Assembly instructions for:
LATTICE GAZEBO

Lattice Gazebo www.foreverredwood.com
CONTENT OF BOXES
QUANTITY
DESCRIPTION
DRAWING
4
Posts
3
Bottom Panels
3
Upper Panels
1
Front support timber
with decorative
cantilevers
4
Roof timbers
(two of each one)
Quantity will
vary depending
on size
Roof panels
1
Skylight
Quantity will
vary depending
on size
Rafters
4
Plaques for corners

Lattice Gazebo www.foreverredwood.com
ASSEMBLY INSTRUCTIONS
All Gazebos are completely erected in the shop prior to crating for shipping. All hardware is included. All
parts are fully sanded, routered, notched, drilled and numbered for ease of reassembly. The parts that go
together have the same numbers/letters written next to the predrilled holes they attach to.
All Gazebos parts are notched into the part they connect to. You'll find the numbers next to the notches
and/or drill holes. Before beginning re-assembly, place the parts that go together on the ground with one
another so you don't have to be searching around in the middle of the reassembly. Most Gazebos take less
than one day to reassemble with one helper.
Note: print the drawings that you approved before start the construction, they are needed to see the
distances between the posts.
Step 1. Attach your anchor kit (if you ordered) to the ground. See the distance between the posts shown
in your approved drawings.

Lattice Gazebo www.foreverredwood.com
Step 2: Attach posts to lower & upper panels with deck screws (3”X #8) per side. Screw from inside of
panel frame into the posts. Match up the numbers to attach the correct two parts together. Repeat this
step with other two posts and panels and then attach the back panels.
Step 3: Attach front support timber with decorative cantilevers to posts with deck screws (3”X #8) into
each post. Match up the numbers to attach the two ends to the correct sides.

Lattice Gazebo www.foreverredwood.com
Step 4: Attach the 4 roof timbers together to form the base of the roof. Use a plaque and four lag bolts
(5/16” x 4”) per corner. (Match up the numbers to attach the two parts together). Insert the bolts of 7 ½”
to attach the roof panels and then place the frame base above the walls.
Attach the roof base to the walls panels with lag bolts
Step 5: Attach 6 of the center rafters to the rooftop with bolts (4”x 5/16”) washers & nuts. One per
rafter. (Match up the numbers to attach the two parts together). Tap the bolt all the way into the wood to
set it. Then add a washer and nut and lightly tighten.

Lattice Gazebo www.foreverredwood.com
Step 6: Attach the corner rafters to the rooftop with bolts (8”x 3/8”) washers & nuts. (Match up the
numbers to attach the two parts together). Tap the bolt all the way into the wood to set it. Then add a
washer and nut and lightly tighten.
Step 7: Attach the rafters to base of roof with bolts (6 ½”x 3/8”) washers & nuts. (Match up the numbers
to attach the two parts together). Tap the bolt all the way into the wood to set it. Then add a washer and
nut and lightly tighten.
Step 8: Attach the roof panels to rafters with deck screws (#8 x 3”) (Match up the numbers to attach
the two parts together). Tap the bolt all the way into the wood to set it. Then add a washer and nut and
lightly tighten. Continue with the other roof panels.

Lattice Gazebo www.foreverredwood.com
This completes the Gazebo assembly. Hope you enjoy your set for many decades. If you ever have a
problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you.
