Grange BOWED WALKWAY 221800A001OWBZ01C1 User manual

BOWED WALKWAY
BWALK 293cm [H] x 180cm [W] x 480cm [D]
221800A001OWBZ01C1
02_05_2019
www.grangefencing.co.uk

BEFORE YOU START
Check the pack/s and make sure that you have all of the parts listed below.
If not, contact your retailer who will be able to help you.
When you are ready to start make sure you have the right tools to hand, plenty of space
with a clean and dry area for assembly.
It is advisable for two people to carry out the work.
Where the wood is screwed we advise to pre-drill the holes (the diameter of the holes
should be 2mm smaller than the diameter of the used screw)
HEALTH AND SAFETY
Do not lean or stand on the roof assembly at any time - the structure is not of a load
bearing design.
Do not overreach when working from the step ladder
In order to reduce the risk of suffocation please keep all plastic bags and small parts
away from children.
[email protected]

Screws
8 cm
x12
Screws
4 cm
x60
[y] [z]
Hardware pack
APosts x6
B
Rafters x10
C
Curved Beams x3
B
Metal Brackets
(long)
x5
[x]
[w]
Metal Brackets
(short)
x10
Recommended tools ( not included )

1
FOOTPRINT
PLAN
183 cm183 cm
141 cm
480 cm 160 cm
297 cm

22
AAAA
A
A
!

3
39 cm
39 cm
39 cm
39 cm
39 cm
39 cm
39 cm
39 cm
[z]
[z]
BB
BB
Metal Brackets
(long)
x5
[x]
[w]
Metal Brackets
(short)
x10

4
[y]
!
B
BB

5
[y]
!
B
B

6
[y]
!
B
B

27
!
[z]
C
C
C
C

8
[z]
!
C
C
C
C

9
[z]
C
C
C
C
C
C
C
C
C
C
C
C

Your item is ready!
10
