x6 and 10x6 sheds,
screw the shorter roof support strips
into the space provided as shown below.
Repeat this for both sides and ensure
they are ush to the sheet edges.
6X4 & 7X5 SHEDS
8X6 & 10X6 SHEDS
Measure out equal lengths based on your
chosen shed and overlap it on the top, around
the edges and fold the corners; tack to keep
secure as shown below. Ensure 50mm at the
bottom and work from the bottom to the top.
8X6 & 10X6 SHEDS
6X4 & 7X5 SHEDS
Secure the fascias with screws as shown below
The fascia options differ based on your chosen
shed. The parts that are left over are an indiciation
on which steps to follow. Use pages 8-9 for
measurement guidance.
Once the roof support strips are screwed
onto the front and back of the OSB roof
sheets, push the sheets forward from the
back, ensuring the roof support strip is
in contact with the shed as shown below.
Then screw the OSB roof sheets into the
beam(s) and shed frame.
6X4 & 7X5 SHEDS
8
Place the OSB roof sheets, one at
a time onto the shed frame and
beams. Ensure where the OSB roof
sheets join, are central for each
beams.
8X6 & 10X6 SHEDS
TOP TIP: Mark onto the OSB sheet and draw a line
to ensure you drill and screw into the beam(s).
5
202mm
175mm
DOOR FIXINGS
TOP TIP: Line up the hasp &
staple. Mark the edges with a
pencil for guidance.
Fix the Hasp and Staple as shown. Ensure the screws go into the
framework behind.
FRAMEWORK
DOOR FACE
NOTCH IN
LINE WITH
DOOR FACE
DOOR
Make sure the outer
face of the notch on
the hinge is in line
with the door face.
HASP & STAPLE POSITIONING
PRE-DRILL
WITH 2MM BIT
FOR ALL STEPS
BELOW.
Attach 2 hinges onto the door frame with
the measurements provided. Please take note
of the hinge position shown below.
Place the door into the opening,
ensuring it’s level. Make sure the hinges
are up against the door weather strip face.
5mm
Allow a 5mm gap at the
top when placing door.
HINGE POSITION
DOOR

Part Code
Description Qty Part Code Description Qty Part Code Description Qty
OPPMRHA4 Right Pent Section (370x1180mm) 1OPPMRHA4 Right Pent Section (370x1180mm) 1OPPMRHA5 Right Pent Section (368x1475mm) 1
OPPMLHA4 Left Pent Section (370x1180mm) 1OPPMLHA4 Left Pent Section (370x1180mm) 1OPPMLHA5 Left Pent Section (368x1475mm) 1
OPPM885BP
Section D - 3ft Pent Back Panel (885 x 1717mm) 2OPPM885BP Section D - 3ft Pent Back Panel (885 x 1717mm) 2OPPM885BP Section D - 3ft Pent Back Panel (885 x 1717mm) 1
OPM885TPP Section E - 3ft Pent Front Panel (885 x 1945mm) 1OPM885TWP
Section E - 3ft Pent Front Window Panel
(885 x 1945mm)
1OPPM1180BP Section G - 3ft Pent Back Panel (1180 x 1717mm) 1
OPM885TDP
Section I - 3ft Door Panel (885 x 1945mm) 1OPM885TDP Section I - 3ft Door Panel (885 x 1945mm) 1OPM885TDP Section I - 3ft Door Panel (885 x 1945mm) 1
OPM1180PP Section F - 4ft Panel (1180 x 1603mm) 2OPM1180PP Section F - 4ft Panel (1180 x 1603mm) 2OPM885PP Section C - 3ft Panel (885 x 1603mm) 2
MSPDR Door (582x1692mm) 1MSPDR Door (582x1692mm) 1OPM590PP Section A - 2ft Panel (590 x 1603mm) 2
MSBFL46 Floor (1180x1826mm) 1MSBFL46 Floor (1180x1826mm) 1OPM1180TPP
Section H - 4ft Pent Front Panel (1180 x 1945mm) 1
28121637PPT
Slamming Strip (28x12x1637mm) 128121637PPT Slamming Strip (28x12x1637mm) 1MSPDR Door (582x1692mm) 1
28280973 Roof Support Strip (28x28x973mm) 228160550PT
Window Cover Strip (28x16x550mm) 3MSBFL257 Floor (737x2121mm) 2
28281934 Roof Support Strip (28x28x1934mm) 228280973 Roof Support Strip (28x28x973mm) 228121637PPT
Slamming Strip (28x12x1637mm) 1
38121710PPT
Weather Strip (38x12x1710mm) 128281934 Roof Support Strip (28x28x1934mm) 228281115 Roof Support Strip (28x28x1115mm) 6
44161695PT Cover Strip (44x16x1695mm) 338121710PPT
Weather Strip (38x12x1710mm) 138121710PPT Weather Strip (38x12x1710mm) 1
44161925PT Cover Strip (44x16x1925mm) 344161695PT Cover Strip (44x16x1695mm) 344161695PT Cover Strip (44x16x1695mm) 3
45451153PAII79 Roof Beam (45x45x1153mm) 144161925PT Cover Strip (44x16x1925mm) 344161810PT Cover Strip (44x16x1810mm) 2
59121390PPT Side Fascia (59x12x1390mm) 245451153PAII79 Roof Beam (45x45x1153mm) 144161925PT Cover Strip (44x16x1925mm) 3
59121978PPT Front Fascia (59x12x1978mm) 159121390PPT Side Fascia (59x12x1390mm) 245451441PAII81 Roof Beam (45x45x1441mm) 1
OSB13759678 OSB Roof Sheet (1375x967x8mm) 259121978PPT Front Fascia (59x12x1978mm) 159121132PPT Front Fascia (59x12x1132mm) 2
RPET885
Window (428x577mm) 259121688PPT Side Fascia (59x12x1688mm) 2
OSB13759678 OSB Roof Sheet (1375x967x8mm) 2OSB168811158 OSB Roof Sheet (1688x1115x8mm) 2
Part Code
Description Qty Part Code Description Qty Part Code Description Qty
OPPMRHA5 Right Pent Section (368x1475mm) 1OPPMRHA6 Right Pent Section (362x1770mm) 1OPPMRHA6 Right Pent Section (362x1770mm) 1
OPPMLHA5 Left Pent Section (368x1475mm) 1OPPMLHA6 Left Pent Section (362x1770mm) 1OPPMLHA6 Left Pent Section (362x1770mm) 1
OPPM885BP
Section D - 3ft Pent Back Panel (885 x 1717mm) 1OPPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 2OPPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 2
OPPM1180BP
Section G - 3ft Pent Back Panel (1180 x 1717mm) 1OPM885PP Section C - 3ft Panel (885 x 1603mm) 4OPM885PP Section C - 3ft Panel (885 x 1603mm) 4
OPM885TDP Section I - 3ft Door Panel (885 x 1945mm) 1OPM1180TPP Section H - 4ft Pent Front Panel (1180 x 1945mm) 1OPM1180TWP
Section H - 4ft Pent Front Window Panel
(1180 x 1945mm)
1
OPM885PP Section C - 3ft Panel (885 x 1603mm) 2OPM1180TDP
Section J - 4ft Door Panel (1180 x 1945mm) 1OPM1180TDP Section J - 4ft Door Panel (1180 x 1945mm) 1
OPM590PP Section A - 2ft Panel (590 x 1603mm) 2MSPDR Door (582x1692mm) 1MSPDR Door (582x1692mm) 1
OPM1180TWP
Section H - 4ft Pent Front Window Panel
(1180 x 1945mm)
1MSBFL46 Floor (1180x1826mm) 2MSBFL46 Floor (1180x1826mm) 2
MSPDR Door (582x1692mm) 128121637PPT
Slamming Strip (28x12x1637mm) 128121637PPT Slamming Strip (28x12x1637mm) 1
MSBFL257 Floor (737x2121mm) 228280988 Roof Support Strip (28x28x988mm) 428160550PT
Window Cover Strip (28x16x550mm) 3
28121637PPT
Slamming Strip (28x12x1637mm) 128281242 Roof Support Strip (28x28x1242mm) 428280988 Roof Support Strip (28x28x988mm) 4
28160550PT
Window Cover Strip (28x16x550mm) 338121710PPT Weather Strip (38x12x1710mm) 128281242 Roof Support Strip (28x28x1242mm) 4
28281115 Roof Support Strip (28x28x1115mm) 644161695PT Cover Strip (44x16x1695mm) 338121710PPT
Weather Strip (38x12x1710mm) 1
38121710PPT
Weather Strip (38x12x1710mm) 144161810PT Cover Strip (44x16x1810mm) 244161695PT Cover Strip (44x16x1695mm) 3
44161695PT Cover Strip (44x16x1695mm) 344161925PT Cover Strip (44x16x1925mm) 344161810PT Cover Strip (44x16x1810mm) 2
44161810PT Cover Strip (44x16x1810mm) 245451783PAII83 Roof Beam (45x45x1783mm) 244161925PT Cover Strip (44x16x1925mm) 3
44161925PT Cover Strip (44x16x1925mm) 359121020PPT Side Fascia (59x12x1020mm) 445451783PAII83 Roof Beam (45x45x1783mm) 2
45451441PAII81 Roof Beam (45x45x1441mm) 159121259PPT Front Fascia (59x12x1259mm) 259121020PPT Side Fascia (59x12x1020mm) 4
59121132PPT Front Fascia (59x12x1132mm) 2OSB20328288 OSB Roof Sheet (2032x828x8mm) 359121259PPT Front Fascia (59x12x1259mm) 2
59121688PPT Side Fascia (59x12x1688mm) 2RPET590
Window (575x577mm) 2
RPET590
Window (575x577mm) 2OSB20328288 OSB Roof Sheet (2032x828x8mm) 3
OSB168811158 OSB Roof Sheet (1688x1115x8mm) 2
Part Code
Description Qty Part Code Description Qty
OPPMRHA6 Right Pent Section (362x1770mm) 1OPPMRHA6 Right Pent Section (362x1770mm) 1
OPPMLHA6 Left Pent Section (362x1770mm) 1OPPMLHA6 Left Pent Section (362x1770mm) 1
OPPM885BP
Section D - 3ft Pent Back Panel (885 x 1717mm) 2OPPM885BP Section D - 3ft Pent Back Panel (885 x 1717mm) 2
OPPM1180BP
Section G - 4ft Pent Back Panel (1180 x 1717mm) 1OPPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 1
OPM885PP Section C - 3ft Panel (885 x 1603mm) 4OPM885PP Section C - 3ft Panel (885 x 1603mm) 4
OPM885TPP
Section E - 3ft Pent Front Panel (885 x 1945mm) 2OPM590TPP Section B - 2ft Pent Front Panel (590 x 1945mm) 1
OPM1180TDP Section J - 4ft Door Panel (1180 x 1945mm) 1OPM1180TWP
Section H - 4ft Pent Front Window Panel
(1180 x 1945mm)
1
MSPDR Door (582x1692mm) 1OPM1180TDP
Section J - 4ft Door Panel (1180 x 1945mm) 1
MSBFL56 Floor (1475x1826mm) 2MSPDR Door (582x1692mm) 1
28121637PPT
Slamming Strip (28x12x1637mm) 1MSBFL56 Floor (1475x1826mm) 2
28280988 Roof Support Strip (28x28x988mm) 428121637PPT
Slamming Strip (28x12x1637mm) 1
28281537 Roof Support Strip (28x28x1537mm) 428160550PT
Window Cover Strip (28x16x550mm) 3
38121710PPT
Weather Strip (38x12x1710mm) 128280988 Roof Support Strip (28x28x988mm) 4
44161695PT Cover Strip (44x16x1695mm) 428281537 Roof Support Strip (28x28x1537mm) 4
44161810PT Cover Strip (44x16x1810mm) 238121710PPT
Weather Strip (38x12x1710mm) 1
44161925PT Cover Strip (44x16x1925mm) 444161695PT Cover Strip (44x16x1695mm) 4
45451783PAII83 Roof Beam (45x45x1783mm) 244161810PT Cover Strip (44x16x1810mm) 2
59121020PPT Side Fascia (59x12x1020mm) 444161925PT Cover Strip (44x16x1925mm) 4
59121555PPT Front Fascia (59x12x1555mm) 245451783PAII83 Roof Beam (45x45x1783mm) 2
OSB203210258 OSB Roof Sheet (2032x1025x8mm) 359121020PPT Side Fascia (59x12x1020mm) 4
59121555PPT Front Fascia (59x12x1555mm) 2
RPET590
Window (575x577mm) 2
OSB203210258 OSB Roof Sheet (2032x1025x8mm) 3
Overlap Pent 8' x 6' - No Windows (OPP86NWM)
Contact our aftersales team with your product code if you are missing your felt.
Overlap Pent 10' x 6' - 2 Windows (OPP106M)
Contact our aftersales team with your product code if you are missing your felt.
Overlap Pent 10' x 6' - No Windows (OPP106NWM)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Overlap Pent 7' x 5' - No Windows (OPP75NWM)
Contact our aftersales team with your product code if you are missing your felt.
Overlap Pent 8' x 6' - 2 Windows (OPP86M)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Overlap Pent 6' x 4' - 2 Windows (OPP64M)
Overlap Pent 6' x 4' - No Windows (OPP64NWM)
Overlap Pent 7' x 5' - 2 Windows (OPP75M)
DON’T FORGET TO
PRE-DRILL AND ATTACH
YOUR FOREST BADGE
PRESSURE TREATED OVERLAP PENT SHEDS
CHECK YOU HAVE ALL YOUR PARTS PRIOR TO ASSEMBLY.
(The parts do not have codes on them. They are listed above should you need to order one.)
9

Part Code
Description Qty Part Code Description Qty Part Code Description Qty
SDPMRHA4 Right Pent Section (358x1180mm) 1SDPMRHA4 Right Pent Section (358x1180mm) 1SDPMRHA5 Right Pent Section (356x1475mm) 1
SDPMLHA4 Left Pent Section (358x1180mm) 1SDPMLHA4 Left Pent Section (358x1180mm) 1SDPMLHA5 Left Pent Section (356x1475mm) 1
SDPM885BP Section D - 3ft Pent Back Panel (885 x 1717mm) 2
SDPM885BP
Section D - 3ft Pent Back Panel
(885 x 1717mm) 2
SDPM885BP Section D - 3ft Pent Back Panel (885 x 1717mm) 1
SDM885TPP Section E - 3ft Pent Front Panel (885 x 1945mm) 1
SDM885TWP
Section E - 3ft Pent Front Window Panel
(885 x 1945mm)
1SDPM1180BP Section G - 3ft Pent Back Panel (1180 x 1717mm) 1
SDM885TDP
Section I - 3ft Door Panel (885 x 1945mm) 1SDM885TDP 3ft Pent Door Panel (885 x 1945mm) 1SDM885TDP Section I - 3ft Door Panel (885 x 1945mm) 1
SDM1180PP Section F - 4ft Panel (1180 x 1603mm) 2SDM1180PP Section F - 4ft Panel (1180 x 1603mm) 2SDM885PP Section C - 3ft Panel (885 x 1603mm) 2
MSDDR Door (582x1692mm) 1MSDDR Door (582x1692mm) 1SDM590PP Section A - 2ft Panel (590 x 1603mm) 2
MSBFL46 Floor (1180x1826mm) 1MSBFL46 Floor (1180x1826mm) 1SDM1180TPP
Section H - 4ft Pent Front Panel (1180 x 1945mm) 1
28121637PDT
Slamming Strip (28x12x1637mm) 128120550PDT Window Cover Strip (28x12x550mm) 3MSDDR Door (582x1692mm) 1
28280973 Roof Support Strip (28x28x973mm) 228121637PDT
Slamming Strip (28x12x1637mm) 1MSBFL257 Floor (737x2121mm) 2
28281934 Roof Support Strip (28x28x1934mm) 228280973 Roof Support Strip (28x28x973mm) 228121637PDT
Slamming Strip (28x12x1637mm) 1
38121710PDT
Weather Strip (38x12x1710mm) 128281934 Roof Support Strip (28x28x1934mm) 228281115 Roof Support Strip (28x28x1115mm) 6
40121695PDT Cover Strip (40x12x1695mm) 338121710PDT
Weather Strip (38x12x1710mm) 138121710PDT Weather Strip (38x12x1710mm) 1
40121925PDT Cover Strip (40x12x1925mm) 340121695PDT Cover Strip (40x12x1695mm) 340121695PDT Cover Strip (40x12x1695mm) 3
45451153PAII79 Roof Beam (45x45x1153mm) 140121925PDT Cover Strip (40x12x1925mm) 340121810PDT Cover Strip (40x12x1810mm) 2
59121390PDT Side Fascia (59x12x1390mm) 245451153PAII79 Roof Beam (45x45x1153mm) 140121925PDT Cover Strip (40x12x1925mm) 3
59121978PDT Front Fascia (59x12x1978mm) 159121390PDT Side Fascia (59x12x1390mm) 245451441PAII81 Roof Beam (45x45x1441mm) 1
OSB13759678 OSB Roof Sheet (1375x967x8mm) 259121978PDT Front Fascia (59x12x1978mm) 159121132PDT Front Fascia (59x12x1132mm) 2
RPET885
Window (428x577mm) 259121688PDT Side Fascia (59x12x1688mm) 2
OSB13759678 OSB Roof Sheet (1375x967x8mm) 2OSB168811158 OSB Roof Sheet (1688x1115x8mm) 2
Part Code
Description Qty Part Code Description Qty Part Code Description Qty
SDPMRHA5 Right Pent Section (356x1475mm) 1SDPMRHA6 Right Pent Section (350x1770mm) 1SDPMRHA6 Right Pent Section (350x1770mm) 1
SDPMLHA5 Left Pent Section (356x1475mm) 1SDPMLHA6 Left Pent Section (350x1770mm) 1SDPMLHA6 Left Pent Section (350x1770mm) 1
SDPM885BP
Section D - 3ft Pent Back Panel (885 x 1717mm) 1SDPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 2SDPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 2
SDPM1180BP
Section G - 3ft Pent Back Panel (1180 x 1717mm) 1SDM885PP Section C - 3ft Panel (885 x 1603mm) 4SDM885PP Section C - 3ft Panel (885 x 1603mm) 4
SDM885TDP 3ft Door Panel (885 x 1945mm) 1SDM1180TPP Section H - 4ft Pent Front Panel (1180 x 1945mm) 1SDM1180TWP
Section H - 4ft Pent Front Window Panel
(1180 x 1945mm)
1
SDM885PP Section C - 3ft Panel (885 x 1603mm) 2SDM1180TDP
Section J - 4ft Door Panel (1180 x 1945mm) 1SDM1180TDP 4ft Door Panel (1180 x 1945mm) 1
SDM590PP Section A - 2ft Panel (590 x 1603mm) 2MSDDR Door (582x1692mm) 1MSDDR Door (582x1692mm) 1
SDM1180TWP
Section H - 4ft Pent Front Window Panel
(1180 x 1945mm)
1MSBFL46 Floor (1180x1826mm) 2MSBFL46 Floor (1180x1826mm) 2
MSDDR Door (582x1692mm) 128121637PDT
Slamming Strip (28x12x1637mm) 128121637PDT Slamming Strip (28x12x1637mm) 1
MSBFL257 Floor (737x2121mm) 228280988 Roof Support Strip (28x28x988mm) 428120550PDT
Window Cover Strip (28x12x550mm) 3
28120550PDT Window Cover Strip (28x12x550mm) 328281242 Roof Support Strip (28x28x1242mm) 428280988 Roof Support Strip (28x28x988mm) 4
28121637PDT
Slamming Strip (28x12x1637mm) 138121710PDT Weather Strip (38x12x1710mm) 128281242 Roof Support Strip (28x28x1242mm) 4
28281115 Roof Support Strip (28x28x1115mm) 640121695PDT Cover Strip (40x12x1695mm) 338121710PDT
Weather Strip (38x12x1710mm) 1
38121710PDT
Weather Strip (38x12x1710mm) 140121810PDT Cover Strip (40x12x1810mm) 240121695PDT Cover Strip (40x12x1695mm) 3
40121695PDT Cover Strip (40x12x1695mm) 340121925PDT Cover Strip (40x12x1925mm) 340121810PDT Cover Strip (40x12x1810mm) 2
40121810PDT Cover Strip (40x12x1810mm) 245451783PAII83 Roof Beam (45x45x1783mm) 240121925PDT Cover Strip (40x12x1925mm) 3
40121925PDT Cover Strip (40x12x1925mm) 359121020PDT Side Fascia (59x12x1020mm) 445451783PAII83 Roof Beam (45x45x1783mm) 2
45451441PAII81 Roof Beam (45x45x1441mm) 159121259PDT Front Fascia (59x12x1259mm) 259121020PDT Side Fascia (59x12x1020mm) 4
59121132PDT Front Fascia (59x12x1132mm) 2OSB20328288 OSB Roof Sheet (2032x828x8mm) 359121259PDT Front Fascia (59x12x1259mm) 2
59121688PDT Side Fascia (59x12x1688mm) 2RPET590
Window (575x577mm) 2
RPET590
Window (575x577mm) 2OSB20328288 OSB Roof Sheet (2032x828x8mm) 3
OSB168811158 OSB Roof Sheet (1688x1115x8mm) 2
Part Code
Description Qty Part Code Description Qty
SDPMRHA6 Right Pent Section (350x1770mm) 1SDPMRHA6 Right Pent Section (350x1770mm) 1
SDPMLHA6 Left Pent Section (350x1770mm) 1SDPMLHA6 Left Pent Section (350x1770mm) 1
SDPM885BP
Section D - 3ft Pent Back Panel (885 x 1717mm) 2SDPM885BP Section D - 3ft Pent Back Panel (885 x 1717mm) 2
SDPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 1SDPM1180BP Section G - 4ft Pent Back Panel (1180 x 1717mm) 1
SDM885PP Section C - 3ft Panel (885 x 1603mm) 4SDM885PP Section C - 3ft Panel (885 x 1603mm) 4
SDM885TPP
Section E - 3ft Pent Front Panel (885 x 1945mm) 2SDM590TPP Section B - 2ft Pent Front Panel (590 x 1945mm) 1
SDM1180TDP Section J - 4ft Door Panel (1180 x 1945mm) 1SDM1180TWP
Section H - 4ft Pent Front Window Panel
(1180 x 1945mm)
1
MSDDR Door (582x1692mm) 1SDM1180TDP
Section J - 4ft Door Panel (1180 x 1945mm) 1
MSBFL56 Floor (1475x1826mm) 2MSDDR Door (582x1692mm) 1
28121637PDT
Slamming Strip (28x12x1637mm) 1MSBFL56 Floor (1475x1826mm) 2
28280988 Roof Support Strip (28x28x988mm) 428121637PDT
Slamming Strip (28x12x1637mm) 1
28281537 Roof Support Strip (28x28x1537mm) 428120550PDT
Window Cover Strip (28x12x550mm) 3
38121710PDT
Weather Strip (38x12x1710mm) 128280988 Roof Support Strip (28x28x988mm) 4
40121695PDT Cover Strip (40x12x1695mm) 428281537 Roof Support Strip (28x28x1537mm) 4
40121810PDT Cover Strip (40x12x1810mm) 238121710PDT
Weather Strip (38x12x1710mm) 1
40121925PDT Cover Strip (40x12x1925mm) 440121695PDT Cover Strip (40x12x1695mm) 4
45451783PAII83 Roof Beam (45x45x1783mm) 240121810PDT Cover Strip (40x12x1810mm) 2
59121020PDT Side Fascia (59x12x1020mm) 440121925PDT Cover Strip (40x12x1925mm) 4
59121555PDT Front Fascia (59x12x1555mm) 245451783PAII83 Roof Beam (45x45x1783mm) 2
OSB203210258 OSB Roof Sheet (2032x1025x8mm) 359121020PDT Side Fascia (59x12x1020mm) 4
59121555PDT Front Fascia (59x12x1555mm) 2
RPET590
Window (575x577mm) 2
OSB203210258 OSB Roof Sheet (2032x1025x8mm) 3
Shiplap Pent 6' x 4' - No Windows (SDP64NWM)
Shiplap Pent 7' x 5' - No Windows (SDP75NWM)
Contact our aftersales team with your product code if you are missing your felt.
Shiplap Pent 6' x 4' - 2 Windows (SDP64M)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Shiplap Pent 8' x 6' - 2 Windows (SDP86M)
Contact our aftersales team with your product code if you are missing your felt.
Shiplap Pent 10' x 6' - No Windows (SDP106NWM)
Shiplap Pent 10' x 6' - 2 Windows (SDP106M)
Shiplap Pent 7' x 5' - 2 Windows (SDP75M)
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Contact our aftersales team with your product code if you are missing your felt.
Shiplap Pent 8' x 6' - No Windows (SDP86NWM)
Contact our aftersales team with your product code if you are missing your felt.
DIP TREATED SHIPLAP PENT SHEDS
CHECK YOU HAVE ALL YOUR PARTS PRIOR TO ASSEMBLY.
(The parts do not have codes on them. They are listed above should you need to order one.)
10
