Franke A800 User manual

USER MANUAL
A800
FCS4050
en
Read the user manual before working on the machine.
Keep the manual with the machine and pass the manual on to the
next operator if the machine is sold or transferred to a third party.

Franke Kaffeemaschinen AG Table of contents
User manual A800 iii
TABLE OF CONTENTS
1For your safety 6
1.1 Intended use 6
1.2 Prerequisites for using the coffee machine 7
1.3 Explanation of safety instructions 7
1.4 Safety concerns when using the coffee machine 8
2Explanation of symbols 11
2.1 Symbols used in the manual 11
2.2 Symbols used in the software 11
3Scope of delivery 15
4Identification 17
4.1 Position of type plates 17
4.2 Type code 19
5Description of machine 21
5.1 Coffee machine 21
5.2 Add-on units 24
5.3 Overview of operating modes 26
5.4 Franke Digital Services (option) 28
6Installation 29
6.1 Preparations 29
6.2 Dimensions 29
6.3 Requirements of the water supply 31
7Filling and emptying 33
7.1 Filling beans 33
7.2 Filling powder 34
7.3 Filling the cooling unit 34
7.4 Filling the Flavor Station 36
7.5 Setting the grind coarseness 37
7.6 Emptying the bean hopper 39
7.7 Emptying the powder hopper 39
7.8 Emptying the grounds container 40
7.9 Emptying the cooling unit 41
7.10 Emptying the Flavor Station 43
8Preparing beverages 44
8.1 Preparing beverages with Quick Select 44
8.2 Preparing beverages with Cash Register 44
8.3 Preparing beverages with ground coffee 45
8.4 Preparing hot water 46

Table of contents Franke Kaffeemaschinen AG
iv User manual A800
8.5 Steam dispenser (Autosteam/Autosteam Pro) 47
8.6 Preparing beverages using the touchpad 47
9Cleaning 48
9.1 Introduction 48
9.2 Required cleaning accessories 48
9.3 5-step method 48
9.4 Starting the cleaning process 49
9.5 Cleaning the aerator 50
9.6 Weekly cleaning 50
9.7 Rinsing the coffee machine 52
10 Configuration 54
10.1 Calling up the maintenance level 54
10.2 PIN codes 54
10.3 My settings menu tree 54
10.4 Input methods 55
10.5 My settings 55
11 Individualization and data transfer 71
11.1 Overview 71
11.2 Individualization and data transfer menu tree 71
11.3 Multimedia functions 71
11.4 Manage Digital Signage via USB stick 72
11.5 Configure application 72
11.6 Loading/backing up data 76
11.7 Set default values 76
11.8 Activating configurations 76
12 Troubleshooting 78
12.1 Error messages 78
12.2 Troubleshooting the system 79
12.3 Tips for good coffee beverages 80
12.4 Help with problems concerning product quality 81
13 Decommissioning 82
13.1 Preparing for decommissioning 82
13.2 Back up data 82
13.3 Short-term decommissioning (up to 3 weeks) 82
13.4 Long-term decommissioning 82
13.5 Transport and storage 83
13.6 Recommissioning after prolonged periods of storage or non-use 83
14 Disposal of parts 84
15 Technical data 85

Franke Kaffeemaschinen AG Table of contents
User manual A800 v
15.1 Capacities in accordance with DIN 18873-2:2016-02 85
15.2 Electrical connection data 85
Index 87

1 | For your safety Franke Kaffeemaschinen AG
6 User manual A800
1 FOR YOUR SAFETY
1.1 Intended use
1.1.1 Coffee machine
– The A800 is a commercial machine for preparing beverages and is intended for use in food services,
offices and other similar environments.
– The A800 is designed to process whole coffee beans, ground coffee, powder that is suitable for auto-
matic devices, and fresh milk.
– The A800 is intended for the preparation of beverages in accordance with this manual and the techni-
cal data.
– The A800 is intended for operation indoors.
Please note
– The A800 is not suitable for use outdoors.
1.1.2 Add-on units
Cooling unit
– The cooling unit is intended exclusively to keep milk cool for the preparation of coffee drinks with a
Franke coffee machine.
– Only use precooled milk (2-5°C).
– Remove the milk when the cooling unit is not in use. Store the milk in a suitable refrigerator.
– Use only the recommended cleaners. Other cleaners may leave residues in the milk system.
– The cooling unit is intended exclusively for operation indoors.
– Please also observe the Declaration of Conformity delivered with the device.
Flavor Station
– The Flavor Station is intended exclusively for the automatic conveyance of syrups and other fluid aro-
mas for the preparation of drinks.
Please note
– The Flavor Station is not designed to pump viscous fluids such as chocolate sauce.
– The Flavor Station is not suitable for the storage of alcoholic or explosive substances.
Cup warmer
– The cup warmer is intended only for preheating coffee cups and glasses used when preparing drinks.
Please note
– Drinking containers made of paper or plastic must not be used. The cup warmer is not designed to dry
dish towels or other cloths. It is not necessary to cover the cups to warm them.
Accounting system
– Depending on the version, the accounting system can be used for various methods of payment. Exam-
ples: Payment with coins, cards, or mobile payment systems.

Franke Kaffeemaschinen AG For your safety | 1
User manual A800 7
1.2 Prerequisites for using the coffee machine
– The A800 is intended for use by trained personnel or as a self-service machine.
– Self-service machines must always be monitored to protect the users.
– Each operator of the A800 must have read and understood the manual. This does not apply to its use
in the self-service area.
– Do not operate the A800 or add-on units until you have completely read and understood this manual.
– Do not use the A800 or add-on units if you are not familiar with the various functions.
– Do not use the A800 if the connection lines of the A800 or the add-on units are damaged.
– Do not use the A800 unless the A800 or the add-on units have been cleaned or filled as intended.
– Children under the age of 8 are not permitted to use the A800 and the add-
on units.
– Children or persons with restricted physical, sensory or mental abilities, or
lack of experience and knowledge, may only use the A800 and the add-on
units under supervision or after adequate instruction by a person responsible
for their safety; they are not permitted to play with the A800 and the add-on
units.
– Children are not permitted to clean the A800 and the add-on units.
1.3 Explanation of safety instructions
To ensure personal safety and the protection of material goods, observation of these safety instructions is
imperative.
Symbol and signal word indicate the severity of the hazard.
WARNING
WARNING indicates a potential danger. DANGER indicates an imminent danger which, if
not avoided, will result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE
NOTICE directs your attention to the risk of damage to machinery.

1 | For your safety Franke Kaffeemaschinen AG
8 User manual A800
1.4 Safety concerns when using the coffee machine
WARNING
Risk of fire
If the power cord is electrically overloaded, the heat generated can cause a fire.
a) Never use power outlet strips, multi-sockets or extension cords to connect the coffee machine to the
power supply.
WARNING
Risk of fatal injury from electrocution
Damaged power cords, pipes or plugs can lead to electrocution.
a) Do not connect any damaged power cords, pipes or plugs to the power grid.
b) Replace damaged power cords, pipes or plugs.
If the power cord is permanently assembled, contact the service technician. If the power cord is not
permanently assembled, order and use a new, original power cord.
c) Ensure that the machine/appliance and the power cord are not near any hot surfaces such as gas or
electric stoves or ovens.
d) Ensure that the power cord is not pinched and does not chafe on sharp edges.
e) Only pull on the plug and not on the cable when disconnecting the device from the power grid.
WARNING
Risk of fatal injury from electrocution
Liquid/moisture entering the machine or leaks can lead to electrocution.
a) Never point a liquid or steam jet at the machine.
b) Do not pour any liquids on the machine.
c) Do not immerse the machine in liquid.
d) Disconnect the machine from the power supply in the event of a leak or if liquid/moisture enters the
machine.
WARNING
Risk of fatal injury from electrocution
Work, repairs or servicing improperly performed on electrical systems can lead to electrocution.
a) Have repairs on electrical parts carried out by service technicians using original spare parts.
b) Have servicing carried out by authorized persons with corresponding qualification only.
WARNING
Risk of scalding
Hot water is released during rinsing.
a) Keep hands away from the spouts and nozzles during this process.
b) Do not place anything on the drip grid.
c) IN CASE OF SCALDING: Immediately cool the affected area and, depending on the severity of the in-
jury, consult a doctor.

Franke Kaffeemaschinen AG For your safety | 1
User manual A800 9
WARNING
Risk of scalding
Hot beverages can lead to scalding.
a) Always be careful with hot beverages.
b) Use only suitable drinking vessels.
WARNING
Risk of scalding
Hot liquids and steam escape during cleaning and can lead to scalding.
a) Keep hands away from the spouts and nozzles during this process.
WARNING
Risk of injury
If objects find their way into the bean hopper or grinder, splinters may be ejected, leading to injury.
a) Never insert any objects into the bean hopper or grinder.
CAUTION
Cutting injuries/crushing
The powder hoppers worm gear mechanism can cause cuts or crushing injuries.
a) Exercise care when cleaning the powder hopper.
CAUTION
Irritation from cleaners
Cleaning tablets, milk system cleaning agent, and descaler can lead to irritation of the skin or eyes.
a) Observe the hazard warnings on the label of the respective cleaner.
b) Avoid contact with your eyes and skin.
c) Wash your hands after coming into contact with cleaning supplies.
d) Cleaning supplies must be kept away from beverages.
CAUTION
Health hazard due to germ formation
Inadequate cleaning can result in food residues accumulating in the machine and at the spouts, thereby
contaminating products.
a) Do not use the machine unless it has been cleaned according to the instructions.
b) Clean the machine daily in accordance with the instructions.
c) Inform operating personnel of the necessary cleaning measures.

1 | For your safety Franke Kaffeemaschinen AG
10 User manual A800
CAUTION
Health hazard due to germ formation
Residues may build up in the machine if not used for a long time.
a) Clean the machine if it is not used for extended periods (more than 2days).
CAUTION
Formation of mold
Mold can form on the coffee grounds.
a) Empty and clean the grounds container at least once a day.
NOTICE
Risk of damage to the coffee machine
If the spout cleaning device is placed on the drip grid too soon, the dispensing spout will move toward the
spout cleaning device. This may damage the coffee machine and/or the spout cleaning device.
a) Only place the spout cleaning device on the drip grid when prompted to do so, and only once the dis-
pensing spout has been fully lowered.

Franke Kaffeemaschinen AG Explanation of symbols | 2
User manual A800 11
2 EXPLANATION OF SYMBOLS
2.1 Symbols used in the manual
2.1.1 Orientation
Symbol Description
Clean components using the 5-step method.
This symbol indicates tips, tricks and additional information
Prerequisites for additional steps
Result or intermediate result for additional steps
2.2 Symbols used in the software
2.2.1 Symbols used for navigation and operation
Symbol Designation Description
Cancel button Cancel preparation
Select next/previous
page Scroll through menus with multiple pages
Start button Start preparation
2.2.2 Symbols on the dashboard and on the user interface
When a symbol is illuminated on the dashboard, additional information and instructions can be displayed
by tapping the symbol. If an error occurs, refer to the Troubleshooting [ } 78] chapter for help.
Symbol Designation Description
Franke logo Call up the maintenance level
Bean left/right Active grinder

2 | Explanation of symbols Franke Kaffeemaschinen AG
12 User manual A800
Symbol Designation Description
Double product Produce double beverage quantity (double production)
Ground coffee
Energy-saving mode Switch the machine into energy-saving mode
Servicing/cleaning Machine must be cleaned and/or serviced
Rinse Machine must be rinsed or machine is rinsing
Grounds container Grounds container must be emptied
Door The door is open
Payment Payment active
First Shot Preheat system
Service/configuration/
administration
Brightness Set brightness
Individualization Customize beverages and display
Screen saver
Advertising images
Favorites Favorites button, can be assigned to a function that is used fre-
quently
Product
Coffee bean Bean hopper is empty or not installed correctly

Franke Kaffeemaschinen AG Explanation of symbols | 2
User manual A800 13
Symbol Designation Description
Milk Milk container is empty or not installed correctly
Powder resource Powder hopper is empty or not installed correctly
Info
Event log List of event and error messages
Individual products
counter
Inactive
Data transfer Data is being transferred
2.2.3 Depiction of error messages
Espresso Cappuccino Chococcino
Caffè Crema To Go Steam Tea water
Highlighted products cannot be prepared. The illu-
minated symbol on the dashboard takes you to the
error message.
Door open
The door is open. Please close the door.
If the entire system is affected by an error, the error
message will appear automatically.

2 | Explanation of symbols Franke Kaffeemaschinen AG
14 User manual A800
Color code for error messages
Temporary interruption
System still fully functional
System has limited functionality
Some or all resources are locked

Franke Kaffeemaschinen AG Scope of delivery | 3
User manual A800 15
3 SCOPE OF DELIVERY
The scope of delivery may vary, depending on the configuration of the appliance. Additional accessories
may be obtained directly from your retailer or from Franke Kaffeemaschinen AG in Aarburg, Switzerland.
Item description Item number
Coffee machine A800 (FCS4050)
Manual set 560.0001.662 / 560.0001.708
Cleaning tablets (100 pcs.) 567.0000.010
Cleaning tablets (China) 5
Cleaning tablets (USA/Canada) 567.0000.002
Milk system cleaning agent (dosing bottle) 567.0000.005
Milk system cleaning agent (dosing bottle) (USA/
Canada/Mexico) 567.0000.006
Measuring cup 1000ml 560.0002.653
Cleaning brushes 560.0003.728
Twisted-in-wire brush
(Option SU05) 560.0001.019
Hose brush
(option FM/MS) 560.0007.380
Paint brush 560.0003.716
Microfiber cloth 560.0002.315
Grinder adjustment wrench 560.0003.876

3 | Scope of delivery Franke Kaffeemaschinen AG
16 User manual A800
Item description Item number
Aerator/hose wrench 560.0522.696
Drip grid extension 560.0484.609
Drip grid extension
(option single-piece drip grid extension (USA)) 560.0574.078

Franke Kaffeemaschinen AG Identification | 4
User manual A800 17
4 IDENTIFICATION
4.1 Position of type plates
4.1.1 Coffee machine
The type plate for the coffee machine is located on
the right interior wall.
4.1.2 SU05 cooling unit
The type plate for the SU05 cooling unit is located
on the left inner wall.
4.1.3 Cooling unit SU12/UT12
The type plate for the cooling unit is located on the
left-hand side in the cooling chamber.

4 | Identification Franke Kaffeemaschinen AG
18 User manual A800
4.1.4 Flavor Station FS
The type plate for the FS Flavor Station is located in
the interior on the rear panel.
4.1.5 Under-counter Flavor Station FSU
The type plate of the under-counter Flavor Station
(FSU) is located on top of the left-hand side of the
housing.
4.1.6 CW (option)
The type plate for the cup warmer is located in the
interior on the rear panel.
4.1.7 AC200 (Option)
The type plate of the AC200 is located on the left-
hand side of the pullout.

Franke Kaffeemaschinen AG Identification | 4
User manual A800 19
4.2 Type code
4.2.1 Coffee machine
Type code Description
A800 Coffee machine (fully automatic)
Series: A
Overall size: 800
1G 1 grinder
2G 2 grinders
3G 3 Grinders
1P 1 powder dosing unit
2P 2 powder dosing units
EC EasyClean
H1 Left-hand hot water spout
H2 Center hot water spout
FM FoamMaster (cold and warm milk, cold and warm milk foam)
NM NoMilk (coffee machine without milk system)
TS TwoStep (manual milk foam production using steam plant)
S1 Steam wand
S2 Autosteam (steam wand with temperature sensor)
S3 Autosteam Pro (steam wand with temperature sensor and programmable milk foam con-
sistency)
1IC Iced Coffee Module
4.2.2 Add-on units
Type code Description
SU05 Cooling unit (5l) positioned next to the coffee machine
SU12 Cooling unit (12l or 2 x 4.5l) right next to the coffee machine
UT12 Under-counter cooling unit (12l or 2 x 4.5l)
KE200 Cooling unit (4l) positioned next to the coffee machine
MU Milk pump module
UC05 Base cooling unit (5 l), positioned directly below the coffee machine
UC09 Base cooling unit (9 l), positioned directly below the coffee machine
FS30 Flavor Station with 3 flavor pumps
FSU30 Under-counter Flavor Station with 3 flavor pumps
CW Cup warmer
FM FoamMaster (cold and warm milk, cold and warm milk foam)
EC EasyClean
Twin Modified cooling unit for the simultaneous use with two coffee machines
AC Accounting system

4 | Identification Franke Kaffeemaschinen AG
20 User manual A800
Type code Description
CC Coin changer
CL Cashless
CV Coin validator
