Forest garden Overlap Apex Shed 6 x 4 User manual

Overlap Apex Shed
6' x 4'
Important :
Assembly of this
shed requires a
minimum of two
adults.
Issue 0216
B
ODA4PE
PLAIN END
17917658
ROOF SHEET
QTY 2
DE
A
ODA46NW PARTS LIST
SFL46
FLOOR
SDRDT
DOOR
ODA4DE
DOOR END
44161570DT
1570mm C/STRIP QTY 4
H
K
H
45281753
1753mm BATTEN QTY 1
F
Place the corner strips so that they cover the joins
between the panels. Fix each in place using 3 x 30mm
screws
2
11
C
ODA6PS
PLAIN SIDE QTY 2
3
REQUIRED TOOLS :
(NOT SUPPLIED)
POZI DRIVE
SCREWDRIVER
SPIRIT LEVEL
TAPE MEASURE HAMMER
51120810PAII58DT
810mm BARGE BOARD QTY 4
I
Top View
C
B
C
Must Pre-drill for
each screw used.
37281791
1791mm BATTEN QTY 2
J
FELT
FELT4BLROSE
QTY 1
GFIN20010512DTR
FINIAL
QTY 1
20121695PDT
20 x1695mm STRIP QTY 1
L
SHARP KNIFE
Fix the 20 x 1695mm strip to the side
of the door frame so that it is tight
with the cladding and flush with the
frame. Use 3 x 30mm screws.
Place the panels on top of the floor. Make sure that all the panels are tight and flush before
fixing them to each other using 3x50mm screws.
Make sure that the panels are sitting flush before fixing to the floor using 50mm screws making
sure that all of the screws are positioned so that they screw into the bearers underneath.
3x50mm screws for the sides.
2x50mm screws for the plain and door ends.
Place the 1753mm batten so that it connects the door end and plain
end. Fix this in position using a 50mm screw for each end as shown.
4
H
J
J
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
This building is pre-treated with a factory base coat for
protection during storage and transit. We recommend that
you treat your new building as soon as possible after
assembly using a wood preservative treatment. Apply in
accordance with the manufacturers instructions.
- Timber is a natural material. It will shrink and swell as a
result of varying moisture content.
- Due to the nature of the material the doors may need some
trimming for a neater fit.
- Please keep all plastic bags and small parts away from
children
- The roof of this building is not a load bearing structure.
- This product must be built on a solid level base.
Technical Helpline: 0333 7777 089 8.30 am and 5.00
pm Monday to Friday.
Please check all parts prior to assembly
Assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled
to.
If the product is not constructed in accordance with the
instructions, or is altered in any way (e.g. painted), the
manufacturer cannot be held liable for any resulting damage.
Fixing Pack (OPA46FP)
This fixing pack is used for several products.
There may be additional fixings.
Not to Scale
Flush Hinge
Qty 2
50mm Screw Qty 24
30mm Nail Qty 45
25mm Screw Qty 17
Hasp &
Staple
30mm Screw Qty 19
10mm Felt tacks
Qty 100
40mm Screw Qty 12
25mm Security Screws
Screws Qty 7
AA
D
A
L
E
Place the hinge against the inside of the door frame and
position the large section of the hinge so that it is flush
with the inside of the framing as shown. Fix with 25mm
screws.
Open the hinge and fix the smaller section to the door
framing. Again make sure that the hinge is flush and that
the holes are positioned so that the 25mm screws locate
correctly into the batten.
ab

6
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products to give protection against wood destroying insects & wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)), Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off-cuts responsibly – do not burn.
7
Place the roof board on to one of the 1791mm battens. Make sure that the
board is flush on all sides.
Fix each batten in place using 30mm nails spaced in 300mm intervals.
(Repeat for the other roof section)
K
F
Lift the roof sections into place making sure that they are in line with the apex and
the front and back panels of the shed.
Fix the roof in place using 30mm nails spaced in approximately 300mm intervals.
(Make sure the nails locate into the framework of the panels)
5
I
8
Unroll the felt and cut it in to two equal lengths. Place the sheets on each side so
that there is a 50mm overhang on the eaves and they overlap at the apex. Fix these
to the roof using felt nails spaced in 150mm intervals. Cut and fold the corners
securing with a single felt nail for each.
Place the barge boards against the front and back of the shed. Make sure
that these are in line with the roof sheet and meet at the apex. Fix each in
place using 3 x 40mm screws.
Place the finial over the top of where the barge boards meet at front of shed
and fix it in place using 2 x 30mm screws.
9
Maintenance.
We recommend that you treat your shed at the beginning of each season with wood preservative treatment. Apply in
accordance with the manufacturers instructions.
Regularly check (1) All fixings are secure (2) Roofing felt is free of holes and tears (3) Sand off any rough/sharp edges.
Attention
Take care when
cutting and
trimming the roof
felt.
Before fixing the Hasp to the door make sure that it is in line with the framing on the reverse
and is positioned so that it will close over the Staple. Fix this in place using 3 x 25mm
screws.
Position the Staple opposite, again making sure that it is in line with the framing behind and
fix it in place using 2 x 25mm screws.
