FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC EN
ABOUT THIS MANUAL
This user manual applies to several models of
the device. Thus it may be possible that some
of the described features and functions are not
available on your specific model.
The explanatory images and figures, described
in the various sections, are available at the end
of the manual.
Symbol Meaning
Warning symbol. Warning against risks of injury.
Actions in safety and warning notes to avoid injury or damage.
Action step. Specifies an action to be done.
X Carefully read the user manual before using
the device.
X Keep the user manual.
X Use the device described in this user
manual only according to the intended use.
Franke reserves the right to make modifications
to the product without prior notice.
All information correct at time of issuance.
TABLE OF CONTENTS
About this manual 3
Safety Information 4
Technical data 7
Installation 8
Installation procedure 9
Intended use 11
Cleaning and care 13
Cleaning the appliance 13
Maintenance and repair 14
Disposal 15
Packaging 15
Disconnection 15
Customer service 15

– 4 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC
EN
SAFETY INFORMATION
In this manual and on your
applicance we have provided
many important safety
messages. Always read and
obey all safety messages.
Franke reserves the right to
make modifications to the
product without prior notice.
All information correct at time
of issuance.
This appliance can
be used by children aged
from 8 years and above and
persons with reduced physical,
sensory or mental capabilities
or lack of experience and
knowledge if they have
been given supervision
orinstruction concerning use
ofthe appliance in a safe way
and understand the hazards
involved. Children shall not play
with the appliance. Cleaning
and user maintenance shall not
be made by children without
supervision.
Risk of injury!
Z This device is not a toy.
Z Keep children and pets
away from the device and
the packaging material e.g.
plastic film and polystyrene;
it can be dangerous, dispose
of it in a proper way.
Z Do not leave children near
the device unattended.
Z Do not let children play with
the device.
Risk of burns!
During use the appliance
becomes hot. Care should be
taken to avoid touching the hob.
WARNING: Accessible parts
may become hot during use.
Young children should be
kept away. Children less than
8years of age shall be kept
away unless continuously
supervised.
Z Ensure the gas type and
supply is compatible with
appliance specifications.
The hob was developed
exclusively for non-
professional, domestic use
inthe household only.
Z The type of gas for which
the appliance is arranged is
specified on the dataplate
on the bottom of the tray.
Z Prior to installation, ensure
that the local distribution
conditions (nature of the gas
and gas pressure) and the
adjustment of the appliance
are compatible.
Z This appliance is not
connected to a combustion
products evacuation device.

– 5 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC EN
It shall be installed and
connected in accordance
with current installation
regulations. Particular
attention shall be given to
the relevant requirements
regarding ventilation.
Z The adjustment conditions
for this appliance are stated
on the label (or data plate).
Z Pay particular attention to
the applicable regulations on
ventilation.
Z After use, switch off the hob
by its controls.
Z Make sure the burners are
cold before closing the lid, if
the appliance has one.
Risk of electric shock
due to entering liquid!
The device contains electrical
components.
Z Make sure that no liquid
enters the interior of
the device.
Z Do not use pressurised
steam to clean the device.
Z In the event of the burner
flames accidentally
extinguished, turn off the
burner control and do not
attempt to reignite the burner
for at least 1 min.
Z The device shall not be
operated for more than
15 seconds if after 15 seconds
the burner has not lit, stop
operating the device and
open the compartment door
and/or wait at least 1 minute
before attempting a further
ignition of the burner.
Z Ensure that the device
is installed in a way that
allows to disconnect it from
the power supply, with a
contact opening distance
(3 mm) that ensures
complete disconnection
in category III overvoltage
conditions.
Z Ensure that the appliance
is connected to an earthing
system in compliance with
the current regulations.
CAUTION: The use
of a gas cooking appliance
results in the production of
heat, moisture and products
of combustion in the room in
which it is installed.
Z Ensure that the kitchen is
well ventilated especially
when the appliance is in
use: keep natural ventilation
holes open or install a
mechanical ventilation
device (mechanical
extractor hood).
Z Do not operate the appliance
with an external time switch
or a separate remote control
system.

– 6 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC
EN
CAUTION: The cooking
process has to be supervised.
A short term cooking
process has to be supervised
continuously.
Z Do not use steam cleaners
or direct jets of water.
Z Never use scouring pads,
steel wool, muriatic acid or
other products which could
scratch or mark the surface.
Z Never use sharp objects,
as they could damage the
seals between the trim and
worktop.
Z Ensure the gas outlet zones
are perfectly clean.
Z These instructions are only
valid if the country symbol
appears on the appliance.
Z If the symbol does not
appear on the appliance,
itis necessary to refer to the
technical instructions which
will provide the necessary
instructions concerning
modification of the appliance
to the conditions of use of
the country.
Risk of fire!
Z Do not store items on the
cooking surfaces.
WARNING: Unattended
or automatic cooking on a hob
with fat or oil can be dangerous
and may result in fire. Hot oil
ignites readily.

– 7 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC EN
TECHNICAL DATA
FHTL/FCH 604 3G TC
2
41
2
FHTL/FCH 604 4G
2
31
2
FHTL/FCH 755 4G TC
3
2
1
2
4
Position Burner Rated Capacity
- G20 Injectors G20 20
mbar
Rated Capacity
- G30 Rated Capacity -
G31
Injectors
G30/G31
28-30/37
mbar
Rated
Power
(kW)
Reduced
Power
(kW)
4TC 0.362 141 277 277 98 3.8 2.10
3 R 0.286 125 218 218 85 3 1.10
2 SR 0.167 97 127 127 66 1.75 0.70
1AUX 0.095 78 73 73 50 1 0.55
Pressure
(mbar)
min 17 20 25
nom 20 28-30 37
max 25 35 45
Type of Gas G20 natural gas
LPG
G30 Butane
G31 Propane
Cat. II 2H3+
MOD. nr
AUX nr SR nr R nr TC N bur- ners Heat source Total Rated
Capacity
G20
(m³/h)
Total
Rated
Capacity
G30 (g/h)
Air
Necessary
for
combustion
(m³/h)
Total
installed
Gas Rated
Power
(kW)
Weight
(net-gross)
(kg)
Power supply
voltage/
frequency
Power/
current
FCH 604
3G TC 1 2 1 4 GAS 0.791 604 16.6 8.3 6.1-11.5 220-240 V~
50-60 Hz 0.6 W
FCH 755
4G TC 1 2 1 1 5 GAS 1.077 822 22.6 11.3 7.8-14.7 220-240 V~
50-60 Hz 0.6 W
FHTL 604
3G TC 1 2 1 4 GAS 0.791 604 16.6 8.3 6.1-11.5 220-240 V~
50-60 Hz 0.6 W
FHTL/FCH
604 4G 1 2 1 4 GAS 0.715 545 15 7.5 6.1-11.5 220-240 V~
50-60 Hz 0.6 W
FHTL 755
4G TC 1 2 1 1 5 GAS 1.077 822 22.6 11.3 7.8-14.7 220-240 V~
50-60 Hz 0.6 W
TC=Triple Crown SR=Semi-Rapid R=Rapid AUX=Auxiliary

– 8 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC
EN
INSTALLATION
Installation and electrical/gas
connection must only be carried out by
specialized and licensed personnel.
The manufacturer declines any liability for
injury to persons or damage to things due to
failure noncompliance with these provisions.
The gas connection must comply with the
regulations in force in the country at the time
of installation.
Z Ensure that the device is connected
directly to the mains socket. Ensure that
no adapters, no multi-sockets and no
extension cables are used to connect the
device.
Cabinet requirements
This handbook refers to a class 3 built-in gas
hob and type Y for electric part.
The gas pipe must not come into contact with
the sides of any oven under the hob.
For fitted units, the components (plastic
materials and veneered wood) must be
assembled with heat-resistant adhesives (min.
100°C): Unsuitable materials and adhesives
can result in warping and detachment.
The Ventilation of rooms must be in compliance
with local regulation.
The kitchen element must allow sufficient room
for the electrical connections of the appliance.
IMPORTANT:These devices are „Y“ type with
respect to the degree of protection against
the dangers of fire. The minimum distance
from the edge appliance is 150 mm for the
side wall, 50 mm for the rear and 700 mm
for any cabinets above it. The appliance is
recommended to be built into 40 mm thick
worktops. In case the dimensions are different,
eventual modifications have to be managed by
the technician.
Note: if a hood is installed above the hob,
for the distance to be respected refer to the
assembly instructions of the hood.
BB
D
C
A
C
MINIMUM DIMENSIONS (MM)
A = 590/750 B = 50
C = 400 D = 700
Z If the appliance is not installed above an
oven: arrange a separator baffle.
* 120x120 mm
120
120
Max 150 mm
20 mm
Max 50 mm

– 9 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC EN
Max 150 mm
50 mm
20 mm
Installation procedure
The appliance is fixed to the unit by means of
the brackets and accessories provided.
Z Make sure that there is free access to the
fixing elements in front and in the rear
after the installation of the appliance.
Z Prepare the hole in the worktop according
to the dimensions indicated. Be sure to
comply with the dimensions indicated.
Yp Xp
Ytop
Htop
Xtop
Model xp
mm yp mm xtop mm ytop mm htop mm
FCH 604 3G TC 590 510 550 480 40
FCH 755 4G TC 750 510 550 480 40
FHTL 604 3G TC 590 510 550 480 40
FHTL/FCH 604 4G 590 510 550 480 40
FHTL 755 4G TC 750 510 550 480 40
X Apply the sealing strip around he hole and
position the hob.
X Fix the appliance with the screws and
brackets.
X Remove any excess sealing strip.
Connection to gas supply
X Connect the appliance to the gas supply in
compliance with the current regulations,
only after making sure it is arranged for the
type of gas to be used. Otherwise, carry out
the operations described in the paragraph
„Replacing injectors“.
Z For liquid gas use pressure regulators
complying with the current regulations.
Connection to the gas supply can be made
in two ways:
X A. Connect the gas hob using a 12 mm
diameter rigid copper pipe (3). To ensure
a good seal, use the elastomer gasket
supplied as an accessory (1).
X B. Connect the hob using a continuous-
surface flexible steel tube (2). Also in this
case, to ensure a good seal use the gasket
supplied as an accessory (1). The maximum
length of the hose is 2 linear metres.
IMPORTANT: if a stainless steel hose is used, it
must be installed so as not to touch any mobile
part of the furniture. It must pass through an
area where there are no obstructions and where
it is possible to inspect it on all its length.
X After connection to the gas supply light up
the burners and turn the knobs from max
position to minimum position to check
flame stability.
X After carrying out the connection use soapy
water to check for any leaks.

– 10 –
FCH 604 4G / FCH 604 3G TC / FCH 755 4G TC / FHTL 604 3G TC / FHTL 604 4G / FHTL 755 4G TC
EN
11
2
3
For United Kingdom, Northern Ireland and
Republic of Ireland.
1
2
3
Electrical connection
The FRANKE cooking hob comes with a 3-core
power cable with free terminals.
X Ensure the following:
– The characteristics of your household
electrical power supply (voltage, maximum
output and current) are compatible with
those of your FRANKE hob.
– The plug and the socket can be easily
reached and are positioned so that no
live part is accessible when inserting or
removing the plug.
– A 3 x 0.75 mm H05RR-F type cable
for completely gas hobs is used when
replacing the power cable.
– The terminals of two appliances are not
connected to the same plug.
– The polarities of the free terminals
(Blue = Neutral = (1) /Yellow and Green =
Earth =(2) / Brown = Live = (3)) are respected.
1
2
3
LN
Adjustment to different types of gas
WARNING: This operation must be performed
by a qualified technician.
Minimum flame adjustment
X Remove the knob.
X Adjust the minimum flame by turning the
adjustment screw clockwise to decrease
the flame and anticlockwise to increase it.
The screwdriver for adjustment is supplied
with the accessories.
+-
Replacing injectors
Not supplied injectors must be requested to
the customer service.
IMPORTANT:All the appliances are factory-set
for natural gas (G20). If a different type of gas
is to be used, change the injectors as follows:
– Remove the grids, burner caps and flame-
spreaders;
– Unscrew the injectors and replace them
with those provided and suitable for the
gas supply, making sure the marking
matches that given in the table;
– Refit the flame-spreaders, burner caps
and grids.
These burners do not require air adjustment.
7
ø
