FREE MOTION EPIC F801.0 User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
QUESTIONS?
If you have questions, or if parts
are damaged or missing, please
see HOW TO CONTACT
CUSTOMER CARE on the back
cover of this manual.
www.freemotionfitness.com
Model No. F801.0
Serial No.
Write the serial number in the
space above for reference.
OWNER’S MANUAL
Serial Number
Decal

2
FREEMOTION is a registered trademark of ICON IP, Inc.
IMPORTANT PRECAUTIONS..................................................................3
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ADJUSTMENT ............................................................................19
MAINTENANCE AND TROUBLESHOOTING.....................................................21
CABLE DIAGRAM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
PART LIST ...............................................................................24
EXPLODED DRAWING A ....................................................................26
HOW TO CONTACT CUSTOMER CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
TABLE OF CONTENTS

3
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the strength equipment only as
described in this manual.
3. It is the responsibility of the owner to
ensure that there is enough space around
the strength equipment for the intended
exercise.
4. Use the strength equipment only on a level
surface. Cover the floor beneath the strength
equipment to protect the floor.
5. Anchor the strength equipment to the floor
with the anchor strap where required or
where possible to provide maximum stability.
6. It is the responsibility of the owner to ensure
that all users of the strength equipment are
adequately informed of all precautions, have
read and understood all warning and caution
labels, and are informed of how to use the
strength equipment properly.
7. All users of the strength equipment should
be instructed to report any injury or strength
equipment irregularity to facility staff
immediately.
8. Keep children under age 12 and pets away
from the strength equipment at all times.
9. The strength equipment is designed to sup-
port a maximum user weight of 350 lbs.
(159 kg).
10. Always wear athletic shoes for foot protec-
tion while exercising.
11. Keep hands and feet away from moving
parts. Do not lean on or rest your hands on
the strength equipment while it is in use.
12. Make sure that the weight pin is completely
inserted into one of the weight plates.
13. Make sure that the handles are attached
securely before each use of the strength
equipment.
14. Check each cable, cable connection, and
pulley before each use of the strength
equipment. Make sure that all parts are
properly tightened. Replace any worn parts
immediately.
15. Make sure that each cable remains on the
pulleys at all times. If a cable binds while
you are exercising, stop immediately and
make sure that the cable is on the pulleys
and that nothing is interfering with the cable
or the pulleys.
16. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your strength equipment before using your strength
equipment. FreeMotion Fitness assumes no responsibility for personal injury or property damage
sustained by or through the use of this product.
IMPORTANT PRECAUTIONS

4
This drawing shows the location(s) of the warning decal(s). If a decal is missing or illegible, see the
back cover of this manual and request a free replacement decal. Apply the decal in the location
shown. Note: The decal(s) may not be shown at actual size.
WARNING DECAL PLACEMENT
Spanish
French
German
Italian

5
Length: 4 ft. 2 in. (127 cm)
Width: 4 ft. 9 in. (145 cm)
Weight: 645 lbs. (293 kg)
Thank you for selecting the FREEMOTION®LEG
EXTENSION strength equipment. With unrestricted
motion, you can work your body’s muscle groups the
way you do naturally, to train more effectively and
efficiently.
For your benefit, read this manual carefully before
using the strength equipment. If you have questions
after reading this manual, please see the back cover
of this manual. To help us assist you, note the product
model number and serial number before contacting us.
The model number and the location of the serial num-
ber decal are shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
BEFORE YOU BEGIN
Counterweight Adjustment
Lever
Drop-down Weight/Knob
Seat
Handle
Backrest
Weight Pin
Adjustment Knob
Adjustment Knob
Cam
Tower
Leg Pad
Anchor Strap
