Four-Faith F8314 User manual

F8X14 Series
User Manual
Documentation No. Product Version Page
Product Name： Total:
F
FF
F8
88
8X
XX
X1
11
14
44
4 S
SS
Series
erieseries
eries User Manual
User ManualUser Manual
User Manual
The user manual is suitable for the following model:
Model
Product Type
F8114 ZigBee + GPRS IP MODEM
F8214 ZigBee + CDMA IP MODEM
F8314 ZigBee + EDGE IP MODEM
F8414 ZigBee + WCDMA IP MOEM
F8514 ZigBee + TD-SCDMA IP MOEM
F8614 ZigBee + EVDO IP MOEM
Xiamen Four
Xiamen FourXiamen Four
Xiamen Four-
--
-Faith Communication Technology Co., Ltd.
Faith Communication Technology Co., Ltd.Faith Communication Technology Co., Ltd.
Faith Communication Technology Co., Ltd.
Add ：
：：
： J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,C ina Zip Code:361008
Tel ：
：：
： [phone] ，
，，
， 6300325 ，
，，
， 6300324
Fax:[phone]
ttp://www.fourfait .com

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Files Revised Record
Files Revised RecordFiles Revised Record
Files Revised Record
Date Version Remark Author
2011.04.19 V0.5 Draft Tracy.zheng
2011.06.28 V0.6
Modification Tracy.zheng
2011.07.14 V0.7
Modification Tracy.zheng

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 3 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Copyright Notice
All content in the file are protected by copyright law, and all copyright are re erved by Xiamen
Four-Faith Communication Technology Co., Ltd. Without written permi ion, all commercial
u e of the file from Four-Faith are forbidden, uch a copy, di tribute, reproduce the file , etc.,
but non-commercial purpo e, downloaded or printed by individual (all file hall be not revi ed,
and the copyright and other proprietor hip notice hall be re erved) are welcome.
Trademark Notice
Four-Faith 、四信、 、 、 are all regi tered trademark of Xiamen
Four-Faith Communication Technology Co., Ltd., illegal u e of the name of Four-Faith,
trademark and other mark of Four-Faith i forbidden, unle written permi ion i authorized in
advance.

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
C
Co on nt te en nt t
Chapter 1 Brief Introduction of Product ........................................................................................... 6
1.1 General ................................................................................................................................ 6
1.2 Feature and Benefit .......................................................................................................... 6
1.3 Working Principle ............................................................................................................... 7
1.4 Specification ...................................................................................................................... 8
Chapter 2 In tallation Introduction ................................................................................................. 12
2.1 General .............................................................................................................................. 12
2.2 Enca ement Li t ................................................................................................................ 12
2.3 In tallation and Cable Connection .................................................................................... 12
2.4 Power ................................................................................................................................ 15
2.5 Indicator Light Introduction ............................................................................................ 15
Chapter 3 Configuration .................................................................................................................. 16
3.1 Configuration Connection ................................................................................................. 16
3.2 Configuration Introduction................................................................................................ 16
3.3 Run the configure Tool: IP Modem Configure.exe ........................................................... 17
3.4 Re-power IP MODEM ...................................................................................................... 18
3.5 Configuration .................................................................................................................... 18
3.5.1 Data Service Center Setting .................................................................................. 18
3.5.2 IP MODEM Setting .............................................................................................. 21
3.5.3 Other Setting ......................................................................................................... 26
3.5.4 Scheduled Power ON/OFF Setting ........................................................................ 29
3.5.5 ZigBee Setting ..................................................................................................... 38
3.6 Function ........................................................................................................................... 41
3.7 Work State Switch ............................................................................................................. 43
Appendix ......................................................................................................................................... 45

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Chapter 1 Brief Introduction of Product
1.1 General
1.2 Features and Benefits
esign for Industrial Application
 High-powered indu trial cellular module
 High-powered indu trial ZigBee module
 High-powered indu trial 32 bit CPU
 Support low power con umption mode, including multi- leep and trigger mode to reduce the
power di ipation farthe t
 Embedded Real Time Clock(RTC) circuit which can realize timing online/offline function
 Hou ing: iron, providing IP30 protection
 Power range: DC 5~35V
Stability and Reliability
F8X14 IP MODEM i a kind of data terminal device that provide data tran fer function by
public cellular network and ZigBee network.
It adopt high-powered indu trial 32 bit CPU and embedded real time operating y tem. It
upport RS232, RS485 (or RS422) and ZigBee port that can conveniently and tran parently
connect one device to a cellular network, allowing you to connect to your exi ting erial and
ZigBee device with only ba ic configuration. It ha low power con umption tate in which the
power con umption could be 1ower than 1mA@12VDC. It ha compatible digital I/O channel,
ADC, input pul e counter and pul e wave output function.
It ha been widely u ed on M2M field , uch a intelligent tran portation, mart grid,
indu trial automation, telemetry, finance, POS, water upply, environment protection, po t,
weather, and o on.

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
 Support hardware and oftware WDT
 Support auto recovery mechani m, including online detect, auto redial when offline to make
it alway online
 RS232/RS485/RS422 port: 15KV ESD protection
 SIM/UIM port: 15KV ESD protection
 Power port: rever e-voltage and overvoltage protection
 Antenna port: lightning protection(optional)
Standard and Convenience
 Adopt terminal block interface, convenient for indu trial application
 Support tandard RS232 and RS485(or RS422) port that can connect to erial device directly
 TTL logic level RS232 interface can be cu tomized
 Support intellectual mode, enter into communication tate automatically when powered
 Provide management oftware for remote management
 Support everal work mode
 Convenient configuration and maintenance interface
High-performance
 Support data tran fer by cellular and ZigBee network
 Support TCP erver and upport multi TCP client connection(optional)
 Support double data center , one main and another backup
 Supply 5 I/O channel , compatible 2 pul e wave output channel , 2 analog input and one
pul e input counter .
 Support multi data center and it can upport 5 data center at the ame time
 Support multi online trigger way , including SMS, ring and data. Support link di connection
when timeout
 Support dynamic domain name(DDNS) and IP acce to data center
 De ign with tandard TCP/IP protocol tack
 Support APN/VPDN
1.3 Working Principle
The principle chart of the IP MODEM i a following:

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
1.4 Specifications
Cellular Specification
F8114 Specification
Item Content
Cellular Module Indu trial cellular module
Standard and Band EGSM900/GSM1800MHz,
GSM850/900/1800/1900MHz(optional)
Compliant to GSM pha e 2/2+
GPRS cla 10, cla 12(optional)
Bandwidth 85.6Kbp
TX power GSM850/900: <33dBm
GSM1800/1900: <30dBm
RX en itivity <-107dBm
F8214 Specification
Item Content
Cellular Module Indu trial cellular module
Standard and Band CDMA2000 1xRTT 00MHz
CDMA 00/1900MHz(optional)
CDMA450MHz(optional)
Bandwidth 153.6Kbps
TX power <30dBm
RX en itivity <-104dBm
F8314 Specification
Item Content
Cellular Module Indu trial cellular module
Standard and Band GSM 50/900/1 00/1900MHz
GPRS/EDGE Class 12
Cellular
Module
MCU
Antenna
SIM/UIM
Interface
Indicator
Light
SRAM&
FLASH
WDT Module
RTC Module
U er Interface
RS232/RS485/RS422
Module
Power Module

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Bandwidth 236. Kbps
TX power GSM 50/900 ： <33dBm
GSM1 00/1900 ： <30dBm
RX en itivity <-106dBm
F8414 Specification
Item Content
Cellular Module Indu trial cellular module
Standard and Band UMTS/WCDMA/HSDPA/HSUPA 50/1900/2100MHz
UMTS/WCDMA/HSDPA/HSUPA 50/900/1900/2100MHz(optional)
GSM 50/900/1 00/1900MHz
GPRS/EDGE CLASS 12
Bandwidth HSUPA: 5.76Mbps( 上行 ) / HSDPA: 7.2Mbps( 下行 )/UMTS: 3 4Kbps (DL/UL)
TX power <24dBm
RX en itivity <-109dBm
F8514 Specification
Item Content
Cellular Module Indu trial cellular module
Standard and Band TD-SCDMA/HSDPA/HSUPA 1880-1920/2010-2025MHz
GSM850/900/1800/1900MHz 四频
GPRS/EDGE CLASS 12
Bandwidth 2. Mbps(down) ， 2.2Mbps(up)
TX power <24dBm
RX en itivity <-10 dBm
F8614 Specification
Item Content
Cellular Module Indu trial cellular module
Standard and Band CDMA2000 1X EVDO Rev A 800MHz
CDMA2000 1X EVDO Rev A 800/1900MHz (optional)
CDMA2000 1X EVDO Rev A 450MHz (optional)
IS-95 A/B 、 CDMA2000 1xRTT
Bandwidth 3.1Mbps(down) ， 1. Mbps(up)
TX power <23dBm
RX en itivity <-104dBm
ZigBee Specification
Item Content
ZigBee Module Indu trial ZigBee module
Standard and Band IEEE 802.15.4
ISM 2.4 GHz
Indoor/Urban Range 60m
90m(for enhanced ver ion)
Outdoor/RF Line-of-Sight 100m

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Range 800m(for enhanced ver ion)
Tran mit Power 0dBm
22dBm (for enhanced ver ion)
Bandwidth 250Kbp
Receiver Sen itivity -95dBm
-104dBm(for enhanced ver ion)
Network Topologie Point-to-Point, Point-to-Multipoint, Peer-to-Peer and Me h
Number of channel 16 Direct Sequence Channel
15 Direct Sequence Channel (for enhanced ver ion)
Channel 11 to 26
11 to 25 (for enhanced ver ion)
Max packge ize 100Byte (on Broadca t workmode)
1024 Byte (on Ma ter-Client and Accord workmode)
Hardware System
Item Content
CPU Indu trial 32 bit CPU
FLASH 512KB(Extendable)
SRAM 256KB(Extendable)
Interface Type
Item Content
Serial 1 RS232 port and 1 RS485(orRS422) port, 15KV ESD protection
Data bit : 5, 6 ,7, 8
Stop bit : 1, 1.5, 2
Parity: none, even, odd, pace, mark
Baud rate: 110~230400 bp
Indicator "Power", "ACT", "Online"
“ ZigBee ”
Antenna Cellular: Standard SMA female interface, 50 ohm
GPS: Standard SMA female interface, 50 ohm
lighting protection(optional)
SIM/UIM Standard 3V/1.8V u er card interface, 15KV ESD protection
Power Terminal block interface, rever e-voltage and overvoltage protection

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Power Input
Item Content
Standard Power DC 12V/0.5A
Power Range DC 5~35V
Power Consumption
Working State Power Con umption
Communication 50-90mA@12VDC
； 115-165mA@5VDC
Standby 25mA@12VDC
； 45mA@5VDC
Sleep 8mA@12VDC
； 18mA@5VDC
Timing Power
Off
0.6mA@12VDC ； 1mA@5VDC
Physical Characteristics
Item Content
Hou ing Iron, providing IP30 protection
Dimen ion 91x58.5x22 mm
Weight 210g
Environmental Limits
Item Content
Operating
Temperature
-25~+65ºC （ -13~+149 ℉）
Extended
Operating
Temperature
-30~+75ºC （ -22~+167 ℉）
Storage
Temperature
-40~+85ºC （ -40~+185 ℉）
Operating
Humidity
95% ( Non-conden ing)

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Chapter 2 Installation Introduction
2.1 General
The IP MODEM mu t be in talled correctly to make it work properly.
Warning: Forbid to in tall the IP MODEM when powered!
2.2 Encasement List
Name Quantity Remark
IP MODEM ho t 1
2.4G ZigBee Antenna 1
Cellular Antenna 1
Power adapter 1
RS232 data cable 1 optional
RS485 data cable 1 optional
Manual CD 1
Certification card 1
Maintenance card 1
Table 2-1 Encasement List
2.3 Installation and Cable Connection
imension : (unit: mm)

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
58.5
35
28
28
22 8
25
Ф3
Ф5
4
Figure 2-1 Installation Chart
Installation of SIM/UIM card:
Fir tly power off the IP MODEM, and pre the out button of the SIM/UIM card outlet with a
needle object. Then the SIM/UIM card heath will flick out at once. Put SIM/UIM card into the
card heath (Pay attention to put the ide which ha metal point out ide), and in ert card heath
back to the SIM/UIM card outlet.
Warning: Forbid to in tall SIM/UIM card when powered!
Installation of antenna:
Screw the SMA male pin of the antenna to the female SMA outlet of the IP MODEM tightly.
Warning: The antenna mu t be crewed tightly, or the ignal quality of antenna will be influenced!
User Interface Signal efinition
Pin Number Signal Name Default Function Exten ible Function
1 PWR Power input anode N/A
2 GND Power Ground N/A
3 GND Power Ground N/A
4 RX RS232 RX N/A
5 TX RS232 TX N/A
6 A RS485 anode Re erved compatible DTR
7 B RS485 cathode Re erved compatible DSR
8 IO1 GPIO Re erved compatible RTS and
RS232 RX (TTL logic level)
9 IO2 GPIO Re erved compatible CTS and
RS232 TX (TTL logic level)
10 IO3 GPIO Re erved compatible DCD

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
11 IO4 GPIO Re erved compatible RI,ADC,
and pul e output
12 IO5 GPIO Re erved compatible pul e wave
input counter, ADC, and pul e
output
Installation of cable:
F8X14 adopt indu trial terminal block interface. The recommendatory cable i 28-16AWG.
The detail de cription of tandard layout adapter and communication cable a i following:
Adapter （ Rating Output 12VDC/0.5A ）：
Cable Color Power Output Polarity
Black &White Alternate Anode
Black Cathode
RS232 Cable ：
Cable Color Corresponding B9-M Pin Number
Brown Pin 2
Blue Pin 3
Black Pin 5
RS485 Cable ：
Cable Color Signal definition
Red RS485(A)
Black RS485(B)

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Power adapter and communication cable connection chart a following:
2.4 Power
The power range of the IP MODEM i DC 5 ~ 35V
Warning: When we u e other power, we hould make ure that the power can upply power
above 4W.
We recommend u er to u e the tandard DC 12V/0.5A power adaptor.
2.5 Indicator Lights Introduction
The IP MODEM provide three indicator light : “Power”, “ACT”, “Online”.
Indicator
Light
State Introduction
Power ON IP MODEM i powered on
OFF IP MODEM i powered off
ACT BLINK Data i communicating
OFF No data
Online ON IP MODEM ha logged on network
OFF IP MODEM ha n’t logged on network
ZigBee ON ZigBee Tran port data
OFF No data
Communication Interface: RS232 Communication Interface: RS485
F8X14 Terminal
Block Interface
User evice
( B9M) User evice
1
2
3
4
5
6
7
8
9
10
11
12
RX
GND
TX
A
B
IO1
IO2
IO3
IO4
PWR
GND
IO5
+ Anode
- Cathode
A
B
F8X14 Terminal
Block Interface
1
2
3
4
5
6
7
8
9
10
11
12
RX
GND
TX
A
B
IO1
IO2
IO3
IO4
PWR
GND
IO5
1
2
3
4
5
6
7
8
9
GND
TX
RX
+ Anode
- Cathode
RX

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Chapter 3 Configuration
3.1 Configuration Connection
Before configuration, It’ nece ary to connect the IP MODEM with the configure PC by the
hipped RS232 or RS232-485 conver ion cable a following.
3.2 Configuration Introduction
There are two way to configure the IP MODEM:
Configuration oftware tool: All the etting are configured through the hipped oftware tool.
It’ nece ary to have one PC to run thi tool.
Extended AT command: All the etting are configured through AT command, o any device
with erial port can configure it. Before configuration with extended AT command, you hould
make IP MODEM enter configure tate. The tep how to make IP MODEM enter configure
tate, plea e refer to appendix.
The following de cribe how to configure IP MODEM with the configure oftware tool. At the
ame time, it give out the corre ponding AT command of each configuration item.

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
3.3 Run the configure Tool: IP Modem Configure.exe
The “Serial Parameter ” column how the current erial port etting . To configure IP
MODEM, plea e choo e the correct erial port which connect to IP MODEM, and the baud-rate
i 115200 with no parity, then open the erial port. If the button text i “Clo e”, it how the erial
port now ha been opened. If the text i “Open”, you hould open the port fir t. When the port
opened, the “Output Info” column will di play
“Port(COM1) Ha Opened Plea e Re-Power the IP MODEM,
Waiting IP MODEM Enter Configure State...”

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
3.4 Re-power IP MO EM
After Re-power IP MODEM, The configure tool will make it enter configure tate. At the
ame time, the oftware will load current etting from IP MODEM and di play on the right
configure column . It’ now ready to configure.
3.5 Configuration(F8114 for example)
3.5.1 ata Service Center Settings
Setting on thi page are the parameter related to Data Service Center (DSC).
◆ Data Center Number
IP MODEM upport two Data Service Center method to tran mit data.
Main and Backup: IP MODEM alway trie to connect with the Main DSC. If fail to connect
with Main DSC, it will connect with Backup DSC at once
Note ： If no Backup DSC exi t , plea e configure the Backup DSC ame a Main DSC.

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
Multi ata Service Center: IP MODEM can connect with at mo t five DSC at the ame time.
All the multi DSC can receive the ame application data .
If the Data Center Number i 0,there i no DSC working.
If the Data Center Number i 1, IP MODEM work in Main and Backup DSC method.
When “Data Center Number” i greater than 1, IP MODEM work in Multi Data Service Center
method
GPS data tran mi ion DSC i elf-governed. Setting detail plea e reference the ection 3.5.5.
AT command:
AT+SVRCNT=x
x: Data Service Center number
Note: every AT command i terminated with a enter character.
◆ Main Center Addr+Port:
IP Addre and Port of the Main DSC, It’ better to et the port greater than 1024.
AT command of the Main DSC IP addre or domain name:
AT+IPAD=xxx
xxx: The IP addre or domain name.
AT command of the Main DSC port:
AT+PORT=xxx
xxx: The port value
◆ Backup Center Addr+Port:
IP addre and port of the Backup DSC
AT command of the Backup DSC IP addre or domain
AT+IPSEC=xxx
xxx: The IP addre or domain name
AT command of the Backup DSC port
AT+PTSEC=xxx
xxx: The port value
◆ Multi DSC Configuration

U er Manual
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 48
Add ： J1-J3,3
rd
Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .36100 .China
http ： //www.fourfaith.com Tel ： [phone] 6300325 6300324 Fax ： [phone]
When “Data Center Number” i greater than 1, thi etting i valid. For example etting the
“Data Center Number” a 3, Main Center, 2nd Center, 3rd Center work a the e three DSC
AT Command of the 2~5 DSC IP addre or domain name
AT+IPADn=xxx
n i 1~4 corre pond to center 2~5
xxx: The IP addre or domain name
AT Command of the 2~5 DSC port
AT+PORTn=xxx
n i 1~4 corre pond to port of center 2~5
xxx: The port value
Example:
Set IP addre of center 3 a 166.111.8.238, and port 5001, the AT command i a following:
AT+IPAD2=166.111.8.238
AT+PORT2=5001
◆ Main and Backup Center DNS Server
When the DSC Internet acce u e domain name, It’ nece ary to et DNS erver re olving the
DSC domain name. When the Data Center Number i 1, Main and Backup Center DNS Server i
u ed to re olve the Main center and Backup center corre pondingly.
AT command of Main Center DNS erver:
AT+DNSSVR=aaa.bbb.ccc.ddd
aaa.bbb.ccc.ddd: The DNS erver IP addre (mu t be IP addre ） .
AT command of Backup Center DNS erver:
AT+DNSSV2=aaa.bbb.ccc.ddd
