Dakota Digital PGR-1000-F User manual

MAN#650194
PGR-1000-F
Programmable Gear Readout
Fairing Mount (1.25” hole)
See back page for alternative wiring for bikes w/ECM tach output
Display readout:
‘n’ -transmission in neutral
‘-‘-no speed or rpm signal. (key on with engine off)
‘0’ -engine is running, but no speed signal. (key on with engine on)
‘E’ -speed signal is present, but no rpm signal.
‘1’ – ‘7’-current transmission gear.
‘C’ -settings cleared and waiting to learn gear pattern.
Programming:
When the display shows a flashing ‘C’ or ‘n’ it is ready to start learning the gear pattern.
After you start the engine you should see a flashing ‘0’.
Once you start driving this will change to a flashing ‘1’.
Drive at a constant speed in 1st gear for 20-25 seconds. Once the display quits flashing,
shift to 2nd.
Drive at a constant speed in 2nd gear for 20-25 seconds. Once the display quits flashing,
shift to 3rd.

MAN#650194
Repeat these steps until you have programmed all of the gears in order. Once you stop or
shift into neutral the settings will all be saved and the readout will begin normal operation.
Clearing or resetting the gear programming, or if PGR is mounted below the handle-bars:
1. 2. 3. 4. 5. 6.
1. Turn the key on and make sure the transmission is in neutral and ‘n’ is displayed on the
readout.
2. Turn the key off and then back on again rapidly. The display should show 1 bar. If you wait
too long before continuing the readout will exit the setup routine. (If the unit has already
been cleared, it will immediately jump to step 6.)
3. Repeat step #2. The display should show 2 bars.
4. Repeat step #2. The display should show 3 bars.
5. Repeat step #2. The display should show 2 bars.
6. Repeat step #2. The display should show ‘n’ with a bar over it. If the display is upside
down then kick the transmission out of neutral and the display will invert and show ‘C’.
Tach adapter(for open-collector tach signal from ECM w/out pull-up resistor)
(2004+ Victory motorcycles use this option, most other bikes use application on front page)
VSS Notes:
The PGR-1000 is designed for motorcycles with an Electronic VSS signal. Most modern
motorcycles use a 3-wire hall-effect type speed sensor in the transmission with a power, ground,
and a signal wire. The SEN-1019 is available for motorcycles without a factory VSS signal,
fabrication will be required for sensor mounting.
1996-2003 Harley Davidson wiring
All signal wires should be found behind the speedometer or tachometer along with power and
ground. Neutral should be at the indicator lights.
Signal
Wire Color
Speed
White/Green
Tach
Pink
Neutral
Tan
Power
Orange
Ground
Black

MAN#650194
2004-2007 Harley Davidson wiring
The power, ground, and neutral can be found behind the speedometer and indicator lights. Speed
signal and Tach need to be run to the ECU or cruise control module where you should find the wire
colors listed here. This is due to the data bus configuration.
Signal
Wire Color
Speed
White/Green (Pin 33 @ ECU)
Tach
Pink (Pin 3 @ ECU)
Neutral
Tan
Power
Orange
Ground
Black
2008-2009 Harley Davidson wiring
The power, ground, and neutral can be found behind the speedometer and indicator lights. Speed
signal and Tach need to be run to the ECU or cruise control module where you should find the wire
colors listed here. This is due to the data bus configuration.
Signal
Wire Color
Speed
White/Green (Pin 40 @ ECU)
Tach
Blue/Orange (Pin 54 @ ECU)
Neutral
Tan
Power
Orange
Ground
Black
NOTE: These wire colors should be correct for most models of Harleys, however it is a good idea to verify
locations and colors, check voltages and consulting your service manual before making connections.
SERVICE AND REPAIR
DAKOTA DIGITAL offers complete service and repair of its product line. In addition, technical consultation is available to help you work through any questions
or problems you may be having installing one of our products. Please read through the Troubleshooting Guide. There, you will find the solution to most problems.
Should you ever need to send the unit back for repairs, please call our technical support line, [phone], to request a Return Merchandise Authorization
number. Package the product in a good quality box along with plenty of packing material. Ship the product by UPS or insured Parcel Post. Be sure to include the RMA
number on the package, and include a complete description of the problem with RMA number, your full name and address (street address preferred), and a telephone
number where you can be reached during the day. Any returns for warranty work must include a copy of the dated sales receipt from your place of purchase. Send no
money. We will bill you after repair.
