Framery Q (UL) Flip 'n Fold
Contents
1 Important safety and product instructions............................................... 5
1.1 Preface....................................................................................................................5
1.2 Copyright.................................................................................................................5
1.3 Product information................................................................................................ 5
1.4 Manual contents..................................................................................................... 5
1.5 Intended use...........................................................................................................5
1.5.1 Non-conventional use................................................................................. 5
1.5.2 Ambient conditions for use.........................................................................6
1.6 Warning, information, and safety symbols in this manual...................................... 6
1.7 Main safety risks related to the installation, maintenance, disassembly, and
use of the product.................................................................................................... 7
1.7.1 Installation, maintenance, and disassembly...............................................7
1.7.2 Electrical safety.......................................................................................... 7
1.7.3 Fire safety...................................................................................................8
1.7.4 Use..............................................................................................................9
1.8 Location of Product Markings...............................................................................11
2 Entering the pod........................................................................................13
3 Folding the table and the seats............................................................... 15
4 Connecting electrical equipment............................................................. 16
5 Exiting the pod.......................................................................................... 18

Framery Q (UL) Flip 'n Fold

Framery Q (UL) Flip 'n Fold
1 Important safety and product instructions
1.1 Preface
This instruction manual describes the use of the product. Everyone involved in using the
product must read and understand the contents of the user and safety instructions.
This instruction manual gives you necessary information for the correct use.
All product instructions are also available at help.frameryacoustics.com.
1.2 Copyright
This document must not be copied, presented, or delivered to a third party without explicit
permission from Framery. The use of this document for any purpose other than those
allowed by Framery is prohibited. Framery reserves the right to change the instructions
related to the product without separate notice.
1.3 Product information
The information in this manual corresponds to the product at the time of delivery. All
information included in this manual is valid at the time of publication.
1.4 Manual contents
The user instructions contain the following information:
• General information about the purpose and content of the instructions
• Information related to safety
• User instructions
1.5 Intended use
The Framery Q is a pod intended for short term indoor commercial and household use by
one to four (1-4) people at a time.
Warning: WARNING –To reduce the risk of burns, fire, electric shock, or injury to
persons:
Use this product only for its intended use as described in the user instructions. Do not use
attachments not recommended by the manufacturer.
1.5.1 Non-conventional use
Any use or maintenance of the product that is not specifically allowed in the installation,
maintenance, troubleshooting or user instructions is prohibited, including the following:
• Installation, maintenance or disassembly of the pod without reading and understanding
the instructions for those actions
• Use of the pod beyond the limits of use
User instructions
[email protected]
5

Framery Q (UL) Flip 'n Fold
• Making alterations to the pod
• Using the pod in spite of obvious defects or damage
• Using the pod outdoors or in conditions where the temperature or air quality is not safe
• Climbing on top of the product or placing any load on the roof of the product
• Smoking in the pod
1.5.2 Ambient conditions for use
The pod is intended to be used in the following conditions:
• Ambient temperature: +15°C ... +30°C (59°F ... 86°F)
• Humidity: max. 50%
• Sufficient air quality surrounding the product
1.6 Warning, information, and safety symbols in this manual
The warnings in this manual have been divided into the following two categories:
• The term "DANGER" indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
• The term “WARNING” indicates a hazardous situation which, if not avoided, could result
in death or injury.
The safety symbols found in this manual may also be posted on the product. All personnel
who install, disassemble, perform maintenance, or use the product are to be familiar
with and observe all safety symbols, labels, and instructions about the action they are
performing.
Table 1: Hazard
An exclamation point symbol inside a colored triangle indicates a hazardous
situation.
Table 2: Mandatory action
A white symbol inside a colored circle indicates an action that must be taken to
avoid a hazardous situation.
Table 3: Prohibited action
A ring with a diagonal bar indicates an action that is not allowed.
6User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
1.7 Main safety risks related to the installation, maintenance, disassembly,
and use of the product
1.7.1 Installation, maintenance, and disassembly
WARNING!
To reduce the risk of burns, fire, electric shock, or injury to persons, obey
the following:
Use cut resistant safety gloves during the installation, maintenance, or
disassembly of the product.
Use steel toed safety boots during the installation, maintenance, or disassembly
of the product.
Use safety glasses during the installation, maintenance, or disassembly of the
product.
Read and understand the instructions and plan your work beforehand.
Obey all local rules and regulations regarding workplace safety.
Keep the work site tidy and free from debris throughout the installation,
maintenance, or disassembly process.
Do not climb on top of the product or place any load on the roof of the product.
Do not push the the finished product to move it without engaging the optional
casters.
The product is very heavy and moving the product after installation without
engaging the optional casters requires a significant amount of force. Moving
a finished product (not using the optional casters) without disassembly and
reassembly requires an on-site risk assessment to be performed by the party
responsible for moving the product.
1.7.2 Electrical safety
Input for the electrical system: 100-240 VAC (10 A) 50-60 Hz
The maximum load for the electrical system is 6.6 A.
User instructions
[email protected]
7

Framery Q (UL) Flip 'n Fold
DANGER!
To reduce the risk electric shock, obey the following:
Disconnect the power cord from the power outlet before starting any cleaning,
maintenance, or disassembly procedures.
The power cord serves as a power disconnect device for pluggable equipment.
The power outlet shall be located near the equipment and shall be easily
accessible.
WARNING!
To reduce the risk of burns, fire, electric shock, or injury to persons, obey
the following:
Connect the power cord to a properly grounded outlet only.
This product is for use on a nominal 120-volt circuit and has a grounding plug
that looks like the plug illustrated in the figure below. Make sure that the product
is connected to an outlet having the same configuration as the plug. No adapter
should be used with this product.
Keep the power cord of the product away from heated surfaces.
Do not use the pod if you notice any defects or damage to the electrical
equipment.
Do not connect any extension cords to the power outlet(s) of the product.
1.7.3 Fire safety
The fire load for the Framery Q is approx. 5200 MJ.
8User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
WARNING!
To reduce the risk of burns, fire, electric shock, or injury to persons, obey
the following:
If safely possible to perform, disconnect the power cord from the power outlet if
there is a fire inside the product.
The power cord serves as a power disconnect device for pluggable equipment.
The power outlet shall be located near the equipment and shall be easily
accessible.
Fire safety end devices (alarms, sprinklers etc.) can also be installed inside the pods
(instructions available upon request). The need for end devices inside the pod is always
determined by the applicable local authorities.
1.7.4 Use
Maximum loads for Framery Q Flip 'n' Fold table is 131 lb (60 kg).
Maximum load for the display bracket is 22 lbs (10 kg).
WARNING!
To reduce the risk of burns, fire, electric shock, or injury to persons, obey
the following:
Read and understand the user instructions before using the product.
Note: The following statement applies to use in Japan.
This equipment is not suitable for use in locations where children are likely to
be present.
Note: The following statements apply to use in all other countries.
Close supervision is necessary when this furnishing is used by, or near
children, invalids, or disabled persons.
Keep children away from extended foot support (or other similar parts).
Risk of injury! Keep hands and other body parts clear of the side edges of the
table when raising or lowering the electrically adjustable table top. This applies
to all Framery pods with an electric adjustable table.
Do not use the product if the surrounding conditions are in any way hazardous;
the air circulating inside the pod is derived from the surrounding space.
Do not use the product if the ventilation is not functioning.
User instructions
[email protected]
9

Framery Q (UL) Flip 'n Fold
Do not use the product if the ventilation channels are blocked. Keep the
ventilation channels free of lint, hair, and the like.
Do not use the pod if you notice any defects in the electrical equipment or if
the product is not working properly. Disconnect the power cord from the power
outlet and contact your local dealer or the manufacturer immediately.
Do not drop or insert any object into any opening if not specifically instructed to
do so in this manual.
Do not use outdoors.
Do not use where aerosol (spray) products are being used or where oxygen is
being administered.
Do not climb on top of the product or place any load on the roof of the product.
Do not lean against the product.
Do not smoke inside the product.
Do not obstruct the view through the front and back glasses by posting signs,
decorations, or by installing blinds or draperies that would prevent occupants
from seeing the visible alarm appliances located in the structure where the pod
is installed.
10 User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
1.8 Location of Product Markings
Position Label Label text
1. This furnishing has not been evaluated for
flammability or cigarette ignition resistance
L'inflammabilité ou la résistance à l'allumage d'une
cigarette n'a pas été évaluée pour cette garniture
User instructions
[email protected]
11

Framery Q (UL) Flip 'n Fold
Position Label Label text
2. Framery
MANUFACTURED / FABRICATION
Product / Produit FRAMERY Q FNF
Input / Entrée 100-240 VAC (10 A) 50-60 HZ
Manufacturer / Fabricant: Framery Oy
WEB: www.frameryacoustics.com Email:
[email protected] Made in Finland /
Fabriqué en Finlande
Attention! Always connect the product correctly
to a grounded socket to avoid danger for fire or
electrical shocks.
Product evaluated class A (ASTM E84 / UL 723)
Attention! Branchez toujours le produit dans
une prise reliée à la terre pour éviter tout risque
d’incendie ou de choc électrique.
Produit de classe A (ASTM E84 / UL 723)
3. SN / N° de série:
4. WARNING - Risk of fire and shock Use only ‘SJT’
type ‘16’ AWG cord
AVERTISSEMENT - Risque d’incendie et de
choc électrique, utiliser uniquement un cordon
d'alimentation ‘SJT’ de type ‘16’ AWG
5. Framery
WARNING Risk of injury Maximum table load 131
lbs / 60 kg
L'AVERTISSEMENT Risque de blessure Poids
maximal autorisé 131 lbs / 60 kg
SAVE THESE INSTRUCTIONS
12 User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
2 Entering the pod
1. Push the button outside the pod.
Note: The door can also be opened by pulling the handle.
2. Wait until the door is fully open.
User instructions
[email protected]
13

Framery Q (UL) Flip 'n Fold
3. Enter the pod.
4. Wait for the door to close automatically.
14 User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
3 Folding the table and the seats
1. Flip the the tabletop down.
2. Flip the seat down.
User instructions
[email protected]
15

Framery Q (UL) Flip 'n Fold
4 Connecting electrical equipment
1. To connect your device to the power outlet, connect one end of the cord to your device
and the other end to the suitable connector on the power outlet.
16 User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
2. To disconnect your device from the power outlet, disconnect one end of the cord from
your device and the other end from the suitable connector on the power outlet.
User instructions
[email protected]
17

Framery Q (UL) Flip 'n Fold
5 Exiting the pod
1. Push the button inside the pod.
Note: The door can also be opened by pushing at the handle.
2. Wait until the door is fully open.
18 User instructions
[email protected]

Framery Q (UL) Flip 'n Fold
3. Exit the pod.
The door closes automatically.
User instructions
[email protected]
19

Framery Q (UL) Flip 'n Fold
20 User instructions
[email protected]
