Forever Redwood THE DAWN BENCH User manual

ASSEMBLY INSTRUCTIONS FOR THE
THE DAWN BENCH
866.332.2403 (TOLL FREE); 7am –7pm Pacific Time, Monday-Saturday

The Dawn Bench
www.ForeverRedwood.com
1
CONTENT OF BOXES
No.
1
2
3
Drawing
Description
Bench Seat
Legs
Backrest
Qty.
1
2
1
Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent.

The Dawn Bench
www.ForeverRedwood.com
2
CONTENT OF BOXES
No.
a
b
c
d
Drawing
Description
5/16” x 4” Bolts
(To attach the bench seat to the legs. / To
attach the backrest to the bench seat).
5/16”x 3”Bolts
(To attach the backrest to the seat).
Nuts
Washers
Note: Dimensions of your hardware will vary depending on size.

The Dawn Bench
www.ForeverRedwood.com
3
No.
1
2
3
DESCRIPTION
Bench Seat
Legs
Backrest
Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent.
1
2
2
3

The Dawn Bench
www.ForeverRedwood.com
4
Step 1: Use 5/16’’ x 4’’ bolts (a), with washers (d) and nuts (c)to attach the bench seat (1) to the legs (2). Each part has a series
of numbers that indicate where to attach the part with the corresponding number.
Step 2: Finally, attach the backrest (3) to the legs with 5/16’’ x 3’’ bolts (b), washers and nuts and to the bench seat with 5/16’’
x 4’’ bolts (a), washers (d) and nuts (c). Each part has a series of numbers that indicate where to attach the part with the
corresponding number.
1
2
2
5/16’’ x 4’’ Bolts
5/16’’ x 4’’ Bolts
5/16’’ x 3’’ Bolts
3

The Dawn Bench
www.ForeverRedwood.com
5
This completes the Bench Assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't
hesitate to call us (866 332 2403) or email us. We are here to support you.
