User manual
Uninterruptible Power Supply System
FDC-106KMR-ISO / FDC-110KMR-ISO
FDC-206KMR / FDC-210KMR

Table of content
1. Introduction
1.1 Transportation and storage
1.2 Preliminary steps
1.3 Initial setup
1.4 Important safety instructions
1.5 Standards
2. Installation and operation
2.1 Unpacking and inspection
2.2 UPS front and rear panel views
2.3 UPS installation
2.4 Output configuration
2.5 ForzaTracker monitoring software
3. Advanced operation
3.1 Description of buttons and functions
3.2 LED Indicators and LCD panel
3.3 Audible alarm
3.4 Single UPS operation
3.5 Parallel operation
3.6 Abbreviations in the LCD display
3.7 UPS parameter settings
3.8 Operating Mode/Status description
3.9 Fault codes
3.10 Warning indicators
4. Troubleshooting guide
5. Storage and maintenance
6. Technical specifications
1. Introduction
Thank you for purchasing the Forza Atlas FDC-106KMR-ISO/FDC-110KMR-ISO/FDC-206KMR/FDC-210KMR Modular Rack-
mountable Online UPS. To enjoy all the features and benefits of this unit, please read and follow all installation and operation
instructions thoroughly before unpacking, installing or operating this device. After you have read this manual, keep it in a safe place
for future reference.
The information contained in this manual covers the 6000VA/10000VA uninterruptible power system, its basic functions, operating
procedures, options available and troubleshooting guide. It also includes information on how to ship, store, handle, and install the
equipment.
1-1. Transportation and storage
• Transport the UPS system only in the original package to protect it against shock and impact.
• The UPS must be stored in a dry, well-ventilated area.
1-2. Preliminary steps
• Water condensation may occur if the UPS is unpacked in a very cold environment and then moved to a warmer
location.
• The UPS must be thoroughly dry before being installed. Failure to do so may increase the risk of electric shock.
• Do not install the UPS system near water or in moist environments.
• To reduce the risk of overheating, do not cover the cooling vents in the UPS housing.
• Avoid exposing the UPS to direct sunlight or installing the unit near heat-emitting appliances, such as electric heaters or
furnaces.
1-3. Initial setup
• Do not connect appliances or equipment that may overload the UPS system (such as big motor-type equipment) to the UPS
output sockets or terminal.
• Place cables in such a way that no one can step on or trip over them.
• Do not block air vents in the housing of UPS. The UPS must be installed in a location with good ventilation. Ensure there is
enough space on each side for air to flow.
• The UPS is provided with an earthed terminal. Equipotential earth bonding to the external UPS battery cabinets must be provided
if such configuration is used.
• The UPS can be installed only by qualified maintenance personnel.
• These UPS units are extremely heavy. Caution should be taken in moving and positioning equipment.
• An appropriate disconnect device as short-circuit backup protection should be provided in the building wiring installation.
• An integral single emergency switching device which prevents further supply to the load by the UPS in any mode of operation
should be provided in the building wiring installation
• Connect the earth before connecting the unit to the building wiring terminal.
• Installation and wiring must be performed in accordance with local electrical regulations and laws.
1-4. Important safety instructions
• This UPS should be connected using a TN earthing system.
• The power supply for this unit must be single-phase rated in accordance with the equipment nameplate. It also must be
suitably grounded.
WARNING
HIGH LEAKAGE
CURRENT.
Earth connection
essential before
connecting supply.

• It is not recommend the use of this UPS in life support applications where failure or malfunctions of the product can be reasonably
expected to cause failure of the life support device or to significantly affect its safety or effectiveness. Do not use this equipment
in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.
• Connect your UPS power module’s grounding terminal to a grounding electrode conductor.
• The UPS is connected to a DC energy source (battery). The output terminals may be live when the UPS is not connected to an AC
supply.
• This is a product for commercial and industrial application in the second environment – installation restrictions or additional
measures may be needed to prevent disturbances.
• In accordance with safety standard EN-IEC 62040-1, installation has to be provided with a “Backfeed protection” system, as a
contactor for example, which will prevent the appearance of voltage or dangerous energy in the input mains during a mains fault.
There is no standard backfeed protection inside of the UPS. Please isolate the UPS before operating the product according to
Diagram 1. The isolation device must be able to carry the UPS input current.
Diagram 1: External backfeed protection wiring
Warning labels should be placed on all primary power switches installed in places away from the device to alert the electrical
maintenance personnel of the presence of a UPS in the circuit. The label will bear the following or an equivalent text:
Do not disconnect the earth conductor cable on the UPS or the building wiring terminals at any time since this would cancel the
protective earth of the UPS system and of all connected loads.
The UPS system features its own, internal current source (batteries). The UPS output sockets or output terminals block may be
electrically live even if the UPS system is not connected to the building wiring outlet.
In order to fully disconnect the UPS system, first press the OFF button and then disconnect the power from the AC mains.
Do not allow any kind of liquid or foreign object to enter this UPS unit. Do not place beverages or any other containers with liquid
on or nearby the unit.
The UPS can be operated by any individual with no previous experience.
1-5. Standards
2. Installation and operation
The Forza Atlas series is offered in four different models, as shown in the table below.
* Safety
Safety conformance: IEC/EN 62040-1,UL1778 (5th Edition)
* EMI
Conducted emission..............................:IEC/EN 62040-2,FCC PART15 CLASS A
Radiated emission.................................:IEC/EN 62040-2,FCC PART15 CLASS A
* EMS
ESD.........................................................:IEC/EN 61000-4-2
RS...........................................................:IEC/EN 61000-4-3
EFT..........................................................:IEC/EN 61000-4-4
SURGE....................................................:IEC/EN 61000-4-5
CS............................................................:IEC/EN 61000-4-6
Power-frequency magnetic field...............:IEC/EN 61000-4-8
Low frequency signals..............................:IEC/EN 61000-2-2
Level 4
Level 3
Level 4
Level 4
Level 3
Level 4
Model Capacity
FDC-106KMR with isolation transformer
FDC-110KMR with isolation transformer
FDC-206KMR
FDC-210KMR
6000VA /6000W
10000VA/ 1000W
6000VA /6000W
10000VA/ 10000W
Q T
L/L1
N/L2
L/L1
External Distribution Panel UPS
N/L2
B Coil Remote Switch
Q Magneto_Thermal Input Main Switch
T AC Contactor as backfeed protection device
N/L2 Neutral L/L2
L/L1 L1 Line Input
Legend
There can be no derivation in the line that goes from the «Backfeed protection» to the UPS, as the
standard safety would be infringed.
Before working on this circuit
- Isolate Uninterruptible Power System (UPS)
- Then check for Hazardous Voltage between all terminals
including the protective earth
Risk of Voltage Backfeed

2-1. Unpacking and inspection
Remove the UPS from its package and make sure that all the following items are included:
Carefully inspect the UPS to check for any damages that may have occurred during shipping. Should any evidence of damage be
found or if some parts are missing, do not turn the UPS on; you must immediately notify the carrier or dealer where you purchased
the unit.
2-2. UPS front and rear panel views
Front view
Rear panel
2-3. UPS installation
Installation and wiring must be performed by qualified personnel, and in accordance with the local electrical regulations and codes.
Also, you must observe the following instructions:
1) Make sure the mains wire and breakers in the building are enough for the rated capacity of UPS to avoid the hazards of
electric shock or fire.
Note: Do not use a wall receptacle as the input power source for the UPS, as its rated current is less than the UPS maximum
input current. Failure to do so may result in a broken or burned out receptacle.
2) For safety considerations, turn off the mains switch in the building before installation.
3) Turn off all the devices before connecting them to the UPS.
4) Wiring sizes should be installed in accordance with the following table:
16. Isolation transformer output terminals
17. Isolation transformer input terminals
18. Isolation transformer input grounding
19. Isolation transformer output grounding
20. Battery pack ground
21. UPS secondary ground for battery pack
22. Output breaker
23. Maintenance bypass switch
24. Output control signal slot
25. Maintenance bypass ground
26. Maintenance bypass output terminals
27. Maintenance bypass UPS output terminals
28. Maintenance bypass UPS input terminals
29. Utility input terminals
1. Parallel current port
2. Parallel data ports
3. External battery connector
4. Intelligent slot
5. RS-232 communication port
6. USB communication port
7. Emergency power off (EPO) connector
8. Input circuit breaker
9. Output terminals
10. Ground
11. Input terminals
12. Cooling fans
13. External maintenance bypass switch
14. Battery pack output circuit breaker
15. External battery connector
Isolation transformer version (110V) Standard version (220V)
- Online UPS
- Battery bank
- Isolation transformer
- CD with ForzaTracker monitoring software
- USB cable
- One parallel cable
- Share current cable
- Battery pack cable
- Isolation transformer cable
- Rack mounting brackets and hardware
- Tower support base
- User manual
- Warranty certificate
- Online UPS
- Battery bank
- CD with ForzaTracker monitoring software
- USB cable
- One parallel cable
- Share current cable
- Battery pack cable
- Rack mounting brackets and hardware
- Tower support base
- User manual
- Warranty certificate
Wiring specification (AWG)
Model Input GroundOutput Battery
6K
10K
10
8
10
8
10
8
Diagram 1: UPS unit
Diagram 2: Battery pack Diagram 3: Isolation transformer
input and output terminals
Diagram 4: Maintenance bypass switch with breaker input and output terminals
19 16 17 18
15 2014
BYPASS LINE BATT FAULT
OFF/ESC TEST/UP MUTE/DOWN ON/ENTER
5 6 7 13
4
3
1
2
12 9 10 11 8 21
2925 26 2827 25 22 23 24

Input neutral
Input line
Ground
Output line
Output neutral/ Ground
Note 1: The cable for 6K should be able to withstand currents of over 40A. It is recommended to use a 10AWG or thicker wire for
safety and efficiency.
Note 2: The cable for 10K should be able to withstand currents of over 63A. It is recommended to use an 8AWG or thicker wire for
safety and efficiency.
Note 3: The color selection of wires should be made according to the local electrical codes and regulations.
5) Remove the terminal block cover on the rear panel of UPS. Proceed to connect the wires according to the following terminal
block diagrams: (Make sure to attach the earth wire first when connecting the wires. When removing the wiring, make sure to
remove the earth wire last).
Terminal block wiring diagram of the UPS
Terminal block wiring diagram of the isolation transformer
Terminal block wiring of the maintenance bypass switch with breaker
Note 1: Make sure that the wires are connected tightly to the terminals.
Note 2: If necessary, you may add an output breaker with leakage current protection between the output terminal and the load.
Note 3: Install the leakage current breaker at the output power distribution panel of the UPS.
6) Put the terminal block cover back in the rear panel of the UPS.
Warning:
• For safety considerations, switch all power off using the main switch before installation.
• A standard battery pack will come with one DC breaker to disconnect the battery pack and the UPS. But if additional external
battery packs are used, a DC breaker or other protection device must be installed between the UPS and the pa
Note: The battery pack breaker must also be set to OFF before installing the battery pack.
• Pay close attention to the rated battery voltage marked on the rear panel. If you want to change the number of batteries, please
make sure you modify the settings accordingly. A connection with the wrong battery voltage may cause permanent damage to the
UPS. Make sure the voltage of the battery pack is correct.
• Pay close attention to the polarity markings on the external battery terminal block, and make sure to match the correct battery
polarity of the cells. Wrong connection may cause permanent damage to the UPS.
• Make sure the protective earth ground wiring is correctly installed. The wire current specification, color, position, connection and
conductance reliability should be checked carefully.
• Make sure the utility input and output wiring is correct. The wire current specification, color, position, connection and conductan-
ce reliability should be checked carefully. Make sure the L/N wiring is correct, not reversed and short-circuited.
2-4. Output configuration
The output of the UPS should be connected to the input of the isolation transformer, making the output of the isolation transformer
the final power output of the system. Follow diagram below to connect the UPS output to the input terminals of the isolation
transformer.
Input ground
Input neutral
Input 2 line
Input 1 line
Output neutral
Output ground
Output X1 line
Output X2 line
Output neutral
Output X3 line
Maintenance bypass ground
Utility input neutral
Utility input line
Maintenance bypass UPS input neutral
Maintenance bypass UPS input line
Maintenance bypass ground
Maintenance bypass output line
Maintenance bypass output neutral
Maintenance bypass UPS output line
Maintenance bypass UPS output neutral
System wiring overview with isolation transformer

Isolation transformer
terminals
UPS
240V input
Isolation transformer
terminals
UPS
208V input
There are three different wiring configurations that the output terminals of the isolation transformer can be set in order to fulfill
different applications.
The following connection will give you one set of 120V output, with total 10KVA load max.
Connect X1-X3 via jumper wire.
Connect N-N via jumper wire.
This will give you 120V output for 10KVA load.
The following connection will give you two sets of 120V outputs, each output takes 5KVA load max.
Connect X1-N – 120V output for 5KVA load
Connect X3-N – 120V output for 5KVA load
*Option 2:
After connecting N and X3, it becomes one 208V output at X2-N.
*Option 3:
After connecting N and X3, it becomes one 240V output at X1-N. Then connect load to X1-N terminal.
*Option 4:
Output 1 Output 2
*Option 1:
Output
120V
Output
Output

* CVCF stands for converter mode.
Mode LED
UPS startup
Bypass mode
AC mode
Battery mode
CVCF mode
Battery test
ECO mode
Fault
Bypass Line Battery Fault
Note: means LED is illuminated means LED is not illuminated
2-5. ForzaTracker monitoring software
ForzaTracker is a new generation of UPS monitoring software, which provides user-friendly interface to monitor and control your
Uninterruptible Power System. This unique software provides safe auto-shutdown for multi-computer systems during power
failures. With this software, users can monitor and control any UPS on the same LAN no matter how far they might be from the
UPS.
Installation procedure for Windows users:
1. Use the supplied CD or go to the website: http://www.forzaups.com/us/driver-downloads/.
2. After clicking the software icon, choose the required operation system.
3. Follow the on-screen instructions to install the software.
4. When you finished downloading all required files, enter the serial No (Installation Password): 5242-87f6-64re-di8d-986u to install
the software (include the hyphens).
5. In order to access as Administrator, input the password: 111296.
6. When your computer restarts, the management software will appear as a light blue round icon located in the system tray, near
the clock.
For Mac users, please refer to the ForzaTracker quick installation guide inside the Mac folder.
3. Advanced operation
3-1. Description of buttons and functions
3-2. LED Indicators and LCD panel
There are four LEDs on front panel design to show the operation status of the UPS:
FunctionButton
ON/Enter
Button
OFF/ESC
Button
Test/Up
Button
Mute/Down
Button
Test/Up +
Mute/Down
Button
Turns on the UPS: Press and hold this button over 0.5 second to turn on the UPS.
Enter Key: Press this button to confirm the selected settings of the configuration menu.
Turns off the UPS: Press and hold this button for 0.5 second to turn off the UPS.
Esc key: Press this button to return to the last setting of the configuration menu.
Battery test: Press and hold this button for 0.5 second to test the battery status while
in AC mode, or CVCF mode.
UP key: Press this button to display the next selection in the configuration menu.
Mutes the alarm: Press and hold the button for 0.5 second to mute the buzzer.
Please refer to sections below for details.
Down key: Press this button to display previous selection in the configuration menu.
Press and hold these two buttons simultaneously for 1 second either to enter
or exit the menu settings.
•
•
•
•
•
•
•
•
•
LCD Panel
BYPASS LINE BATTERY FAULT
OFF/ESC TEST/UP MUTE/DOWN ON/ENTER
Backup
Time Info
Mode Operation
Info
Programmable
Output Info
Input & Battery
Voltage Info
Output & Battery
Voltage Info
Battery Info Load Info
Fault
Info Mute Operation
Display Function
Backup time information
Fault information
Mute operation
Output & battery voltage information
Load information
Provides a digital indication of the battery discharge time.
H: hours, M: minutes, S: seconds
Indicates that a warning or fault has occurred.
Displays the fault codes, listed in detail in the sections below.
Indicates that the UPS alarm has been disabled.
Provides an indication of the output voltage, frequency or battery
voltage. VAC: output voltage, VDC: battery voltage, Hz: frequency
Indicates the load level at 0-25%, 26-50%, 51-75%, and 76-100%
Overload indication.
Indicates the load or the output is short-circuited.
Display Function
Backup time information
Fault information
Mute operation
Output & battery voltage information
Provides a digital indication of the battery discharge time.
H: hours, M: minutes, S: seconds
Indicates that a warning or fault has occurred.
Displays the fault codes, listed in detail in the sections below.
Indicates that the UPS alarm has been disabled.

Description
UPS status
Bypass mode
Battery mode
Fault mode
Warning
Overload
Other alert
Fault
All
Buzzer status
Beeps once every 2 minutes
Beeps once every 4 seconds
Beeps continuously
Beeps twice every second
Beeps once every second
Beeps continuously
Yes
Yes
Yes
Muted
2) Press and hold the ON button for 0.5 second to power on the UPS. The buzzer will beep once.
3) After a few seconds, the UPS will enter into the AC mode. In case of abnormal utility power, the UPS will transfer to battery
mode operation to provide uninterrupted power to the outlets.
Note: In battery mode, the UPS will shut down automatically when the remaining charge is low. Once the utility power is
restored, the UPS will restart automatically in AC mode.
2. Turn on the UPS without utility power (Battery mode)
1) Make sure that the battery pack breaker is in its ON position.
2) Press and hold the ON button for 0.5 second to power on the UPS. The buzzer will beep once.
3) After a few seconds, the UPS will be turned on and begin operating on “off-grid” or Battery mode.
3. Connecting devices to the UPS
After the UPS is turned on, you can connect devices to the unit.
1) Turn on the UPS first and then start powering one load at a time only after all of them have been plugged into the unit. The total
load level will be displayed on the LCD panel.
2) Should you need to connect inductive loads, such as a monitor or a laser printer to the UPS, the start-up power should be used
for calculating the capacity of the UPS, as energy consumption increases during initial power on.
3) If the UPS is overloaded, the buzzer will beep twice every second.
4) In the event of an overload, all unnecessary loads must be removed one by one, to lower the total loads connected to the UPS to
less than 80% of its nominal power capacity to prevent the overload condition.
5) If the overload time exceeds the time specified in AC mode, the UPS will automatically transfer to Bypass mode. After the
overload is removed, the UPS will return to AC mode. If the overload time exceeds the time specified in Battery mode, the UPS
will transfer to fault status. At this time, if the bypass is enabled, the UPS will supply power to the loads using the bypass mode.
If the bypass function is disabled or the input power is not within the bypass acceptable range, the output power will be cut off
immediately.
4. Charging the batteries
1) Once the UPS is connected to utility power, the unit will charge the batteries automatically, except when the UPS is running in
Battery mode or while the battery self-test is in progress.
2) It is recommended to charge the batteries at least 10 hours before use to ensure proper backup time.
3) Verify that battery number setting on the control board is consistent with the actual quantity of units being connected.
5. Battery mode operation
1) When the UPS is in Battery mode, the buzzer will beep according to the battery capacity.
a. If the battery capacity is over 25%, the buzzer will beep once every 4 seconds.
b. If the battery voltage drops to the alarm triggering level, the buzzer will beep once every second to indicate that the battery has
reached its lowest capacity, and that the UPS will soon shut down automatically. Shutting down non-critical loads at this point
will disable the alarm and prolong the backup time. If the programmable timer function is enabled, the UPS will shut off program-
mable output terminals automatically.
Note: Should there be no more loads to turn off, you will need to shut down all existing connected equipment as soon as
possible to protect it or save the data. There is the risk of data loss or load failure if battery runtime is exceeded.
2) To silence the buzzer sound in Battery mode, press the Mute button.
3) The backup time varies depending upon the capacity of the external batteries being used.
4) When the backup time is set at 16.5 hours (LCD panel default value), the UPS will shut down automatically to protect the battery
after the discharging period expires. This battery discharge protection can be enabled or disabled using the LCD panel control.
6. Testing the batteries
1) To check the battery status when the UPS is running in AC mode/CVCF mode/ECO mode, press the Test button to initiate the
self-diagnostic tool.
2) To maintain the system reliability, the UPS will perform an automatic battery self-test on a periodic basis. The default setting for
the battery self -test is once per week.
3) Battery self-test interval can also be set through the monitoring software.
4) When the UPS is in battery self-test mode, the LCD Display and buzzer indication will be the same as in battery mode, with the
exception that the battery LED will appear blinking in this case.
7. Turn off the UPS with utility power in AC mode
1) Turn off the inverter of the UPS by pressing the OFF button for at least 0.5 second. The buzzer will beep once and the UPS will
go into Bypass mode.
Note 1: If the UPS has been set to enable the bypass output, it will bypass voltage from utility power to the output terminal even
though the UPS (inverter) has been turned off.
Note 2: After turning off the UPS, please beware that the UPS is operating in Bypass mode and there is a risk of power loss for
connected devices.
2) In Bypass mode, output voltage of the UPS is still present. In order to shut off the output voltage, switch off the input breaker to
the UPS. A few seconds later, there will be no display shown on the LCD panel while the UPS is now completely turned off.
8. Turn off the UPS without utility power supply in Battery mode
1) Turn off the UPS by pressing the OFF button for at least 0.5 second. The buzzer will beep once.
2) The UPS will cut off power to the output, in which case there will be no indication showing on the display panel.
9. Muting the buzzer
1) To silence the buzzer, press the Mute button for at least 0.5 second. If you press it again, the buzzer will be enabled.
2) Some warning alarms cannot be muted unless the error that triggered them is fixed.
10. Operation in warning status
1) When the Fault LED flashes and the buzzer beeps once every second, it means that the UPS is experiencing operation issues.
Fault codes are available via the LCD panel. Refer to the troubleshooting table for additional details.
2) Some warning alarms cannot be muted unless the error that triggered them is fixed.
11. Operation in fault mode
1) When the Fault LED illuminates and the buzzer beeps continuously, it means that there is a fatal error in the UPS. Fault codes are
available via the LCD panel. Refer to the Troubleshooting table for additional details.
2) Check the loads, wiring, ventilation, utility, battery and so on when a fault occurs. Do not try to turn on the UPS again before
solving the problems. If the issues persist, contact the dealer or service personnel immediately.
3) In case of emergency, disconnect the UPS from the utility, external battery, and output immediately to avoid danger.
12. Changing battery numbers
1) This operation should only be performed by trained and qualified technicians.
2) Turn off the UPS. If the load cannot be shut down, remove the cover from the maintenance bypass switch on the rear panel of
the unit, and slide the maintenance switch to the BPS position.
3) Switch off the input breaker and battery breaker.
4) Remove the UPS cabinet cover. Disconnect the battery wire and modify the jumper on the control board to set the battery
numbers, as shown on the table below.
5) Modify the battery pack to match the setting number in control panel.
6) Then, modify charger voltage according to the table below to match the setting number on the control board. There are 5
jumpers on the charger board. Please refer to the below table to modify charger voltage.
7) After executing the previous steps, replace the UPS cover. Switch on the battery breaker followed by the input breaker. The UPS
will enter into the Bypass mode. If the UPS is in maintenance Bypass mode, turn the maintenance switch to the UPS position
before turning on the system.
13. Changing charging current
1) This operation should only be performed by trained and qualified technicians.
2) Turn off the UPS. If the load could not be cut off, you should remove the cover of maintenance bypass switch on the rear panel
and turn the maintenance switch to the BPS position first.
3) Switch off the input breaker and then do the same with the battery breaker.
4) Remove the cabinet cover and disconnect battery wire. Then modify the jumpers on the charger board to set the charging
current (refer to table below). Be careful that the maximum setting should not exceed the charging current acceptable for the
battery.
3.5 Parallel system operation
1. Parallel system installation
If the UPS is only available for single operation, you may skip this section to the next.
1) Install and wire the UPS units according to section 3.5.2 in this manual.
2) Connect the output wires of each UPS to an output breaker or maintenance bypass switch with an output breaker
(sold separately).
3) Connect all output breakers to a maintenance bypass switch with breaker.
4) Each UPS must be connected to its own power bank. In the event a single power bank is used for all the UPS units, it will cause
permanent damage to the equipment.
5) Remove the cover of the parallel share current cable port on the UPS. Connect each UPS one by one with the parallel cable and
share current cable, and then screw the cover back again.
6) Refer to the following wiring diagram.
Input and battery voltage information
Battery information
Indicates the battery is charged at 0-25%, 26-50%, 51-75%, and
76-100% of its capacity.
Indicates the input voltage or frequency, or battery voltage.
VAC: input voltage VDC: battery voltage Hz: input frequency
Indicates the battery is not connected.
Low battery and low voltage indicator.
Indicates that the UPS is connected to the mains.
Indicates the battery is in working status.
Indicates the bypass circuit is in working status.
Indicates the ECO mode is enabled.
Indicates the inverter circuit is working.
Indicates the output connector is working properly.
Mode operation information
Input and battery voltage information
Battery information
Indicates the load level at 0-25%, 26-50%, 51-75%, and 76-100%
Indicates the battery is charged at 0-25%, 26-50%, 51-75%, and
76-100% of its capacity.
Indicates the input voltage or frequency, or battery voltage.
VAC: input voltage VDC: battery voltage Hz: input frequency
Overload indication.
Indicates the load or the output is short-circuited.
Indicates the battery is not connected.
Low battery and low voltage indicator.
Indicates that the UPS is connected to the mains.
Indicates the battery is in working status.
Indicates the bypass circuit is in working status.
Indicates the ECO mode is enabled.
Indicates the inverter circuit is working.
Indicates the output connector is working properly.
3-3. Audible alarm
3-4. Single UPS operation
1. Turn on the UPS with utility power (On grid/ AC mode)
1) In order for this equipment to operate properly, first you need to make sure that the connection between the UPS and the
power pack is correct. Then set the battery pack breaker to its ON position. Next, set the UPS breaker to its ON position. At
this point, the fan will start running while the UPS supplies power to the loads via the bypass. This means that the UPS has
begun operating in Bypass mode.
Caution: To maintain the system reliability, make sure to follow the correct sequence when powering on the equipment.
Note: When the UPS is in Bypass mode, the output voltage will directly power the loads from utility after you have switched on
the input breaker. In Bypass Mode, the load is not protected by the UPS. To protect your load devices, you should turn on the
UPS as explained below.

2) Press and hold the ON button for 0.5 second to power on the UPS. The buzzer will beep once.
3) After a few seconds, the UPS will enter into the AC mode. In case of abnormal utility power, the UPS will transfer to battery
mode operation to provide uninterrupted power to the outlets.
Note: In battery mode, the UPS will shut down automatically when the remaining charge is low. Once the utility power is
restored, the UPS will restart automatically in AC mode.
2. Turn on the UPS without utility power (Battery mode)
1) Make sure that the battery pack breaker is in its ON position.
2) Press and hold the ON button for 0.5 second to power on the UPS. The buzzer will beep once.
3) After a few seconds, the UPS will be turned on and begin operating on “off-grid” or Battery mode.
3. Connecting devices to the UPS
After the UPS is turned on, you can connect devices to the unit.
1) Turn on the UPS first and then start powering one load at a time only after all of them have been plugged into the unit. The total
load level will be displayed on the LCD panel.
2) Should you need to connect inductive loads, such as a monitor or a laser printer to the UPS, the start-up power should be used
for calculating the capacity of the UPS, as energy consumption increases during initial power on.
3) If the UPS is overloaded, the buzzer will beep twice every second.
4) In the event of an overload, all unnecessary loads must be removed one by one, to lower the total loads connected to the UPS to
less than 80% of its nominal power capacity to prevent the overload condition.
5) If the overload time exceeds the time specified in AC mode, the UPS will automatically transfer to Bypass mode. After the
overload is removed, the UPS will return to AC mode. If the overload time exceeds the time specified in Battery mode, the UPS
will transfer to fault status. At this time, if the bypass is enabled, the UPS will supply power to the loads using the bypass mode.
If the bypass function is disabled or the input power is not within the bypass acceptable range, the output power will be cut off
immediately.
4. Charging the batteries
1) Once the UPS is connected to utility power, the unit will charge the batteries automatically, except when the UPS is running in
Battery mode or while the battery self-test is in progress.
2) It is recommended to charge the batteries at least 10 hours before use to ensure proper backup time.
3) Verify that battery number setting on the control board is consistent with the actual quantity of units being connected.
5. Battery mode operation
1) When the UPS is in Battery mode, the buzzer will beep according to the battery capacity.
a. If the battery capacity is over 25%, the buzzer will beep once every 4 seconds.
b. If the battery voltage drops to the alarm triggering level, the buzzer will beep once every second to indicate that the battery has
reached its lowest capacity, and that the UPS will soon shut down automatically. Shutting down non-critical loads at this point
will disable the alarm and prolong the backup time. If the programmable timer function is enabled, the UPS will shut off program-
mable output terminals automatically.
Note: Should there be no more loads to turn off, you will need to shut down all existing connected equipment as soon as
possible to protect it or save the data. There is the risk of data loss or load failure if battery runtime is exceeded.
2) To silence the buzzer sound in Battery mode, press the Mute button.
3) The backup time varies depending upon the capacity of the external batteries being used.
4) When the backup time is set at 16.5 hours (LCD panel default value), the UPS will shut down automatically to protect the battery
after the discharging period expires. This battery discharge protection can be enabled or disabled using the LCD panel control.
6. Testing the batteries
1) To check the battery status when the UPS is running in AC mode/CVCF mode/ECO mode, press the Test button to initiate the
self-diagnostic tool.
2) To maintain the system reliability, the UPS will perform an automatic battery self-test on a periodic basis. The default setting for
the battery self -test is once per week.
3) Battery self-test interval can also be set through the monitoring software.
4) When the UPS is in battery self-test mode, the LCD Display and buzzer indication will be the same as in battery mode, with the
exception that the battery LED will appear blinking in this case.
7. Turn off the UPS with utility power in AC mode
1) Turn off the inverter of the UPS by pressing the OFF button for at least 0.5 second. The buzzer will beep once and the UPS will
go into Bypass mode.
Note 1: If the UPS has been set to enable the bypass output, it will bypass voltage from utility power to the output terminal even
though the UPS (inverter) has been turned off.
Note 2: After turning off the UPS, please beware that the UPS is operating in Bypass mode and there is a risk of power loss for
connected devices.
2) In Bypass mode, output voltage of the UPS is still present. In order to shut off the output voltage, switch off the input breaker to
the UPS. A few seconds later, there will be no display shown on the LCD panel while the UPS is now completely turned off.
8. Turn off the UPS without utility power supply in Battery mode
1) Turn off the UPS by pressing the OFF button for at least 0.5 second. The buzzer will beep once.
2) The UPS will cut off power to the output, in which case there will be no indication showing on the display panel.
9. Muting the buzzer
1) To silence the buzzer, press the Mute button for at least 0.5 second. If you press it again, the buzzer will be enabled.
2) Some warning alarms cannot be muted unless the error that triggered them is fixed.
10. Operation in warning status
1) When the Fault LED flashes and the buzzer beeps once every second, it means that the UPS is experiencing operation issues.
Fault codes are available via the LCD panel. Refer to the troubleshooting table for additional details.
2) Some warning alarms cannot be muted unless the error that triggered them is fixed.
11. Operation in fault mode
1) When the Fault LED illuminates and the buzzer beeps continuously, it means that there is a fatal error in the UPS. Fault codes are
available via the LCD panel. Refer to the Troubleshooting table for additional details.
2) Check the loads, wiring, ventilation, utility, battery and so on when a fault occurs. Do not try to turn on the UPS again before
solving the problems. If the issues persist, contact the dealer or service personnel immediately.
3) In case of emergency, disconnect the UPS from the utility, external battery, and output immediately to avoid danger.
12. Changing battery numbers
1) This operation should only be performed by trained and qualified technicians.
2) Turn off the UPS. If the load cannot be shut down, remove the cover from the maintenance bypass switch on the rear panel of
the unit, and slide the maintenance switch to the BPS position.
3) Switch off the input breaker and battery breaker.
4) Remove the UPS cabinet cover. Disconnect the battery wire and modify the jumper on the control board to set the battery
numbers, as shown on the table below.
5) Modify the battery pack to match the setting number in control panel.
6) Then, modify charger voltage according to the table below to match the setting number on the control board. There are 5
jumpers on the charger board. Please refer to the below table to modify charger voltage.
7) After executing the previous steps, replace the UPS cover. Switch on the battery breaker followed by the input breaker. The UPS
will enter into the Bypass mode. If the UPS is in maintenance Bypass mode, turn the maintenance switch to the UPS position
before turning on the system.
13. Changing charging current
1) This operation should only be performed by trained and qualified technicians.
2) Turn off the UPS. If the load could not be cut off, you should remove the cover of maintenance bypass switch on the rear panel
and turn the maintenance switch to the BPS position first.
3) Switch off the input breaker and then do the same with the battery breaker.
4) Remove the cabinet cover and disconnect battery wire. Then modify the jumpers on the charger board to set the charging
current (refer to table below). Be careful that the maximum setting should not exceed the charging current acceptable for the
battery.
3.5 Parallel system operation
1. Parallel system installation
If the UPS is only available for single operation, you may skip this section to the next.
1) Install and wire the UPS units according to section 3.5.2 in this manual.
2) Connect the output wires of each UPS to an output breaker or maintenance bypass switch with an output breaker
(sold separately).
3) Connect all output breakers to a maintenance bypass switch with breaker.
4) Each UPS must be connected to its own power bank. In the event a single power bank is used for all the UPS units, it will cause
permanent damage to the equipment.
5) Remove the cover of the parallel share current cable port on the UPS. Connect each UPS one by one with the parallel cable and
share current cable, and then screw the cover back again.
6) Refer to the following wiring diagram.
16
17
18
19
20 (default setting)
x
x
x
x
x
Battery number
in series
Pin1 and pin2
x
x
x
x
x
Pin3 and pin4
1
0
0
0
0
Pin5 and pin6
0
1
1
0
0
Pin7 and pin8
0
1
0
1
0
Pin9 and pin10
JP1
16
17
18
19
20 (default setting)
218
232
245
259
273
Battery number
in series
Charge
voltage (V)
JP01 JP02 JP03 JP04
0
0
0
1
0
0
0
1
0
0
0
1
0
0
0
1
0
0
0
0
JP05
0
0
0
0
0
JP1
Note: 0 = no jumper; 1 = connect with jumper; x = the pins are for other functions.
Note: 0 = no jumper; 1 = connect with jumper.
Charge current (A)
1A
2A
3A
4A
JP06
0
0
1
0
JP07
0
1
0
0
JP08
1
0
0
0
Note: 0 = no jumper; 1 = connect with jumper

L N L N
Ground
L N L N
Ground
Input neutral Input line
Output neutral Output line
Diagram 1: Power cable connection
Parallel communication port connection
Share current cable connection
Diagram 2: Wiring diagram of parallel system
2. Parallel system connection
NOTE: For parallel installation each UPS must have a maintenance bypass output breaker/switch connected. This device is offered
separately.
1) Once you have verified all wiring has been done properly, turn off the input, output and battery breakers of each UPS.
2) Remove all the maintenance bypass covers and change the maintenance switches from UPS to BPS, turn on the input breaker
of the each UPS and change the maintenance switches from BPS to UPS. When done, replace the maintenance bypass cover.
With a multimeter, measure the L1-N1 and L2-N2 voltage difference between each UPS. If the voltage difference is less than
2V, it means all connections are correct. If the difference is higher than 2V, check if the wiring has been done correctly.
3) Turn on the input breakers of each UPS in the parallel system. Before turning on each UPS in turns, check if PAR001~PAR003
are displayed in each UPS sequentially. If no “PARXX exists in any UPS, please check if the parallel cables are connected
correctly.
4) Turn on each UPS one by one and make sure that AC mode LED or Battery mode LED display is lit in each UPS. Using a
multimeter, measure the output voltage of each UPS to make sure the voltage difference is less than 2V (typical 1V). If the
difference is above 2V, check that parallel cables and/ or parallel current cables are connected properly. If all connections are
done properly, it may be a UPS internal issue. In this case, contact your local distributor or service center for help.
5) Turn off each UPS in sequence. After all of the UPS are transferred to Bypass mode, turn on the output breaker of each unit.
6) Finish by turning on the UPS units in AC mode. Now the system is ready for operation in parallel mode.
3. Adding one new unit into the parallel system
1) You cannot add one new unit into the parallel system while the whole system is running. First, all loads and each UPS in the
system must be shutdown.
2) Make sure all of the UPS are parallel models, and follow the wiring scheme shown earlier in this manual.
3) Install the new UPS and follow instructions in the previous section for proper connection, testing and startup.
Full installation with maintenance bypass and isolation transformer (110V or 220V operation)
MAINTENANCE
BYPASS
UPS
BATTERY PACK
ISO (Output to load)
Full installation with maintenance bypass (220V operation only)
MAINTENANCE
BYPASS
(Output to load)
UPS
BATTERY PACK
Output load
Ground

09
10
11
12
13
14
15
16
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Reserved for future use
Reserved for future use
01
02
03
04
05
06
07
08
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Output voltage
Output frequency
Voltage range for bypass
Frequency range for bypass
ECO mode enable/disable
Voltage range for ECO mode
ECO mode frequency range setting
Bypass mode setting
Battery backup time setting
Reserved
Reserved
Hot standby function enable/disable
Battery voltage adjustment
Charger voltage adjustment
Inverter voltage adjustment
Output voltage adjustment
Code Description Bypass
Y
AC ECO CVCF Battery Battery
test
Parameter 3: Output voltage
You may choose the following output voltage in parameter 3: 208: The output
voltage is 208VAC
220: The output voltage is 220VAC 230: The output voltage is 230VAC
240: The output voltage is 240VAC
Or
104: The output voltage is 104VAC
110: The output voltage is 110VAC
115: The output voltage is 115VAC
120: The output voltage is 120VAC
Interface Setting
01: Output voltage settings
4. Removing one unit from the parallel system
There are two methods that can be used to remove one UPS from the parallel system:
First method:
1) Press the OFF button twice for about 0.5 second each. The UPS will enter into bypass mode without output.
2) After turning off the output breaker, do the same with the input breaker of the UPS.
3) After the UPS shuts down, turn off the battery breaker. Then remove the parallel cable and share current cable. You can now
remove the unit out from the parallel system.
Second method:
1) If the bypass is abnormal, the UPS cannot be removed without interruption. You must first power down the load and complete
ly shut down the UPS system.
2) Enable the Bypass setting in each UPS and then power off the running UPS. All UPS units in the parallel system will transfer to
Bypass mode. Remove all maintenance bypass covers and change the maintenance switches from UPS to BPS. Next, turn off
input breakers and battery breakers.
3) Remove the desired UPS.
4) Turn on the input breaker of the remaining UPS units and the system will transfer to Bypass mode.
5) Set the maintenance switches from BPS to UPS and replace the maintenance bypass covers. Turn on the remaining UPS units
and finish the parallel system connections.
Warning: (parallel system only)
• Before turning on the parallel system to activate the inverter, make sure that every maintenance switch on the UPS is in the same
position.
• When the parallel system is turned on to operate through the inverter, do not change the maintenance switch of any unit.
3-6. Abbreviations on the LCD display
ENA
DIS
ATO
BAT
NCF
CF
SUB
ADD
ON
OFF
FBD
OPN
RES
OP.V
PAR
Enable
Disable
Auto
Battery
Normal mode (not CVCF mode)
CVCF mode
Subtract
Add
On
Off
Not allowed
Allow
Reserved
Output voltage
Parallel
Abbreviation Display content Meaning
Parameter 1: it is used for the different configu-
ration options. There are 16 programs to set up.
Refer to the table below.
Parameter 2 and parameter 3: they represent
the setting options or values of each program.
Parameter 1
Parameter 2 Parameter 3
List of the programs for parameter 1:
*Y means that this program can be set in this mode.
Note: All parameter settings will be saved only when UPS shuts down normally with internal or external battery connection.
(Normal UPS shutdown means turning off input breaker in bypass/no output mode).
3-7. UPS parameter settings
Three parameters need to be configured in order to set up the UPS. Refer to following diagram:

Parameter 2: Sets the low voltage point in ECO mode. This setting ranges
from 5% to 10% of the nominal voltage.
Parameter 3: Sets the high voltage point in ECO mode.
This setting ranges from 5% to 10% of the nominal voltage.
Interface Setting
06: Voltage range for ECO mode
Parameter 2: Output frequency
To set the output frequency, choose any of the following three options in
parameter 2:
50.0Hz: The output frequency is set to 50.0Hz.
60.0Hz: The output frequency is set to 60.0Hz.
ATO: When selected, the output frequency will be set according to the latest
normal utility frequency. If it ranges from 46Hz to 54Hz, the output frequency
will be 50.0Hz.
If it ranges from 56Hz to 64Hz, the output frequency will be set at 60.0Hz.
ATO is the default setting.
Interface Setting
02: Output frequency settings
60 Hz, CVCF mode
Parameter 2: Sets low frequency point for ECO mode. 50Hz system: Ranges
from 46.0Hz to 48.0Hz.
60Hz system: Ranges from 56.0Hz to 58.0Hz. The default value is
48.0Hz/58.0Hz.
Parameter 3: Sets the high frequency point for ECO mode. 50Hz: Ranges
from 52.0Hz to 54.0 Hz.
60Hz: Ranges from 62.0Hz to 64.0Hz. The default value is 52.0Hz/62.0Hz.
Interface Setting
07: Frequency range for ECO mode
Parameter 2:
OPN: Bypass allowed. When selected, the UPS will operate in Bypass mode
depending on the enable/disable bypass setting.
FBD: Bypass not allowed. When selected, the UPS will not be able to operate
in Bypass mode under any circumstances.
Parameter 3:
ENA: Bypass enabled. When selected, it means that the Bypass mode is
activated.
DIS: Bypass disabled. When selected, the automatic bypass may be used,
but manual bypass is never allowed. Manual bypass allows users to manually
operate the UPS in Bypass mode. For example, by pressing the OFF button in
AC mode, it will cause the unit to start running in Bypass mode.
Interface Setting
08: Bypass mode setting
Parameter 2: Sets the acceptable low voltage for bypass operation. Setting
ranges from 110V to 209V, with a default value of 110V.
Parameter 3: Sets the acceptable high voltage for bypass operation. Setting
ranges from 231V to 276V, with a default value of 264V.
Interface Setting
03: Voltage range for bypass
Parameter 3: Frequency mode
Enables you to set the output frequency in either CVCF mode or no CVCF
mode. You may choose any of the following two options in parameter 3:
CF: Sets the UPS in the CVCF mode. If selected, the output frequency will be
fixed at 50Hz or 60Hz according to the setting in parameter 2. The input
frequency could range from 46Hz to 64Hz.
NCF: Sets the UPS to normal mode (not CVCF mode).
If selected, the output frequency will synchronize with the input frequency
within 46~54Hz at 50Hz or within 56~64 Hz at 60Hz according to the setting
defined in parameter 2.
If 50Hz is selected in parameter 2, the UPS will transfer to battery mode
provided the input frequency does not fall within 46~54Hz range. If 60Hz is
selected in parameter 2, the UPS will transfer to battery mode provided the
input frequency does not fall within the 56~64Hz range.
*If ATO is selected in Parameter 2, Parameter 3 will show the current frequency
50 Hz, Normal mode
ATO
Note: If the UPS is set to CVCF mode, the bypass function will be disabled automatically.
But when a single UPS without parallel function is powered on with utility power and before the UPS finishes the startup, there will
be a few seconds of voltage pulse (same as the input voltage) on the bypass output.
If you need to remove the pulse on this mode to better protect your load, you could contact the dealer for help.
This situation will not happen in UPS units working on parallel mode.
Parameter 2: Sets the acceptable low frequency for bypass operation.
50Hz system: Setting ranges from 46.0Hz to 49.0Hz. 60Hz system: Setting
ranges from 56.0Hz to 59.0Hz. The default value is 46.0Hz/56.0Hz.
Parameter 3: Sets the acceptable high frequency for bypass operation.
50Hz: Setting ranges from 51.0Hz to 54.0 Hz. 60Hz: Setting ranges from
61.0Hz to 64.0Hz. The default value is 54.0Hz/64.0Hz.
Interface Setting
04: Frequency range for bypass
Parameter 3: Enables or disables the ECO feature. You may choose between
the following two options:
DIS: Disables the ECO feature
ENA: Enables the ECO feature
When the ECO feature is disabled, the voltage and frequency range can still
be set for this mode, however, such parameters will take effect only if the
ECO function has been enabled.
Interface Setting
05: ECO mode enable/disable

Parameter 3:
000~999: Sets the maximum backup time from 0min to 999min. UPS will shut
down to protect battery after backup time expires. The default value is
990min.
DIS: When battery discharge protection is disabled, the backup time will
depend on battery capacity. “DIS” is the default value.
Interface Setting
09: Battery backup time setting
Reserved
Interface Setting
10: Reserved
Reserved
Interface Setting
11: Reserved
Parameter 2:
HS.H: Enables or disables the Hot standby function. You may choose one of
the following two options in Parameter 3:
YES: Hot standby function is enabled. It means that the current UPS is set to
hot standby so it will restart once electricity is reestablished, even without a
battery connected.
NO: Hot standby function is disabled.
The UPS is operating in normal mode and therefore it will not restart without
having a battery connected.
Interface Setting
12: Hot standby function enable/disable
Parameter 2: Select Add or Sub function to adjust battery voltage to its
actual reading.
Parameter 3: The voltage ranges from 0V to 5.7V, the default value is 0V.
Interface Setting
13: Battery voltage adjustment
Parameter 2: You may choose Add or Sub to adjust the charger voltage.
Parameter 3: The voltage ranges from 0V to 9.9V, the default value is 0V.
NOTE:
*Before making any voltage adjustment, disconnect all batteries first to get the
accurate charger voltage.
*We strongly suggest using the default value (0). Any modification should
match battery specifications.
Interface Setting
14: Charger voltage adjustment
Parameter 2: You may choose Add or Sub to adjust the inverter voltage.
Parameter 3: The voltage ranges from 0V to 6.4V, the default value is 0V.
Interface Setting
15: Inverter voltage adjustment
Parameter 2: You may choose Add or Sub to adjust the output voltage.
Parameter 3: The voltage ranges from 0V to 6.4V, the default value is 0V.
Interface Setting
16: Output voltage adjustment
3-8. Operating mode/Status description
When parallel UPS systems are successfully set up, an additional screen with “PAR” in parameter 2 will be displayed and assigned
a number in parameter 3, as shown below. The master UPS will be assigned “001” as default, while the slave UPS units will be
identified as either “002” or “003”. The assigned numbers may be changed dynamically during operation.

Operating mode/status
Description
LCD display
LCD display
When the input voltage is within an acceptable range, the UPS will provide pure and stable
AC power to the output. The UPS will also charge the battery in AC mode.
AC mode
ECO mode
CVCF mode
Battery mode
Bypass mode
Description When the input voltage is within the voltage regulation range and ECO mode is enabled, the
UPS will bypass voltage to the output for energy saving.
Operating mode/status
Description
LCD display
When the input voltage is within an acceptable range, the UPS will provide pure and stable
AC power to the output. The UPS will also charge the battery in AC mode.
Fault status
LCD display
Description When input frequency is within 46 and 64Hz, the UPS can be set at a constant output
frequency of 50Hz or 60Hz. The UPS will still charge the battery while operating in this mode.
LCD display
Description When the input voltage exceeds the acceptable range or during a power failure, the UPS will
start supplying power from the battery while the alarm will beep every 4 seconds.
LCD display
Description When the input voltage is within the acceptable range and the bypass is enabled, turn off the
UPS in order to transfer the unit to Bypass mode. The alarm beeps once every two minutes in
this case.
Battery test
LCD display
Description When UPS is in AC mode or CVCF mode, press and hold the Test key for 0.5 second. The
UPS will beep once and start performing the “Battery test”. The line between I/P and inverter
icons blinks while the diagnostics is in progress. This operation is used to check the battery
status.
3-9. Fault codes
3-10. Warning indicators
Fault event
Bus start failure
Bus over
Bus under
Bus unbalanced
Inverter soft start failure
High inverter voltage
Low inverter voltage
Inverter output short circuited
Negative power fault
Inverter over current
Inverter waveform abnormal
Fault code
01
02
03
04
11
12
13
14
1A
60
63
Fault code
21
24
2a
31
36
41
42
43
6A
6B
6C
Fault event
Battery SCR short circuited
Inverter relay short circuited
Charger short circuited
Communication fault
Parallel output current unbalanced
Over temperature
CPU communication failure
Overload
Battery turn-on failure
PFC current failure in battery mode
Bus voltage changes too fast
Icon
None
None
None
None
None
None
None
None
None
None
Icon
None
None
None
None
None
None
None
None
None
None
3-11. Warning codes
Warning code
01
07
08
09
0A
0B
0D
0E
Warning code
10
21
22
33
3A
3D
3E
Warning event
Battery is not connected
Over charge
Low battery
Overload
Fan failure
EPO enable
Over temperature
Charger failure
Warning event
L1 IP fuse is blown
Line issues are different in a parallel system
Bypass issues are different in parallel system
Locked in bypass after an overload is detected 3 times in 30 minutes
Cover of maintenance switch is open
Bypass is unstable
Boot loader is missing
Warning
Battery low
Overload
Battery not connected
Over charge
EPO enable
Fan failure/Over temperature
Charger failure
I/P fuse broken
3 overload occurrences in 30min
Alarm
Beeps once every second
Beeps twice every second
Beeps once every second
Beeps once every second
Beeps once every second
Beeps once every second
Beeps once every second
Beeps once every second
Beeps once every second
Icon (blinking)

General
Capacity
Topology
Input
Nominal voltage
Voltage range (low line transfer)
Voltage range (low line comeback)
Voltage range (high line transfer)
Voltage range (High Line comeback)
Frequency
Power factor
Total harmonic distortion (THDi)
AC plug style
Output
Nominal voltage
AC voltage regulation (battery mode)
Frequency (synchronized range)
Frequency (battery mode)
Power factor
Efficiency (AC mode)
Efficiency (battery mode)
Overload
Transfer time (line to battery)
Transfer time (inverter to bypass)
Crest ratio
Harmonic distortion
Waveform
Type of outlet
Battery pack (included)
Battery type and quantity
Recharge time
Charging current
Charging voltage
Communications
LCD display
Visual indicators
Audible
Communication ports
Power management software
Special features
"Cold start” option
Auto charge
Environment
Operating temperature
Storage temperature
Relative humidity
Operating altitude
Audible noise
Physical appearance
Housing
Color
Dimensions
Weight
Additional information
Warranty
6000VA/6000W 10000VA/10000W 6000VA/6000W 10000VA/10000W
Double conversion
110-300VAC
176VAC / 140VAC / 110VAC ± 3%
(based on load percentage 100%-80% / 80%-60% / 60%-0%)
Low line transfer voltage + 10V
300VAC ± 3%
High line transfer voltage - 10V
46-54Hz at 50Hz system / 56-64Hz at 60Hz system
≥0.99 at 100% load
<4% at 100% load / <6% at 50% load
Hard wired
± 2% ± 1%
46-54Hz at 50Hz system / 56-64Hz at 60Hz system
50Hz ± 0.1Hz or 60Hz ± 0.1Hz
1
> 91% > 94%
> 90% > 92%
AC mode: 100%-110%: 10min / 110%-130%: 1min / >130%: 1sec
Battery mode: 100%-110%: 30sec / 110%-130%: 10sec / >130%: 1sec
0ms
0ms
3:1 (max)
≤2% THD (linear load) / ≤6% THD (non-linear load) ≤1% THD (linear load) / ≤4% THD (non-linear load)
Pure sine wave
Terminal block
12V / 9Ah (20)
7 hours to 90% capacity
1A ± 10% (max) standard model / 4A ± 10% (max) long-run model
273VDC ± 1%
Graphical LCD with blue backlight
Status LEDs
Battery mode: Sounds every 4 seconds
Low battery: Sounds every second
Overload: Sounds every 0.5 second
Fault: Continuous sound
SNMP, RS-232, USB
ForzaTracker
Included
Included
32°F-104°F
UPS: -5°F-140°F
Battery: 32°F-95°F
0 -90% non-condensing
<1000m
Every 100m above 1000m decreases output power 1% up to 4000m
<55dB at 1 meter
ABS and metal
Black
2 years
MPN FDC-106KMR FDC-110KMR FDC-206KMR FDC-210KMR
Standard operation: 208/220/230/240VAC
With step-down isolation transformer:
104/110/115/120VAC
Standard operation: 208/220/230/240VAC
With step-down isolation transformer:
104/110/115/120VAC
Even when utility power is normal, there is
no indication on the front panel and the
alarm has gone off.
The icon and the warning code blink
on the LCD display, and the alarm starts
beeping once every second.
The and icons become illuminated
on the LCD display, and alarm starts
beeping once every second.
The and icons blink on the LCD
display, and the alarm starts beeping twice
every second.
Fault code 43 becomes illuminated along
with the icon on the LCD display, and
the alarm starts beeping continuously.
Fault code 14 becomes illuminated along
with the icon on the LCD display, and
the alarm starts beeping continuously.
Fault code 01, 02, 03, 04, 11, 12, 13, 14,1A,
21, 24, 35, 36, 41, 42 or 43 become
illuminated on the LCD display, and alarm
starts beeping continuously.
Battery backup time is shorter than its
nominal value.
The AC input cable is not properly
connected.
EPO function is enabled.
The external or internal battery connection
is incorrect.
UPS is overloaded.
UPS is overloaded. Devices connected to
UPS are fed directly with utility power
through Bypass
After repetitive overloads, the UPS is
locked in Bypass mode.
Connected devices are fed directly from
utility power.
The UPS malfunctions due extended
system overload.
The UPS will shut down automatically.
The UPS shuts down automatically
because the output is short circuited.
A UPS internal fault has occurred. There
are twopossible causes:
1. Power is continued to be supplied to
the load, but is done directly from the AC
grid via a bypass.
2. Power is no longer supplied to the load.
Batteries are not fully charged
Defective batteries
Check to make sure the power cord is
firmly connected to the AC mains outlet.
Set the circuit in its closed position to
disable the EPO function.
Check if all batteries are properly
connected.
Remove excess loads from the UPS
output.
Remove excess loads from the UPS
output.
Remove excess loads from the UPS
output first. Then shut down the UPS and
restart the unit once again.
Remove excess loads from the UPS
output and restart the unit once again.
Check the output wiring and if the
connected devices are short-circuited.
Contact the dealer or service center.
Charge the batteries for at least 7 hours
and then check their capacity.
If the problem persists, consult your
dealer.
Contact your dealer for a replacement.
Symptom Possible cause Solution
-25°C - 40°C
40°C - 45°C
Every 3 months
Every 2 months
1-2 hours
1-2 hours
Storage temperature Recharge frequency Runtime
5. Storage and maintenance
5-1. Storage
4. Troubleshooting guide
If the UPS system does not operate correctly, use the table below to troubleshoot the problem.
Charge the UPS for at least 7 hours before storing the unit. Cover the UPS, and place it upright in a cool, dry location. During
storage, recharge the battery in accordance with the following table:
5-2. Maintenance
The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified maintenance personnel.
Even after the unit is disconnected from the mains, components inside the UPS system are still connected to the battery packs
which are potentially dangerous.
Before carrying out any kind of service and/or maintenance, disconnect the batteries and verify that no current is present and no
hazardous voltage exists in the terminals of high capability capacitor such as BUS-capacitors.
Servicing of batteries should be performed or supervised by personnel with knowledge of batteries and the required precau-
tions. Keep unauthorized personnel away from batteries.
Verify that no voltage between the battery terminals and the ground is present before maintenance or repair. In this product, the
battery circuit is not isolated from the input voltage. Hazardous voltages may occur between the battery terminals and the
ground.
A battery can present a risk of electric shock and high short circuit current. The following precaution should be observed when
working on batteries:
- Remove watches, rings or other metal objects.
- Use tools with insulated handles.
Replace batteries with the same type and number of units.
Do not attempt to dispose of batteries by burning them. This could cause battery explosion. The batteries must be properly
deposed according to local regulations.
Do not open or destroy batteries. Released electrolyte is highly poisonous and harmful to the skin and eyes.
Replace the fuse only with the same type and amperage in order to avoid fire hazards.
Do not disassemble the UPS system.

General
Capacity
Topology
Input
Nominal voltage
Voltage range (low line transfer)
Voltage range (low line comeback)
Voltage range (high line transfer)
Voltage range (High Line comeback)
Frequency
Power factor
Total harmonic distortion (THDi)
AC plug style
Output
Nominal voltage
AC voltage regulation (battery mode)
Frequency (synchronized range)
Frequency (battery mode)
Power factor
Efficiency (AC mode)
Efficiency (battery mode)
Overload
Transfer time (line to battery)
Transfer time (inverter to bypass)
Crest ratio
Harmonic distortion
Waveform
Type of outlet
Battery pack (included)
Battery type and quantity
Recharge time
Charging current
Charging voltage
Communications
LCD display
Visual indicators
Audible
Communication ports
Power management software
Special features
"Cold start” option
Auto charge
Environment
Operating temperature
Storage temperature
Relative humidity
Operating altitude
Audible noise
Physical appearance
Housing
Color
Dimensions
Weight
Additional information
Warranty
6000VA/6000W 10000VA/10000W 6000VA/6000W 10000VA/10000W
Double conversion
110-300VAC
176VAC / 140VAC / 110VAC ± 3%
(based on load percentage 100%-80% / 80%-60% / 60%-0%)
Low line transfer voltage + 10V
300VAC ± 3%
High line transfer voltage - 10V
46-54Hz at 50Hz system / 56-64Hz at 60Hz system
≥0.99 at 100% load
<4% at 100% load / <6% at 50% load
Hard wired
± 2% ± 1%
46-54Hz at 50Hz system / 56-64Hz at 60Hz system
50Hz ± 0.1Hz or 60Hz ± 0.1Hz
1
> 91% > 94%
> 90% > 92%
AC mode: 100%-110%: 10min / 110%-130%: 1min / >130%: 1sec
Battery mode: 100%-110%: 30sec / 110%-130%: 10sec / >130%: 1sec
0ms
0ms
3:1 (max)
≤2% THD (linear load) / ≤6% THD (non-linear load) ≤1% THD (linear load) / ≤4% THD (non-linear load)
Pure sine wave
Terminal block
12V / 9Ah (20)
7 hours to 90% capacity
1A ± 10% (max) standard model / 4A ± 10% (max) long-run model
273VDC ± 1%
Graphical LCD with blue backlight
Status LEDs
Battery mode: Sounds every 4 seconds
Low battery: Sounds every second
Overload: Sounds every 0.5 second
Fault: Continuous sound
SNMP, RS-232, USB
ForzaTracker
Included
Included
32°F-104°F
UPS: -5°F-140°F
Battery: 32°F-95°F
0 -90% non-condensing
<1000m
Every 100m above 1000m decreases output power 1% up to 4000m
<55dB at 1 meter
ABS and metal
Black
2 years
UPS unit: 37.5lb
Battery pack: 125.7lb
Step-down isolation transformer: 147.7lb
UPS unit [2U]: 23.6x17.2x3.5in
Battery pack [3U]: 23.6x17.2x5.2in
UPS unit: 37.5lb
Battery pack: 125.7lb
Step-down isolation
transformer: 147.7lb
UPS unit: 44.1lb
Battery pack: 138.9lb
Step-down isolation
transformer: 198.4lb
UPS unit: 37.5lb
Battery pack: 125.7lb
UPS unit: 44.1lb
Battery pack: 138.9lb
6. Technical specifications
General
Capacity
Topology
Input
Nominal voltage
Voltage range (low line transfer)
Voltage range (low line comeback)
Voltage range (high line transfer)
Voltage range (High Line comeback)
Frequency
Power factor
Total harmonic distortion (THDi)
AC plug style
Output
Nominal voltage
AC voltage regulation (battery mode)
Frequency (synchronized range)
Frequency (battery mode)
Power factor
Efficiency (AC mode)
Efficiency (battery mode)
Overload
Transfer time (line to battery)
Transfer time (inverter to bypass)
Crest ratio
Harmonic distortion
Waveform
Type of outlet
Battery pack (included)
Battery type and quantity
Recharge time
Charging current
Charging voltage
Communications
LCD display
Visual indicators
Audible
Communication ports
Power management software
Special features
"Cold start” option
Auto charge
Environment
Operating temperature
Storage temperature
Relative humidity
Operating altitude
Audible noise
Physical appearance
Housing
Color
Dimensions
Weight
Additional information
Warranty
6000VA/6000W 10000VA/10000W 6000VA/6000W 10000VA/10000W
Double conversion
110-300VAC
176VAC / 140VAC / 110VAC ± 3%
(based on load percentage 100%-80% / 80%-60% / 60%-0%)
Low line transfer voltage + 10V
300VAC ± 3%
High line transfer voltage - 10V
46-54Hz at 50Hz system / 56-64Hz at 60Hz system
≥0.99 at 100% load
<4% at 100% load / <6% at 50% load
Hard wired
± 2% ± 1%
46-54Hz at 50Hz system / 56-64Hz at 60Hz system
50Hz ± 0.1Hz or 60Hz ± 0.1Hz
1
> 91% > 94%
> 90% > 92%
AC mode: 100%-110%: 10min / 110%-130%: 1min / >130%: 1sec
Battery mode: 100%-110%: 30sec / 110%-130%: 10sec / >130%: 1sec
0ms
0ms
3:1 (max)
≤2% THD (linear load) / ≤6% THD (non-linear load) ≤1% THD (linear load) / ≤4% THD (non-linear load)
Pure sine wave
Terminal block
12V / 9Ah (20)
7 hours to 90% capacity
1A ± 10% (max) standard model / 4A ± 10% (max) long-run model
273VDC ± 1%
Graphical LCD with blue backlight
Status LEDs
Battery mode: Sounds every 4 seconds
Low battery: Sounds every second
Overload: Sounds every 0.5 second
Fault: Continuous sound
SNMP, RS-232, USB
ForzaTracker
Included
Included
32°F-104°F
UPS: -5°F-140°F
Battery: 32°F-95°F
0 -90% non-condensing
<1000m
Every 100m above 1000m decreases output power 1% up to 4000m
<55dB at 1 meter
ABS and metal
Black
2 years
MPN FDC-106KMR-ISO FDC-110KMR-ISO FDC-206KMR FDC-210KMR
Standard operation: 208/220/230/240VAC
With step-down isolation transformer:
104/110/115/120VAC
Standard operation: 208/220/230/240VAC
*Derate capacity to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
**If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be derated one percent per 100m.
***Product specifications are subject to change without further notice.
