1 O Ov ve er rv vi ie ew ws s
FOSCAM FI9802W is an integrated wireless IP Camera with a color CMOS sensor enabling
viewing resolution 1280*720. It combines a high quality digital video camera, with a powerful web
server, to bring clear video to your desktop from anywhere on your local network or over the
Internet.
FI9802W supports the industry-standard H.264 compression technology, drastically reducing file
sizes and conserving valuable network bandwidth.
The IPCAM is based on the TCP/IP standard. There is a WEB server inside which could support
Internet Explore. Therefore the management and maintenance of your device is simplified by
using the network to achieve the remote configuration and start-up.
The camera is designed for outdoor surveillance applications such as courtyards, supermarket,
and school. Controlling the IPCAM and managing images are simplified by using the provided
web interface across the network utilizing wireless connectivity.

3
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 3
1
1. .1 1 K Ke ey y F Fe ea at tu ur re es s
Standard H.264 video compression algorithm to satisfy the transmission of high definition
video in narrow bandwidth network
1.0 Mega-Pixel
Supports IE/Firefox/Google/Safari browser or any other standard browsers
Supports WEP,WPA and WPA2 Encryption
Wi-Fi compliant with wireless standards IEEE 802.11b/g/n
IR night vision (Range:50m)
Supports image snapshot
Supports dual-stream
Supports IR-Cut and the filter change automatically
Embedded FOSCAM DDNS(dynamic domain name service) Service
Supports remote viewing & record from anywhere anytime
Multi-level users management with password protection
Motion detection alert via email or upload image to FTP
Supporting Third Party Domain name
Supports multiple network protocols: HTTP /TCP /IP /UDP /FTP /DHCP /DDNS / UPNP
1
1. .2 2 R Re ea ad d B Be ef fo or re e U Us se e
Please first verify that all contents received are complete according to the Package Contents
listed below. Before the Network Camera is installed, please carefully read and follow the
instructions in the Quick Installation Guide to avoid damage due to faulty assembly and
installation. This also ensures the product is used properly as intended.
1
1. .3 3 P Pa ac ck ki in ng g C Co on nt te en nt ts s
● IPCAM×1
● CD×1
●Wi-Fi Antenna×1 (only available for wireless
model)
● Quick Installation Guide ×1
● DC Power Supply×1
●Warranty Card×1
● Mounting bracket×1(option)
●Network Cable×1

4
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 4
1
1. .4 4 P Ph hy ys si ic ca al l D De es sc cr ri ip pt ti io on n
Front Panel
Figure 1.1
1 WIFI Antenna: Wireless Antenna
2 Infrared LED: 36 IR LEDs
3 LENS: CMOS sensor with fixed focus lens
4 Induction IC
Interface
Figure 1.2
1）Reset button : Press and hold on the reset button for 5 seconds. Releasing the reset
button, the password will back to the factory default administrator password. The default
administrator user is admin with no password.
1
2
3
4
5
1
2
3
4

5
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 5
2）Audio input interface: The jack is used to plug external microphone.
3）Audio output interface:The jack is used to plug external speakers.
4）LAN: 10/100M adaptive Ethernet interface. Through this interface, IPCAM can be connected
with various network devices, such as hub, router, etc.
5）Power Interface: Connect the external power adapter, request for 12V/2A power.
Bottom View
There are up to three labels located at the bottom of the camera; this is an important feature of
original Foscam cameras. If your camera does not have labels as shown in Figure 1.3, it may be
a clone. Cloned Foscam cameras can not use original firmware and are not eligible for warranty
or technical services.
Figure 1.3
MAC address of wireless connection
MAC address of wired connection
FOSCAM DDNS Service
S/N Sticker of FOSCAM

6
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 6
2
2 S Su ur rv ve ei il ll la an nc ce e S So of ft tw wa ar re e G GU UI I
Please refer to the Quick Installation Guide if you install the camera at first time. After finishing
quick installation, you can take time to learn the operation of the software.
2
2. .1 1 L Lo og gi in n W Wi in nd do ow w
Figure 2.1
Please check the login window above, it was divided to 5 sections from no. 1 to 5.
Section1 Enter the User name and password
The default administrator username is admin with no password, please reset the password at
first using and prevent unauthorized users login the camera (read chapter 3.2.4 about how to
change).
Section2 Media port
The Media port is used to transfer video stream, and the default port no. is 888, you can reset the
port no. between 1 ~65535 on the Settings-NetworkPort page. The camera will obtain the
port no. automatically, you need not to fill it manually.
Section3 Stream
2
3
4
5
1

7
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 7
The camera supports two stream modes: Main stream and sub stream. If you want to access the
camera form LAN, here you can select Main stream. If you want to access the camera from
Internet, here we recommend sub stream.
Note: When the network bandwidth is badly you’d better select Sub Stream and the video will be
more fluency.
Section4 Select the language
You can select the language you need via click on the language dropdown list to switch.
Section5 Login the camera
Click Login button and you will see the surveillance windows.
Figure 2.2

8
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 8
2.2 Surveillance Window
Figure 2.3
Section1 FOSCAM Logo/ LiveVideo / Settings buttons
:FOSCAM LOGO
: Path to surveillance window. Click this button and back to the surveillance window
: Path to Administrator Control Panel, Click it, and it will lead to Administrator
Control Panel and do advanced settings.
Section2 Multi-Device Window
The firmware inside the camera supports up to maximum of 9 cameras being monitoring at the
same time. You can add other cameras in multi-camera panel (read chapter 3.2.5).
1
2
4
7
3
5
6

9
w
w
w
ww ww w. .f fo os sc ca am m. .c co om m
S
Sh he en nz zh he en n F Fo os sc ca am m I In nt te el ll li ig ge en nt t T Te ec ch hn no ol lo og gy y C Co o. ., , L Li im mi it te ed d
T
Te el l: : 8 86 6 7 75 55 5 2 26 67 74 4 5 56 66 68 8 F Fa ax x: : 8 86 6 7 75 55 5 2 26 67 74 4 5 51 16 68 8 9
Figure 2.4
Section3 Mode/ Stream / Mirror/ Flip buttons
Mode
1) 50HZ ---------Indoor surveillance (Region: Europe, China)
2) 60HZ ---------Indoor surveillance (Region: USA, Canada)
Stream
The default Stream supports four modes: 0/720P/30fps/2M, 1/VGA/25fps/2M, 2/VGA/ 15fps/ 1M
and 3/ VGA/10fps/200 The format of the stream type is Stream type no. / Resolution /
Maximum frame rate/ Bit rate
1) Stream type no. : The number is used to identify the stream type.
2) 720P/ VGA
There are two resolutions, the bigger one is 720P, and the smaller one (VGA) is 640x480 pixels.
The bigger the resolution, the better of the image quality is. If you are accessing the camera via
internet and want to get more fluent video streaming, please select resolution VGA.
3) Maximum frame rate
When the video format is 50Hz, the maximum frame rate is 25 fps. When the video format is
60Hz, the maximum frame rate is 30 fps. You should lower frame rate when the bandwidth is
limited. Normally, when the frame rate above 15, you can achieve fluently video.
4) Bit rate
Generally speaking, the larger the bit rate is, the clearer video will become. But the bit rate
configuration should combine well with the network bandwidth. When the bandwidth is very
