Franke Evolution User manual

Evolution
Translation of Original Operating Instructions
Read the operating instructions and the chapter on safety information before operating the machine.
Keep the operating instructions near the machine.

Dear customer,
Page 1
Congratulations on your purchase of an Evolution coee machine.
Thank you for your condence in us.
Evolution is a powerful and space-saving coee machine. It adapts to
your needs perfectly. Your customers will be impressed as you quickly
prepare high-quality, customized coee specialties.
We hope you enjoy your Evolution and that it will bring you consist-
ently satised customers.
Sincerely, FRANKE Kaeemaschinen AG
Dear customer,

Page 2
Explanation of symbols
........................................... 3
for your safEty
................................................... 4
propEr usE
.................................................... 4
GEnEral safEty concErns durinG usE
............................ 5
scopE of dElivEry and idEntification
................................ 7
scopE of dElivEry
.............................................. 7
idEntification
.................................................. 9
dEscription of machinE
...........................................10
Evolution
....................................................10
installation and tEchnical data
..................................12
installation
..................................................12
dimEnsions
...................................................13
installation dimEnsions
.......................................13
commissioninG, fillinG and EmptyinG
...............................15
start-up of thE Evolution
.....................................15
start-up of thE rEfriGEration unit (optional)
....................17
prEparinG drinks
.................................................19
prEparinG astandard drink
....................................19
prEparinG adrink with prEsElEction
.............................20
hot watEr dispEnsEr
...........................................21
stEam wand
..................................................21
clEaninG and rinsinG
.............................................22
ovErviEw of thE sEparatE clEaninG instructions
..................22
clEaninG watEr and stEam nozzlEs
.............................23
rinsinG thE coffEE and milk systEms manually
...................23
confiGurinG your Evolution
......................................24
product dEfinition
............................................25
shut-down and disposal
.........................................28
shut-down for lonGEr pEriods and storaGE
.....................28
disposal
.....................................................28
troublEshootinG and Error codEs
.................................29
cErtifications
...................................................31
dEclaration of conformity
....................................31
indEx
...........................................................32
Table of Contents

!
!
!
explanation of symbols
Page 3
NOTICE
WARNING
CAUTION
DANGER
explanation of symbols
Disinfecting a component.
This symbol indicates tips, shortcuts
and additional information.
NOTICE indicates possibility of dam-
age to the machine.
DANGER indicates potentially life-
threatening danger or grave injury.
CAUTION indicates risk of minor
injury.
WARNING indicates risk of injury.

For Your Safety Page 4
For Your Safety
Both you and the Evolution are important to us. Therefore, we would like to provide you with detailed safety
information. For us, a high level of safety goes without saying. Protect yourself against remaining risks from
use of the machine.
Proper use
If you need more information
or if specic problems occur
that cannot be resolved using
these instructions, contact
your local customer service
representative for the required
information or contact FRANKE
Kaeemaschinen AG in Aar-
burg, Switzerland, directly.
Important
Do not operate the Evolution and its add-on units until you have
read and understood these instructions in full. Keep these instruc-
tions near your Evolution.
The Evolution coee machine is intended for use by trained sta.
Each operator of the Evolution must have read an understood these
instructions. This does not apply to self-service customers. Self-serv-
ice machines must always be monitored to protect the users.
Children or physically or mentally challenged persons must never
approach the machine alone and must always be supervised.
Have the machine serviced at regular intervals. Regular mainte-
nance will ensure the safe operation and high performance of your
Evolution.
If the Evolution is sold or transferred to a third party, please give the
operating instructions to the next user.
Evolution
The Evolution is a coee machine for use in food service, oces and
similar environments. It is designed to process whole coee beans.
The various add-on units allow integrated processing of milk with
the Evolution.
The Evolution is designed exclusively for preparing coee drinks,
milk combination drinks, hot water and steam in accordance with
these instructions and the technical data.
Refrigeration Unit/Milk Systems (optional)
Milk systems are optional add-on units for Evolution coee ma-
chines. They are to be used only to cool milk in conjunction with
preparing coee drinks with an Evolution coee machine.
Only use pre-cooled milk (2-5°C or 36-41°F). Only use FRANKE
cleaning solution. Other detergents may leave a residue in the milk
system.
Cup Warmer (optional)
The cup warmer is an optional add-on unit for Evolution coee ma-
chines. It is intended only for warming coee cups and glasses used
when preparing drinks.
The cup warmer is not designed to dry dish towels or other cloths. It
is not necessary to cover the cups to warm them.

! !
!
For Your Safety
Page 5
Risk of injury!
Reaching into the Evolution may result in abrasions or injuries
caused by crushing from interior components.
• Only open the Evolution when daily work requires it (to empty
the grounds container).
• Exercise care and caution when working on an open Evolu-
tion.
• Only service personnel should open the Evolution for any
other purpose.
WARNING
Risk of injury, eye injury and damage to the machine!
Objects in the coee bean hopper or grinder may splinter and be
ejected, leading to damage to the machine or injury.
• Never put any objects in the coee bean hopper or grinder.
• Never poke around in the coee bean hopper or grinder with
any object.
WARNINGDANGER
Risk of death by electrocution!
• Never operate a machine that has been damaged or has a
damaged power supply cable.
• If you suspect damage to the machine (for instance, a hot or
burning odor), unplug the machine from the outlet and con-
tact your service technician.
If the power supply cable to this machine is damaged, it must be
replaced by a special power cord.
• Only a qualied service technician should replace the power
supply cable.
• Ensure that the machine and power supply cable are not near
any hot surfaces such as gas or electric stoves or ovens.
• Ensure that the power supply cable is not pinched and does
not rub against sharp edges. The machine contains electri-
cally conductive parts. Opening the machines can pose risk of
death.
• Never open or attempt to repair the machine yourself.
• Do not make any modications to the machine that are not
described in the owner's manual.
• Repairs should only be made by a service technician using
original replacement and add-on unit parts.
General safety concerns during use

!
!
!
For Your Safety Page 6
Damage to the machine!
• Install the machine out of the reach of children.
• Do not expose the machine to the elements, such as rain, frost
or direct sunlight.
The power supply cable may pose the risk of tripping or become
damaged.
• Never let the power supply cable hang loose.
NOTICE
Damage from water jets!
The Evolution is not protected against water jets.
• Do not use water jets or high-pressure cleaners to clean the
machine.
• Read the chapter "Cleaning and Rinsing."
NOTICE
Damage from foreign objects!
Putting foreign objects through the powder lid can lead to damage
to the machine.
• Never insert any foreign objects.
• Never poke around in the powder lid with any object and
never insert anything except cleaning tablets or ground cof-
fee.
NOTICE
Risk of scalding!
During automatic and manual cleaning, hot water and steam are
released repeatedly.
• Keep hands away from the outlets and nozzles during clean-
ing!
When drinks are dispensed, the products themselves pose a risk of
scalding.
• Always be careful with hot drinks!
WARNING
Risk of burns!
The coee and milk dispensers, hot water nozzle and steam dis-
penser are hot.
• Do not touch the outlets or nozzles.
The surfaces of the cup warmer are hot.
• Do not touch these surfaces.
WARNING
Risk of spoiled food residue!
If the machine is not cleaned regularly, milk, powder, syrup and cof-
fee residue may accumulate in the machine, clog the outlets or nd
its way into drinks.
• Clean the Evolution and its add-on units at least once a day.
• Read the chapter "Cleaning and Rinsing."
CAUTION

Scope of Delivery and Identication
Page 7
Cleaning brushes (optional)
To clean the dispenser system.
Item no: L  
Cleaning brush
To clean the brewing unit.
Item no: L  
Cleaning solution (optional)
To keep your milk system clean
and hygienic.
Item no: BK  
Cleaning tablets
To clean and protect your cof-
fee system.
Item no: BK  
Evolution
Basic model. Optional add-on
units can be ordered from your
FRANKE retailer.
Scope of delivery
Scope of Delivery and Identication
The Evolution is a powerful coee machine.
Listed below are ways to identify your machines and what is included in the standard delivery.

Scope of Delivery and Identication Page 8
The conguration of your
Evolution may dier from that
shown in the instructions.
Please refer to your purchase
agreement.
Additional accessories may be
obtained directly from your
retailer or from FRANKE Kaf-
feemaschinen AG in Aarburg,
Switzerland.
Owner's manual
Operating instructions
Item no.: T  
Also refer to the chapter
"Cleaning and Rinsing."
Other manuals can be down-
loaded via the Internet.
www.franke.com
Adjust card
To program the machine and
back up data.
Item no:   

Inst. Nr:
Typ:
App. Nr:
Kältemittel:
Kältemittelmenge:
Stromaufnahme:
Spannung (Klimazone N):
Spannung (Klimazone T):
Frequenz:
Absicherung:
AK4-xxx xxx
KE 320
39.0000.00001
R134a
40 g
0.72 A
200 - 240 V~
220 - 240 V~
50 Hz
10 A
Kaffeemaschinen AG
CH-4663 Aarburg
Franke Kaff eemaschinen AG
Franke-Strasse 9
CH – 4663 Aarburg
Schweiz
Boiler: Kaff ee Tee/Dampf
Wasserinhalt: 1.2l 1.6l
Betriebsdruck: 1000kPa 200kPa
Name: Evolution
Seriennr: 12345678
Inst. Nr: 466xxx
App. Nr. 3x.9.0.xxxx
Typ: E xM H D xx xx
Spannung: 400 V 2L N PE
Frequenz: 50 / 60 Hz
Leistung: 5200 W
Absicherung: 16 A
Wasserdruck: 0.8MPa
Scope of Delivery and Identication
Page 9
Refrigerant
Apparatus number
Electrical data
Boiler performance data
Identication code
Manufacturer
Model (for model codes, see below)
Model code Component
E Evolution
E II Evolution Top
2M Number of grinders (max. 2)
H Hot water dispenser
D Steam dispenser
CF Milk foam, warm and cold milk
KE Refrigeration unit (optional)
TW Cup Warmer (optional)
Model codePosition of the type plates
Refrigeration unit type plate (as an example for add-on units)Evolution type plate
Identication

Description of machine Page 10
Specialty Hourly capacity of Evolution*
Espresso 180 cups
Café crème 120 cups
Cappuccino 120 cups
Latte macchiato 120 cups
Warm milk 120 cups
Cold milk 150 cups
Hot water 20 liters (5.28 gallons)
* The hourly capacity is a theoretical value and depends on the conguration of the
machine(s) and the size of the drinks. Because of its innovative milk system, the
Evolution with Foam Master has a much higher hourly capacity for milk than the
Evolution. Your sales representative will be glad to help you.
Drip tray with drip grid
Steam dispenser
Outlet
(coee, milk and milk foam)
Hot water dispenser
Grounds door
Control panel
(with display and product buttons)
Chip card reader
Powder lid
Coee bean hopper
Evolution capacity
The Evolution has numerous options. To give you an overview of
your machine, we will illustrate various options with a sample con-
guration.
You will become familiar with the Evolution and its controls as well
as the refrigeration unit and cup warmer.
Please note that your Evolution may look dierent from the congu-
ration shown here.
Evolution
You have chosen enjoyment of every single coee with the Evolution. In this section you will learn more about the
functions and options of your Evolution and where the controls are located.
Description of machine

Description of machine
Page 11
On/O switch (behind door)
On/O switch
Cup Warmer (optional)
To enjoy coee at its best, you
need pre-heated cups.
The cup warmer ts perfectly
on your Evolution.
Refrigeration unit
(optional)
In many regions, milk is part of
a good cup of coee.
You can connect the milk
cooler directly to the Evolution
to make sure the milk does not
spoil.
Switch to other menu levels
Product names
Prompt
Add-on unitsEvolution control panel

Installation and technical data Page 12
Technical data of Evolution
Coee bean hopper 1.3 kg (2.9 lb) per grinder (optional: lockable)
Grounds container 50 cakes (optional: grounds ejection)
Boiler volume small boiler: coee 1.2 l 1.0 MPa (145 psi)
large boiler: hot water/steam 1.6 l 0.2 MPa (29 psi)
Electrical connection 230 - 240 V 1 L N PE 2.2 kW 50/60 Hz Fuse: 10 A
400 V 2 L N PE 5.2 kW 50/60 Hz Fuse: 16 A
Electric cable l = 1800 mm (70 ¾")
Supply line Metal hose with union nut G3/8", l = 1500 mm (59")
Waste-water hose d = 16 mm (¾"), l = 2000mm (78 ¾")
not permanently attached to the drain (vented)
noise emission < 70 dB (A)
Weight 1M 46kg (101.4 lb) 2M 50kg (110.2 lb)
Cold water connection G3/8” outside thread
Water pressure 80 - 800kPa (0.8 - 8.0 bar or 11.6 - 116psi)
water shut-o with check valve and lter
water hardness max. 70 mg CaO/1l water (7dH, 13 °fH)
Chlorine content max. 0.1 mg/l (0.1 ppm)
Ideal pH value 7
Funnel d = 50 mm (2") with siphon
Drain pipe dmin = 1"
Ambient conditions Humidity: max. 80%
Ambient temperature: 10 - 35°C (50 - 95°F)
Preparations
• The power connection for the coee machine must be protect-
ed by a ground fault circuit interrupter (GFCI).
• Each terminal of the power supply must be able to be inter-
rupted by a switch.
• The water connection must have a shut-o with a check valve
and lter and must meet the requirements of the technical data.
• The water for the preparation of coee should always be fresh,
oxygenated and rich in minerals.
• If your Evolution has an electrical connection other than the
one described in the table opposite, you will have received ad-
ditional information regarding the installation with your order
conrmation.
Installation
You must have completed these preparations before one of our
service technicians can install the Evolution for you.
One of our service technicians will install your Evolution and put
them into operation for the rst time. The technician will walk you
through the basic functions.
Your Evolution must be properly installed so that you can operate it correctly – one of our service techni-
cians will do that for you. You'll have to take care of a few things rst. You'll nd the preparations for problem-
free enjoyment of your coee machine here.
Installation and technical data
Installation

min 50
min 200
300
315
210
96
Ø80
Ø120
320
500
25
160
600
675
80
150
160 440
300
315
210
96
Ø80
Ø120
320
500
25
160
600
675
80
150
160 440
300
315
210
96
Ø80
Ø120
320
500
25
160
600
675
80
150
160 440
300
315
210
96
Ø80
Ø120
320
500
25
160
600
675
80
150
160 440
Installation and technical data
Page 13
Cross-section from above (grommet hole)Top view
Side viewFront view
30 mm (1 ¼") foot 675 mm (26 ½") + 32 mm (1 ¼") = 707mm (27 ¾")
40 mm (1 ½") foot 675 mm (26 ½") + 45 mm (1 ¾") = 720mm (28 ¼")
70 mm (2 ¾") foot 675mm (26 ½") + 70...80mm (2 ¾"...3 ¼") =745...755mm (29 ¼"...29 ¾")
100 mm (4") foot 675 mm (26 ½") + 100...115 mm (4"...4 ½") = 775...785mm (30 ½"...31")
Prepare a stable, ergonomic surface (min. load capacity: 150 kg or 330.7 lb). The
control panel should be at eye level.
Distance to the wall must be at least 50 mm (2"). Clearance above
the machine must be at least 200 mm (7 ¾").
Adjustable feet can be used to compensate for unevenness or
height dierences.
If optional add-on units are installed, up to an additional 320 mm
(12 ½") may be required per add-on unit.
Observe the connection requirements of the add-on units.
Adjustable feet (optional)
Installation DimensionsDimensions

min 50
min 200
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
463
320
480
14
2650060
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
463
320
480
14
2650060
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
463
320
480
14
2650060
Installation and technical data Page 14
Top viewSide viewFront view
Adjustable feet (optional)
30 mm (1 ¼") foot 560 mm (22") + 32 mm (1 ¼") = 592mm (23 ¼")
40 mm (1 ½") foot 560 mm (22") + 45 mm (1 ¾") = 605mm (23 ¾")
70 mm (2 ¾") foot 560 mm (22") + 70...80 mm (2 ¾"...3 ¼") = 630...640 mm (24 ¾"...25 ¼")
100 mm (4") foot 560 mm (22") + 100...115 mm (4"...4 ½") = 660...675 mm (26"...26 ½")
Technical data for the cup warmer
Capacity up to 80 cups (depending on cup size)
electrical connection 200 - 240V 1L N PE 140W 50/60 Hz Fuse: 10 A
Electric cable 2000 mm (78 ¾")
Weight approx. 15 kg (33 lb)
Width 225mm (8 ¾")
Depth 440 mm (17 ¼")
Height 540 mm (21 ¼")
Technical data for the refrigeration unit
Milk container 10 liters (2.64 gallons)
electrical connection 200 - 240V 1L N PE 100W 50/60 Hz Fuse: 10 A
115 V 1L N PE 100 W 50/60 Hz Fuse: 10 A
Electric cable 2000 mm (78 ¾")
Ambient conditions Humidity: max. 80%
Ambient temperature: 5 - 32°C (41 - 89.6°F)
Weight approx. 26 kg (57 lb)
Width 320mm (12 ½")
Depth 460 mm (18")
Height 500 mm (19 ¾")
Place the optional add-on units in line with the Evolution and at eye
level.
Distance to the wall must be at least 50 mm (2"). Clearance above
the machine must be at least 200 mm (7 ¾").
Adjustable feet can be used to compensate for unevenness or
height dierences.
If optional add-on units are installed, up to an additional 320 mm
(12 ½") may be required per add-on unit.
Installation Dimensions for Add-on units

01 02 03 04
!
01 02 03
!
4444
444
Start-up, Filling and Emptying
Page 15
Daily start-up of the coee machine
WARNING
WARNING
Filling the coee bean hopper
Risk of injury, eye injury and damage to the machine!
Objects in the coee bean hopper or grinder may splinter and be
ejected, leading to damage to the machine or injury.
Never put any objects in the coee bean hopper or grinder.
Never poke around in the coee bean hopper or grinder with any
object. Close the coee bean hopper.
Pour in coee beans.
Open the coee bean hopper.
Risk of scalding
from hot water, splatters and
hot steam.
Do not touch the outlets or
the area under the outlets.
Point the steam wand down-
wards.
The Evolution is ready for
operation.
Add coee beans and milk, if
necessary.
The Evolution automatically
vents the boiler system while
heating.
Switch on the Evolution using
the On/O button.
In this chapter you will learn how to start up your Evolution. In addition to the start-up procedure, you will
learn about processes that take place automatically during start-up and about additional preparations. Get
primed for a busy day!
Start-up, Filling and Emptying
Start-up of the Evolution

01 02 03
444
01 02
4 4
03
04 05
4 4
4
4
4
Start-up, Filling and Emptying Page 16
NOTICE
The quality of the coee
may be impaired!
Dry the coee bean hopper
well after cleaning it. There
must not be any residue from
cleaning agents.
Pull the bean pusher out.Place the coee bean hopper
on the Evolution and tighten
fastening screw.
Empty, clean and dry the cof-
fee bean hopper.
Loosen fastening screw in the
coee bean hopper and lift the
coee bean hopper straight
up.
Slide the bean pusher inward
to close o the coee bean
hopper.
NOTICE
Formation of mildew due
to coee residue!
Empty and clean the grounds
container at least once daily.
Replace the grounds container
and close the grounds con-
tainer door.
Empty, clean and dry the
grounds container.
Open the grounds container
door and remove the grounds
container.
Emptying the coee bean hopper
Emptying the grounds container

01
4
03
44
04
4
05
01 02
44 4
Start-up, Filling and Emptying
Page 17
Temperature display
Thermostat
left button
Set button
right button
Press Set.
The temperature is set.
Set the desired temperature
using the left or right button.
Press Set until the temperature
is displayed.
The thermostat is located in
the refrigeration unit and can
be set manually.
Open refrigeration unit.
Milk quantity and temperature
are monitored constantly.
Setting the temperature of the refrigeration unit (KE 320) (optional)
Open the refrigeration unit
and switch it on with the On/
O switch.
Start-up of the Refrigeration Unit (optional)

01 02 03
444
01 02 03
4444
04 05
4 4
!
Start-up, Filling and Emptying Page 18
CAUTION
Beware of spoiled milk!
If the machine is not cleaned regularly, milk residue may accumulate
in the machine, clog the dispensers or nd its way into drinks.
Clean the Evolution and its add-on units daily.
Close the refrigeration unit.Clean the milk container and
refrigeration unit.
Emptying the refrigeration unit (optional)
NOTICE
The refrigeration unit may not
be used to store milk!
Clean the milk system
of the Evolution.
Store the remaining milk in a
refrigerator or dispose of it.
Open the refrigeration unit and
remove the milk container.
Instead of the milk container,
you can also use bag-in-a-box
containers or gallon containers.
Milk quantity and temperature
are monitored constantly.
Slide in the milk container and
close the door.
Add milk to the container and
insert the suction tube.
Open the refrigeration unit and
remove the milk container.
Filling milk (optional)
